S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
1
VISIX S-Series Indoor IP Dome Camera
VX-4V-ID-RIAWD Quick Start Guide
v01-2019

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
2
Table of Contents
VISIX S-SERIES INDOOR IP DOME CAMERA....................................................................................................... 1
1 CAMERA OVERVIEW...................................................................................................................................... 3
PACKAGE CONTENTS ...................................................................................................................................... 3
Available Mounts........................................................................................................................................... 3
INSTALLATION ............................................................................................................................................... 4
Removing Dome ............................................................................................................................................ 4
Installing the MicroSD Card ........................................................................................................................... 4
Installing The Camera - Cabling Routed Through Base ................................................................................. 5
Installing The Camera — Cabling Routed Through Side ............................................................................... 6
Installation – Cabling and Safety Wire .......................................................................................................... 7
Installation – Finalizing Installation............................................................................................................. 10
2 CAMERA SETUP ........................................................................................................................................... 11
DETECTING,ACTIVATING CHANGING THE CAMERA IP ADDRESS ............................................................................ 11
1.1 ADDING A VISIX S-SERIES CAMERA TO VIGIL SERVER............................................................................................ 12
1.2 ACCESS UI VIA WEB BROWSER .......................................................................................................................... 14

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
3
1Camera Overview
Package Contents
Please see the descriptions of the camera’s box contents.
Number Description
1Camera
2Mounting Base
32x Installation Hardware (screws and anchors)
4T20 Torx Key
NOTE: Press and hold RESET for 10s when the camera is powering on or rebooting to restore the default
settings, including the user name, password, IP address, port No., etc.
AVAILABLE MOUNTS
VX-WM-D2: Wall Mount Adaptor
VX-PM-D2: Pendant Mount Adaptor
VX-FM-D2: Indoor Ceiling Flush-Mount Adaptor
VX-POLE: Pole Mount Adaptor
VX-CM: Corner Mount Adaptor
VX-WMJ-D2: Wall Mount Adaptor with Junction Box
T20
1
2
3
4

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
4
Installation
REMOVING DOME
1. Use the supplied torx key to unscrew the three fastening points for the dome.
2. Lift the dome to remove it from the camera chassis.
INSTALLING THE MICROSD CARD
Steps:
1. Use the supplied hardware to unfasten the dome screws and remove the from the chassis.
2. Insert the microSD card into the available reader slot.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
5
INSTALLING THE CAMERA - CABLING ROUTED THROUGH BASE
Steps:
1. Use a pencil and the mounting base to mark the drilling points and the cable hole on the installation
surface.
2. Drill the cable hole and anchoring points into the installation surface.
3. Insert the anchors.
4. Route the cablings harness through the center cable hole.
5. Use a Philipps-head screwdriver to fasten the mounting base to the installation surface.
6. Proceed to Installation – Cabling and Safety Wire for next steps.
5.0

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
6
INSTALLING THE CAMERA — CABLING ROUTED THROUGH SIDE
Steps:
1. Use a pencil and the mounting base to mark the drilling points on the installation surface.
2. Drill the anchoring points into the installation surface.
3. Insert the anchors.
4. Use a screwdriver to fasten the mounting base to the installation surface.
5. Proceed to Installation – Cabling and Safety Wire for next steps.
5.0

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
7
INSTALLATION – CABLING AND SAFETY WIRE
1. If routing the cable through the base of the camera, route the cabling through the hole you drilled in
the installation surface (A). If you are routing the cable through the side of the camera, no action is
required (B).
2. Attach the safety cable to the clip located on the camera mounting base.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
8
3. Attach the GND wire to the grounding point using a Philipps screwdriver.
4. Remove the alarm and power blocks from the camera.
5. Wire the alarm and power blocks as necessary. Available wiring and inputs / outputs may vary
depending on your camera model.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
9
6. Connect all cabling (Audio In / Out, RJ-45, etc…) and reattach the wired alarm and power blocks to the
camera.
7. If you are routing cabling through the base of the camera, proceed to Installation – Finalizing
Installation. If routing through the side of the camera chassis, remove the cabling plug and route the
cabling harness through the side.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
10
INSTALLATION – FINALIZING INSTALLATION
1. Secure the camera body to the mounting base aligning the camera and base using the indicators then
pushing and turning the camera body counter-clockwise into the base until snug.
2. Use the provided torx key to secure the camera body to the base.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
11
2Camera Setup
Detecting, Activating Changing the Camera IP Address
After networking the camera with the LAN, the user must obtain the camera’s IP address to connect to the
device. To obtain the IP address, the 3xLOGIC Camera (VISIC IP) Setup Utility, a software tool which can
automatically detect online network cameras on the LAN, add these devices to VIGIL Server and list the device
information including IP address, subnet mask, port number, device serial number, device version, etc… is
recommended. An example is shown in Figure 2-3.
This utility is installed alongside VIGIL Server or can be downloaded separately. If on a VIGIL Server system,
launch utility from Start>Programs>VIGIL>Utility or download the utility from the 3xLOGIC website’s Software
Support Center > VIGIL Utilities (http://www.3xlogic.com/software-center) to a Windows PC.
Steps:
1. Launch the utility.
2. Click Detect Online Devices / Change IP Address.
Figure 2-1 3xLOGIC Camera (VISIX IP) Setup Utility
3. Select the camera from the list of online devices.
4. If you are configuring the camera for initial setup, click Activate to assign a new password. This step is
required for security purposes and must be completed before continuing. If the camera has previously
been configured, skip to Step 5.
5. Once you have assigned a new password to the camera, click Change IP Address and change the IP address
and subnet mask to the same subnet as that of your computer. Save the settings.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
12
Figure 2-2 3xLOGIC Camera (VISIX IP) Setup Utility – Changing Device IP Address
6. Enter the IP address of network camera in the address field of the web browser to access the camera’s
web UI.
NOTE:
The default IP address is 192.0.0.64 and the port number is 8000.
For accessing the network camera from different subnets, please set the gateway for
the network camera after you logged in.
1.1 Adding a VISIX S-Series Camera to VIGIL Server
Purpose:
By following the steps outlined in this section, a user can add a camera to VIGIL Server using the 3xLOGIC
Camera (VISIX IP) Setup Utility. The utility was previously utilized in Section 2.1.2 to detect and change the
camera’s IP address. This utility is installed alongside VIGIL Server and will launch automatically when following
the below steps.
Steps:
1. Login to VIGIL Server.
2. Open the Settings > Camera Setup Tab.
3. Select an unused camera channel to associate with the camera.
4. Toggle the Network Camera checkbox. The Network Camera Settings form will deploy. If the form does not
deploy automatically, click the Network Camera - Settings button.
5. Click the Detect Cameras button located next to the Type field. The 3xLOGIC Camera Setup Utility will
deploy and will automatically begin detecting devices on the network.
Figure 1-1 Launching the 3xLOGIC Camera Setup Utility
6. Select the desired camera from the list of online devices and click Next.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
13
Figure 1-2 3xLOGIC Camera (VISIX IP) Setup Utility – Selecting Camera from Online Devices List
7. After the utility successfully accesses the camera, click Save to VIGIL. A window will deploy where the user
can assign the camera’s stream profiles.
NOTE: If the utility fails to access the camera, confirm the utility is using the correct log-in credentials for
the camera (created during camera activation) and re-attempt saving to VIGIL. If issues persist, contact
3xLOGIC Support.
Figure 1-3 Assigning Stream Profiles
8. Assign the streams as desired and click OK.
The user will be returned to the Network Camera Settings form.
9. Configure additional settings as desired.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
14
1.
2. Click OK to on the Network Camera Settings form then click Apply on the VIGIL Server Settings window
to save the new settings.
The camera will now be saved to VIGIL and can be accessed and controlled via the VIGIL Server UI. Any other
applicable VIGIL utilities (VIGIL Client, View Lite II) that have been interfaced with the VIGIL Server will also be
able to access and control the camera. See the VIGIL Server and VIGIL Client User Guides for more information
on interacting with the camera and its footage. Visit the 3xLOGIC Document Library for the latest available
support documentation.
1.2 Access UI via Web Browser
Steps:
1. Open a web browser.
2. Input the IP address of the network camera in the URL address bar, e.g., 192.0.0.64 and press the Enter key
to enter the login interface. Alternatively, if the camera is interfaced with VIGIL Server, the web UI can be
instantly deployed by opening the camera’s Network Settings form in VIGIL Server Settings > Cameras Tab
and clicking the Web Settings button.
3. Input the user name and password and click Login.
NOTE: The username/password for the camera will have been configured during camera activation If the
camera has already been configured using one of 3xLOGIC’s setup tools (VIGIL Easy Setup Wizard, 3xLOGIc
Camera Setup Utility) then default credentials will have been changed by the installer (this is a standard
security precaution enforced by the setup tools). Contact your security network administrator for
credentials.
NOTE: English is the only supported language.

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
15
Figure 2-3 Login Interface
4. To view video and have full access to the camera’s configuration settings, you will need to install the Web
Components plug-in. Click “Activate Web Components” to start the plug-in installation.
NOTE: Depending on your web browser, you may be required to authorize the installer to run.
NOTE: You may have to close the web browser to install the plug-in. Reopen the web browser and log in
again after installing the plug-in.
Figure 2-4 Download and Install Plug-in

S-Series Camera Quick Start Guide | VX-4V-ID-RIAWD
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
16
Figure 2-5 Install Plug-in (1)
Figure 2-6 Install Plug-in (2)
After the Web Components plugin successfully install, you can access and operate the camera’s browser
interface. Visit the 3xLOGIC Document Library for the latest available support documentation.
