4DRC 4D-F10 User manual

4D-F10
English
Suitable for ages over 14
Quadcopter operating instructions
In order to meet the requirements of the aeronautical radio station's
electromagnetic environment (various of aero models and UAV are not
allowed to fly within the range of 10 km on each side of center line and
20km on both ends of the airport runway and in the) and civil aviation
routes and airlines. Using various models and drones in the no-fly zone
issued by the relevant state departments is prohibited.

Warning
1. The packaging and instructions contain important information and should be kept.
2. With this aircraft, you are responsible for ensuring that no harm will be caused to the personal and
property of others.
3. Commissioning and installing of aircraft must be strictly in accordance with the operating
instructions, and attention shall be paid to the distance between the aircraft and the user or other
people shall be 2 to 3m to prevent the aircraft from bumping into the head, face and body of
people and causing injury in flying and landing, etc.
4. Our company and distributors are not responsible for any loss and damage, as well as injury to
people caused by improper use or operation.
5. Children should be guided by adults when operating the aircraft. This product is prohibited to be
operated by children under 14 years old.
6. Please follow the instructions or packaging instructions to install and use correctly, and some parts
should be assembled by adults.
7. The product contains small parts, please place it out of the reach of children to prevent the risk of
accidental eating or suffocation.
8. It is strictly forbidden to play on the road or in the place where water is accumulated to avoid
accidents.
9. Please put away the packing materials in time to avoid harm to children.
10. Do not disassemble or modify the aircraft. Disassembly or modification may cause malfunction to
the aircraft.
11. The charging cable needs to be inserted into the designated power supply 5V 2A that is the
same as the product label.
12. The use of other charging cables will cause damage to the battery and may cause unexpected
dangers.
13. The charging cable is not a toy.
14. When charging the rechargeable battery, it must be under the supervision of an adult. When
charging, it must be far away from flammable materials. During charging, the guardian should not
leave the monitoring range.
15. Please do not short circuit or squeeze the battery to avoid explosion.
16. Do not mix different types of lithium batteries.
17. The aircraft uses a rechargeable lithium battery, which needs to be pulled out for charging.
18. Do not short-circuit, decompose or throw the battery into fire; do not put the battery in a place
with high temperature and heat (such as in fire or near electric heating device).
19. The aircraft should be used as far away from other electrical equipment and magnetic objects as
possible, they may cause mutual interference.
20. Please keep a safe distance from the high-speed rotating propeller to avoid the risk of scalp or
cut
21. The motor is a hot part; please do not touch it to avoid burns.
22. LED has laser radiation; please do not give direct light beam to others.
23. Do not use the model near your ears! Misuse may cause hearing damage.
24. The USB charging cable must use the data cable provided by our company to charge the battery,
otherwise it will cause serious damage to the battery and will lead to unexpected danger.
25. To meet the magnetic environment requirements of aeronautical radio stations. During the radio
control order issued by the relevant state departments, the model remote control should be
stopped within the city area as required.
26. Turn off the switch and unplug the battery when the battery of the aircraft is used up, and charge
after 30 minutes of rest, otherwise the battery will be easily damaged.
01

3. Wind blade installation diagram:
2. Name of each part of aircraft:
1. List of accessories included:
Fan blade ×2
USB charging
cable ×1
Operating
Instructions ×1
Screwdriver ×1Lithium battery ×1Aircraft ×1
Battery
Shell
Fan blade
Camera
Bottom camera
Fan blade clip
Motor
LED lights
B/D
B/D
2
B/D
B/D
1
3.1 Unscrew the screw and remove the
fan blade.
3.2 Loosen the screw, open the two fan blades
and the connecting parts, and remove
the fan blades for replacement. (When
B/D fan blade is broken, replace B/D,
and so do to A/C fan blade, error in
replacement will cause that it can’t take
off)
Note: The fan blade is printed with letters
of ABC, and D, in which, A=C,B=D,
please install it correctly according
to the diagram, otherwise it cannot
take off. 02

4. Unfolding steps of the aircraft: (It is in the storage state when it leaves the factory)
1. Unfold the aircraft according to the steps
5. Lithium battery charging instructions:
5.2 Remove the battery.5.1 Buckle the battery lock of the aircraft.
Desktop PC Mobile power USB adapter USB power
socket
Laptop
It must be charged with the aircraft charging cable provided by the factory, and
other charging cables cannot be used. Be sure to remember to avoid accidents.
Warning
3
5.3 Charging: Insert the USB port of the USBcharging cable into the computer USB port (or use 5V 2A
power adapter), and connect the other end of the USB charging cable to thebattery socket. When
charging, the red indicator on the module battery is on, The green light will always be on when the battery
is full and the charging is completed.
1
54
3
A/C
B/D
B/D
A/C
2
1 2
03

GPS
6. Name of each part of the remote control:
Fine adjustment (press and
hold)/speed gear
Power Indicator
Left stick
Power switch (long press)
Horizontal calibration (short
press) Geomagnetism
(compass) calibration (long
press for 3s)
One-key take-off / one-key
landing
Press the
emergency
pause button at
the same time
Photo / Video (long
press)
Right stick
GPS switch (long
press)
Headless mode
One-key return
Description of remote
control indicator:
One-key
return
Headless
mode
Normal/GPS button: Press and hold this button for 3s after frequency matching to switch between
normal mode and GPS mode (It is by default GPS mode after starting up, GPS indicator will be on,
and when it enters normal mode, the indicator will be off).
Headless mode button: Press this button once to enter the headless mode, the headless light will
be on; press it again to exit the headless mode, and the headless light will be off.
Return button: Press this button once to return home, and the return light will be on. Press again to
cancel the returning, and the return light will be off.
7. Remote control battery installation:
AAA battery
Battery cover
Battery installation:
7.1 Press the battery cover button with
a screwdriver and remove the
battery cover at the same time.
7.2 According to the polarity
instructions on the battery
compartment, remove the battery
cover on the back and insert a 4X
“AAA” battery (not included).
Note
1. The positive and negative poles and the positive and
negative poles of the battery box must be identified when
inserting the battery, and error is not allowed.
2. Do not mix old and new batteries.
3. Do not mix different types of batteries.
When the aircraft is not in flying, disconnect the
battery plug from the power connector of the aircraft
circuit board to prevent the battery from being
damaged.
Warning
Instructions in charging:
Do not put the charged battery in a place with high temperature and heat, such as an
open flame or an electric heating device, otherwise damage or explosion may occur.
Do not hit or beat the surface of hard objects with the battery.
Do not disassemble the battery.
Do not immerse the battery in water, and please store the
battery in a dry place.
Do not leave battery alone when charging.
●
●
●
●
●
04

Download on the
4DRC PRO
8. APP download and installation instructions:
8.1 Download and install the software
For Google mobile phone, after scanning the code, choose to open and download in the browser
Google system: Please
scan this QR code to install
Apple system: Please scan
this QR code to install
8.2 Link description
① Turn on the power of aircraft, enter the (Settings) option (of mobile phone or IPAD), and open the
wireless network; find the device name of "4DRC_6K_GPS " in the wireless network search list and
connect; after connection, exit the setting option.
②Open the software icon "4DRC PRO " in mobile phone to enter the control interface. (Try to stay away
from other signal source environments when flying).
Open "4DRC PRO " software Select Go to enter the
control interface
Select and click "More Features" Enter the function menu
Satellite signal
Flight status
More features
Return
Takeoff / landing
One-key return
Unlock
Map
Flight distance
9. APP control interface function introduction:
05

3D stereo
Reverse the lens
Unlock
Gesture photo
Music
Lens switching
Multipoint flight
Follow
Orbit
Find the plane
Speed gear
Touch joystick
Novice mode
Flight distance,
default 30m, (20m-2000m)
Flight altitude,
default 30m, (10m-120m)
Note: After being proficient in flight operation, it is necessary to close the novice mode
and set the flight distance and altitude before the aircraft can fly further!
10. Environmental requirements before flight:
Please choose an outdoor open environment with no rain, snow and wind less than
Level 3. Please stay away from people, trees, wires, tall buildings, airport and signal
transmission tower when flying. Do not play it indoor environment or an environment
with weak GPS signals.
06

2
1
2
3
11.3: Turn on the remote control (default mode): long
press the power switch button (step 1), turn on
the power and the indicator flashes; push the
throttle lever up to the top (step 2) and then to the
bottom (step 3), and thus the frequency matching
is successful, the UAV lights change from flashing
to being permanently on.
Warning
11. Preparation instructions before flight
11.2 Turn on the WiFi function in the mobile device,
select "4DRC_6K_GPS " in the WiFi list, and
open the APP after it connected successfully.
11.1 Turn on the power of the aircraft and place it on
the horizontal plane. At this time, the aircraft
placed on the horizontal plane will automatically
enter the code-matching state, and the front white
light and the red light of fuselage will flash.
Note: Set the aircraft in a correct direction, and the
nose shall face forward. It must be placed on the
horizontal plane.
It must ensure that the power of the aircraft/remote control is sufficient or
it cannot take off!
11.4 Horizontal calibration operation:
Short press the horizontal calibration button on the remote control , the white and red lights on the
aircraft will flash quickly. When the white and red lights on the aircraft are always on, it will means that
the calibration is completed (Figure 1).
APP application operation: Click "Set more" icon in the APP interface, and follow the text prompt
steps after entering, and it can also be horizontally calibrated (Figure 2).
Note: In calibration, the aircraft must be placed on a horizontal surface to complete the calibration.
07

Figure 1
Figure 2
Figure 3
Figure 4
11.5 Geomagnetic calibration operation
2. Rotate horizontally clockwise to
pick up the aircraft, rotate
clockwise until the front white light
is always on and the rear red light
flashes, and the remote control
emits a beep, it means that the
horizontal calibration is completed.
3. Rotate clockwise with the tail of the
aircraft is upward -pick up the aircraft,
with its nose being vertically down,
and rotate clockwise until the white
light on the front and the red light on
the rear of the aircraft are always on,
and the remote control emits a beep,
it means that the guide calibration is
completed.
1. Long press the
geomagnetic calibration
key until the front
white light and the rear
red light flash on the
aircraft.
APP application operation: In entering the interface of "Setting more", according to the
text prompt and operation steps, you can also guide the calibration (Figure 4).
08

GPS
Figure 6
Figure 5
Figure 7
11.6 Star search status (In GPS mode by default)
The remote control is in GPS mode and the GPS light is always on, which means that the
GPS is in the state of star searching. When the red tail light of the aircraft flashes quickly, it
means that the star searching succeeded, and the remote controller will emit a beep. The
aircraft can be unlocked at this time (Figure 5).
Note: You need to wait at least a few minutes for the first search. When the search
signal reaches 3 blocks or more, you can take off.
Description of remote
control indicator:
One-key
return
Headless
mode
11.7 Start/stop (GPS mode)
Push the left and right joysticks on the remote control outward to unlock, (if the star search
is unsuccessful, it cannot be unlocked and started) (Figure 6). At this time, the aircraft can
take off normally. After taking off, all the indicators of the aircraft are always on.
APP operation: Click "One Key Unlock" icon (Figure 7) in APP control interface, the
one-key unlock function can also be achieved.
11.8 One-key take-off and landing
When unlocking is complete, gently press the “One Key Takeoff/Landing” key on the
remote control (Figure 8), the aircraft will automatically rise to a height of about 1 meter to
maintain a stable flight; when you press this function key gently again, the aircraft will
automatically land slowly.
APP operation: Click "one-key take-off" icon (Figure 9) in APP control interface, the
one-key take-off function can also be achieved; during flight, click this icon again, the
aircraft will automatically land slowly.
09

3. Then push up the left
joysticks (Figure 12)
2. Push the left and right joysticks on the remote
control outward to unlock (Figure 11)
11.10 Start / stop (common mode needs to be turned on for indoor operation)
4. Or press one key take off button
to take off (Figure 13)
1. Long press the GPS button on the
remote control, GPS indicator of the remote
control will enter normal mode (Figure 10)
11.9 Normal mode
The aircraft enters the normal mode
Figure 12 Figure 13
Figure 10 Figure 11
Figure 8 Figure 9
10

Warning
When the left joystick (throttle) is
pushed up, the rotation rate of the main
blade increases and the aircraft rises.
When the left joystick (throttle) is
pushed down, the rotation rate of the
main blade slows down and the aircraft
descends.
When the left joystick (rudder) is
pushed to the left, the aircraft nose
turns to the left. When the left joystick
(rudder) is pushed to the right and the
nose of the aircraft will turn to the right.
When the right joystick (rudder) is
pushed up, the aircraft moves forward.
When the right joystick (rudder) is
pushed down, the aircraft moves
backward.
When the right joystick (rudder) is
pushed to the right, the aircraft
fuselage deviates to the right.
When the right joystick (rudder) is
pushed to the left, the aircraft fuselage
deviates to the left.
Before flying, please perform the following steps in the above order: open (refer
to 11.1) → link to WIFI (refer to 11.2) → remote control to start frequency
matching(refer to 11.3) → horizontal calibration (refer to 11.4) → geomagnetic
calibration (refer to 11.5) → Star search status (in GPS mode by default)
(reference 11.6) → start/stop (GPS mode) (reference 11.7) → takeoff and landing
(refer to 11.8) → normal mode(refer to 11.9) → start/stop (it needs to open the
normal mode for indoor operation) (refer to 11.10)
APP application operation: Enter the APP control interface and click the "more functions"
icon to open the "joystick on/off" icon, you can see the operation joystick on the interface.
The operation method is as follows:
12. Control method:
11

Warning
Figure 15 Figure 16
When the aircraft is in 1m from the ground, the aircraft will become unstable due to
the influence of its own blade vortex, which is called "ground effect response". The
lower the height of the aircraft, the greater the effect of the ground effect response.
13. Introduction to the APP application and remote control function operation:
13.1 Headless mode
The front of the aircraft when the code-matching is turned on is by default the front in
headless mode; if it is necessary to adjust the direction, please turn on the code-matching
again, and short press the remote controller "headless mode" function key (Figure 14).
When exiting, please tap gently press this function key again.
Special prompt: Please make sure the aircraft is aligned with the straight line and let
the gyroscope automatically detect the straight line, and the headless mode of straight
line flight can be realized.
Figure 14
13.2 One key return
Press the one-key return button , the aircraft will return to the place above the geomagnet-
ic calibration position (Figure 15). (The aircraft will automatically rise to a safe altitude when it
is flying below the safe altitude) and then land slowly. If there are obstacles during the landing,
press the one-key return button again to turn off the return operation and avoid by the manual
control joystick, pull down the throttle lever to land.
APP operation: Click the "one-key return" icon (Figure 16) in the APP control interface, you
can also return the aircraft; during the return flight, click this icon again to cancel the return.
Front
Right
Rear
Left
Front
Right
Rear
Left
12

1
2
34
1
2
34
1
2
34
Warning
Runaway return: When the signal of the remote controller is interrupted for
about 4s, the aircraft will automatically return to the place where there is a
signal and stop. Low battery return: when the aircraft is in low battery electricity,
it will forcefully return to a place that is 20m above the take-off point. The return
flight cannot be cancelled during the low battery return.
13.4 Waypoint flight mode
①In GPS mode, click the "More Functions" icon (Figure 20) in the APP control interface to
enter the multi-point flight (Figure 21). At this time, the interface changes from the image
transmission page to the map page. On the map page, click to set the track range of the
segmented waypoints or continuous waypoints (Figure 22). During the setting, if the track
waypoints are too dense, you can click the delete icon to delete all the waypoints (Figure 23).
②After setting of the waypoint, click the send icon (Figure 24), the aircraft will fly to all
waypoints from the initial point to complete the preset flight trajectory. The direction of the
aircraft can be controlled by the joystick during the flight.
Figure 29 Figure 30
Figure 17 Figure 18 Figure 19
Figure 20 Figure 21
Figure 23 Figure 24
Figure 22
13.3 Speed switching
When the aircraft takes off, it is by default in the low-speed mode (3-geared switching);
gently press the remote control by a "beep" sound for low-speed gear, two "beep" sounds for
medium-speed gear, and three "beep" sounds for high-speed gear (Figure 17)".
APP operation: Click the "More Functions" icon (Figure 18) in the APP control interface, and
the flight speed can also be switched (Figure 19).
13

Figure 25 Figure 26 Figure 27
Figure 28 Figure 29 Figure 30
Figure 31 Figure 32
13.5 Orbital flight mode
In GPS mode, click "More Features" icon in the APP control interface (Figure 25) to enter the
orbit flight mode (Figure 26), the aircraft will automatically orbit in a radius (Figure 27), and
the radius can be adjusted on the APP (Figure 28). At this time, push the right direction
joystick to fly left or right (Figure 29) at the default speed, the orbital speed can be adjusted.
Push the right direction joystick front or rear, the orbit radius can be adjusted, and when the
orbit button is pressed again, the orbit flight will end (Figure 30).
13.6 GPS follow mode
In GPS mode, click the “More Functions” icon (Figure 31) in the APP control interface to
enter the follow (Figure 32). The aircraft will use the distance from the current position to the
operator (mobile phone or IPAD) device as a reference, and move by tracking changes in the
location of mobile devices. In following, lightly press the red icon to cancel the following.
13.7 Gesture recognition
When facing the camera's front lens, click the gesture photo button on the APP, and use any
of the following gestures to trigger the aircraft's photo or camera function.
Special Tip: Please face the lens with the front being at a position about 2-3M away and
in a better light and background environment to perform the gesture recognition.
14

Yeah gesture photo
In about 3m front of the aircraft lens, make Yeah gesture with one hand in
horizontal position; after the aircraft successfully recognizes the gesture, count
down 3 seconds and take photos.
Palm gesture video-recording
In about 3m front of the aircraft lens, put five fingers together and lift one hand to
horizontal position; after the aircraft successfully recognizes the gesture, it will
start recording. The recording will end when the gesture is re-recognized (the time
difference between the two recognitions shall be greater than 3s).
Figure 33 Figure 34 Figure 35
13.8 MV interface
Click the "filter interface" icon (Figure 33) in the APP control interface, after entering the
filter interface, you can choose to match your favorite filter effect, click the recording icon to
start recording (Figure 34). After the recording is completed, the synthesized short video or
picture will be saved to the media library (Figure 35).
Tips: During the recording process, you can rotate the screen or switch the filter effect,
and you can also turn the joystick on / off to control the direction and altitude of the aircraft.
14. FAQ and solving guidelines:
Question
The aircraft indicator flashes
without any response
The blades of the aircraft rotate
but cannot fly
The aircraft vibrates badly
After the impact, start the aircraft
again and it fly uncontrollably
After the impact, start the aircraft
again and it fly uncontrollably
Reason
1. Geomagnetic anomaly
2. The aircraft has insufficient power
1. Low battery
2.1 Blade deformation
2.2 Installation error of AB
propeller
Blade deformation
1. Blade deformation
2. Defective motor
The three-axis acceleration
sensor loses its balance due to
impact
Solution
1. Move the aircraft to an open place and
search for stars again
2. Charge the battery
1. Charge the battery
2.1 Replace the blade
2.2 The fan blades are printed with letters
A and B. For fan blade A or B, replace
the one that is broken
Replace the blade
1. Replace the blade
2. Replace the motor
After leaving the aircraft for 5-10 seconds,
or by the horizontal calibration, it will be ok.
For the steps, please refer to the manual,
11.4 horizontal calibration operation.
15
