512 Audio SCRIPT User manual

SCRIPT
PREMIUM USB MICROPHONE FOR PODCASTING,
STREAMING, AND RECORDING
EN | FR | DE | ES | 中文 | 日本語

TABLE OF CONTENTS
English...................................................................................... 3
French .....................................................................................15
Deutsch................................................................................... 27
Español ...................................................................................39
中文 .......................................................................................51
󳺝󴂷󸎅................................................................................... 63

EN | 3
WELCOME
Congratulations on becoming an owner of Script, a premium USB microphone
for podcasting, streaming, or recording. Script delivers broadcast-quality audio
in an elegant, minimalist design that looks as good as it sounds. With plug ‘n play
compatibility, it’s never been easier to start streaming in a matter of minutes on any Mac
or PC. Script features a zero-latency stereo headphone output, adjustable volume,
push-button mute, a dedicated pickup pattern switch, and an LED status indicator so
you can know if you’re muted at a glance. Script brings the most important elements of
a broadcast studio to your desk so you can sound your best wherever you are.

4 | EN
FEATURES
DUAL CAPSULES
Two 14mm electret condenser capsules deliver smooth, clear sound for podcasting,
streaming, and video-conferencing.
ZEROLATENCY STEREO HEADPHONE OUTPUT
Script features an industry-standard ¹/” headphone jack for simple and easy zero-
latency monitoring for when you’re recording, streaming, or in a meeting.
HEADPHONE VOLUME CONTROL
Quickly adjust the volume of your headphones with the dedicated volume knob on the
front of the microphone.
MUTE BUTTON
Press the headphone volume knob to instantly mute or unmute your microphone. A white

EN | 5
FEATURES
LED indicates when the mic is active. A red LED indicates that your Script is muted.
ARM MOUNT
Script includes an arm mount adapter that screws onto the base of the microphone
body. Once secured in place, you can easily attach Script to most boom arms,
microphone stands, and desktop mounts.
USBC CONNECTION
Script connects to any Mac or PC with the included USB-C to USB-A cable.
PATTERN SELECTION
Switch between cardioid and omni with a simple toggle switch on the back of Script.

6 | EN
GETTING STARTED WITH SCRIPT
First, remove Script from its packaging and attach the included arm mount to the bottom
of the microphone. Rotate and tighten as needed so that the 512 logo and headphone
volume knob are facing you and the microphone is firmly attached to the arm mount.
You are now ready to attach Script to a microphone boom arm, mic stand, or desktop
mount. Once mounted to your mic stand of choice, connect Script to your computer
with the included USB-C to USB-A cable. The headphone volume knob/mute button
should illuminate, which indicates that the microphone is now powered.
When you are ready to record or begin streaming, confirm that the 512 Audio logo
and volume knob are facing you. Next, position the microphone a few inches away
from your mouth.
That’s it! You’re all set to capture your voice with broadcast-quality audio. Enjoy!

EN | 7
GETTING STARTED WITH SCRIPT
WINDOWS QUICKSTART GUIDE
(Windows 7, 8.1, 10, or newer)
1. Connect Script to your PC with the included USB cable.
2. Click Start (or the Windows logo), then select Control Panel.
3. Once you open Control Panel, select the “Sound” icon.
4. Click the “Recording” tab and select “Script”.
5. Click the “Playback” tab and select “Script”.

8 | EN
GETTING STARTED WITH SCRIPT
MAC OS QUICKSTART GUIDE
(macOS 10.10 or newer)
1. Connect Script to your Mac with the included USB cable.
2. Open System Preferences and select the “Sound” icon.
3. Click the “Input” tab and select “Script”.
4. Click the “Output” tab and select “Script”.
5. On the same screen, locate the “Output” volume and set to 100%.

EN | 9
POPULAR SOFTWARE COMPATIBILITY
It’s easy to use Script with your favorite software. With universal compatibility, you can
start recording great audio right out of the box. Script works seamlessly with the apps
you already use including Garageband, iMovie, Zoom, Facetime, Skype, Audacity,
Logic Pro, and more. Just plug into your Mac or PC, choose Script as your audio input
in the software of your choice, and begin to capture broadcast-quality audio. Script
does not require any drivers, it’s that simple.

10 | EN
POLAR PATTERNS
Script’s unique dual-capsule design gives you the flexibility to choose the right pickup
pattern in any scenario.
CARDIOID
Recommended for recording podcasts, live-streaming, singing, and voiceovers. The
cardioid pickup pattern records sounds that are directly in front of the microphone and
rejects ambient noise around you.
OMNIDIRECTIONAL
Ideal for multi-person podcasts, a group conference call, or when you want to capture
the ambience of a live performance. The omnidirectional pickup pattern captures sound
from all around the mic, ideal for multi-person content or calls.

EN | 11
SIDE ADDRESS
Script is a side-address microphone – in cardioid mode, sound is captured from the
front, so you should speak or sing facing the 512 Audio logo and volume knob. When
in omni mode, Script captures sound from all directions. If you are in a conference room
with multiple people, it may be best to place the microphone in the center so all your
participants are captured at a relatively equal volume.

12 | EN
SPECS
MICROPHONE
Sample Rates: 44.1kHz, 48kHz, and 96kHz
Bit Rate: 24-bit
Capsules: Dual 14mm electret condenser capsules
Polar Patterns: Cardioid, Omnidirectional
Frequency Response: 100Hz–20kHz
Sensitivity: -25dBFS (min gain)
Max SPL: 120dB
Dynamic Range: 95dB
Interface: USB-C

EN | 13
SPECS
HEADPHONES
3.5mm Stereo Jack: Zero-latency monitoring
Bit Rate: 24-bit
Sample Rate: 48kHz
Power Output: 75mW @ 16 ohms
DIMENSIONS
L = 140.2mm W = 58.5mm H = 44.4mm
Weight = 160g
Learn more and sign up for our e-newsletter at www.512audio.com.

14 | EN
WARRANTY STATEMENT
512 Audio warranties this product to be free from defect in materials and workmanship for one year from the date of
purchase, for the original purchaser to whom this equipment is registered. This warranty is non-transferable.
This warranty is void in the event of damage incurred from unauthorized service to this unit, or from electrical or
mechanical modification. This warranty does not cover damage resulting from abuse, accidental damage, misuse,
improper electrical conditions such as mis-wiring, incorrect voltage or frequency, unstable power, disconnection
from earth ground (for products requiring a 3 pin, grounded power cable), or from exposure to hostile environmental
conditions such as moisture, humidity, smoke, fire, sand or other debris, and extreme temperatures.
512 Audio will, at its sole discretion, repair or replace this product in a timely manner. This limited warranty extends
only to products determined to be defective and does not cover incidental costs such as equipment rental, loss of
revenue, etc. Please visit us at www.512audio.com for more information on your warranty, or to request warranty
service.
This warranty applies to products sold in the United States of America. For warranty information in any other country,
please refer to your local 512 Audio distributor. This warranty provides specific legal rights, which may vary from
state to state. Depending on the state in which you live, you may have rights in addition to those covered in this
statement. Please refer to your state laws or see your local 512 Audio retailer for more information.

FR | 15
BIENVENUE
Félicitations, vous êtes désormais l’heureux possesseur d’un Script, un microphone USB
haut de gamme pour le podcast, le streaming ou l'enregistrement. Script offre un son
de qualité professionnelle dans un design élégant et minimaliste, aussi beau qu'il sonne
bien. Grâce au plug-and-play, il est très simple de lancer un streaming en quelques
minutes sur n'importe quel Mac ou PC. Script est doté d'une sortie casque stéréo sans
latence, d'un volume réglable, d'un bouton de mise en sourdine, d'un commutateur de
directivité dédié et d'un indicateur d'état LED qui vous permet de savoir d'un coup d'œil
si vous êtes en mode silencieux. Script rassemble les éléments les plus importants d'un
studio de diffusion sur votre bureau afin que vous puissiez donner le meilleur de vous-
même où que vous soyez.

16 | FR
DOUBLE CAPSULES
Deux capsules à condensateur à électret de 14 mm offrent un son clair et régulier pour le
podcast, le streaming et la vidéoconférence.
SORTIE CASQUE STÉRÉO SANS LATENCE
Script dispose d'une prise casque de 3,5 mm conforme aux normes de l'industrie pour un
contrôle simple et facile sans latence lorsque vous enregistrez, diffusez ou êtes en réunion.
CONTRÔLE DU VOLUME DU CASQUE
Réglez rapidement le volume de votre casque grâce au bouton de volume dédié situé à l'avant
du microphone.
BOUTON DE MISE EN SOURDINE
Appuyez sur le bouton de volume du casque pour couper ou rétablir instantanément le son de
CARACTÉRISTIQUES

FR | 17
CARACTÉRISTIQUES
votre microphone. Un voyant blanc indique quand le micro est actif. Un voyant rouge indique
que votre Script est en sourdine.
MONTAGE SUR BRAS
Script comprend un adaptateur de montage sur bras qui se visse sur la base du corps du
microphone. Une fois en place, vous pouvez facilement fixer Script à la plupart des perches,
des pieds de micro et des supports de bureau.
CONNEXION USBC
Script se connecte à n'importe quel Mac ou PC avec le câble USB-C vers USB-A fourni.
SÉLECTION DE LA DIRECTIVITÉ
Passez de cardioïde à omni à l’aide d’un simple bouton à l'arrière du Script.

18 | FR
MISE EN ROUTE DU SCRIPT
Tout d'abord, sortez le Script de son emballage et fixez le support de bras fourni à la
base du microphone. Tournez et serrez autant que nécessaire afin que le logo 512 et
le bouton de volume du casque soient face à vous et que le microphone soit fermement
fixé au support de bras. Vous êtes maintenant prêt à fixer le Script sur un bras de micro,
un pied de micro ou un support de bureau. Une fois installé sur le pied de micro de
votre choix, connectez Script à votre ordinateur à l'aide du câble USB-C vers USB-A
fourni. Le bouton de volume/mise en sourdine du casque doit s'allumer, ce qui indique
que le microphone est maintenant sous tension.
Quand vous êtes prêt à enregistrer ou à commencer le streaming, confirmez que le
logo 512 Audio et le bouton de volume sont face à vous. Ensuite, placez le microphone
à quelques centimètres de votre bouche.
Ça y est ! Vous êtes prêt à capturer votre voix avec un son de qualité professionnelle.
Profitez-en !

FR | 19
MISE EN ROUTE DU SCRIPT
GUIDE DE DÉMARRAGE RAPIDE POUR WINDOWS
(Windows 7, 8.1, 10, ou plus récent)
1. Connectez le Script à votre PC à l'aide du câble USB fourni.
2. Cliquez sur Démarrer (ou le logo Windows), puis sélectionnez Panneau de
configuration.
3. Une fois que vous avez ouvert le Panneau de configuration, sélectionnez l'icône "Son".
4. Cliquez sur l'onglet "Enregistrement" et sélectionnez "Script".
5. Cliquez sur l'onglet "Playback" et sélectionnez "Script".

20 | FR
GUIDE DE DÉMARRAGE RAPIDE POUR MAC
(macOS 10.10 ou plus récent)
1. Connectez le Script à votre Mac avec le câble USB fourni.
2. Ouvrez les Préférences Système et sélectionnez l'icône "Son".
3. Cliquez sur l'onglet "Entrée" et sélectionnez "Script".
4. Cliquez sur l'onglet "Sortie" et sélectionnez "Script".
5. Sur le même écran, localisez le volume de "Sortie" et réglez-le sur 100%.
MISE EN ROUTE DU SCRIPT
