8 Level SMART WRT-150 User manual

V1.0_20110828
USER MANUAL
WRT-150 SMART
150Mbps Wireless Broadband Router

150Mbps Wireless Broadband Router User Manual
FCC Statement
This equipment has been tested and found to complywith the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this equipment.
(Example- use only shielded interface cables when connecting to computer or peripheral
devices)
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located oroperating in conjunction with any other
antenna or transmitter.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate the
equipment

150Mbps Wireless Broadband Router User Manual
1
COPYRIGHT & TRADEMARKS
We reserve the right to change the product specification without notification.
is a registered trademark of 8level. No part of the manual may be reproduced, translated or
processed in any other form without permission from 8level NEXT LEVEL IN
NETWORKING. All rights reserved. Copyright © 2012 8level.
SAFETY NOTICE
Do not use this product near water. Using the product during a thunderstorm should be avoided.
Do not place heavy objects on the casing.
RECYCLING NOTICE
The symbol of the crossed-out wheeled bin on this product means that it is
forbidden to place the equipment waste together with other waste (under penalty
of fine). Detailed information about recycling of the product can be obtained at
local authorities, local waste treatment plants or local distributors. Forwarding
the equipment waste to recycling or recovery points helps to avoid the negative
influence of the harmful components present in the equipment on the environment and human
health; in this scope the primary role is played by each household.

150Mbps Wireless Broadband Router User Manual
2

150Mbps Wireless Broadband Router User Manual
3
NATIONAL RESTRICTIONS
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.
Frequency range - 2400.0 - 2483.5 MHz
Country
Country
Reason/remark
Bulgaria
none
General authorization required for outdoor use and
public service.
France
Outdoor use limited to 10
mW e.i.r.p. within the band
2454-2483.5 MHz
Military Radiolocation use. Refarming of the 2.4
GHz band has been ongoing in recent years to allow
current relaxed regulation. Full implementation
planned 2012.
Italy
none
If used outside of own premises, general
authorization is required.
Luxembourg
none
General authorization required for network and
service supply (not for spectrum).
Norway
Implemented
This subsection does not apply for the geographical
area within a radius of 20 km from the centre of
Ny-Ålesund.
Russian
Federation
none
Only for indoor applications.
Note: Please don’t use the product outdoors in France.

150Mbps Wireless Broadband Router User Manual
4
Package Contents
The following items should be found in your package:
150Mbps Wireless Broadband Router (WRT-150 SMART)
Power adapter
Quick Installation Guide
CD-Rom
Ethernet cable
Make sure that the package contains above items. If any of the above items is missing or
damaged, please contact the store you bought this product from.
Manufactured for: Sunnyline Computer Products Poland Sp z o.o., ul. Graniczna 58 B, 62-082 Przeźmierowo - POLAND

150Mbps Wireless Broadband Router User Manual
5
Contents
1. INTRODUCTION .........................................................................................................................8
1.1. PRODUCT OVERVIEW...............................................................................................................8
1.2. MAIN FEATURES ......................................................................................................................8
1.3. SUPPORTING STANDARD AND PROTOCOL.................................................................................9
1.4. WORKING ENVIRONMENT........................................................................................................9
2. HARDWARE INSTALLATION.................................................................................................10
2.1. SYSTEM REQUIREMENT .........................................................................................................10
2.2. PANEL....................................................................................................................................10
2.3. RESTORE TO FACTORY CONFIGURATION .................................................................................11
2.4. HARDWARE INSTALLATION PROCEDURES ..............................................................................11
3. LOGIN..........................................................................................................................................13
3.1. CONFIGURE COMPUTER..........................................................................................................13
3.1.1. Windows XP .................................................................................................................13
3.1.2. Windows Vista ..............................................................................................................16
3.1.3. Windows 7 ....................................................................................................................20
3.1.4. MAC OS .......................................................................................................................22
3.2. CHECKING CONNECTION WITH THE ROUTER .........................................................................24
3.3. LOGIN....................................................................................................................................25
4. ROUTER SETUP ........................................................................................................................27
4.1. STATUS...................................................................................................................................27
4.1.1. Version..........................................................................................................................27
4.1.2. WAN..............................................................................................................................27
4.1.3. LAN ..............................................................................................................................28
4.1.4. Wireless ........................................................................................................................28
4.1.5. Router Status................................................................................................................29
4.1.6. Traffic Statistics............................................................................................................29
4.2. QUICK SETUP.........................................................................................................................29
4.2.1. DHCP (dynamic)..........................................................................................................30
4.2.2. PPPoE..........................................................................................................................30
4.2.3. Static.............................................................................................................................30
4.2.4. Wireless Configuration.................................................................................................31
4.2.5. MAC Clone...................................................................................................................32
4.3. WPS SETTINGS......................................................................................................................32
4.3.1. WPS Settings ................................................................................................................32
4.3.2. Add a New Device........................................................................................................33
4.3.3. WPS Configuration ......................................................................................................34
4.4. NETWORK..............................................................................................................................34
4.4.1. WAN..............................................................................................................................34
4.4.1.1. Wired Access ...........................................................................................................35

150Mbps Wireless Broadband Router User Manual
6
4.4.1.2. Wireless Access........................................................................................................36
4.4.2. LAN ..............................................................................................................................37
4.4.3. MAC Clone...................................................................................................................37
4.4.4. Port Settings.................................................................................................................37
4.4.5. IGMP Proxy .................................................................................................................38
4.5. WIRELESS..............................................................................................................................38
4.5.1. WIRELESS SETTINGS..............................................................................................................38
4.5.2. Wireless Security ..........................................................................................................40
4.5.2.1. None.........................................................................................................................40
4.5.2.2. WEP.........................................................................................................................40
4.5.2.3. WPA-PSK ................................................................................................................41
4.5.2.4. WPA2-PSK ..............................................................................................................41
4.5.2.5. WPA/WPA2-PSK.....................................................................................................42
4.5.3. Wireless MAC Filtering................................................................................................42
4.5.4. WDS Settings................................................................................................................43
4.5.5. Wireless Advanced........................................................................................................44
4.5.6. Wireless Statistics.........................................................................................................45
4.5.7. Multiple AP Settings.....................................................................................................45
4.6. DHCP...........................................................................................................................46
4.6.1. DHCP Settings .............................................................................................................46
4.6.2. DHCP Clients List........................................................................................................46
4.6.3. Address Reservation.....................................................................................................46
4.7. FORWARDING.........................................................................................................................47
4.7.1. Virtual Servers..............................................................................................................47
4.7.2. Port Triggering.............................................................................................................47
4.7.3. DMZ .............................................................................................................................48
4.7.4. UPnP............................................................................................................................49
4.7.5. FTP Private Port..........................................................................................................49
4.8. Security.........................................................................................................................49
4.8.1. Security Settings...........................................................................................................49
4.8.2. IP Address Filtering .....................................................................................................50
4.8.3. MAC Filtering..............................................................................................................51
4.8.4. Domain Filtering..........................................................................................................52
4.9. STATIC ROUTING....................................................................................................................53
4.10. QOS SETTINGS ......................................................................................................................54
4.11. DYNAMIC DNS......................................................................................................................54
4.12. SYSTEM TOOLS ......................................................................................................................55
4.12.1. FIRMWARE .............................................................................................................................55
4.12.2. TIME SETTINGS......................................................................................................................55
4.12.3. PASSWORD.............................................................................................................................56
4.12.4. WOL .....................................................................................................................................56
4.12.5. SYSTEM LOGS........................................................................................................................56
4.12.6. REMOTE MANAGEMENT ........................................................................................................57
4.12.7. FACTORY DEFAULTS...............................................................................................................57

150Mbps Wireless Broadband Router User Manual
7
4.12.8. REBOOT .................................................................................................................................58
5. TROUBLESHOOTING...............................................................................................................58

150Mbps Wireless Broadband Router User Manual
8
1. Introduction
1.1. Product Overview
The 150Mbps Wireless Broadband Router is dedicated to Small Office/Home Office (SOHO)
Wireless network solution. It is 4 in 1 network device, which combines wireless access point,
firewall, 4-port Switch and the NAT-Router. It provides up to 150Mbps data transmission rate
in 2.4GHz frequency, complies with IEEE 802.11n, IEEE 802.11g and IEEE802.11b and
backwards compatible with all IEEE 802.11n/g/b devices. And the router also supports
wireless LAN up to 128-bit WEP, WPA/WPA2 encryption security. The 150Mbps Wireless
Broadband Router also provides WEB and Remote Management and system log so that
network administrators can manage and monitor the network in real time.
The 150Mbps Wireless Broadband Router also provides a hardware WPS (Wi-Fi protected
setup) button, which helps you setup a secure wireless network in a snap. The button lets you
activate the wireless protection easily.
1.2. Main Features
Comply with IEEE802.11n/g/b, IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
standards
Support MIMO technology with 1 transmit and 1 receive, up to 150Mbps wireless LAN
data transfer rates
Support DHCP Client, PPPoE Client, Static IP, L2TP, PPTP
Support multi-wireless mode: AP, WDS, AP+WDS, repeater, client, etc.
Support static ARP, MAC filtering, IP access control, DNS filter
Support FTP, PPTP and L2TP pass through
Support UPNP (universal plug and play)
Upgradeable firmware for future functions
WPS button can easily setup a secure network
Support WMM
Support data encryption mode: WEP, WPA, WPA2
Support DMZ

150Mbps Wireless Broadband Router User Manual
9
1.3. Supporting Standard and Protocol
IEEE 802.11b/g/n
IEEE 802.11e
IEEE 802.11h
IEEE 802.11k
IEEE 802.11i
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
1.4. Working Environment
Temperature
0° to 40° C (operating)
-40° to 70° C (storage)
Humidity
10% to 90 % non-condensing (operating)
5% to 90% non-condensing (storage)
Power
DC 9V

150Mbps Wireless Broadband Router User Manual
10
2. Hardware Installation
2.1. System Requirement
Minimum Requirements:
Broadband (DSL/Cable) modem and service with Ethernet port
802.11n b/g/n wireless adapter or Ethernet adapter and cable for each computer
Internet Explorer® 5.0, Firefox® 2.0 or Safari® 1.4 or higher
2.2. Panel
Front panel
LED
Status
Meaning
SYS
Flashing
Device is on
Device system activated
WPS
Flashing
WPS activity
WAN
On
WAN connection is active
Flashing
Data transfer
LAN (1 to 4)
On
LAN connection is active
Flashing
Data transfer

150Mbps Wireless Broadband Router User Manual
11
Rear panel
Example of product
2.3. Restore to factory configuration
If the router ever freezes in a setting change process or if you can’t access it because you can’t
remember the IP you have given it or other problem, you may have to utilize the reset button on
the back of the router to put it back to factory settings. You have to press and hole this button
for a few seconds (2-6s) with a pencil when it is working, then release and it will restore
settings to the factory configuration.
The other way to restore factory settings is through the same user interface used in setup.
Click on ‘System management’- ‘Restore’, and click on the ‘Restore’ button.
2.4. Hardware Installation Procedures
The procedures to install the 150Mbps Wireless Broadband Router please refers to the
following picture
Description
Function
PWR
Connect to Power adapter, please don’t use the unknown
power adapter, otherwise your device may be damaged.
LAN 1-4
Connect with computer NIC or Ethernet device
WAN
Internet access
Reset
Restore settings

150Mbps Wireless Broadband Router User Manual
12
Attach one end of an Ethernet cable to your computer’s Ethernet port, and the other end to
one of the LAN ports of your router.
Connect another Ethernet cable from your Cable/DSL modem to the WAN port of your
router.
Connect the single DC output connector of the power adapter to the power jack on the back
of the router and plug the PowerAdapter into an AC outlet.

150Mbps Wireless Broadband Router User Manual
13
3. Login
You can manage the 150Mbps Wireless Broadband Router through the Web browser-based
configuration utility. To configure the device via Web browser, at least one properly configured
computer must be connected to the device via Ethernet or wireless network. The 150Mbps
Wireless Broadband Router is configured with the default IP address of 192.168.1.1 and
subnet mask of 255.255.255.0 and its DHCP server is enabled by default. Before setting up
the Router, make sure your PCs are configured to obtain an IP address automatically from the
Router by the steps below.
3.1. Configure computer
3.1.1. Windows XP
Please follow the steps below to setup your computer:
1. Go to Start Settings Control Panel.
2. Click Network and Internet Connections.
3. Click Network Connections.

150Mbps Wireless Broadband Router User Manual
14
4. Highlight the icon LocalArea Connection, right click your mouse, and click Properties.
5. Highlight Internet Protocol (TCP/IP), and then press Properties button.

150Mbps Wireless Broadband Router User Manual
15
6. Choose Obtain an IP address automatically and Obtain DNS server address automatically,
and then press OK to close the Internet Protocol (TCP/IP) Properties window.
7. Press OK to close the Local Area Connection Properties window.

150Mbps Wireless Broadband Router User Manual
16
3.1.2. Windows Vista
Please follow the steps below to setup your computer:
1. Go to Start Settings Control Panel.
2. Click Network and Sharing Center.
3. Click Manage Network Connections.

150Mbps Wireless Broadband Router User Manual
17
4. Highlight the icon LocalArea Connection, right click your mouse, and click Properties.
5. Highlight Internet Protocol Version 4 (TCP/IP) and then press Properties button.

150Mbps Wireless Broadband Router User Manual
18
6. Choose Obtain an IP address automatically and Obtain DNS server address automatically,
and then press OK to close the Internet Protocol (TCP/IP) Properties window.
