This technical manual contains information for the installation of our range
of Evo System fire and smoke curtains, the manual should only be used by
competent installers of fire and smoke curtains with relevant training and or
experience, in no way should untrained individuals attempt to install this life
critical fire / smoke protection range of products.
Disclaimer
Mechanical
Electrical
Head box
Side guides
Roller and curtain assembly
Bottom bar
Wiring of main control board
Wiring of motor control board
Wiring of auxiliary’s including:
switches, Initial connection procedure Initial tests and
checks, Mains and PSU checks
The installation guide is broken down to two sections Mechanical and Electrical
Installation.
3

Back to contents
Mechanical
Installation
Instructions
4

Back to contents
Mechanical Installation instructions
Prior to mechanical installation
This product should only be installed by competent engineers/ installers.
All risk assessments for the installation should be site specific and carried out
by a competent person prior to installation.
All packaging must be removed with extreme care and no sharp tools should
be used, the fabric is rolled around the roller assembly and will very easily be
damaged.
Check carefully the structural measurements of the opening against the
relevant drawing.
Ensure that all walls surfaces and closing surfaces are suitably fire rated, level
and true.
The opening must be capable of carrying the weight of the complete assembly
of the fire curtain, the weight is indicated on the approved working drawing.
The opening should be equal or greater than the required fire performance of
the product.
Check the kit list is complete and all components are correct.
5

Back to contents
Approved xings for smoke & re curtains
Head Box
Side Guides
1, M6 loose bolt shield anchor with
steel and nylon washer.
Drill size 14mm minimum hole depth
70mm
Embedded depth 55mm
2, Concrete screws
M6 x 80, 100, 120 or 125mm with
steel and nylon washer.
Drill size 6mm minimum depth 10mm
deeper than fixing length.
1, M6 loose bolt shield anchor with
steel and nylon washer.
Drill size 12mm minimum hole depth
55mm
Embedded depth 45mm
2, Concrete screws
M6 x 80, 100, 120 or 125mm with
steel and nylon washer.
Drill size 6mm minimum depth 10mm
deeper than fixing length.
Steel and nylon washers must be used on each xing, steel rst
followed by nylon then the head box or guide, in the event of a re
the nylon washer will melt and leave the xing secure allowing the
head box or guide to expand as required.
Each pre-drilled hole must be utilised and all xings must achieve the
minimum embedded depth into the structure.
Incorrect xing will lead to impeded performance of the curtain in the
event of a re.
Minimum embedded depth of 55mm
Minimum embedded depth of 45mm

Back to contents
Head Box - Drawing ID 01/02
Side Guides - Drawing ID 01/02
• The head box is manufactured from mild steel sheet, which depending on the
length may come in pre-assembled sections. Each part of the head box is
clearly marked inside. All roller support brackets and hood support brackets
must be installed in the pre-drilled locations.
• Position the back cover of the box to the structure in accordance with the
dimensions and fixing detail indicated on the approved drawing. It is important
to use the central anchor point and position each bolt to the extremity of
each slot as the product must expand either side of the anchor point in a fire
situation.
• Check the box housing is level with a spirit level or laser device, mark the fixing
holes and drill for the specified fixing type.
• Lift the box housing and fix to the structure using the fixings and fusible
washers. Carry out a final check to ensure the box housing is level. If the box
housing is not installed level this will result in the fabric travelling sideways
along the roller tube when retracting. This will result in the curtain snagging.
• When smoke seals have been supplied they must be riveted to the head box
using steel rivets into the pre-drilled holes, if the housing has been supplied in
sections. Housings supplied in one section will have the smoke seals factory
fitted.
Now position the back section of the guide to the structure with the top edge
entering into the head box housing by 40mm. Use a spirit level or laser device
and set the guides plumb to the correct dimensions indicated on the working
drawing. Mark the fixing holes at the top of the slots to allow for expansion.
Drill for the specified fixing type.
Fix to the structure using the fixings and fusible washers. If required the guide
must be suitably shimmed to ensure they remain vertical without any twisting.
7

Back to contents
Roller Assembly and Curtain - Drawing ID 03 + 04
Attaching the Bottom Bar - Drawing ID 04 + 06
• Using the correct lifting method (minimum two people) lift the curtain and roller
assembly up to the head box. Install the dummy sliding end into the end plate
cup and secure with the M8 x 40 Allen screw. Push the roller assembly as far
as possible to the non-drive end allowing the dummy end to contract as far as
possible. Now insert the motor drive end (ensure the motor cable is positioned
on top of the shaft) into the end plate cup and secure with an M8 x 40 Allen
screw.
• The box housing should now be drilled for the motor cable to pass through
a stuffing gland, ensure the motor cable cannot snag as the roller operates.
Unwind approximately 300mm of fabric from the roller.
• Now install the head box cover by steel riveting to the end plate returns and
across the front lip. Ensure the fabric remains accessible through the slot in the
head box.
• Pull the remaining fabric from the roller assembly through the gap in the head
box. Ensure the motor cable wires are not touching each other or it will not be
possible to rotate the roller mechanism without force, which in turn will damage
the motor brake assembly. The roller should rotate freely.
• Determine the curtain drop and mark both edges of the curtain at the fully closed
fire-safe position. Using a laser or chalk line, mark the curtain across the full
width from both points.
• Place the angles of the bottom bar back to back with the 40 x 40 angle on the
same side of the curtain as the roller assembly on the marked line. Ensure the
fabric is pulled tight and clamp the angles to the marked line on the fabric. Slide
the bottom bar guide retainers between the 2 angles sandwiching the fabric, the
2 m6 holes in the retainers holes will line up with the holes in the bottom bar. Pull
the fabric flush with the bottom bar and push the two piece double cap rivets (6
at each side) through the retainers and fabric. Place a hammer on one side of the
rivet and hit the other side crushing the rivets securely together.
8

Back to contents
Attaching the bottom bar cont.
• All 6 rivets must be fitted and secured to prevent the curtain pulling through the
retainers.
• Drill through the fabric with a 6.5mm drill bit (the pre drilled bottom bar holes
should align and you should only be drilling the fabric) the bottom bar has been
factory assembled and no cutting or drilling is required. If the holes do not align
then you have not arranged the angles correctly. The rail at either end when
assembled has two 6.5mm holes drilled at 50mm and 100mm from each end. the
front and rear angle joints never align and must be fully overlapped to maintain
the rails strength. insert the M6 x 16 screw into the holes with the screwhead
on the 40 x 20 angle side roller side of the bottom bar. Attach the nyloc nut on
the opposite side and tighten accordingly. Proceed all the way along the bottom
bar until the bolts have been installed. If the screws are fitted the opposite way
round the nuts will hit the headbox and prevent the bottom bar pulling tight and
closing flush with the headbox.
• Carefully trim the excess material which is below the now assembled bottom
bar with a Stanley knife or similar, take extreme care as not to slip and cut the
curtain above the bottom bar.
Nylon cover caps are provided for the nyloc nuts.
• Curtains require a minimum bottom bar weight of 10kg per motor to close under
gravity failsafe. this allows for friction against the smoke seals and the fabric
rubbing on the guide surfaces.
• For assemblies where multi rollers are used the bottom bar is one continuous rail.
The curtain fabrics are overlapped. Where the fabrics overlap it is essential that
the fabric is pulled tight prior to the angles being secured together which will
provide a good seal to the overlapping fabrics. The fabrics should overlap true
and plum.
• Wide roller assemblies will deflect due to their own weight and curtain assembly
load. This deflection may cause the bottom bar to sag when fully retracted. To
overcome this remove the bottom bar screws in the middle of the rail and pull
the fabric through to replicate the sag at the head box. Re drill the curtain fabric
and replace the fixings accordingly. Do not over exaggerate this and check when
the bottom bar is in its fire safe position it still seals along the closing surface. If
this does not rectify the issue then packers can be inserted between the roller
tube and the fabric at the points of the sag. This will increase the circumference
of the roll and give an increase in the travel distance, off cuts of the fabric
should be used for the packers. Start small and slowly increase to achieve the
required retract position and the bottom bar pulls up flush with the head box, It
is possible to use both methods.

Back to contents
Guide fronts - Drawing ID 07
MCC and MCB Fixing
• Lift the guide front onto the rear part of the guide channel and align with the
M6 studs, secure with M6 nuts provided, Nylon cover caps are provided for
the nuts. if the guides are slightly pinched or overfolded then gently prise the
guides open leaving a true gap of between 8 mm to 10mm from top to bottom
between the internal running faces of the guides
• The main control panel should now be securely fixed to the building structure,
the dimensions of the metal casing is
Width 39cm
Height 36cm
Depth 11cm
The panel should be installed allowing sufficient air flow of approx 10cm
around the panel and the louvres must not be obstructed.
• The motor control board should be securely fixed to the headbox the
dimensions of the metal casing are
Width 24cm
Height 16cm
Depth 6cm
• The mechanical install is now complete and wiring of the Main control Board
and Motor control board should now be carried out in accordance with the
wiring instructions provided in this manual.
10

CENTRAL ANCHOR FIXING
FIXINGS TO THE OUTERMOST END OF THE
SLOTS TO ALLOW FOR EXPANSION REAR BOX SECTION
GUIDE ENTERS BOX
HOUSING BY 40mm
FIXINGS TO THE TOP OF THE SLOTS
TO ALLOW FOR EXPANSION
HEADBOX AND GUIDE FIXING DETAIL
N.B - ALL FIXINGS PROVIDED
F.F.L
REAR GUIDE SECTION
All drawings must not be reproduced or copied without permission from A1S
A1 Shutters Limited
Jackson Works
Raikes Lane Industrial Estate Bolton BL3 2NH
Telephone [phone]
DRAWING ID - 01 / 02
11

SHAFT TO ENDPLATE INSTALLATION
SECTION A - A TOP VIEW
M8 x 40mm BOLT
CUP
INSERT M8 BOLT
THROUGH CUP
AND SHAFT
SHAFT
BARREL
A A
All drawings must not be reproduced or copied without permission from A1S
A1 Shutters Limited
Jackson Works
Raikes Lane Industrial Estate Bolton BL3 2NH
Telephone [phone]
DRAWING ID - 03
12

CORRECT INSTALLATION IN- CORRECT INSTALLATION
20 x 40mm
ANGLE
40 x 40mm
ANGLE
GUIDE ALIGNED
WITH HEADBOX
GUIDE ENTERS HEADBOX
BY 40mm
FABRIC TO
RUN DOWN
THE CENTRE
OF THE GUIDE
ROLLER SIDE OF
THE HEADBOX
All drawings must not be reproduced or copied without permission from A1S
A1 Shutters Limited
Jackson Works
Raikes Lane Industrial Estate Bolton BL3 2NH
Telephone [phone]
DRAWING ID - 04
13

HEADBOX FRONT COVER INSTALLATION
SECTION A - A FRONT VIEW
FRONT
COVER
END PLATE
REAR
COVER A
A
DRILL & RIVET FRONT
COVER TO REAR COVER -
DRILL & RIVET FRONT
COVER TO END PLATE - 2
1
2 2
2
1
All drawings must not be reproduced or copied without permission from A1S
A1 Shutters Limited
Jackson Works
Raikes Lane Industrial Estate Bolton BL3 2NH
Telephone [phone]
DRAWING ID - 05
14

BOTTOM RAIL FIXING DETAIL
BOTTOM BAR REAR
40 x 20mm ANGLE
CURTAIN FABRIC
BOTTOM BAR GUIDE RETAINERS
2 No. MACHINE SCREWS
C/W NUTS
N.B - ALL FIXINGS PROVIDED
6 No. DOUBLE
CAP RIVETS
SECTION THROUGH THE BOTTOM
RAIL ASSEMBLY
All drawings must not be reproduced or copied without permission from A1S
A1 Shutters Limited
Jackson Works
Raikes Lane Industrial Estate Bolton BL3 2NH
Telephone [phone]
DRAWING ID - 06
15

GUIDE INSTALLATION
REAR GUIDE SECTION FRONT GUIDE SECTION COMPLETE GUIDE
THREADED
STUD - M6
PRE-DRILLED
M6 HOLE
M6 NUT AND
NYLON CAP
All drawings must not be reproduced or copied without permission from A1S
A1 Shutters Limited
Jackson Works
Raikes Lane Industrial Estate Bolton BL3 2NH
Telephone [phone]
DRAWING ID - 07
16

Back to contents
Control
Panel
Lighting
17

Back to contents
Control Panel Lighting
Normal
Delay
Override
Control panel
malfunction
Alarm signal
activated
Low battery
fault / Power
failure
Green power on
Blue light on
Amber light on
Red light on
Green power on
Red alarm on
Panel beeps
Amber light on
Retracted
Alarm Delay set in
programming
Override activated by
switch during alarm
Control panel fault
Closing or Closed
Open or Closed

Back to contents
• CPM red light on indicates there is a system malfunction on the
panel programming, wiring or PCB failure.
• Delay blue light indicates there is an active alarm signal been
received and the panel is holding the curtains for the programmed
time in the stored settings.
• A Green light Power on indicates the panel has a healthy mains
supply to the PSU.
• Amber light Low battery fault on indicates either there is a mains
failure to the panel or the batteries are below the required
voltage and will require charging, the panel constantly monitors
the battery voltage and will detect when low, once recharged the
light will go out.
If the light does not go out after 2 hours the batteries will require
replacing. If the panel has had no mains supply the batteries will
hold the curtains in the retracted position until the low voltage
close system has been triggered, the curtains will then close in a
controlled decent but will no longer retract until the mains supply
is reinstated. If the batteries have totally depleted the LCD
screen will be blank and both batteries will require replacement.
• Alarm red light on indicates there is an active signal to one of the
panel inputs, this could be the main alarm terminal or either input
1 or input 2, this will not go off until the signal has returned to
normally closed.
• Override amber light on indicates there is an active signal to
one of the panel inputs, this could be the main alarm terminal
or either input 1 or input 2 and the override button has been
pressed, once the curtain has returned to its fire safe position
the light will go out.
19

Back to contents
Motor
Control
Board Lighting
20
