Aaeon SRG-APL User manual

Last Updated: January 27, 2022
SRG-APL
IoT Gateway System
User’s Manual 1st Ed

Preface II
IoT Gateway System SRG-APL
Copyright Notice
This document is copyrighted, 2022. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original manufacturer.
Information provided in this manual is intended to be accurate and reliable. However,
the original manufacturer assumes no responsibility for its use, or for any infringements
upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.

Preface III
IoT Gateway System SRG-APL
Acknowledgements
All other products’ name or trademarks are properties of their respective owners.
Microsoft Windows is a registered trademark of Microsoft Corp.
Intel® is a registered trademark of Intel Corporation
ARM, Cortex, and Cortex-A8 are registered trademarks of Arm Limited (or its
subsidiaries).
ITE is a trademark of Integrated Technology Express, Inc.
IBM and VGA are trademarks of International Business Machines Corporation.
Ubuntu is a registered trademark of Canonical
All other product names or trademarks are properties of their respective owners. No
ownership is implied or assumed for products, names or trademarks not herein listed
by the publisher of this document.

Preface IV
IoT Gateway System SRG-APL
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
SRG-APL
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
IoT Gateway System SRG-APL
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver installation
instructions (if any), to facilitate users in setting up their product.
Users may refer to the product page at AAEON.com for the latest version of this
document.

Preface VI
IoT Gateway System SRG-APL
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. All cables and adapters supplied by AAEON are certified and in accordance with
the material safety laws and regulations of the country of sale. Do not use any
cables or adapters not supplied by AAEON to prevent system malfunction or
fires.
3. Make sure the power source matches the power rating of the device.
4. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
5. Always completely disconnect the power before working on the system’s
hardware.
6. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
7. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
8. Always disconnect this device from any AC supply before cleaning.
9. While cleaning, use a damp cloth instead of liquid or spray detergents.
10. Make sure the device is installed near a power outlet and is easily accessible.
11. Keep this device away from humidity.
12. Place the device on a solid surface during installation to prevent falls
13. Do not cover the openings on the device to ensure optimal heat dissipation.
14. Watch out for high temperatures when the system is running.
15. Do not touch the heat sink or heat spreader when the system is running
16. Never pour any liquid into the openings. This could cause fire or electric shock.

Preface VII
IoT Gateway System SRG-APL
17. As most electronic components are sensitive to static electrical charge, be sure to
ground yourself to prevent static charge when installing the internal components.
Use a grounding wrist strap and contain all electronic components in any
static-shielded containers.
18. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
19. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
IoT Gateway System SRG-APL
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur.
Recycler les batteries usées en accord avec les instructions du fabricant et les directives
gouvernementales de recyclage.

Preface IX
IoT Gateway System SRG-APL
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON System QO4-381 Rev.A0
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯
醚(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
○
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
×
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
电池
×
○
○
○
○
○
本表格依据 SJ/T 11364 的规定编制。
○ ：表示该有毒有害物质在该部件所有均质材料中的含量均在
GB/T 26572标准规定的限量要求以下。
×：表示该有害物质的某一均质材料超出了GB/T 26572的限量要求，然而该
部件
仍符合欧盟指令2011/65/EU 的规范。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、电源为选购品。
三、上述部件物质液晶模块、触控模块仅一体机产品适用。

Preface X
IoT Gateway System SRG-APL
China RoHS Requirement (EN)
Hazardous and Toxic Materials List
AAEON System QO4-381 Rev.A0
Component
Name
Hazardous or Toxic Materials or Elements
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (Cr(VI))
Polybrominat ed biphenyls (PBBs)
Polybrominat ed diphenyl ethers (PBDEs)
PCB and
Components
X
O
O
O
O
O
Wires &
Connectors for
Ext.Connections
X
O
O
O
O
O
Chassis
O
O
O
O
O
O
CPU & RAM
X
O
O
O
O
O
HDD Drive
X
O
O
O
O
O
LCD Module
X
X
O
O
O
O
Optical Drive
X
O
O
O
O
O
Touch Control
Module
X
O
O
O
O
O
PSU
X
O
O
O
O
O
Battery
X
O
O
O
O
O
This form is prepared in compliance with the provisions of SJ/T 11364.
O: The level of toxic or hazardous materials present in this component and its parts is
below the limit specified by GB/T 26572.
X: The level of toxic of hazardous materials present in the component exceed the
limits specified by GB/T 26572, but is still in compliance with EU Directive 2011/65/EU
(RoHS 2).
Notes:
1. The Environment Friendly Use Period indicated by labelling on this product is
applicable only to use under normal conditions.
2. Individual components including the CPU, RAM/memory, HDD, optical drive, and
PSU are optional.
3. LCD Module and Touch Control Module only applies to certain products which
feature these components.

Preface XI
IoT Gateway System SRG-APL
Table of Contents
Chapter 1 - Product Specifications.......................................................................................... 1
1.1 Specifications............................................................................................................ 2
Chapter 2 –Hardware Information ....................................................................................... 5
2.1 Dimensions ............................................................................................................... 6
2.2 I/O Location.............................................................................................................. 7
2.2.1 List of Connectors ................................................................................... 8
2.2.2 Giga LAN Port.......................................................................................... 9
2.3 Wireless Hardware Setup......................................................................................10
2.3.1 Mini Card and M.2 E Key Slot Installation .........................................10
Chapter 3 –Drivers Installation............................................................................................. 13
3.1 Drivers Download and Installation......................................................................14

IOT Gateway System SRG-APL
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
IoT Gateway System SRG-APL
1.1 Specifications
System
Processor
Intel Atom X5-E3940 Processor SoC / Intel
HD 500 Graphics
Memory
Onboard LPDDR4 1866MHz 4GB / 8GB
(Optional)
Storage
eMMC 5.1 32GB / 64GB (Optional)
Real Time Clock
RTC x 1, with 3V CR2032 Lithium battery
Security
—
Indicators
—
Cellular
Mini PCIe Connector x 1
Wireless Lan
M.2 2230 E Key slot x 1
Operating System
Windows 10 IoT Enterprise / Linux
Support Protocol
—

Chapter 1 –Product Specifications 3
IoT Gateway System SRG-APL
I/O
Serial Port
—
Ethernet
Gigabit Ethernet x 2, RJ-45
USB
USB 3.0 x 4, Type A
ADC
—
DI/DO
—
CAN Bus
—
Display
HDMI 1.4 x 1
Power Connector
DC Jack
Debug Port
—
Expansion Slot
SIM card slot x 1
Micro SD slot x 1
Other Interface
Power switch button x 1
Reset switch button x 1
Antenna x 3 (Optional)
Power Supply
Power Requirement
12V DC-In @ 3A-5A 5.5/2.5 mm
Power Consumption
20 W (Full Loading)
MTBF (Hours)
516,789

Chapter 1 –Product Specifications 4
IoT Gateway System SRG-APL
Environmental and Mechanical
Dimension
3.16” x 3.7” x 2.5” (80.28 x 95 x 63.6 mm)
Weight
1.94lb (880g)
Mount Options
Wall Mount / DIN Rail (Optional)
Operation Temperature
32 °F ~ 140 °F (0 °C ~ 60 °C)
Storage Temperature
-40 °F ~ 176 °F (-40 °C ~ 80 °C)
Operation Humidity
10% ~ 95% relative humidity, non-condensing
Vibration
2 Grms @ IEC 60068-2-64, random wave,
5-500 Hz, 1 hr per axis (without USB devices
attached)
Shock
20G peak acceleration (11 msec. Duration,
eMMC, microSD, or SSD) IEC 68-2-27
CE/FCC
CE/FCC (with CE-RED)
Green Product
RoHS

Chapter 1 –Product Specifications 5
IOT Gateway System SRG-APL
Chapter 2
Chapter 2 –Hardware Information

Chapter 2 –Hardware Information 6
IoT Gateway System SRG-APL
2.1 Dimensions

Chapter 2 –Hardware Information 7
IoT Gateway System SRG-APL
2.2 I/O Location

Chapter 2 –Hardware Information 8
IoT Gateway System SRG-APL
2.2.1 List of Connectors
The SRG-APL features several connectors which can be configured for your application.
This section details those connections and their specifications.
Position
Function
1
Giga LAN Port
The standard RJ-45 LAN jack is provided the connection to the Local Area
Network (LAN).
2
USB 3.0 Port
The USB 3.0 type A connector, it could also support usb mass storage.
3
Power Light
Power on will turn on the blue light.
4
HDMI Port
The HDMI 1.4 support output, viewing OS on additional display.
5
DC Power Jack
The gateway could accept DC 12V input.
6
Reset Button
Press the button will reboot the OS.
7
Micro SD Slot
User can increase the storage by insert the micro SD card.
8
Power Switch Button
Press the button long time will force shutdown.
9
Antenna Connector
The Antenna type will be Wi-Fi/Bluetooth/LTE.
10
Micro SIM Slot
User can insert the micro SIM card into the slot when using LTE module on
mini card slot.

Chapter 2 –Hardware Information 9
IoT Gateway System SRG-APL
11
Mini Card Slot
This mini PCIe slot can support LTE module (USB+PCIe signal).
12
M.2 2230 E Key slot
This M.2 E key slot can support Wi-Fi/Bluetooth module (USB+PCIe signal).
2.2.2 Giga LAN Port
LED
Function
Status
Yellow
Active status
ON: LAN link is established.
OFF: LAN link is not established.
Blink: Data received and transmitted.
Orange
/Green
Link Speed status
Green on: 10/100Mbps.
Orange on: 1000Mbps.
