Aaeon FWS-2200 User manual

Network Appliance
FWS-2200
FWS-2200
Desktop
Network Appliance Platform
2.5”SATA HDD, CF SATA Socket
6 LAN Ports
2 USB2.0, 1 COM for Console
1 Mini PCI
FWS-2200 Manual 4th Ed.
April 30, 2014

Network Appliance
FWS-2200
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Network Appliance
FWS-2200
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
Intel®and Atom™are trademarks of Intel®Corporation.
AMI is a trademark of American Megatrends Inc.
CompactFlash™is a trademark of the Compact Flash
Association.
Microsoft Windows®is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their
respective owners.

Network Appliance
FWS-2200
iii
Caution
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du
fabricant et les directives gouvernementales de recyclage.

Network Appliance
FWS-2200
iv
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
FWS-2200
CD-ROM for manual (in PDF format) and drivers
D-sub 9-pin Cable x 1
Rubber Foots
60W Power Adapter
SATA Power Cable x 1
SATA Cable x 1
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
Note:
VGA Cable is an optional accessory. Please purchase those
cables according to the following item numbers.
M0422000020 Ear Bracket
1700160253 VGA Cable

Network Appliance
FWS-2200
v
Contents
Chapter 1 General Information
1.1 Introduction..........................................................1-2
1.2 Features ..............................................................1-3
1.3 Specifications ......................................................1-4
1.4 General System Information ...............................1-7
Chapter 2 Quick Installation Guide
2.1 Safety Precautions..............................................2-2
2.2 Location of Connectors of Main Board................2-3
2.3 Mechanical Drawing of Main Board ....................2-4
2.4 List of Jumpers....................................................2-5
2.5 List of Connectors ...............................................2-5
2.6 Setting Jumpers ..................................................2-7
2.7 CMOS Setting Selection (JP3)............................2-8
2.8 Auto PWRBTN Selection (JP6)...........................2-8
2.9 4-pin ATX Power Connector (CN9).....................2-8
2.10 Front Panel Connector (FP1)............................2-8
2.11 Pin Header (USB2)............................................2-9
2.12 RS-232 Box Header (COM2) ............................2-9
2.13 SATA Connector (SATA 1) ...............................2-9
2.14 CF-SATA Connector (CFD1) ............................2-10
2.15 Software Programmable Button (RSW1)..........2-11
2.16 Analog Display (VGA1) .....................................2-11

Network Appliance
FWS-2200
vi
2.17 Installing the Hard Disk Drive............................2-12
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization .............................3-2
3.2 AMI BIOS Setup..................................................3-3
Chapter 4 Driver Installation
4.1 Installation ...........................................................4-3
Appendix A Programming the Watchdog Timer
A.1 Programming ..................................................A-2
A.2 W83627DHG Watchdog Timer Initial ProgramA-6
Appendix B I/O Information
B.1 I/O Address Map.............................................B-2
B.2 Memory Address Map.....................................B-4
B.3 IRQ Mapping Chart.........................................B-5
B.4 DMA Channel Assignments............................B-8
Appendix C Standard Firewall Platform Setting
C.1 Standard Firewall Platform Setting.................C-2
C.2 Status LED Sample Code...............................C-4
C.3 LAN Bypass Mode Sample Code...................C-7
C.4 Console Redirection .....................................C-11
Appendix D AHCI Settings
D.1 Setting AHCI...................................................D-2

Network Appliance FWS-2200
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Network Appliance FWS-2200
1.1 Introduction
FWS-2200 adopts the Intel®Dual Core Atom™ D525 Processor
and equips with Intel®Atom™ D525 + ICH8M chipset. The system
memory features two 204-pin single channel DDR3 800MHz
SODIMM slots up to 4GB. It deploys six Gigabit Ethernet LAN
ports with one pair LAN bypass function (two pairs bypass function
is optional). FWS-2200 condensed appearance features desktop
form factor that fits nicely into a space-limited environment.
This compact FWS-2200 is equipped with one 2.5” SATA HDD
and and CF-SATA socket. In addition, it offers flexible
expansion with network products and features one Mini-PCI
expansion slot, two USB2.0 ports and one RS-232 console port
on the rear panel. The console port deploys console re-direction
that increases the network security via remote control. All of
these designs provide for a more user-friendly solution.
Chapter 1 General Information 1- 2

Network Appliance FWS-2200
1.2 Features
Desktop platform 6 LAN ports Network Appliance
Onboard Intel®Dual-Core Atom™ D525 processor
Intel®Atom™D525 + ICH8M
Two 204-pin Single Channel DDR3 800MHz SODIMM Up to
4GB
10/100/1000Base-TX Ethernet Port x 6 With One Pair LAN
Bypass Function (Two Pairs Bypass Function Is Optional)
2.5” SATA HDD x 1 and CF-SATA socket
COM for Console x 1, USB2.0 x 2
DC 12V Power Input Requirement
Mini PCI Slot x 1
Chapter 1 General Information 1- 3

Network Appliance FWS-2200
1.3 Specifications
System
Form Factor Desktop 6 LAN ports NetworkAppliance
Processor Onboard Intel®Atom™ D525 processor
System Memory
204-pin single channel DDR3 800MHz
SODIMM slot x 2, up to 4GB
Chipset Intel®Atom™ D525 + ICH8M
Ethernet Intel®82574L controller, Gigabit Ethernet
x 6 with 1 pair LAN bypass function (two
pairs LAN bypass function is optional)
BIOS AMI BIOS
Serial ATA SATA 3.0Gb/s x 1
SSD CF-SATA x 1
Expansion Interface Mini PCI slot x 1
Watchdog Timer System reset: 1~255 steps by software
programming
RTC Internal RTC
Storage 2.5” SATA HDD x 1 and CF-SATA socket
System Fan 4cm ball bearing fan x 2
Front I/O Panel Power LED x 1, Bypass LED x 1 (2 for
optional), Status LED x 1, HDD Active
LED x 1, LAN LED x 12
Rear I/O Panel LAN x 6 (the 3rd and 4th LAN port with
bypass function), USB x 2, DB-9
Chapter 1 General Information 1- 4

Network Appliance FWS-2200
connector x 1, DC power input x 1,
Software programmable button x 1
Color Black
Power Supply 60W AC/DC power adapter
Dimension 10.24”(W) x 7.01”(D) x 1.73”(H) (260mm x
178mm x 44mm)
Power Consumption 29W
Display
Chipset Intel®Atom™ D525 + ICH8M
Graphic Engine Intel®Atom™ D525 integrated GMA 3150
graphic engine
Resolution 2048x1536
Output Interface VGA internal box header
I/O
Serial Port COM x 2 (Internal pin header x 1):
COM1: RS-232
COM2: RS-232 (Box Header)
Keyboard & Mouse Reserved pin header
USB USB2.0 x 4: Dual Type-
A
connector on the
front panel x 2, Pin header x 2 (Internal)
Environment
Operating 32oF~104oF (0oC ~40oC)
Chapter 1 General Information 1- 5

Network Appliance FWS-2200
Temperature
Storage
Temperature
-4oF~104oF (-20oC ~60oC)
Operating Humidity 10%~80% relative humidity,
non-condensing
Storage Humidity 10%~80% @ 40oC, non-condensing
Vibration 0.5g rms/5~500Hz/ operation (2.5” HDD)
1.5g rms/5~500Hz/ non-operation
Shock 10G peak acceleration (11m sec.
duration), operation
20G peak acceleration (11m sec.
duration), non operation
Chapter 1 General Information 1- 6

Network Appliance FWS-2200
Chapter 1 General Information 1- 7
1.4 General System Information

Network Appliance FWS-2200
Chapter2QuickInstallationGuide2-1
Quick
Installation
Guide
Chapter
2

Network Appliance FWS-2200
Chapter 2 Quick Installation Guide 2-2
2.1 Safety Precautions
The installation is intended for technically qualified personnel who
have experience installing and configuring system boards.
The equipment can be installed in a restricted access location (RAL)
only.
A restricted access location is a site location for equipment where
the following criteria apply:
01. Access can only be gained by service persons or by users who
have been trained on the restrictions and the precautions for this
specific site.
02. Access is by means of at least one of the following, special tool,
lock and key, or other means of security, and is controlled by the
authority responsible for the location.
Safety Precautions:
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Network Appliance FWS-2200
Chapter 2 Quick Installation Guide 2-3
2.2 Location of Connectors of Main Board
LEDs on Front Panel of FWS-2200
Connectors on Rear Panel of FWS-2200

Network Appliance FWS-2200
Chapter 2 Quick Installation Guide 2-4
2.3 Mechanical Drawing of Main Board

Network Appliance FWS-2200
Chapter 2 Quick Installation Guide 2-5
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP3 CMOS Setting Selection
JP6 Auto PWRBTN Selection
2.5 List of Connectors
The board has a number of connectors that allow you to configure
your system to suit your application. The table below shows the
function of each board's connectors:
Label Function
SO-DIMM1 DDR3 SOCKET
SO-DIMM2 DDR3 SOCKET
ATX1 4PATX POWER SUPPLY INPUT
CN6 3P FAN
CN14 KB/MS
COM1 COM PORT
COM2 COM PORT
VGA1 Analog Display
USB1 USB 2.0 *2
USB2 USB 2.0 *2
FP1 Front Panel Pin Header

Network Appliance FWS-2200
Chapter 2 Quick Installation Guide 2-6
MPCI1 Mini PCI Slot
SATA1 SATA INTERFACE
CN2 SATA POWER
SYSFAN1 4-PIN Fan Connector
SYSFAN2 4-PIN Fan Connector
CPUFAN1 4-PIN Fan Connector
GPIO1 Digital I/O
CFD1 CF-SATA CARD SOCKET
LLED1 LAN LED Pin Header
BPLED1 Bypass LED Pin Header
PSW1 Power On/Off Switch
RSW1 Software Programmable Button
