A&M STF XP T3 Assembly instructions

Service
STF XP T3
BTE instruments utilize electrostatic sensitive devices
(ESD) which are very sensitive to static charges and
may be destroyed by such charges. All work on open
hearing instruments therefore is recommended at
workplaces according to ESD regulations to prevent
the accumulation of static charges.
Tools
Tools usually used for servicing and repairing hearing
instruments.
Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
Page:
1/9 © Sivantos GmbH. All rights reserved.
STF XP T3
10941683 beige
10941684 grey
10956433 beige - demo

Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Order No. Description
Page:
2/9
STF XP T3
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.
Instrument
10959939 SERV PACK PUNCH TAILOR
10940057 SERV EARHOOK H3410
10942811 SERV HSG SET STF XP BG
10942812 SERV HSG SET STF XP GR
10600047 TOOL REMOVAL H2770 BLU

Page:
3/9
STF XP T3
Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.

Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Order No. Description
Page:
4/9
STF XP T3
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.
Amplifier
10942574 SERV NT BASE STF XP T3
Accessories
10420865 DOUBLETIP REFILL 10/12MM NEUTRAL
10420863 DOUBLETIP REFILL 8/10MM NEUT 1
10937494 ACCESSORY COMFORT COUPLING SET
10674683 INDICATOR CLIP SET
10940334 SERV EARHOOK SMALL H3420
10939964 SERV AXLE SET H3420 TITAN

Page:
5/9
STF XP T3
Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.
Service Instructions
Whenever the instrument housing is opened or exchanged, it is important to follow these instructions when
assembling the instrument.
Required tools:
Tool Removal (order number: 10600047), tweezers
1. There shall be a gap between the receiver box and the frame wing.
2. To achieve this, adjust the receiver assembly as shown in Fig. 1.
For a correct result, refer to Fig. 2 and 3. For an incorrect result (no gap) refer to Fig. 4.
.
Fig. 1
Fig. 2 Fig. 3
Fig. 4:

Page:
6/9
STF XP T3
Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.
3. The rear side of the NT base shall assemble into the bottom housing. Use the rib at the bottom housing
and a slot at the frame as a reference point to insert the NT base.
Fig. 5
4. The NT base shall align with the rib on the bottom housing as shown in Fig. 6 and 7.
Fig. 6 Fig. 7
5. The rear side of the NT base (shown with no. 1 in the Fig. 8 and 9) shall align according to step 4 and
5 before pushing down the screw-on-connector into the bottom housing (shown with no. 2 in Fig. 8
and 9).
Fig. 8 Fig. 9

Page:
7/9
STF XP T3
Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.
6. Push down the rocker switch to ensure that the NT base is fully seated in the bottom housing as shown
in Fig .10.
Fig. 10
7. The push button shall assemble into the top housing according to the correct orientation (reference
point in red circle in Fig. 11). There are two holes and the push button seal as a guidance (shown in
Fig. 12 to 14)
Fig. 11 Fig. 12
Fig. 13 Fig. 14

Page:
8/9
STF XP T3
Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.
8. Assemble the top housing into the bottom housing and the NT base according to the sequence as
shown in Fig. 15.
Fig. 15
9. Assemble the battery door.
10. Assemble the axle pins according to the sequence as shown in Fig. 16.
Fig. 16
11. Assemble the ear hook. Note the correct thread before starting to turn the ear hook.
Fig. 17

Page:
9/9
STF XP T3
Legal Manufacturer http://www.am-hearing.com
Sivantos GmbH
Henri-Dunant-Strasse 100
91058 Erlangen, Germany
Reference number:
D00158336
Replaces edition:
2016-10-06
Edition:
2018-10-29
© Sivantos GmbH. All rights reserved.
12. The ear hook shall touch the frame (Fig. 18) and the ear hook rib shall not be damaged (Fig. 19).
Fig. 18 Fig. 19
