The Apex
Multifuel Stove
Operating & Installation Manual
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rev 3
2004
Part No: AFS1130

Congratulations on your choice of an Aarrow Stove.
More than 20 years experience has been put into the development of
the Apex to ensure ultimate performance and years of
trouble free enjoyment.
Every detail on the fire has been carefully engineered and designed
which is why we are so confident in the reliability of our product.
Should you have any questions about our Apex Stoves that are not
covered in this manual, please contact the Aarrow dealer in your
area, or call our Technical support department on
01308 427234
© COPYRIGHT 2003
Arada Ltd
This booklet has copyright & may not be
copied in whole or part or be used for any
purpose other than that for which it is
supplied without express written consent
from Arada Ltd.

INTRODUCTION Page
Safety Notices 5
The Principle of the Fire 5
Check List 6
Technical Data 7
OPERATING INSTRUCTIONS
Firebox Linings and Throat Plate Removal 8
Airwash System 8
Multi-Purpose Operating Tool 9
Riddling 9
Fire Door Glass 9
Fuel Types 11
Lighting The Fire 11/12
Overnight Burning 12
Ash Removal 13
Over-Firing 13
Cleaning 13
Annual Maintenance 14
INSTALLATION Page
General Precautions 15
Handling 15
Hearth 15
Combustible Materials 15
Firebox Liner Panels 16
Throat Plate Inspection 16
Fitting the Optional Floor Fixing Kit 16
Assembling the Multifuel Grate 17
Flues & Chimneys 18-21
Add In Boilers/Water Connection 22-23
Final Check List 24
Notes 25-26
Parts List 27-29
GUARANTEE
Guarantee 30
Customer Registration 30
SERVICE RECORD
Service Record 31
Final Factory Check List 32
3
CONTENTS

WARNING
TO ALL MULTIFUEL USERS
PETROLEUM COKE
SOME OF WHOSE BRAND NAMES ARE
"CALCO", "PETROCOKE" OR "WONDERCO"
MUST NOT BE BURNED IN THIS APPLIANCE
TO USE THESE FUELS WILL INVALIDATE THE
APPLIANCE GUARANTEE
www.solidfuel.co.uk
IF IN DOUBT CONTACT THE SOLID FUEL ASSOCIATION
TELEPHONE NUMBER 0800 600 000
THE USE OF SPARE PARTS OTHER THAN THOSE SUPPLIED
BY ARADA LTD WILL INVALIDATE THE
APPLIANCE GUARANTEE.
4Apex Multifuel Stoves

Apex Multifuel Stoves 5
INTRODUCTION
SAFETY
A fireguard conforming to BS 8423: 2002 should
be used in the presence of children and old/or
infirm people. If the appliance is used with the fire
door open, a spark guard conforming to BS 3248
should be fitted.
Do not use aerosol sprays or any other flame
near the appliance under fire.
Do not fit an extractor fan in the same room as
the appliance.
Fire cement is caustic, hand and eye protection
should always be worn, prolonged contact with
the skin should be avoided.
Arada Ltd will not be responsible for any conse-
quential or incidental loss or injury however
caused.
Before continuing any further with the installation
of this appliance please read the following guide to
manual handling.
•Always obtain assistance when lifting the
appliance.
•When lifting always keep your back straight. Bend
your legs not your back.
•Avoid twisting at the waist. It is better to
reposition your feet.
•Avoid upper body/top heavy bending. Do not
lean forwards or sideways when handling the fire.
•Always grip with the palms of your hands.Do not
use fingertips for support.
•Always keep the stove as close to the body as
possible. This will minimise the cantilever action.
•Use gloves to provide additional grip.
THE PRINCIPLE OF THE FIRE
Your Aarrow Fire is built to the highest standard of
craftsmanship using the best materials and the most
modern equipment available. It is a highly efficient
and sophisticated piece of machinery and when
properly installed and operated it should provide a
lifetime of heating satisfaction.
Safety is the most important consideration when
installing your fire. If not properly installed and
operated a house fire may result. Installation must
comply with the Building Regulations and conform
to all relevant fire safety standards.
Aarrow Fires produce a variety of appliances
ranging from units, which are traditional in style to
stoves which are modern in appearance, all
bristling with "High Tech" features.
Model types include simple room heaters,
convectors, integral boiler models and inset units.
Your Aarrow Fire is constructed from either single
or twin wall steel strengthened where necessary.
Cast iron is used where appropriate for long life.
All fire doors are fitted with special high
temperature ceramic glass panels through which
the fire can be viewed.
Multifuel stoves are fitted with a cast iron grate to
give full multifuel facility and positive de-ashing.
All models except integral boiler models are lined
with firebricks or heat reflective panels which
ensure complete combustion and provide a good
heat store to even out fluctuations in burning.
An internal throat plate produces turbulence to
encourage secondary combustion and directs the
flue gas around the whole upper firebox before
allowing it to escape up the chimney.
On multifuel appliances the primary air for burning
enters the ash pit chamber beneath the grate,
controlled by the air inlet mechanism.
Aarrow Fires are also fitted with an "air wash" so
called because it provides a curtain of high speed
preheated air behind the glass to help keep it clean
and to provide secondary air/over draught.
The provision of two inlets on all multifuel stoves
gives a wide range of primary air/secondary air,
under draught/over draught combinations. The
optimum settings will only be established by
experience in firing the appliance, and will depend
on type of fuel, the position of the appliance in the
house, condition of chimney etc.

Inside the appliance you should find the following:
6Acorn Multifuel Stoves
CHECK LIST
Part Description
&Visual Aid
(not to scale)
Apex
Multifuel
1. Grate bars
7
2. Fuel retainers
2
3. Throat plate
1
4. Flue spigot
1(5”)
5. Hot plate
1(5”)
6. Ash pan
1
7. Operating tool
1
8. Rear liners
2
9. Side liners
2
10. Fire door
handle 1
11. Instructions
1
Part No.
AFS001
AFS1012
AFS1102
AFS009
AFS1108
AFS008
AFS1103
AFS010
AFS1106
AFS204
AFS1130

Apex Multifuel Stoves 7
TECHNICAL DATA
Room Min/Max
Room Heater Only Output (kW) 1 - 7 kW
TECHNICAL DATA
Room Heater with Domestic Hot
Water with add in boiler type 0
Max Output to Room (kW)
Max Output to Water (kW)
5 kW
2 kW
Height (mm) 550
Width (mm) 447
Depth (mm) 362
Height to Centre of the Rear
Flue (mm) 432.5
Depth from Back to Centre of
Flue (mm) 115
Flue Diameter 127mm
(5”)
Weight unpacked
packed
55kg
60 kg
Apex
Multifuel

FIREBOX LININGS & THROAT
PLATE
The Apex Multifuel stoves firebox has reflective
liners to the sides and rear and a specially shaped
throat plate which sits on the liners. If these are not
in place please refer to page 16 to install these.
MULTIFUEL GRATE
The Aarrow Multifuel grate comprises of a series of
reciprocating cast iron bars seated on a pivoted
"comb". These should come fitted in your stove, if
not please refer to page 17 for fitting and operation
and also operating instructions on fuels for correct
settings of the grate.
AIR INLET CONTROLS
Apex multifuel stoves have two air inlets:
•The air wash system (so called because its
pre-heated high speed air washes across the inner
face of the door glass, keeping it clear), which
provides over draught, and
•The lower set of holes; the primary air inlet
providing under draught to the base of the fire
chamber through controls on the bottom of the
stove door.
PRIMARY AIR FOR MULTIFUEL
Air enters the appliance through the control on the
bottom of the fire door. The Aarrow Apex has a
single control knob which slides left to right.
Sliding the knob to the right will increase the
amount of air intake to the stove. To decrease push
knob to the left.
AARROW AIRWASH SYSTEM
The air wash has an internal sliding plate with slots,
housed in a cover plate, and is located above the fire
door. Sliding the control knob to the right as far as it
will go achieves the fully open position. Sliding it to
the left will shut off the air inlet slots As shown in
figures 1 and 2.
Fig. 1 Fully Closed Fig. 2 Fully Open
Even when all the slots are completely shut a
"bleed" of secondary air will be maintained
ensuring that inflammable gases are burnt off.
DISASSEMBLE AIRWASH
The Apex air wash may be disassembled for
cleaning or adjustment. To achieve this, the
following procedure should be followed:
This should only be carried out when the fire is cold
and unlit.
•Support Air Wash cover with one hand.
•Move cover up by smartly tapping the bottom with
a hammer. (Fig. 3)
Remove assembly from appliance.
•Clean and/or adjust.
•Refit using reverse procedure.
Fig. 3
8Apex Multifuel Stoves
OPERATING INSTRUCTIONS

MULTI - PURPOSE OPERATING
TOOL
Your Aarrow fire comes with a multi-purpose tool,
which is used for, riddling and setting the multifuel
grate position and for emptying the ash pan. (Fig. 4)
Fig. 4
RIDDLING
Use the operating tool for setting the grate in the
coal burning position or the wood burning position.
This means that effective de-ashing (see page 13)
takes place, and also allows the grate to be set in the
coal burning or wood burning position, as
indicated on the right hand side of the appliance.
REMOVING FIRE DOOR
•The door should be removed from the stove so that
replacing the glass can be carried out on a
workbench or similar level surface. This should be
done when the appliance is cold.
Remove the fire door as follows
•Support the fire door in a slightly opened position
and loosen the four screws holding the fire door and
hinge covers in place (fig 5a)
•Remove the hinge covers (fig 5b)
•Continue to remove all four screws and the fire
door.
•To replace the fire door loosely screw the fire door
in place and insert the door hinge covers before
fully tightening screws.
Fig. 5a loosening fire door.
Fig. 5b Removing door hinge covers.
FIRE DOOR GLASS
In the event of the door glass being broken it can
easily be replaced:
•The door should be removed from the stove as
detailed above.
•Unscrew the four screws on the inside of the door
(fig 6a).
Fig. 6a Unscrewing glass clips.
Apex Multifuel Stoves 9
OPERATING INSTRUCTIONS

10 Apex Multifuel Stoves
OPERATING INSTRUCTIONS
•Remove the four glass clips and two retaining
bars (Fig 6b).
Fig. 6b removing glass retaining bars.
•Carefully remove any pieces of broken glass, and
sealing gasket wearing suitable gloves.
•Re-seat the new gasket and glass, ensuring the
sealing gasket is flat and in contact with the glass
(fig 6c)
Fig. 6c Replacing glass.
•Replace the two retaining bars.
•Replace the four glass clips. Do not over-tighten
the screws as damage may occur to the glass.
•Replace the fire door.
