Aarrow Nouveau Manual

Aarrow Fires Ltd
The Fireworks
Bridport
Dorset
DT6 3BE
Great Britain
Tel. [phone]
Fax. [phone]
www.aarrowfires.com
Nouveau Electric Stove
Operating & Installation Manual
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Nouveau Electric Stove
Rev 2
June 2004

Congratulations on your choice of an Aarrow Stove.
More than 20 years experience has been put into the development of
our Nouveau Family to ensure ultimate performance and years of
trouble free enjoyment.
Every detail on the fire has been carefully engineered and designed
which is why we are so confident in the reliability of our product.
Should you have any questions about our Nouveau Stoves that are
not covered in this manual, please contact the Aarrow dealer in
your area, or call our Technical support department on
01308 427234
Flaming Good Fires!
2Nouveau Electric Stove
© COPYRIGHT July 2003
Aarrow Fires Ltd
This booklet has copyright & may not be
copied in whole or part or used for any
purpose other than that for which it is
supplied without express written consent
from Aarrow Fires Ltd.

INSTALLATION
WARNING - THIS APPLIANCE MUST NOT
BE USED IN A BATHROOM.
WARNING - DO NOT USE THIS HEATER
IN THE IMMEDIATE SURROUNDINGS OF
A BATH, A SHOWER OR A SWIMMING
POOL.
WARNING - THIS HEATER MUST NOT BE
LOCATED IMMEDIATELY BELOW A
FIXED SOCKET OUTLET.
WARNING - DO NOT USE THIS HEATER
WITH A PROGRAMMER, TIMER OR ANY
DEVICE THAT SWITCHES THE HEATER
ON AUTOMATICALLY, SINCE A FIRE
RISK EXISTS IF THE HEATER IS
COVERED OR POSITIONED
INCORRECTLY.
UNPACKING AND ASSEMBLY
The feet and necessary fixings are packed with
the heater.
Care should be taken whilst assembling the
feet so as not to damage the painted surface
of the heater.
Note: The high temperature paint acquires
durability by being “cured” in initial use.
During this process the heater will give off
fumes which are non-toxic, but which certain
persons may find an unpleasant or irritant
effect. Ensure that the area is well ventilated
during this time.
• Do not turn the heater upside down
• Lay the heater gently on it’s back.
• The feet are positioned in each corner
of the heater and fixed using the washers
and screws provided.
• Using a No. 2 pozidrive screw-driver
tighten the screws.
POSITIONING YOUR HEATER
Always ensure that the heater is stood on a
firm, level base near to, but not directly
beneath a suitable mains supply socket.
Ensure that curtains and furniture are not
positioned close to the chosen position, as this
would create a potential fire hazard.
The doors of this heater are made from cast
iron and are therefore quite heavy. When
moving into position please take this into
account.
SAFETY WARNINGS
FOLLOW these instructions carefully.
Never cover or obstruct in any way the heat
slots at the back of the heater.
The heater carries a warning ‘DO NOT
COVER’ to alert the user to the risk of
overheating that exists if the heater is
accidentally covered.
The casing of this heater is designed to get
HOT. Care should be taken not to touch the
fire during operation.
It is recommended that a fire guard is provided
when the room is used by the elderly, infirm or
young persons.
Nouveau Electric Stove 3
INSTALLATION

USING THE HEATER
Switching on your heater
• Ensure before connecting to the mains, that
all the switches are in the OFF position.
Located on the right hand side of the heater you
will find the switches to operate the fire.
OFF ECONOMY FLAME
ON 1kW 2kW
(A) (B) (C)
The first switch ‘A (as indicated in the diagram
above), switches on the fire and operates the
flame effect. If you only require the flame
effect with no heat, ensure switch ‘B’ is in the
centre position and switch ‘C’ is in the flame
position.
• For Economy setting- Switch B to ECONOMY.
Leave C to FLAME. You will hear the fan running
at a lower speed and will feel a low heat coming
from the grille.
For 1kW setting
• Switch (B) down to 1kW, leave ‘C’ set to
flame. You will hear the fan speed up and feel
an increased amount of heat coming from the
grille.
For 2kW setting
• Leave ‘B’ set at 1kW and switch ‘C’ +1kW.
Again you will continue to hear the fan and feel
more heat from the grille.
Note: Switches ‘B’ and ‘C’ will not operate
without switch ‘A’ being on.
THERMOSTAT OPERATION
To set the room temperature, turn the knob
fully clockwise to the ‘MAX’ position.
When the room is at the desired temperature,
turn the knob slowly towards the ‘MIN’
position until the thermostat clicks. The heater
will now maintain the selected temperature.
MAINTENANCE
WARNING - BEFORE UNDERTAKING
ANY MAINTENANCE OR CLEANING,
DISCONNECT FROM THE POWER
SUPPLY.
CARE
Do not use water, detergents, abrasive cleaning
powder or polish of any kind on the body of the
heater. Lightly brush with a medium dry brush.
TROUBLESHOOTING
No Heat or Light
• Check heater is plugged in and switched on at the
mains.
• Check the switches are correctly set.
• Check the 13A fuse in the plug. Replace if
necessary.
Light but no Heat
• The thermostatic safety cut-out has operated. This
will re-set after a short period of time, when the
fire cools.
• Ensure the air supply and venting are not
restricted.
• The thermostat may have cut out or maybe set to
high for the room temperature. Please refer to the
‘thermostat operation’ paragraph in these
instructions.
• If still blowing cold air, unplug the heater and
phone our helpline.
No Flame-effect
• Unplug the heater and phone our helpline.
Noise from the fans
• Unfortunately there is always some noise from the
fans, we have done our utmost to reduce this but
they will never be completely silent.
4Nouveau Electric Stove
OPERATING

Nouveau Electric Stove 5
GUARANTEE
Your Nouveau Electric stove carries a guarantee against defects of manufacture and faulty
workmanship for a period of one year from the date of purchase.
However, should you have any problems with your heater please contact your Aarrow stockist
who will have the knowledge and facilities to help you.
This Guarantee only applies in the United Kingdom.
Aarrow Fires Ltd will not be responsible for any consequential or incidental loss, damage, or
injury however caused.
USE OF SPARE PARTS OTHER THAN THOSE SUPPLIED BY AARROW WILL
INVALIDATE THE APPLIANCE WARRANTY.
All Guarantee periods commence on the date of purchase and are non-transferable.
Our Guarantee is offered as an addition to your statutory rights.
Guarantee applicable to original purchaser only. Not transferable.
This installation and operating manual gives sufficient details to enable the appliance to be
installed and maintained. If further information is required, our you local dealer will be pleased to
help.
Please telephone [phone] (local rates apply)
When you contact them, they will need to know :
1. Your name, address, post code and telephone number.
2. Date of purchase and supplier details
3. Name of installer
4. Stove serial number
5. Clear and concise details of the fault.
Please complete the following for you own records
Date of Purchase.............................Model..........................Serial Number.................................
Name and Address of Supplier.........................................................................................................
.........................................................................................................................................................
.........................................................................................................................................................
Name and Address of Installer.........................................................................................................
.........................................................................................................................................................
.........................................................................................................................................................

This appliance conforms to:
European Community standard EN60335-2-30:1997
Low Voltage Directive 73/23/EEC
Electromagnetic Compatibility Directive 89/336/EEC
Specification subject to change without prior notice.
Aarrow Fires Limited
The Fireworks, North Mills, Bridport, Dorset, DT6 3BE
www.aarrowfires.com
Tel:[phone]
Fax [phone]
email:[e-mail]
6Nouveau Electric Stove
