ab command iX2 User manual

THANK YOU
On behalf of the entire team at Thane Direct, we appreciate your recent
purchase of the AbCommand™ iX2™ fitness belt.
How the AbCommand™ iX2™ Fitness Belt Works
The AbCommand™ iX2™ fitness belt is not an ordinary massager.
This advanced unit uses gentle electronic stimulation to contract and
release (exercise) your muscles. You will see your own muscles moving.
There are NO vibrations or sounds from the unit at all. The AbCommand™
iX2™ fitness belt uniquely targets front, side and back muscle groups
at the same time for maximum benefits and fastest results. When you
switch the unit on, the LCD display will light up indicating that your
AbCommand™ iX2™ fitness belt is working properly. After you have
selected either the small or the large belt, depending on your needs,
and fit the belt directly onto the area you want to work, you should switch
the unit on. Choose a program and intensity level as described on the
workout pages in this manual.
Monitor, evaluate and share your exercise goals ONLINE at
www.MyAbCommand.com.
Enjoy your AbCommand™ iX2™ fitness belt, and once again thank you!
WARNING
The AbCommand™ iX2™ is extremely safe and simple to use.
We assume no responsibility for any harm caused by misuse of the product.
Follow all instructions in this Instruction Manual before using the Ab
Command™ iX2™ fitness belt. It will give you a better understanding of
how the product works. The Ab Command™ iX2™ fitness belt should be
used as directed with the supplied Nutrition and Cardio Guide. Please
consult your doctor before using the Ab Command™ iX2™ fitness system
or beginning any other fitness program. The instructions presented in
this Instruction Manual are in no way intended to be a substitute for
medical counseling. The Ab Command™ iX2™ fitness belt is intended
for use on healthy muscles only, and is suitable for use only by adults.
Warnings
1. The AbCommand™ iX2™ belt should NOT be used on the heart area.
2. The AbCommand™ iX2™ belt should NOT be used by people with
cardiac pacemaker, defibrillator or other implanted electronic or
metallic devices.
3. The AbCommand™ iX2™ belt should NOT be used by pregnant
women, or during the first 6 weeks after giving birth.
4. The AbCommand™ iX2™ belt should NOT be used by people with
neuromuscular or hemorrhagic diseases.
5. The AbCommand™ iX2™ belt should NOT be used on injured or
otherwise impaired muscles or tissue.
6. The long-term effects of electrical stimulation are unknown.
7. Apply electrodes ONLY to normal, intact, clean skin.
8. DO NOT APPLY STIMULATION:
- Over the carotid sinus nerves.
- Over the neck or mouth. Severe spasms of the laryngeal and
pharyngeal muscles may occur with contractions strong enough to
close the airway and/or cause difficulty in breathing. Stimulation over
the neck can also have an adverse effect on heart rhythm or blood
pressure.
- On the head or transcerebrally (through the head).
- Over swollen, infected, broken or inflamed areas of skin or skin
eruptions (e.g., phlebitis, thrombophlebitis, varicose veins, etc.)
2

- Transthoracically; introduction of electrical current into the heart
may cause rhythm disturbances, which could be fatal.
- Over, or in proximity to, cancerous lesions.
- If you are epileptic.
- After experiencing acute trauma or fracture.
- Following recent surgery.
- If you have a hernia (abdominal or lingual).
- To the frontal, laryngeal or temporal regions of the neck.
9. Never use the AbCommand™ iX2™ belt while driving, operating
machinery or during activities in which involuntary muscle contractions
may endanger the user or others.
10. Do not use the AbCommand™ iX2™ belt in the bath or shower.
11. Persons with suspected heart problems or epilepsy should obtain
appropriate medical advice before using this product.
12. The AbCommand™ iX2™ belt should never be used while sleeping.
13. The AbCommand™ iX2™ belt must be kept out of reach of children.
For purposes of proper hygiene, the electrode pads and belt are for
single person use only.
Precautions
1. The safety of neuromuscular stimulation during pregnancy has not
been established.
2. Place electrodes in accordance with illustrations in this manual.
3. Users should start all sessions in a sitting or prone position (at a
minimum for the first 5 minutes of use).
4. DO NOT use if you have a tendency to hemorrhage (acute trauma or
fracture).
5. DO NOT use following any recent surgical procedure when muscle
contraction may disrupt the healing process.
6. DO NOT use over the menstruating uterus.
7. DO NOT use if you have skin areas that lack normal sensation.
3
Special Population
The AbCommand™ iX2™ belt is suitable for use only on adults.
Adverse Reactions
Skin irritation and burns beneath the electrodes have been reported with
the use of powered muscle stimulators.
4

5
EXERCISE AREAS
VERY IMPORTANT! You MUST apply a conductive medium such as
AbCommand™ iX2™ Conductive Gel to the Conductive Pads on the
inside of the belt. The Conductive Pads MUST make contact with your
skin. The AbCommand™ iX2™ will NOT work through clothing.
Exercise Points - Women
M. Shoulder:
A. Diaphragm/back:
B. Abs/Upper-mid Back:
C. Lower Abs/Lower Back:
D. Waist/Back:
K. Arms:
F. Buttocks:
J. Upper Thigh/Hips:
I. Upper/Outer Back Thigh:
H. Upper Front Thigh:
G. Thigh/Front Knee:
O. Inner Thigh:
N. Calves:
Gives soothing massage and relaxation
to back of the neck and shoulder area.
Upper abdomen, trains the muscles
around the stomach.
Targets the main abdominal muscles.
Also strengthens back muscles which
support posture.
Exercises muscles in lower abdomen
and back.
Targets muscles in the girth and ‘love
handle’ area.
Targets muscles in the upper arms.
Targets muscles in the buttocks - most
important of the posture muscles.
Targets muscles on the outside front
of the upper thighs and hips.
Targets upper legs and buttocks.
Targets the muscles on the upper
front thighs.
Targets both the main thigh muscle
and the muscles in the knee area.
Targets inner thighs.
Targets the calves.
6
DEVICE DESCRIPTION
The AbCommand™ iX2™ belt combines powerful and fun EMS stimulation
with the latest in fitness technology and lets you record, synchronize,
monitor, evaluate and share your training goals and results online.
The AbCommand™ iX2™ belt generates small and gentle electrical
pulses that are delivered inside the belt placed on your skin. The
AbCommand™ iX2™ belt sends a signal to your muscle and causes it to
contract and then relax. These impulses are designed to copy the natural
nerve signal and to obtain efficient, pleasant muscular contractions,
which repeat again and again.
Clinical research trials have been conducted to test the effectiveness of
the AbCommand™ iX2™ device. The performance of the AbCommand™
iX2™ device has been enhanced with 8 pre-programmed modes for easy
use with maximum benefits and results. The programs are specifically
designed for the respective exercise areas.
AbCommand™ iX2™ Standard Kit includes:
1 x Dual Channel Belt – universal
4 x Conductive Pads
1 x Microprocessor
2 x AAA Batteries
1 x 4oz Conductive Gel
1 x USB Cable
1 x Owner’s manual
1 x Nutritional & Cardio Guide
1 x First Use Guide
1 x Carry Bag
Optional Items:
1 x Belt with hook-and-loop
fasteners
1 x Small Pad with
connecting cable

Exercise Points - Men
M. Shoulder/Neck:
A. Diaphragm/Back:
B. Abs/Upper mid Back:
C. Lower Abs/Back:
D. Waist/Back:
K. Bicep/Tricep:
L. Lower Arm:
F. Buttocks:
J. Upper Thigh:
H. Upper Front Thigh:
G. Knee/Front Thigh:
O. Inner Thigh:
N. Calves:
Gives soothing massage and relaxation
to the back of the neck and shoulder.
Upper abdomen, trains the muscles around
the stomach.
Targets the main abdominal muscles.
Also strengthens back muscles which
support posture.
Exercises muscles in lower abdomen
and back.
Targets muscles in the girth, great for
working muscles in the ‘love handle’ area.
Targets these main arm muscles.
Targets the lower arms.
Targets the buttocks - most important of
the posture muscles.
Targets the upper and outer thigh muscles.
Targets the muscles on the upper front
thighs.
Targets both the main thigh muscle and
the muscles in the knee area.
Targets inner thighs.
Targets the calves.
7
BELT PLACEMENT
As everyone is created differently, exact positioning of the AbCommand™
iX2™ belt will vary from person to person. The ideal positioning is
adjacent to the motor nerve. While the device is operating you will be
able to move the AbCommand™ iX2™ belt on the muscle to find the
most effective placement. As you move the belt by small amounts you
will notice contractions becoming either stronger or weaker. The best
position is when the strongest contraction is felt.
Size range for large belt exercise:
Belt Min. Size: ~24 inch = ~61 cm
Belt Max.Size: 46~47 inch = 117~119 cm
Belt resize procedure:
In order to have an optimum fit the belt has a special solution to reduce
the size. This unique technique allows the back channels to stay centred
and generate additional soft pressure of the Conductive Pads against
your skin.
This guarantees maximum comfort and ease of use. Please follow these
instructions to reduce the size of the belt:
We recommend to evenly reduce the size in the front and two back
positions to have the rear channel pads in the center of your back.
1) Open back & fold in belt 2) Back view while wearing belt
8
M
S
L
Folding Line
FOLDED
IN BELT BACK CAN
OPEN
LIKE THIS
1. FOLD IN 2. CLOSE BACK
BACK, FOLD OVER
BELT FOLD IN
M
S
L
Folding Line
FOLDED
IN BELT BACK CAN
OPEN
LIKE THIS
1. FOLD IN 2. CLOSE BACK
BACK, FOLD OVER
BELT FOLD IN

3) Belt closed and folded in
Belt size adjustment: Small(S) / Medium(M) / Large(L)
You can adjust the belt size to S/M/L. According to the size indicators
and the folding line, you can fold the belt into the rear hook-and-loop
flaps symmetrically on both sides for S/M/L size adjustment.
For Large size approx. 39-44” (99-111cm)
For Medium size approx. 32-36” (81-91cm)
For Small size approx. 24-29” (60-74cm)
For Extra-Large (XL) size, please insert strap for belt length extension.
9

L

M
S
BELT PLACEMENT – CONTINUED
The Conductive Pads can be placed in many different positions, thus
allowing more specific targeting of muscle groups.
There is a belt with hook-and-loop fasteners that can be used to
effectively target individual muscle groups. Use of the correct sized belt
is the key to achieving the best possible results.
The diagrams in this booklet are provided as a starting recommendation
only. AbCommand™ iX2™ is a personalised training tool and can be
adapted to suit the individual. Its intended use is for general physical
conditioning. The diagrams shown below use letters to indicate proper
belt placement. If the contractions are not effective, move the belt
around a little until you can feel strong muscle contractions.
Front Back
* “E” has been intentionally omitted from this diagram.
10
A
B
C
H H
M M
KK
D D
LL
I
G G
I
B
O O
M M
KK
D D
LL
J
R R
J
C F
I I
M
S
L
Folding Line
FOLDED
IN BELT BACK CAN
OPEN
LIKE THIS
1. FOLD IN 2. CLOSE BACK
BACK, FOLD OVER
BELT FOLD IN
M
S
L
Folding Line
FOLDED
IN BELT BACK CAN
OPEN
LIKE THIS
1. FOLD IN 2. CLOSE BACK
BACK, FOLD OVER
BELT FOLD IN

ABCOMMANDTM IX2TM FITNESS BELT – LARGE BELT EXERCISES
A. UPPER ABS/ B. MAIN ABS/MIDDLE BACK
UPPER/MIDDLE BACK
B+D. MAIN ABS/MIDDLE BACK C+D. LOWER ABS/BACK
+ LOVE-HANDLES + LOVE-HANDLES
C. LOWER ABS/LOWER BACK F. BUTTOCKS
KEY:
S = Small Belt
L = Large Belt
11
ABCOMMANDTM IX2TM FITNESS BELT – SMALL BELT EXERCISES
Plug the control unit directly into the cable attached to the small exercise
belt. For operation of the control unit, please refer to page 14. If you wish to
stimulate alternative areas, please adjust the target area accordingly.
Please apply a generous dab of AbCommand™ iX2™ Conductive Gel
onto the conductive area of the small belt before placing it onto your
skin.
Please refer to the belt placement guide for small belt exercises
(marked with an S).
G. KNEE/FRONT THIGH H. UPPER FRONT THIGH
I. UPPER/OUTER BACK THIGH J. UPPER THIGH
12
L
L
L L
L
L
L
L L
L
L
L
L L
L
L L
L
L
L
L L
L
L
L
L L
L L
L
S
S
S S
S
S
S S
S S
S
S
S S
S
S

K. ARMS L. LOWER ARMS
M. SHOULDERS N. CALVES
O. INNER THIGH
13
LCD CONTROL PANEL
1. Mode indicator
Indicates stimulation mode
2. Front level indicator
3. Rear level indicator
4. Timer
5. Battery level indicator
6. USB link information
Solid – active connection
7. Target exercise area
Set to record alternative stimulation
area.
8. Key lock
(press and hold M button 3 sec.)
14









CONTROLS
Front channel up
Front channel down
Rear channel up
Rear channel down
On / Off button
Mode button
toggle through:
Mode
Intensity
Timer
Target Area
KEY LOCK TOGGLE ON/OFF:
Press and hold the Mode M button for 3 seconds.




USAGE GUIDE
FIRST OPERATION
1. Open the battery compartment by sliding the
door gently downwards (please see diagram).
2. Insert 2 x AAA batteries by following the polarity
indications in the compartment.
3. Attach the control unit to the belt by simply plugging the cable
into the control unit.
4. Attach the Conductive Pads to the belt by
simply clipping them on using the press
studs.
5. Make sure the unit is switched off, i.e., the LCD display is OFF.
If you accidentally switch the unit on, please press and hold the
ON/OFF button for 3 seconds to switch it off again.
TIP! Adjust the belt to a tight and comfortable fit WITHOUT gel first.
Then apply the gel and wear the belt for your workout.
6. Place the new AbCommand™ iX2™ belt around your stomach and
fasten the belt to a comfortable, but tight fit pursuant to the
directions in the First Use Guide.
7. Take the belt off again, turn it on its
face and place a generous dab of
AbCommand ™ iX2™ Conductive
Gel onto each of the four Conductive
Pads.
16

15

ATTENTION:
• The unit will NOT work without a conductive medium between your
skin and the conductive area of the belt! To guarantee the best results
in the fastest time use ONLY the specially formulated AbCommand™
iX2™ Conductive Gel. This gel is water-based.
• DO NOT USE gels or creams that contain oils! Oil-based gels can
contain ingredients that react badly with the Conductive Pads of your
belt and could reduce the lifespan and efficiency of the belt significantly.
8. We recommend starting with the upper abs, placing the belt above
your belly button.
9. Switch the unit on by pressing the ON/OFF button once.
The LCD display will light up.
COMPUTER SYNCHRONIZATION
The AbCommand™ iX2™ lets you record, synchronize, monitor,
evaluate and share your training goals and results online at
www.MyAbCommand.com.
FIRST SYNCHRONIZATION
The unit should be set up with your computer before your first operation
to ensure data is tracked properly. Please visit www.MyAbCommand.com
for instructions on setting up the device.
Please connect the provided USB cable to your computer (the
AbCommand™ iX2™ works on Microsoft Windows operating system
versions XP, Vista, and 7/8) and follow the instructions to set up your user
account and synchronize the computer time with the AbCommand™
iX2™ system.
The unit will work without synchronization, but data recording will be
disabled.
After the USB connection is established, the USB icon will be lit
indicating the connection is established successfully.
17
Please follow the on-screen instructions on your computer to synchronize
and disconnect the unit.
You can start using and enjoying the full benefits of your unit after
synchronization.
DATA RECORDING
The unit will recordyour training data on the device for later synchronization
and evaluation online.
After synchronization, the data recording is automatic. Please synchronize
your data to your online user account every 7 days or after 3 hours of
use, which ever is earlier.
Data will only be recorded after 10 seconds of continuous operation
without changes to mode or intensity.
CONTROLLER OPERATION
Use the M button to toggle through the menu:
Mode
Intensity
Timer
Target Area
18




MODE SELECTION
After selecting the program in ‘Mode’, the default intensity is set to ‘0’.
Please press the “M” function button to Intensity setting to increase the
intensity.
ATTENTION:
While Modes 1, 2, 3 are repetitive, Modes 4, 5, 6, 7 and 8 consist of a
large variety of different elements found in a training program. During
the program, the length and pulse change continuously. By confusing the
muscle grouping you can increase your benefits. Short pulses are used for
reflex action and long pulses for endurance, toning and contraction. As
a beginner you should always use the mode and intensity that feel most
comfortable to you.
EXERCISE MODES
You can press the UP/DOWN button to select from these 8 modes:
Mode Name Display Description
1Long Contractions Mode 01 Long Contractions
2Short Contractions Mode 02 Very fast pulses
3Karate Chop Mode 03 Exercise with rest periods
4Workout Mode 04 General mixed exercise
with rest periods
5Ab Fever Mode 05 Routine with increasing
intensity
6Fast Blaster Mode 06 Full exercise routine with
mixed elements
7Crunch Craze Mode 07 Full exercise routine with
left and right elements
8Iron Man Mode 08 Pro exercise routine,
mixed mode with left and
right channel as well as
slow and fast elements
19
INTENSITY SELECTION
10 Intensity Levels
Push the UP/DOWN button for each channel to increase or decrease
the intensity level. Level 1 is the first intensity you can feel. The pre-set
value is 0 after choosing your mode in the mode setting. You will notice
a tingling sensation prior to the muscle contracting. Once the muscle
is contracting you will feel pleasant and relaxed. Adjust the intensity
according to your comfort level.
The intensity level has 10 steps per channel. With every push of the UP/
DOWN button you increase/decrease the intensity by one step. You can
set different intensity levels for left and right channel exercises adjusted
to the individual levels you feel most comfortable with.
TIMER SETTING
Timer
Default time is 10 minutes. Press the UP/DOWN button once to increase
or decrease the time increment. Maximum time is 45 minutes.
1) To switch the unit off, press and hold the ON/OFF button for three
seconds.
2)
To turn the sound on/off, press and hold the FUNCTION and ON/
OFF button for 2 seconds. The display will show the “sound off” icon.
TARGET AREA
The default setting is to record the abdominal exercise. You can set the
unit to record different training areas as follows:
Records training session for abdominal area (default setting)
Records training session for arms
Records training session for buns
Records training session for legs
20

AUTO FUNCTIONS
If the conductive area of the belt (the black area on the back of the
exercise pads) does not touch the skin, the intensity can only be set up
to “1”. An alarm will sound after 2 seconds and the unit will automatically
switch off. If the belt is removed during use, the intensity is automatically
reset to “1”. If the belt is not immediately placed back into contact
with the skin, the unit will automatically turn off after 20 seconds.
The AbCommand™ iX2™ unit has an auto-timer. It will automatically
switch off after 10 minutes of use. If you change the exercise mode
during the 10 minute exercise period, the timer will continue to count-
down from the original leftover time.
OTHER FEATURES
1. Safety features
The AbCommand™ iX2™ unit has several built-in safety features:
A) AUTO OFF: After approximately 10 minutes, the AUTO OFF
function will turn off the unit if it is not in use.
B) FAILSAFE: The unit will not work if you are not wearing it, if
there is not enough Conductive Gel present or no load is
connected.
C) ALARM: In case of B) the unit will sound a beeping alarm.
D) KEYLOCK TOGGLE ON/OFF: Press and hold the “M” function
button for 3 seconds.
2. If no muscle contractions are felt, move the belt slowly around
the area that you want to target. Make sure you have enough
AbCommand™ iX2™ Conductive Gel placed on the inside of the
Conductive Pads. Gradually increase the PULSE INTENSITY by pushing
the UP button for each channel in the mode until muscle contraction is
felt.
21
EXERCISE GUIDANCE
During the first week, you should give your muscles time to adjust to their
new work-out. Use the unit for a maximum of 10 minutes per muscle
group, once or twice a day, with a minimum of 4 hours resting time in
between each exercise session.
After the first week, you can use the AbCommand™ iX2™ belt for
a maximum of 30 minutes per muscle group, 3 times a day, with a
minimum of 4 hours resting time between sessions. You should adjust
your exercise routine to your personal fitness level and you should always
ensure that you feel comfortable.
To avoid unnecessary discomfort and ensure maximum performance,
please replace the Conductive Pads after a while, or sooner if their effect
becomes weak or erratic.
MAINTENANCE
The AbCommand™ iX2™ belt is made of quality materials. The only
maintenance required with the AbCommand™ iX2™ is to clean the
Conductive Pads and belt gently from time to time, and to replace the
battery when needed. Please refer to page 23 for detailed cleaning
methods.
The Conductive Pads are a consumable item and can wear with use,
depending on the gel you are using, your own body fluids and how often
you use the belt. A discoloration of the conductive area and a “crumbled
look” after many uses, however, is normal. NEVER BEND the Conductive
Pads! Worn Conductive Pads can reduce the performance of the unit
or cause the belt to feel erratic. Wear and tear is not covered by the
product warranty.
If several people want to share the AbCommand™ iX2™ belt you can
easily detach the computer unit by unsnapping it from the neoprene
center and use it on your own personal belt for hygienic reasons. Just
pull the unit off and put it on a new belt.
The AbCommand™ iX2™ belt is energy efficient. The batteries last for
approximately 30 sessions of ten minutes each. If the output becomes
22

weak or the unit switches off automatically in less than 10 minutes, it is
time to change the batteries (even if the LCD is still lit up).
The micro-control unit is reliably built and uses SMT technology. It is
maintenance-free and will give you many years of trouble free usage.
Cleaning:
- Machine washing and soaking is PROHIBITED.
- Do not wash the belt in fabric softener as this can damage the belt.
- Do not dry clean.
- Do not use bleach.
- Clean accessories with a slightly wet sponge with detergent, and
wipe with a cloth.
- Clean the unit with a cloth soaked in disinfectant (Mercryl type)
diluted in water at 1/10th.
- Clean the electrodes with a mix of water/hypoallergenic
detergent, then rinse thoroughly.
23
FREQUENTLY ASKED QUESTIONS
Q. How does the AbCommand™ iX2™ fitness belt really work?
A. The AbCommand™ iX2™ fitness belt is designed to copy the
messages sent from your brain to the muscle during exercise.
This message causes the muscle to contract and relax.
Q. Can muscles become over-developed or strained when
using this device?
A. No - the principle is the same for general training of muscles
- the more exercise, with suitable periods of rest, the stronger
the muscles become.
Q. Can this device be used for all ages?
A. No. The AbCommand™ iX2™ belt is suitable for use only by adults.
Q. Will I find it uncomfortable?
A. As long as the Conductive Pads are moist and kept firmly
against the skin you will not feel any unpleasantness. At low
intensity you will feel a slight tingling sensation but as the
intensity gets higher you will only feel pleasant contractions.
Start using it on your upper abs first, not directly over the belly
button where most people are most sensitive.
Q. Should the intensity settings be the same for each muscle?
A. Each muscle will respond differently, so intensities will
accordingly be different. Move the belt around to find the right
trigger point that gives you maximum contractions.
Q. Are there any contra-indications to use of the device?
A. Yes - Please carefully read all warnings and precautions on
pages 2-4 of this manual.
Q. I am getting a prickling sensation but no contractions.
A. Move the belt slightly to find the right trigger points that give
maximum contractions and the most pleasant feeling. Try
increasing the intensity. This could also be caused because
either the belt does not have enough Conductive Gel on it
(water-based) or is not tightly placed against the skin. Failing
this, remove the belt and wash the inner surface with a wet
cloth and soapy water to remove body oils.
24

Q. I noticed a redness of the skin after using the device.
Is this a problem?
A. A slight redness of the skin after a session with the
AbCommand™ iX2™ fitness belt is normal. It should
fade quickly. Some redness may also be caused by pressure to
the skin from the stretched belt. You should not be concerned
about this. If the redness is excessive, you may not have used
enough Conductive Gel and/or one or more of the Conductive
Pads may have dried out during a longer session. Try using
more Conductive Gel the next time, replenish it after each
10 minute session and use a lower intensity level.
25
TROUBLE SHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
LCD Display does
not light up at all
- Batteries not
installed
- Batteries installed
incorrectly
- Batteries are dead
- Install batteries
- Check polarity “+” sign
- Replace batteries
LCD Display lights
up, but warning
beep is emitted
(high pitched
tone)
- No skin contact
- Unit not snapped
on belt correctly
- Microprocessor
hang up
- Batteries are low
- Use water-based gel on
Conductive Pads and
place belt directly onto
skin.
- Check that unit is
connected firmly with
all connectors to the belt.
-
Check that all Conductive
Pads are connected
firmly to the belt.
- Choose intensity mode
and increase intensity by
pushing the up buttons
for left and right
channels
- Remove batteries for
1 minute for full RESET
- Change batteries
LCD Display lights
up, but nothing
occurs
- Intensity set to
low level
- Not enough
Conductive Gel
on belt
- Gel used on the
Conductive Pads is
not water-based
- Choose intensity mode
and increase intensity by
pushing the up buttons
for left and right
channels
- Put more water-based
gel between belt and
skin
- Read label on the gel
that you use. Make
sure you find “water”
or “aqua” in the
ingredient list.
26

27
- Belt is positioned
incorrectly
- Belt is worn or has
oil deposits
- Batteries are low
- Move belt around to
locate your trigger
points
- Clean Conductive
Pads or replace
- Change batteries
LCD Display lights
up, but not all
the buttons are
working
- Microprocessor
hang up
- Batteries are low
- Remove batteries for
1 minute for full RESET
- Change batteries
Cannot connect
to Computer
- Device is plugged
into computer but
no connection
- Switch off the device.
Take out batteries and
wait for 10 seconds,
insert batteries, switch on
device and connect
again to computer.
Unit did not
record any data
- Device is
synchronizing, but
no data recorded
- This can happen when
the device time was not
synchronized with the
computer. In this case the
recorded date cannot be
matched with the correct
time and is not displayed
Data record is
shown for wrong
stimulation area
- Data record is
shown for wrong
stimulation area
after
synchronization
- Please refer to the
manual section
“Recording the
Stimulation Area” on
how to set the correct
stimulation area when
using the device.
SYMBOLS
SYMBOL MEANS SYMBOL MEANS
Manufacturer Authorized
representative
in the European
Community
Date of manufacture CAUTION
REF
Catalogue number
SN
SN number
Direct current Type BF Applied
Part
Made in China. Designed and Engineered in Germany.



Company: Red Lemon Incorporation
ADD: 19/F, Nan Dao Commercial Building
368 – 381 Queen’s Road Central, Hong Kong
Tel: [phone]
Fax: [phone]
Web: www.red-lemon.net
Email: inf[email protected]t

28

Thane Direct Canada Inc.
Mississauga, ON L4W 5M6,
Canada
www.thane.ca
Thane International, Inc.
Canton, OH 44718, U.S.A.
www.thane.com
Thane Direct UK Ltd.
London, WC2A 3LH, UK
www.thane.tv
Danoz Direct Pty Ltd
Alexandria, NSW 2015, Australia
www.danozdirect.com.au
Distributed by:
©2014 Red Lemon Incorporation and Thane International, Inc.
MADE IN CHINA
“Thane”, “Ab Command”, “iX2” and associated logos and variations are trademarks or registered trademarks,
in the U.S. and/or other countries, of Thane International, Inc. and/or its subsidiaries.
ABCOMMANDIX2 MNL ENG R0 141224
