AB IPBox Prismcube Ruby Quick start guide

•Twin Tuner HD Satellite Receiver
• HDMI Output (up to 1080p)
• DiSEqC 1.0, 1.1, 1.2, 1.3 (USALS) Compatible
• Dolby Digital audio output (S/PDIF)
• Extended EPG and program reservation on EPG
• Open source media player XBMC with favorite addons
• Mutilingual OSD menu
• Parental Control
• Ethernet intergrated
• Software update Over The Internet (OTI)
• Available in various external colors
Main Features
1

What's included ?
Easy Setup Guide
HDMI cable
Power Adapter RCU
Power Cable
HDD Bracket Screws
2

Front Panel
Display
Standby Displays the current menu and program information.
CI Module slot
Top
Door
open
Smartcard reader slot
One Smartcard slot is provided.
3
3

Rear Panel
HDMI
Connects to TV using a HDMI cable
for both audio and video signals.
Power Adapter Input
Video/Audio Output
RS232
USB
LNB INPUT 1/2
S/PDIF
Connects to a digital audio system
using S/PDIF cable.
Ethernet
Fan
4

Remote Control
TV Power
Navigation Keys
Teletext
Displays the teletext information of
the current channel if the channel
provides teletext.
Archive
Displays the Archive window.
XBMC
Displays the XBMC Media Center.
Subtitle
Displays the subtitle of
the current channel
if the channel provides subtitle.
i (Information)
Displays the channel and program
-me information in live mode
otherwise popup the Context menu.
SOURCE
Controls the outputs of TV.
EPG
Displays the Electronic Program
Guide (EPG) information
if provided.
Num Lock
Enables NUMERIC (0-9) buttons to
enter a TV/Radio channel number
or menu option number.
Channel+/-
Menu
Color Keys
• Red
• Green
• Yellow
• Blue
Volume+/-
Mute
STB Power
5

Remote Control
QWERTY
Unlock to use
Two coin batteries (CR2032) are used
in the remote control.
The estimated battery lifetime is around 1year.
To replace batteries use a screwdriver
to pry open the lid.
NOTE
1 2
6
6

Connecting Cable
1. Connect Satellite Signal Cable
ABIPBOX Prismcube Ruby is a DVB-S2 Twin Tuner
Receiver. For the best use, connect two separate satellite
cables to LNB 1 & 2.
2. Connect ABIPBOX Prismcube Ruby to the TV
One HDMI cable is included in the accessory box. Connect one end of the cable to the HDMI input
of TV. Connect the other end to the HDMI output of ABIPBOX Prismcube Ruby.
7

Connecting Cable
3. Power Up
A power cord and an adapter are provided in the accessory box.
Plug the round end of the adapter power cord into the power input.
AC input condition
• Nominal Voltage Range: 100 – 250 VAC
• Maximum Voltage Range: 90 – 264 VAC
• Nominal Frequency: 50 - 60 Hz
• Maximum Frequency Range: 47 – 63 Hz
NOTE
8

Run First Time Installation
Step 1. Run First Installation
ABIPBOX Prismcube Ruby is a satellite (DVB-S2) twin tuner receiver.
Please run the following installation steps for the basic system configurations.
- Press MENU and go to Installation.
- Select First Installation and press OK.
Step 2. Language Setup
- Choose the menu language and audio language.
* ABIPBOX Prismcube Ruby
supports all major languages
to make sure its best use
in any part of the world.
Select Next and press OK to go to the next step.
9
