AB IPBox TWO User manual

User manual

AB IPBOX
User manual
3
Digital video broadcasting logo.
This logo informs that the receiver conforms to the Digital Video
broadcasting standards
Risk of electric shock - do not open. to open
This notice warns the user not the receiver housing. The housing may be
opened solely by authorized service technicians.
When this crossed-out wheeled bin symbol is attached to a product it means
that the product is consistent with European Directive 2002/96/
EC. Please inform yourself about the local separate collection system for
electrical and electronic products.
Please act according to your local rules and do not dispose of your old
products with your normal household waste. Correct disposal of your old
product helps to prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the European Directive
2006/66/EC,
which cannot be disposed with normal household waste. Please inform
yourself about the local rules on separate collection of batteries because
correct
disposal helps to prevent negative consequences for the
environmental and human health.
Your product is designed and manufactured whit high quality materials and
components, which can be recycled and reused.
The logo informs that the receiver is consistent with terms and conditions of
Directive 2004/108/EC concerning observance by Member States of
provisions regulating electromagnetic compatibility, and to the terms and
conditions of Directives 2006/95/EC concerning observance by Member
States of provisions regulating low voltage electricity and safety with relation
to the handling and operation of electrical equipment.
This product has been designed, tested and manufactured according the
European CE Directive 2014/53/EC.
This logo informs that the receiver is an electrically safe device, provided
that it is used in accordance with the recommendations set forward in the
chapter concerning safety.

AB IPBOX
User manual
4
Caution: Hot surface. Do not touch. The top surface over the internal heat
sink may become hot when operating this product continuously.
Do not touch hot areas, especially around the ‘Hot surface mark’ and the top
panel.
When this logo is attached to a product, it means a financial contribution has
been paid to the associated national recovery and recycling system.
To avoid electric-shock hazards, do not open the housing, refer servicing to
qualified personnel only.
Do not expose the receiver to direct sunlight. Keep it away from the heat
source.
When the abnormal phenomenon occurs, you should cut off the power supply
immediately
Switch the receiver off whenever it remains out of service for an extended
period.
Keep the receiver away from flower vases, tubs, sinks, etc., in order to avoid
damaging the equipment.
Do not block ventilation holes of the receiver so air can circulate freely.
Do not touch the receiver during thunder, since that might create electric-
shock hazards.
It is recommended to cut off power supply.
Be sure to turn the receiver off and disconnect the AC power cord before
cleaning the receiver surface. If the surface is dirty,
wipe clean with a wetted cloth and wrung out thoroughly, then wipe again with
a dry cloth

AB IPBOX
User manual
5
Contents
Contents........................................................................................................................................................................................................... 5
Major features................................................................................................................................................................................................ 6
Packing contents.......................................................................................................................................................................................... 7
Front & Side Panel....................................................................................................................................................................................... 7
Rear panel....................................................................................................................................................................................................... 8
Remote Controller (RCU).......................................................................................................................................................................... 9
First start........................................................................................................................................................................................................10
How to update your system ...................................................................................................................................................................22
Live TV............................................................................................................................................................................................................28
Service Scan................................................................................................................................................................................................29
Terrestrial (DVB-T) *just for model AB IPBox Two Combo .......................................................................................................29
Satellite...........................................................................................................................................................................................................30
Channel List..................................................................................................................................................................................................31
Channel Info.................................................................................................................................................................................................32
More Info........................................................................................................................................................................................................34
PVR..................................................................................................................................................................................................................35
Time Shift.......................................................................................................................................................................................................36
Program Guide............................................................................................................................................................................................37
Add timer........................................................................................................................................................................................................38
Channel Editor.............................................................................................................................................................................................39
Setup ...............................................................................................................................................................................................................42

AB IPBOX
User manual
6
Major features
Support 4K resolution and 4K(10bit) channels
Operating System : Android
Various Dual/Combo Tuner(DVB-S2,T2,C)
Support Android TV Launcher
Support PVR, Timeshift features
USB HDD, USB memory stick, SD card, NAS
Extended EPG and program reservation on EPG
Support H.265 HW decoding
Support Webserver, NAS, samba, UPNP
Support 2.4G Wire Mouse and Key board
Support Closed Caption/Teletext/DVB-Subtitle.
Built-in WIFI /Bluetooth

AB IPBOX
User manual
7
Packing contents
1. Set-Top Box with WIFI
2. Remote Control Unit
3. HDMI cable
4. 2 batteries for RCU ( AAA x 2pcs )
5. Power Adapter
6. Quick Install Guide
Front & Side Panel
1. TFT LCD : To show working status.
2. Power button & IR sensor.
3. Mic input
4. Micro SD : To support Micro SD card.

AB IPBOX
User manual
8
Rear panel
1. Satellite/Terrestrial /Cable Antenna Connection
Connect the cable from Sattelite/Terrestrial/Cable signal
* This device is available in two variants:
with 2x DVB-S2X tuner or 1x DVB-S2X tuner and DVB-C / T2 tuner
2. USB 3.0 / 2.0 port
To support USB 2.0 device like USB Stick, HDD Camera etc.
3. AV Receiver Connection
Use an AV receiver for better audio quality. Connect the receiver’s SPDIF connector to the AV receiver’s
digital audio input connector using an optical audio cable.
4. HDMI Connection
Connect the receiver’s HDMI output connectors to the TV’s HDMI input connector using an HDMI cable.
5. Network Connection
Connect the receiver LAN port to the router using a network cable. For details, please refer to the Network
Settings on.
6. Power Up
A power cord with an adapter is provided in an accessory.
Plug the round end of the adapter power cord into the power input.
7. Smart card reader

AB IPBOX
User manual
9
Remote Controller (RCU)
Programmable Remote part
How to program for TV RCU button (Example : Power button) :
1. Press “TV” key for 5 seconds
2. The light will be turn on and enter the learning mode.
3. Press “TV” key in 10 seconds the light flash.
4. Keep TV remote IR and STB remote IR face to face in 3~5cm,
Press “Power” key on TV remote, the light flashes 3 times and
keep lighting
5. Press any key except the “TV” key to exit the learning status
STB part
1. POWER : To control STB power.
2. Mouse : Change Mouse mode.
3. Apps: To call Android App list
4. Resolution : Change resolution of 720p,1080i,1080p,2160p.
5. Resolution : Change Ratio of 4:3, 16:9
6. Color buttons : to use specific function in App. E.g. in Live TV app yellow
button- Subtitle/Teletext, green button-Sound, red button-Popup Menu
7. Next/Previous file : Move to next or previous file.
8. Stop : Stop to play/record Media
9. Mute : Sound Mute
10. Rewind : Rewind Media
11. Play/Pause : Pause/Play Media
12. Fast Forward : To move Fast forward
13. TV Guide : Electrical program Guide
14. INFO(i) : Information for TV channel
15 Exit : Exit or Back.
16. Menu : to load Menu in Apps
17. Home : Go Android Home
18. Voice : To call Assistant
19. Vol +, - : To increase/decrease volume
20. CH +, - : To change channel
21. Digit 0 ~ 9 and . : to put channel number / IP address etc
22. Back Space : To delete word

AB IPBOX
User manual
10
First start
This document explains how to install the latest software and initial usage after purchasing the product.
We have taken screenshots in English in consider ration of the global character of this manual, and the
captured pictures may be different from the personal environment.
After purchasing the product, connect the TV and AB IPBOX box with the HDMI cable, connect the DC power
adapter to turn on the power.
When you turn on the AB IPBOX box, the following screen appears.
Enter your desired language:
This option is only available in English:
Here
you can set your network, including Wifi settings.

AB IPBOX
User manual
11
The device then checks for available updates.

AB IPBOX
User manual
12
Sign in with your google account.
Enter your password:

AB IPBOX
User manual
13
Use the virtual keyboard to enter your login details.

AB IPBOX
User manual
14
Accept Terms of Service:
Location:

AB IPBOX
User manual
15
Help improve Android performance:
Google Assistant: * Displayed in English only (following 3 images)
Then you have two ways to activate Google Assistant:
1. Press the Google Assistant button on the remote control.
2. Or you can say "OK Google" or "Hey Google".

AB IPBOX
User manual
16

AB IPBOX
User manual
17

AB IPBOX
User manual
18
Now your device is set up and ready to use:
You will then be prompted to pair the BT remote control:
RCU point to the device, press and hold the "i" button until the LED starts flashing.

AB IPBOX
User manual
19

AB IPBOX
User manual
20
Go to the Setting:
The wired Internet connection is recommended for smooth use of this product. The WIFI connection is
explained below.
Start screen of Settings-Network.
If “Settings” option is selected, the following screen is displayed.
