ABB 2106049 User manual

ABB MEASUREMENT & ANALYTICS
Wi-Fi®Antenna kit installation guide
Secure and easy wireless
access for
configuration.
Measurement made ea
sy
Introduction
This document will define the procedures and list the parts required to
install a Wi-Fi antenna.
IMPORTANT NOTE:
To enable and configure Wi-Fi for secure
access
, refer to the XSeriesG5 XFC or XRC user manuals.

2 | WI-FI ANTENNA KIT | 2106123MNAA
Additional information
Additional free publications are available for download at:
www.abb.com/totalflow.
Related documents
Document number
XSeriesG5 XFC/XRC quick start guide
2106124
XSeriesG5 XRC user manual
2106000
XSeriesG5 XFC user manual
2105999
XSeriesG5 board replacement kit guide
2106079
Cyber security
This product is designed to be connected, and communicate
information and data, via a network interface, which should be
connected to a secure network. It is the customer's sole responsibility
to provide and continuously ensure a secure connection between the
product and the customer network or any other network (as the case
may be). The customer shall establish and maintain appropriate
measures (such as, but not limited to, the installation of firewalls,
application of authentication measures, encryption of data, installation
of antivirus programs, etc.) to protect this product, the network, its
system and interfaces against any kind of security breaches,
unauthorized access, interference, intrusion, leakage and/or theft of
data or information. ABB Inc. and its affiliates are not liable for
damages and/or losses related to such security breaches, any
unauthorized access, interference, intrusion, leakage and/or theft of
data or information.
Although ABB provides functionality testing on the products and
updates that it releases, the customer should institute its own testing
program for any product updates or other major system updates (to
include, but not limited to, code changes, configuration file changes,
third party software updates or patches, hardware change out, etc.) to
ensure that the security measures that the customer has implemented
have not been compromised and that system functionality in the
customer's environment is as expected.
IMPORTANT NOTE:
Enable the highest security settings on
Wi
-Fi, Bluetooth, or wired networks to prevent unauthorized
wirele
ss access to the device. Use unique passwords and
change them
periodically.

2106123MNAA | WI-FI ANTENNA KIT | 3
Safety
Observe warning signs on packaging and on the devices, prior to
software configuration.
Safety symbol conventions
The following conventions are used throughout this document to bring
attention to important information:
"NOTICE" hazards are associated with equipment or property damage,
it must be understood that under certain operating conditions,
operating damaged equipment can result in degraded system /
process performance leading to serious or life-threatening injuries.
Therefore, compliance with all "NOTICE" hazards is required at all
times.
WARNING – Bodily injury:This symbol and with the signal
word "WARNING", indicates a potentially dangerous situation.
Failure to observe this safety information will result in death
or severe injury. The text may state the hazard, how to avoid
the hazard, and the result if not followed. The bolt is for
electrical warnings; the exclamation point is for general
warnings.
IMPORTANT NOTE:
This symbol indicates operator tips,
particularly useful information, or important information about the
product or its further uses
.
Potential safety hazards
WARNING – Bodily injury:Make sure no explosive
atmosphere is present before
connecting or disconnecting any
connector or performing maintenance on this unit.
WARNING – Bodily injury:to prevent RF exposure and
damage to equipment remove all power sources before
installing the Antenna Kit.
!
!
!

4 | WI-FI ANTENNA KIT | 2106123MNAA
1Overview
The photo below shows the Wi-Fi antenna kit parts.
Figure 1: Wi-Fi antenna kit parts
Part number 2106049 kit contents
Photo #
Name
Photo #
Name
1
SMA Fittings
5
Surge protector
2
Antenna
6
SMA plug-to-jack adapter
3
Terminator plug
7
Cable assembly
4
FCC IC tag
8
Ground cable
Cable assembly part numbers for enclosures
Kit number
Cable length
Enclosures
2106049 001
24 inches
6410
2106049 002
32 inches
6413, 6713
2106049 003
44 inches
6890
2
6
3
8
4
5
7
1

2106123MNAA | WI-FI ANTENNA KIT | 5
IMPORTANT NOTE:
The cable used in the following procedure is
included in the kit. Specify by number the required length when
ordering the kit.
2Installation procedures
1. Locate the cable clamp on the upper right corner of the board.
Put the straight end of the cable assembly through the cable
clamp.
Figure 2: Cable clamp
2. Attach the right angle SMA fitting of the cable to the board ANT-
1, connector (J42).
Figure 3: Attach at ANT 1

6 | WI-FI ANTENNA KIT | 2106123MNAA
3. Attach the plug-to-jack adapter
to the straight SMA fitting of the
cable.
Figure 4:
Attach the straight
SMA fitting
4. Attach the surge protector
to the plug-to-jack adapter.
Figure 5: Attach the surge
protector
Figur e 4:
Figur e 5: 5. Cut the ground cable to length. Strip ⅜inch of insulation from
the free end.
IMPORTANT NOTE:
The ground cable is attached to the ground
post located near the enclosure’s door. Allow enough length for a
service loop of
approximately 1 inch from the surge protector to
the ground post.
6. Remove the crimp ring terminal from the surge protector. (See
number 1 in the following photo).
Figure 6: Crimp ring terminal
7. Crimp the surge protector terminal ring to the ground cable.
8. Re-attach the crimped terminal with ground cable to the surge
protector.
9. Attach the cable to the surge protector (see below).
Figure 7: Attach the cable
10. Remove the split washer and hex nut from the surge protector.
1

2106123MNAA | WI-FI ANTENNA KIT | 7
11. Identify the enclosure used and the location of the antenna
hole.
IMPORTANT NOTE:
The 8 AH, 13 AH, 16 AH, and 26 AH
b
atteries fit in the 6410 enclosure with the antenna surge
protector installed.
Enclosure number
Antenna hole location
Photo of enclosure
6410
On the Left side of the
enclosure, in the upper
left corner.
6413
On the bottom of the
enclosure, in the back left
corner
6890
2 holes are on the bottom
left of enclosure, both are
usable

8 | WI-FI ANTENNA KIT | 2106123MNAA
Enclosure number
Antenna hole location
Photo of enclosure
6713
2 holes are on the bottom
of the enclosure in the
back left corner. There is
a 3rd hole of same size in
the Back Right Corner.
The Cable assembly is not
long enough to reach that
hole.
12. Remove the black protective plug from the antenna hole in the
enclosure.
13. Install the assembled surge protector into the hole (see below).
Figure 8: Install surge protector
14. Secure the surge protector to the enclosure with the provided
split washer and hex nut.
View of the installed surge protector from the inside of the enclosure
(see below). Enclosure 6413 shown.

2106123MNAA | WI-FI ANTENNA KIT | 9
Figure 9: Inside the enclosure
15. Attach the ground cable to the ground post (see number 2 in
the picture below).
16. Route the cable assembly via mountable cable ties attached to
the enclosure (see number 1, below).
Figure 10: Cable assembly
number
Name
1
Mountable cable ties
2
Ground cable
3
Enclosure ground post
17. Attach the FCC transmission compliance tag to the outside of
the enclosure (see below).
2
3
1

10 | WI-FI ANTENNA KIT | 2106123MNAA
Figure 11: FCC compliance tag
18. Remove the red protective cap from the surge protector.
19. Attach the antenna to the surge protector. Keep the Antenna in
the straight position (see below).
Figure 12: Straight antenna
20. Attach the terminator plug to the board ANT-2, connector (J43).
(see number 1, below).
Figure 13: ANT-2 terminator plug
The Wi-Fi antenna installation is complete.
1

2106123MNAA | WI-FI ANTENNA KIT | 11
This page is intentionally blank.
