Abestorm DecDust 1350 User manual

DecDust 1350/1350IG
AIR FILTRATION SYSTEM
Installation and User Manual
READ AND SAVE THESE INSTRUCTIONS
Abestorm Solutions INC.
Tel: [phone]

SPECIFICATIONS 1
..................................................
WHAT'S IN THE BOX 1
..............................................
DESCRIPTION 1
........................................................
SAFETY RULES 2
.....................................................
ELECTRICAL SAFETY 3
...........................................
WARRANTY EXCLUSIONS 4
....................................
KNOW YOUR AIR FILTRATION SYSTEM 5
...............
ASSEMBLY AND ADJUSTMENTS 5
..........................
OPERATION 8
...........................................................
MAINTENANCE 9
......................................................
CHECK AND TROUBLESHOOT 10
..............................
WIRING DIAGRAM 10
.................................................
LIMITED WARRANTY 11
.............................................
WARRANTY EXCLUSIONS 12
....................................
DIRECTORY

*DecDust 1350IG has the function of removing ozone and belongsto the plasma
model.
(inch)
DecDust 1350 / 13501G x 1 User's Manua x 1
MERV-11 Filter x 4 Screw x 4
Hanging Piece x 4 Expansion Bolt x 4
Nut x 4 Screw Hooks x 4
Hooks x 4 Hanging Chains x 4
Controller x 1 AAA Battery x 2
Your new tool has been engineered and manufactured to Abestorm’s highest
standards for dependability, ease of operation, and operator safety.When properly
cared for, this product will supply you years of rugged,trouble-free performance. Pay
close attention to the rules for safe operation,warnings, and cautions. lf you use your
tool properly and for intended purpose, you will enjoy years of safe, reliable service.
The machine is equipped with four lightweight filtering devices to avoid the
unnecessary increase in weight and volume increase. lt effectively enhances the air
purification capability that allows to the filtration of small particles such as dust,
sawdust, and many more.
1. Connect the dust collector to a standard 115V/60Hz outlet.
2. Refrain from moving the unit during operation.
3. Keep both air inlet and outlet away from the wall or any obstructions for at
east 2 ft.
4. This product can only filter dust particles above 1μm.
HOW IT WORKS
1
WHAT'S IN THE BOX
SPECIFICATIONS
DESCRIPTION

WARNING: To avoid mistakes and serious injury, do not plug in your tool
until the following steps have been read and understood.
WARNING:
1. DO NOT use power tools in the presence of flammable liquids or gases.
2. KEEP BYSTANDERS AT A SAFE DISTANCE from the work area, especially
when the tool is operating. NEVER allow children or pets near the tool.
3.DRESS FOR SAFETY. Do not wear loose clothing, gloves, neckties, or jewelry
(ring, watches, etc.) when operating the tool. lnappropriate clothing and items can
get caught in moving parts and draw you in. ALWAYS wear non-slip footwear and tie
back long hair.
4. WEAR A FACE MASK OR DUST MASK to fight the dust produced by sawing
operations.
Dust generated from certain materials can be hazardous to your
health. Always operate the tool in a well-ventilated area and provide for proper dust
removal. Use dust collection systems whenever possible.
1. ALWAYS remove the power cord plug from the electrical outlet when making
adjustments, changing parts, cleaning, or working on the tool.
2.AVOID ACCIDENTAL START-UPS.Make sure the power switch is in the OFF
position before plugging in the power cord.
3. REMOVE, ADJUSTMENT TOOLS.Always make sure all adjustment tools are
removed from the saw before turning it on.
4. NEVER STAND ON A TOOL. Serious injury could result if the tool tips or is
accidentally hit. DO NOT store anything above or near the tool.
5. Follow instructions for changing accessories.
6. CHECK FOR DAMAGED PARTS. Check for alignment of moving parts,jamning,
breakage, improper mounting, or any other conditions that may affect the tool's
operation. Any part that is damaged should be properlyrepaired or replaced
before use.
7. DO NOT operate the tool if you are under the influence of drugs, alcohol, or
medication that may affect your ability to properly use the tool.
8. USE SAFETY GOGGLES AT ALL TIMES that comply with ANSI Z87.1.Normal
safety glasses only have impact resistant lenses and are not designed for safety.
Wear a face or dust mask when working in a dusty environment. Use ear protection
such as plugs or muffs during extended periods of operation.
9. Do not use the air filter in environments that have poisonous gases, fumes,
noxious smoke, or other chemical risks. This filtration system is only designed to filter
dust, airborne bacteria, small particles, etc.
2
SAFETY RULES

EQUIPMENT MUST BE GROUNDED
WARNING:
WARNING!
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN,grounding provides the
path of least resistance for an electric current and reduces the risk of electric shock.
This tool is equipped with an electric cord that has an equipment grounding
conductor and a grounding plug. The plug MUST be plugged into a matching outlet
that is properly installed and grounded in accordance with ALL local codes and
ordinances.
DO NOT MODIFY THE PLUG PROVIDED.If it will not fit the outlet, have the proper
outlet installed by a licensed electrician.
IMPROPER CONNECTION of the equipment grounding conductor can result in
electric shock. The conductor with the green insulation (with or without yellow
stripes) is the equipment grounding conductor. lf repair or replacement of the
electric cord or plug is necessary, DO NOT connect the equipment grounding
conductor to a live terminal.
CHECK with a licensed electrician or service personnel if you do not combletely
understand the grounding instructions or whether the tool is properly grounded.
This tool is for indoor use only. Do not expose to rain or use in
damp locations.
·Make sure your extension cord is properly wired and in good condition.
·Protect your extension cords from sharp objects, excessive heat, and damp/wet
areas.
·Use a separate electrical circuit for your tools. This circuit must not be less than a
#12 wire and should be protected with a 15 A time-delayed fuse.
·Before connecting the motor to the power line, make sure the switch is in the OFF
position and the electric current is rated the same as the current stamped on the
motor nameplate. Running at a lower voltage will damage the motor.
Please note that the dust remover can only be used with accessories approved by
Abestorm. Using unauthorized accessories or making changes to the machine may
void your warranty. Please contact us for details.
3
ELECTRICAL SAFETY
WARRANTY EXCLUSIONS
DAMAGE DUE TO THE FOLLOWING IS NOT covered under warranty.

1. Acts of Nature- including but not limited to: Flooding, Fire, Water damage,
Hurricane/storm damage.
2.IMPROPER USAGE-Including but not limited to: Misuse, abuse,or tampering
whether intentional or accidental, lmproper installation, lmproper voltage, lmproper
maintenance, Failure to follow instructions.
3.Corrosion,Freezing.
4. Any additional costs due to changes in laws or building codes.
5. Freight charges.
6. Any costs due to lost profit or delay.
7. Damage to property.
8. Cause beyond control.
9. Consumable parts, including but not limited to: Filters,Batteries,Power cords,
Valves,Switches,Rubber parts.
10. Direct, indirect, collateral or inconsequential damages of any kind.
Abestorm total liability, regardless of nature of claim shall not exceed original
purchase price of the product. lf a product or component is replaced while under
warranty, the applicable warranty period shall not be extended beyond the original
warranty time period.
The foregoing shall constitute the total liability of seller in the case of defective
performance of all or any of the equipment or services provided to Buyer. Buyer
agrees to accept and hereby accepts the foregoing as the sole and exclusive
remedy for any breach or alleged breach of warranty by Seller.
Any dishonesty or fraud in connection with Abestorm warranty thoroughly voids all
warranty policies. Abestorm expressly reserves the right to pursue legal action in
the event of dishonesty, fraud, or attempted fraud.
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL OTHER
WARRANTIES EXPRESSED OR IMPLIED,IN LAW OR IN FACT,INCLUDING
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
ABESTORM SHALL IN NO EVENT BE LIABLE FOR DEATH,INJURIES TO
PERSONS OR PROPERTY,OR FOR INCIDENTAL,CONTINGENT,SPECIAL，OR
CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES,SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO YOU.
4

Carefully unpack the air filter and all its parts. Do not discard the carton or
any packaging until the air filter is completely assembled.
MERV-11 Filter×4
KNOW YOUR AIR FILTRATION SYSTEM
The air filter is designed to circulate air and filter wood and other non-metallic dust.
The unit requires only minimal assembly. However, it is important to consider how
and where to place the unit. When selecting a site, make sure there is a suitable
power source nearby. Do not use extension cords with the air filter.
Warning!
·Two people are required for installation.
·Do not run the machine without a filter installed.
INSTALLATION METHOD #1 (Fig. 1):
1. Thread the locknuts ① almost all the way
up the hanger ②.
2. Thread a hanger into each of the four
mounting holes ③ on the top of the air filter
cabinet.
3. Tighten catch locknut against the cabinet top.
Hold the hangers so that they do not spin
while tightening the locknut.
5
ASSEMBLY AND ADJUSTMENTS

6
CEILING PLACEMENT (Fig. 2)
Make sure the unit will be situated at least 7' above the floor and at least 3' away
from a corner and from any heating or air vents. (CEILING PLACEMENT - Fig. 2)
1.Create a marking on the ceiling where you will be installing the hook.
(recommended installation size: 23.6 × 23.6 inch, 60 × 60 cm.)
2.On the marked spots on the ceiling, use a 3mm drill bit to create a hole.
3. Install the wood screw hooks ② into the building support structure①.Do not
mount the air filter to non-structural surfaces such as drywall or false ceiling grids.
The hooks are rated for this air filter and can support a maximum of 100 lbs.
4. Place a chain ③ on each wood screw hook ②.
5. Attach the hangers ④ on each chain③.
6. Make sure the unit is level horizontally, and is at least 7' above the floor lf it is not,
remove the air filter and adjust the length of the chain as needed. Then remount
the unit.
7. Plug the air filter power cord directly into a power source.
①
②
③
④
Fig. 2

7
INSTALLATION METHOD #2 (Fig. 3):
Make sure the unit will be situated at least 7' above the floor and at least 3' away
from a corner and from any heating or air vents.
1.Use the M4 screws to install 4 mounting brackets on to the equipment.
3.On the marked spots, use a 10mm drill bit to make a hole for the insertion of the
expansion screws to the ceiling.
4.Carefully lift the equipment to insert the ceiling-attached expansion screw to the
hole of mounting brackets. Use the nut to secure the mounting backet and the
machine on the ceiling.
Fig. 3
NOTE: The above installation must be installed by no less than two people!
For a step-by-step video tutorial, search the URL provided below using your
computer browser.
Guide starts at 1:12 of the video.
When you install the unit, you may also put the air outlet to up. (You need to remove
the control panel, and turn around 180°, then install back again.)
https://youtu.be/WWP18hy7ExE
2.Measure the distance between brackets and use it as a guide to create a marking
on the ceiling before for the installation. (recommended installation size: 18.9 ×
18.9 inch, 48 × 48 cm.)

8
The air filter can be operated directly using the control panel or with the remote
control.
The Air filter with power off memory function, power off after the boot again, will
repeat the last operation.
TURN ON AIR FILTER AND SPEED SETTINGS (Fig.3 and 4)
1. Plug the power cord into an appropriate power source.
2. Press the "On/Off" button ① On the control panel or the "On/Off" button ⑨ On the
remote control to switch On the POWER supply of the air filter. The POWER
indicator light ③ is On, and the dust filter is operated before the last shutdown
(except the scheduled shutdown).
3. Press the "SPEED" button ② on the control panel or the ⑩ button on the remote
control to set the SPEED of dust filter and the SPEED selected by the LOW/HIGH
④/⑥ indicator on the control panel.
4. Press ionizer button ⑪ on the remote control to turn ionizer indicator (5)on or off.
5. Press the timer shutdown button ⑫ on the remote control to enter the timer
shutdown.
Dust filter in ON (continuous operation) mode, press timing shutdownbutton ⑫,
enter the timing shutdown of 01H to 09H, for example, set at 06H, 06H display
flashing 5 seconds, start timing shutdown. --H is to cancelthe timed shutdown.
After --H blinks for 5 seconds (or press the timed shutdown button when --H blinks),
cancel the timed shutdown and enter ON.
Note: The DecDust 1350 does not have this feature and the lonizer button on the
remote is not responding!
OPERATION

9
In the dust filter timed shutdown mode (such as 05:39), press the timed shutdown
button ⑫, the current time blinks, no operation within 5 seconds, and the current
timer is restored (05:39). Press the timer shutdown button within 5 seconds of
blinking to enter the timer shutdown (01H-09H) setting. When entering the --H
display, --H flashes for 5 seconds, no operation is performed within 5 seconds, and
the ON mode is entered. --H blinking press the timer shutdown button within 5
seconds to cancel the setting and return to the countdown (05:39).
Note: The unit will automatically shut down after a selected time interval.
6. The infrared receiving opening ⑧ on the control panel should not be blocked by
objects or dirt.
WARNING: To reduce the risk of injury and electric shock, unplug the air filtration
system from the power source before changing the air filters or
servicing the unit.
CHANGE THE FILTERS
Check the inner and outer filters periodically, depending on the amount of use, and
change the filters when needed. Clogged filters will reduce the amount of air
circulating through the filter.
1. When the device is powered off, take it to the middle of the filter ① and take it out
externally.
2. Take out the new filter and place it in the device according to the direction
indicated.
Replacement filters for this unit available at （ ） and all www.abestorm.com
online retailers where this unit is sold.
Note: Wear a mask and gloves when changing filters.
Note: when the operating distance of the remote control is significantly shortened,
please replace the battery of the remote control and wipe the infrared receiver
in time!
MAINTENANCE

1. According to your operating environment, the equipment may be blocked by the
filter, resulting in noise. Please replace the filter in time.
2. Excessive current or abnormal family circuit will lead to power off protector
connected. Equipment power, protect your circuit.
POWER-OFF PROTECTION RECOVERY
1. Disconnect the power supply.
2. Press the circuit breaker ① back to its original position.
3. Switch on the power supply and start the machine.
10
CHECK AND TROUBLESHOOT
WIRNING DIAGRAM

The limited warranty is applicable to the original purchaser only, since the date of
purchase. It should subject to the terms and conditions listed in this limited
warranty file.
WARRANTY PERIOD
Warranty becomes effective from the date of original purchase and will last for one
year.
This limited warranty is not transferable. It is only valid for the original purchaser.
Warranty debarment:
1. Damage caused by the owner when attempting to fix or alter the product by
himself or herself.
2. Damage caused by misuse, abuse, neglect, alterations or unauthorized repair.
3. Natural depreciation.
How to request warranty services?
Abestorm Warranty Steps:
To obtain the benefit of this warranty, please leave your message online web:
(www.abestorm.com) or send an email to [email protected].
Our customer service will address your issue between Mon-Fri 7:00AM to 4:00
PM PST.
1, Upon receiving this item, visit www.abestorm.com and fill out the warranty
registration form. The order number is required to submit a warranty claim.
2, To request warranty service, contact [email protected].
3. After receiving the warranty service request, our customer support tearn will
investigate the issue, Here, will be determined if a Return authorization is
necessary.
4. If the damage to the machine is proven to be one of the warranty exclusions
(Page 10), Abestorm will not be responsible for all the associated repair and
shipping costs. The eligibility of a replacement unit will also be voided.
5. If the damaged unit that can no longer be fixed is within the warranty period,
Abestorm will handle all the cost to send a brand-new replacement unit.
6. When the unit is repaired or replaced, the original warranty period carries over
to the repaired or new unit. No warranty extensions will be offered.
11

DAMAGE DUE TO THE FOLLOWING IS NOT covered under warranty:
1. Acts of Nature- including but not limited to:
Flooding
Filters
Fire
Batteries
Water damage
Power cords
Switches
Hurricane/storm damage
Valves
Rubber parts
11.Direct, indirect, collateral or inconsequential damages of any kind.
Abestorm total liability, regardless of nature of claim shall not exceed original
purchase price of the product. If a product or component is replaced while under
warranty, the applicable warranty period shall not be extended beyond the original
warranty time period.
The foregoing shall constitute the total liability of seller in the case of defective
performance of all or any of the equipment or services provided to Buyer. Buyer
agrees to accept and hereby accepts the foregoing as the sole and exclusive
remedy for any breach or alleged breach of warranty by Seller.
Any dishonesty or fraud in connection with Abestorm warranty thoroughly voids all
warranty policies. Abestorm expressly reserves the right to pursue legal action in
the event of dishonesty, fraud, or attempted fraud.
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL OTHER
WARRANTIES EXPRESSED OR IMPLIED, IN LAW OR IN FACT, INCLUDING
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
2.IMPROPER USAGE- Including but not limited to:
Misuse, abuse, or tampering whether intentional or accidental
lmproper installation
lmproper voltage
mproper maintenance
Failure to follow instructions
3.Corrosion
4.Freezing
5.Any additional costs due to changes in laws or building codes
6. Freight charges
7. Any costs due to lost profit or delay
8. Damage to property
9. Cause beyond control
10. Consumable parts, including but not limited to:
12
WARRANTY EXCLUSIONS:
