Abocom WUG2690 User manual

WUG2690
802.11b/g Wireless LAN USB 2.0 Adapter
A wireless LAN links network users to LAN services
without the hassle of cabling or wiring, which
significantly brings mobile workers the freedom of
staying connected to the network while roaming around a
building or multiple buildings maintaining access to the
Internet, e-mail, networked applications, and print
services.
This device is the perfect solution for your wireless
network applications based on the IEEE 802.11b/g
standard that offers a data rate up to 54Mbps in a wireless
LAN environment. It is a high-speed wireless network
card that plugs into your system and accesses to the LAN
or peer-to-peer networking easily without wires or cables.
No matter where it allows you to share printers, files, and
other network resources.
Compliant with IEEE802.11b/g standard for 2.4GHz
Wireless LAN
USB 2.0 compliant
USB Plug & Play
Interoperable with existing network infrastructure
Secure information transmission
Freedom to roam while staying connected
Compatible with specialty wireless products and
services
Up to 54 Mbps data rate
Low power consumption ; high security and high
performance.
Free inside the Soft Access Point
Support English, Japanese, Simplified_Chinese,
Traditional_Chinese
Power Requirement
Operating Voltage: 5V DC
TX consumption: 250 mA (Max)
RX consumption: 160 mA (Max)
Physical specification
Weight: 8 g
Dimension: 67.67(L) x 25.02(W) x 5.4(H) mm
Supported OS
Windows 2000
Windows XP
Windows ME
Windows 98SE

WUG2690
802.11b/g Wireless LAN USB 2.0 Adapter
WIRELESS SPECIFICATION
Standard IEEE 802.11b/g
Host Interface USB 2.0
Antenna Connector One SMA connector and one I-Pex connector
Frequency Range 2.412GHz ~ 2.4835GHz
Number of Selectable Channels USA, Canada: 11 channels
Europe: 13 channels
Japan: 14 channels
Modulation Technique Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
Orthogonal frequency division multiplexing(OFDM)
Security 64/128/256-bit WEP Encryption and Wi-Fi Protected Access, AES-CCM,
TKIP
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Output power 11g: 13 dBm
11b: 16 dBm
Data Rate 802.11g(54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps)
802.11b(11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)
Throughput 21.5Mbps @ 54Mbps
5.9Mbps @ 11Mbps
Sensitivity -68 dBm@54Mbps
-85 dBm@11Mbps
