Introduction
Abseco® AFi Series Bell Switch module is an innovative, futuristic and affordable smart
automation device which give users total control of their lights, appliances and electrical
outlets through various control methods such as smartphones, voice assistants, network
profiles, and cloud services such as IFTTT.
Our smart-touch solution provides a comprehensive automated home or business
electrical control ecosystem, offering users unparalleled levels of control and visibility
over their home or business lighting, heating, and cooling systems, all delivered in one
affordable, accessible, and easy-to-use package.
Safety Information
Always follow all basic electrical/electronic safety precautions when using this smart
switch (product) to prevent risk of injury from fire or electric shock, or product damage.
• Read and understand all guidelines provided in this document regarding safety,
warranty, installation, and use before installation/use of the product.
• All instructions and safety precautions detailed in this guide must be strictly followed.
Observe all warnings and instructions marked on the product.
• If the instructions and safety precautions detailed in this manual are not correctly
followed, Abseco International Pvt. Ltd. cannot be held responsible for any personnel
injury and/or equipment/product damage.
• To prevent electric shock, disconnect both the poles of the main supply before installing
the product.
• Do not install this product where it can come in contact with water. Never do installation
of the product with wet hands. Dry your hands to avoid electrical shock/injury.
• Product must be installed securely on a wall/surface without uneven gaps.
• This product is a single pole switch and disconnects only one pole when it is in OFF
condition.
• Installation of the product must be performed by a qualified electrical technician.
• Product damage caused by incorrect installation or use is not covered under warranty
and the related warranty claims will be rejected.
• There are no user serviceable parts inside the product. Product repair/servicing must
only be carried out by a qualified service personnel authorized by the company.

Product Familiarization & Installation Guide - Product Overview
Abseco
®
AFi Series Bell Switch - AFI-2M0S1B Page 4
Main Features
• Refined look and feel
• Made of fire resistant, safe and durable materials
• Waterproof tempered glass touch panel with advance capacitive touch technology
• Multiple colour choices to choose from to match with any room decor
• Inbuilt overload and surge protection
• Functional module design to easily replace your traditional mechanical switch
• Separate indicators for on/off status and touch switch illumination for ease of detection
during night
• Simple retrofit installation; does not require special wiring
Technical Specifications
Parameter Specification
Switch Classification Doorbell Wall Switch
Model No. AFI-2M0S1B
Power Supply Mode Live Wire; Requires a
Neutral Line
Rated Current 6 A
Rated Voltage and
Frequency
100-250 VAC,
50-60 Hz

Product Familiarization & Installation Guide - Product Overview
Abseco
®
AFi Series Bell Switch - AFI-2M0S1B Page 5
Parts Identification
Power Connection Terminals
POWER CONNECTION
TERMINALS
REAR ENCLOSURE
TOUCH PANEL
INDICATOR LIGHT
ON/OFF TOUCH SWITCH
L1 (Line-In)
N (Neutral)
MAIN
Model : AFi-2M0S1B
Rated Voltage : 100V - 264V, 50-60Hz
Max Load : 400W/Gang
Made in India
QC
PASSED
SN: 2M0S1B100000000

Product Familiarization & Installation Guide - Installation Instructions
Abseco
®
AFi Series Bell Switch - AFI-2M0S1B Page 6
Installation Instructions
1. Connect the electrical wires to the terminals of the switch module as shown in
the wiring diagram.
2. Insert the switch module into the switch mount box and secure with 2 screws.
3. Align and position the front touch panel (face plate) onto the switch module.
(Line-In)
(Neutral)
MAIN
Model : AFi-2M0S1B
Rated Voltage : 100V - 264V, 50-60Hz
Max Load : 400W/Gang
Made in India
QC
PASSED
SN: 2M0S1B100000000
SWITCH
MODULE
SCREW
(2 PLACES)

Product Familiarization & Installation Guide - Installation Instructions
Abseco
®
AFi Series Bell Switch - AFI-2M0S1B Page 7
4. Carefully press the touch panel by applying even force on all sides until it is
seated securely on the switch module.
Make sure that the touch panel is seated correctly without any uneven gaps.
TOUCH PANEL

Product Familiarization & Installation Guide - Installation Instructions
Abseco
®
AFi Series Bell Switch - AFI-2M0S1B Page 8
5. After installation, switch on the main electrical power supply and verify that the
touch switch is working correctly.

Product Familiarization & Installation Guide - Troubleshooting
Abseco
®
AFi Series Bell Switch - AFI-2M0S1B Page 15
Troubleshooting
If your bell switch is not operating correctly, perform the troubleshooting instructions
given below. If problem persists, contact your Abseco dealer or local authorized Abseco
service center.
FAULT PROBABLE CAUSE REMEDY
Not able to turn on the
Bell switch (indicator light
on the bell switch is OFF)
No power supply or main
power supply is OFF.
Make sure that power
supply is available and
the main power supply is
ON.
Electrical connections to
the bell switch are
incorrect.
Make sure that the
electrical connections to
the bell switch are
correct. Refer to Wiring
Diagram given in
Installation Instructions.
bell not ringing when bell
switch is turned on
(indicator light on bell
switch is ON)
The electric bell is burned
out.
Make sure that the bell is
in working condition. If
necessary, use a an
electric bell that is in
working condition to
make sure that the fault is
not due to a burned
electric bell.
Electrical connections to
the bell switch are
incorrect.
Make sure that the
electrical connections to
the bell switch are
correct. Refer to Wiring
Diagram given in
Installation Instructions.
