Abtus AVA-14G User manual

AVA-GA SERIES
VGA Distribution Amplifier with Audio
AVA-14G/A, 18G/A
USER MANUAL
VGA with Audio
900 MHz, 3dB
Bandwidth
SINGAPORE
SINGA ORE

DESCRI TION
The ABtUS AVA-GA/A is a high quality VGA with Audio Distribution Ampli ier that caters
specially or pro essional AV System Integrators who require high dependable
per ormance in their installations. Simply connect it to your computer and your display
devices such as projectors, Plasma and LCD monitors and the AVA-GA series will provide
the hi hest Quality output for up to 8 display devices.
FEATURES
With a Video bandwidth of 900MHz, it ensures the Amplifier remains transparent even for hi h-
resolution VGA modes like UXGA. It is ideal for presentation systems requirin a local monitor
and up to 8 difference display units with Audio. Projectors, plasma display, LCD panel or monitor.
Compatible with all VGA direct monitors, projectors and most LCD/Plasma panels.
Typical Application
The ABtUS AVA-GA Series is part of the ABtUS series of hi h quality, hi h bandwidth and
cost effective Distribution Amplifiers specially for professional installers. ABtUS products can
be found in industrial, commercial, educational, military and overnment applications like:
Schools; Trainin rooms; Broadcast and duplication studios; Workstation environment; Retail
showrooms; CCTV and surveillance and Multipurpose Hall etc.
INPUTS 1 x VGA D-Sub 15 pin Female connector and
1 x 3.5mm PC Audio
OUTPUTS 2x, 4x, 8x VGA D-Sub 15 pin Female connector and
3.5mm PC Audio.
BANDWIDTH (-3dB) 900MHz per channel
MAX RESOLUTION 1600 x 1200 UXGA
SIGNAL TYPE VGA, SVGA, XGA, UXGA, Multi sync
CABLE LENGTH (Ouput) 1 to 50 meter
POWER SOURCE 12V-DC 500mA
DIMENSIONS (310 x 112.4 x 44) mm *AVA-GA18G/A
WEIGHT 1350 *AVA-GA18G/A
ACCESSORIES AC-DC Power Adaptor 12V-DC 500mA
Typical Application AVA-GA14G/A, 18G/A
Technical Specifications AVA-GA14G/A, 18G/A
AVA-GA SERIES
VGA
DISTRIBUTION AMPLIFIER WITH AUDIO
SINGA ORE
AVA-GA Series
Configuration Diagram
* Specifications are subject to change without notice.
AVA-GA14G/A
D: (200x112.4x44) mm, W: 650g AVA-GA18G/A
D: (310x112.4x44) mm, W: 1350g
