AC Tech SCF SERIES User manual

This guide is intended as an aid to configure the SCF drive.
NOTE: Before installing and operating the SCF drive, please
read and become familiar with the SCF Series installation
and operation manual.
SCF TERMINAL STRIP
QR-SCF-OEOD-e2
PI CONTROL WIRING EXAMPLE
Shown below is a wiring diagram for a typical PI control scheme with
a 2-wire start/stop and 4-20 mA feedback. The PI setpoint is adjusted
using the  and  butons on the front of the drive.
- Set Parameter 10 (TB-13A) to Keypad Setpoint (12).
- Set Parameter 61 (PI MODE) to Normal 4-20 mA (02) or
Reverse 4-20 mA (04) depending on the type of system to be
controlled.
- Set the other PI parameters as necessary
(refer to the SCF manual).
STOP 1
CIRCUIT COMMON 2
0-10 VDC SPEED REFERENCE INPUT 5
10 VDC SUPPLY FOR SPEED POT 6
12 VDC SUPPLY (50 mA MAX.) 11
START 12
CIRCUIT COMMON 2
OPEN COLLECTOR OUTPUT 14
TB-13A FUNCTION SELECT 13A
TB-13B FUNCTION SELECT 13B
TB-13C FUNCTION SELECT 13C
OPEN COLLECTOR OUTPUT 15
4-20 mA SPEED REFERENCE INPUT 25
CIRCUIT COMMON 2
0-10 OR 2-10 VDC OUTPUT: FREQ. OR LOAD 30
0-10 OR 2-10 VDC OUTPUT: LOAD 31
RS-485 SERIAL COMMUNICATIONS TXA
RS-485 SERIAL COMMUNICATIONS TXB
Run/Stop Contact
1 2 5 6 11 12 2 14 13A 13B 13C 15 25 2
4-20 mA Feedback
SCF Series
Quick Reference Guide
DIAGNOSTIC AND DISPLAY MESSAGES
DISPLAY DESCRIPTION
Speed Reference Codes
CP CONTROL PAD: The drive speed is controlled by the ▲ and ▼ buttons on the front
of the drive.
EI EXTERNAL CURRENT: The drive speed is controlled by a 4-20 mA signal between
TB-25 and TB-2.
EU EXTERNAL VOLTAGE: The drive speed is controlled by a 0-10 VDC signal between
TB-5 and TB-2.
JG JOG: The drive is in Jog mode and the speed is set by preset speed #2 (Parameter 32).
OP MOP: Contacts wired to TB-13B and 13C are used to increase and decrease the drive
speed.
Pr1 - Pr7 PRESET SPEEDS #1-7: The drive speed is set by the selected Preset Speed (Param-
eters 31-37).
Status Indication
br DC BRAKING: The DC braking circuit is activated.
CL
CURRENT LIMIT: The output current has exceeded the CURRENT LIMIT setting
(Parameter 25) and the drive is reducing the output frequency to reduce the output
current. If the drive remains in CURRENT LIMIT for too long, it can trip into a CUR-
RENT OVERLOAD fault (PF).
Er ERROR: Invalid data has been entered.
GE “GE” will be displayed if an attempt is made to change the OEM default settings when
the drive is operating in the OEM mode (see Parameter 48).
LC FAULT LOCKOUT: Failed three restart attempts. Requires a manual reset.
SE SERIAL: The optional remote keypad is active as the user interface instead of the but-
tons on the front of the drive.
SP START PENDING: This is displayed during the 15 second interval between restart
attempts.
Diagnostic Codes
AF HIGH TEMPERATURE FAULT: Ambient temperature is too high.
CF CONTROL FAULT: A blank EPM, or EPM with corrupted data has been installed.
Perform a factory reset (Parameter 48).
cF INCOMPATIBILITY FAULT: An EPM with a different parameter version has been
installed.
dF DYNAMIC BRAKING FAULT: The drive has sensed the dynamic braking resistors are
overheating.
EF EXTERNAL FAULT: TB-13A and/or TB13C is set as an external fault input and TB-13A
and/or TB-13C is open with respect to TB-2.
GF DATA FAULT: User data and OEM defaults in the EPM are corrupted.
HF
HIGH DC BUS VOLTAGE FAULT: Line voltage is too high; Deceleration rate is too
fast; Overhauling load. Fast deceleration and overhauling loads may require dynamic
braking.
JF SERIAL FAULT: The watchdog timer has timed out, indicating that the serial link has
been lost.
LF LOW DC BUS VOLTAGE FAULT: Line voltage is too low.
OF
OUTPUT TRANSISTOR FAULT: Phase to phase or phase to ground short circuit on
the output; Failed output transistor; Boost settings are too high; Acceleration rate is
too fast.
PF CURRENT OVERLOAD FAULT: VFD is undersized for the application; Mechanical
problem with the driven equipment.
SF SINGLE-PHASE FAULT: Single-phase input power has been applied to a three-phase
drive.
UF
START FAULT: Start command was present when the drive was powered up. Must
wait 2 seconds after power-up to apply Start command if START METHOD is set to
NORMAL.
F1 EPM FAULT: The EPM is missing or damaged.
F2 - F9, Fo INTERNAL FAULTS: The control board has sensed a problem. Consult factory
AC Technology Corporation
630 Douglas St, Uxbridge, MA 01569
800-217-9100, FAX: [phone]
www.actechdrives.com

To add a potentiometer for speed control, change Parameter #5
(Standard Speed Source) to 0-10 VDC (03).
Once the PROGRAM mode is accessed, use the  and  buttons to
scroll to the desired parameter number, and press the Mode button
to see the parameter setting. Use the  and  buttons to change
the parameter setting and press Mode to store the new setting.
Connections:
Below is a sample wiring diagram for two-wire start/stop control. The
drive is ready to use right out of the box, with these simple control
wiring connections; no parameter adjustments are required. Speed
is controlled from the  and  buttons on the front of the drive.
CONFIGURING THE SCF DRIVE
Entering Program Mode:
To access the parameters, press the Mode button. This will
activate the password prompt. The display will read “00” and the
right-hand decimal point will be blinking. Use the  and  buttons
to scroll to the password value (the factory default password is 225)
and press MODE to enter.
Press Mode
Upper right decimal point blinks
Press Mode to enter password
Display reads “00”
Use  and  to scroll to the password
value (factory default password is 225)
SCF PARAMETER MENU
No. Parameter
Name Range of Adjustment Factory Default
01 Line Voltage High (01), Low (02) High (01)
02 Carrier Frequency 4 kHz (01), 6 kHz (02),
8 kHz (03), 10 kHz (04) 6 kHz (02)
03 Start Method
Normal (01), Start on Power-up
(02), Start w/DC Brake (03),
Auto Restart w/DC Brake (04),
Flying Restart 1 (05), Flying Restart 2 (06),
Flying Restart 3 (07)
Normal (01)
04 Stop Method
Coast (01), Coast with
DC Brake (02), Ramp (03),
Ramp with DC Brake (04)
Coast (01)
05 Speed Source Keypad (01), Preset #1 (02),
0-10 VDC (03), 4-20 mA (04) Keypad (01)
06
13
TB-14 Output
TB-15 Output
None (01), Run (02), Fault (03),
Inverse Fault (04), Fault Lockout (05),
At Set Speed (06),Above Preset #3 (07),
Current Limit (08), Auto Speed (09),
Reverse (10), Min Alarm (11),
Max Alarm (12), Min/Max Alarm (13)
None (01)
None (01)
8 TB-30 Analog Out
None (01), 0-10 VDC Freq (02),
2-10 VDC Freq (03),
0-10 VDC Load (04),
2-10 VDC Load (05)
None (01)
9 TB-31 Analog Out
None (01), 0-10 VDC Load (02),
2-10 VDC Load (03),
Dynamic Braking (04)
None (01)
10 TB-13A Select
None (01), 0-10 VDC (02),
4-20 mA (03), Preset Speed #1 (04),
Run Reverse (05), Start Reverse (06),
External Fault (07), Remote Keypad (08),
DB Fault (09), Auxiliary Stop (10),
Accel/Decel #2 (11),
Keypad Setpoint (12)
None (01)
11 TB-13B Select
None (01), 0-10 VDC (02),
4-20 mA (03), Preset Speed #2 (04),
Decrease Freq (05), Jog Forward (06),
Jog Reverse (07), Auxiliary Stop (08),
Keypad Setpoint (09)
None (01)
12 TB-13C Select
None (01), 0-10 VDC (02),
4-20 mA (03), Preset Speed #3 (04),
Increase Freq (05), External Fault (06),
Remote Keypad (07), DB Fault (08),
Accel/Decel #2 (09),
Keypad Setpoint (10)
None (01)
14 Control
Terminal Strip Only (01),
Remote Keypad Only (02),
Terminal Strip or Remote Keypad (03)
Terminal
Strip (01)
15 Serial Link
Disable (01),
9600, 8, N, 2 with Timer (02),
9600, 8, N, 2, without Timer (03),
9600, 8, E, 1 with Timer (04),
9600, 8, E, 1, without Timer (05),
9600, 8, O, 1 with Timer (06),
9600, 8, O, 1, without Timer (07),
9600, 8, N,
2 with Timer (02)
16 Units Editing Tenths of Units (01), Whole Units (02) Whole Units (02)
17 Rotation Forward Only (01), Forward and Reverse (02) Forward Only (01)
19 Acceleration Time 0.1 - 3600.0 sec 20.0 sec
20 Deceleration Time 0.1 - 3600.0 sec 20.0 sec
21 DC Brake Time 0.0 - 3600.0 sec 0.0 sec
22 DC Brake Voltage 0.0 - 30.0 % 0.0%
23 Min Frequency 0.0 - Max Frequency 0.0 Hz
24 Max Frequency Min Frequency - 240.0 Hz 60.0 Hz
25 Current Limit 30 - 180% 180%
No. Parameter
Name Range of Adjustment Factory Default
26 Motor Overload 30 - 100% 100%
27 Base Frequency 25.0 - 500.0 Hz 60.0 Hz
28 Fixed Boost 0.0 - 30.0% 1.0%
29 Accel Boost 0.0 - 20.0% 0.0%
30 Slip Compensation 0.0 - 5.0% 0.0%
31-
37 Preset Speeds 0.0 - Max Frequency 0.0 Hz
38 Skip Bandwidth 0.0 - 10.0 Hz 0.0 Hz
39 Speed Scaling 0.0 - 6500.0 0
40 Frequency Scaling 3.0 - 2000.0 Hz 60.0 Hz
41 Load Scaling 10 - 200% 200%
42 Accel / Decel #2 0.1 - 3600.0 sec 20.0 sec
43 Serial Address 1 - 247 1
44 Password 000 - 999 225
45 Spd at Min Signal Min Frequency - 999.0 Hz 0.0 Hz
46 Spd at Max Signal Min Frequency - 999.0 Hz 60.0 Hz
47 Clear History Maintain (01), Clear (02) Maintain (01)
48 Program Selection
User Settings (01), OEM Settings (02),
Reset OEM (03), Reset 60 (04),
Reset 50 (05), Translate (06)
User Settings (01)
50 Fault History View Only (N/A)
51 Software Code View Only (N/A)
52 DC Bus Voltage View Only (N/A)
53 Motor Voltage View Only (N/A)
54 Load View Only (N/A)
55 0-10 VDC Input View Only (N/A)
56 4-20 mA Input View Only (N/A)
57 TB Strip Status View Only (N/A)
58 Keypad Status View Only (N/A)
59 TB-30 Output View Only (N/A)
60 TB-31 Output View Only (N/A)
61 PI Mode
Off (01), Normal 4-20 mA (02),
Normal 0-10 VDC (03),
Reverse 4-20 mA (04),
Reverse 0-10 VDC (05)
Off (01)
62 Min Feedback 0.0 - 999.0 0
63 Max Feedback 0.0 - 999.0 100
64 Proportional Gain 0.0 - 99.9 % 5.0%
65 Integral Gain 0.0 - 99.9 sec 0.0 sec
66 PI Accel/Decel 0.0 - 999.0 sec 20.0 sec
67 Min Alarm 0.0 - 999.0 0
68 Max Alarm 0.0 - 999.0 0
69 0-10 VDC Feedback View Only (N/A)
70 4-20 mA Feedback View Only (N/A)
71 Actual Frequency View Only (N/A)
