AcceleVision DVR400SD User manual
MANUAL
4CH Mobile H.264 Digital Video Recorder
DVR400SD
Page 2 of 24
DVR400SD User’s manual
Contents
Chapter I. Before Use
1.1. Important Safety Notice ··········································································· 3
1.2. Introduction ··························································································· 5
1.3. Specification ·························································································· 6
1.4. Material in a package ·············································································· 7
1.5. Installation ···························································································· 9
Chapter II. Getting Started
2.1. IR Remote Controller ··············································································· 10
2.2. Live Screen ··························································································· 10
2.3. Menu Screen ························································································· 11
Chapter III. Viewer Software
3.1. Installation Viewer on PC ·········································································· 19
3.2. Viewer Window ······················································································· 21
3.3. Viewer Icons ·························································································· 22
3.4. Backup ································································································· 23
Page 3 of 24
DVR400SD User’s manual
Chapter I. Before Use
1.1. Important Safety Notice
Follow these instructions to help guard against personal injury and damage to your system.
It is highly recommended that you to read the User’s Manual before you use this product.
Warning
1. Do not block ventilation holes with any material. It could overheat the unit and cause a fire.
2. Do not expose this device to smoke such as comes from candles and cigarettes. It could result in
a fire.
3. Do not use this device near inflammables or combustibles. It could result in fire or explosion.
4. Do not insert sharp objects into ventilation openings or A/V port as it may result in electric shock
and/or fire.
5. Never open, repair, and/or modify this device. It could result in electric shock and/or fire. For post-
purchase service, please contact Technical support.
6. Do not install this device in a wet area. It may result in electric shock and/or fire.
7. Do not touch the product with wet hands. It may cause malfunction or electric shock.
8. Do not spray insecticide or flammable spray while driving. It may cause fire.
Caution
1. Do not clean this device with water. It could result electric shock and/or fire.
2. Use this device follow right voltage. It could result electric shock and/or fire.
3. Do not allow children to touch or play with this device. It could result in an electric shock.
4. Use the power cord, which is supplied or recommended by the supplier, or it may cause fire.
5. Do not disassemble or reassemble the product. It may cause malfunction or fire.
6. Enquire to your vendor for repair. It may cause electric shock or fire if the repair is not done
properly.
7. Install this device tightly on surface. It may result in mechanical failure or cause personal injury
Notice
1. Operate this device on a flat surface. Placing the unit upside-down could result in mechanical
failure or cause personal injury.
2. If smokes or bad odors are emitted by this device, unplug it immediately and contact technical
support. Failure to do so may result in electrical shock and or fire.
3. Place the product where can be free from outer physical shock. It could result electric shock
and/or fire.
This Manual uses “Warning” and “Notice” attention messages. Refer to the following
table for:
Warning: This sign indicates that the user could die or be seriously wounded
if not used or installed properly.
Caution: This sign indicates that the user could be wounded or could expect
property damage if not used or installed properly.
Notice: This sign indicates that the user could be taken minor injury or
damage to product if not used or installed properly.
: Special ca
r
e should be taken in this case to ensure safet
y
.
Page 4 of 24
DVR400SD User’s manual
4. Install the product on even place where less vibration
5. Product installation must be ensured to a professional for product installation, or it may cause
malfunction, electric shock or fire.
6. Place the system in open place where air ventilation is guaranteed, or it may cause over-heating
and seriously damage the system to be fired.
7. Prevent water from instilling inside electrical parts. Clean with a dry towel or malfunction or
electric shock could result.
8. Use a proper power source. Do not operate this product from a power source that applies more
than the specified voltage (DC 9V to 29V at least 1A or over).
9. Use a proper unit in vicinity temperature from -20°C to +70°C. If not, it may cause malfunction or
electric shock.
10. Do not operation unit during drive by yourself. It may cause serious accident or die.
1. Make certain to protect this device from sources of moisture.
2. Do not place a humidifier near the product as extreme humidity can badly affect the product’s
normal operation
3. Avoid dust, humidity and do not place the product where temperature changes extremely.
4. Do not place the product near a microwave, Radio or TV which can generate signal noise due to
radio frequency.
5. Direct ray of light can cause abnormal operation. Keep the product away from direct ray of light
6. Prevent metallic foreign substance from going inside the product. It may cause malfunction or
electric shock.
7. This unit is only support device for user’s convenience. Keep in mind use safety.
8. Do not place the product near microwave, Radio or TV which can generate signal noise due to
radio frequency.
Page 5 of 24
DVR400SD User’s manual
1.2. Introduction
This device is Mobile Digital Video Recorder which is applied many kinds of Vehicles and special
usage. Someone called it mobile black-box but it can take care of video, audio, G-sensor and
GPS data only. However, it has opened more functions if users want to put special data through
RS-232, network or USB which is customize project only.
Mobile Car DVR has been business very long time. It has been installed Buses and Trucks
generally. At this time, increased many type of users are demand higher quality and stable
operation by Mobile Car DVR they called Car Black-Box generally.
This device based CCTV stand alone DVR but it is adjusted to fit mobile industry. Always, mobile
DVR have problem with unstable electricity power from vehicle environment. We have designed
for Auto-mobile which is many things are developed how to run in vehicles. For example,
Electricity power can be accepted 9 Volt to 29 Volt because passenger cars have 12V, and Buses
or Trucks have 24V. If users want to protect more voltage, we can provide special utility device
for more voltage protection. And, we use storage that CF-card (Compact Flash Card) has risk
free for vibration or impact when it is installed auto vehicle. It gives to user easy replace storage
device or/and easy carry. We provide PC viewer software. Also, it gives easy user interface
search and abstraction data on PC.
This device provides easy installation and removes for installer. It is very helpful managing and
operating.
This device has many features for vehicle which are recording video and data to CF-card, SSD
card or HDD Storage about many information from installed cameras, GPS, G-Sensor or/and
others during vehicle is operated or parked. It can be evidence for accident or investigation.
Many options which are GPS, G-sensor and storage are cover from many buyers requested site
by site because many ofprojects or clients have different surrounding and situations.
This device has newest codec compression algorithm technology which is H.264 solution. It has
high quality and longer recording time. Old fashioned device must use Hard Disk Driver because
it has large compression video file but H.264 solved that problems. It provides longer recording
time and higher recorded video quality. User can have many options with it.
GPS data with recording data shows position of event and track Google Map on the own PC
viewer.
Specially, related mobile things Mobile DVR items must be guaranteed keep video data at
anytime or any situation. This device gives risk free such as loosing data when vehicles crashed
or accident period because it is dropped many function from cause of problems.
Choice with this device will give you powerful satisfaction and self protection from unexpected
accident or situation. It provides you true evidence which is save your life.
Page 6 of 24
DVR400SD User’s manual
1.3. Specification
DVR400SD Specifications
Video
Input
Channel 4ch(Customized connection)
)LAP/CSTN(noitceteDotuAnoitceleSlangiS
)rotcennoCdezimotsuC(etisopmoCepyTtupnI
LAP/CSTNtamroFlangiS
troppuSkcehCssoLoediV
Output
Display output Rear : TV-OUT (Stereo Jack Connector),
Front : TV-out & 12V DC Power out (Wafer Connector)
57,p-pV0.1etisopmoCepyTtuptuO Ω
LAP/CSTNtamroFlangiS
Audio Input Channel 4ch (Customized Connector)
MCPDAcedoC
Output (Mono) )rotcennoCkcaJoeretS(hc1
Alarm )lanimreT(hc4otpUtupnIrosneS
)ON/CN(hc1tuptuOmralA
Live
LAPCSTN
)hc/spf52(spf001)hc/spf03(spf021etaRemarF
troppuSelbasiDlennahC
troppuSnoitceteDssoLoediV
4,1tilpSneercS
*)laoitpO(WSnodnepeDpupoPotuAweiVraeR
Recording
462.HnoisserpmoC
*tamrofelifIVA/tamrofelifnwOtamroFeliFecruoS
Resolution &
Recording Speed
LAPCSTN
360x240/ 352x288 Max 120fps(30fps/ch) 100fps(25fps/ch)
720x240/ 720x288 Max 120fps(30fps/ch) 100fps(25fps/ch)
720x480/ 720x576 Max 60fps(15fps/ch) 50fps(12 fps/ch)
troppuSlennahcrepetaRemarFtsujdA
*nevirDtnevEnoitartnecnoCetaRemarF
Image Quality Level *sleveL5,sleveL3RBV
*sleveL5,*sleveL3RBC
htobrorosneS,noitoM/suounitnoCedoMgnidroceR
troppuSytivitisneSnoitceteDnoitoM
*ces03~1mralAybgnidoceRerP
*ces003~2mralAybgnidoceRtsoP
*trelAnoitacidnIDSO&peeB)etirwrevO(gninraWlluFFC
troppuSemitgnivasthgilyad
Storage Exteranl CF
Memory Card
Interface Type CF Memory Card / SSD Card*
etyBagiG46otpu,etyBagiG2revOFC1foyticapaC
Search & Playback
Playback
(Viewer S/W)
Control One step Forward/ Reverse, Play, Fast Forward/ Reverse
8,4,2xdeepS
troppuSkcabyalPemitlaeR
tnevE,etaD&emiTedoMhcraeS
W/SreweivnwOGSOhtiwmaertSoediVF/IresU
Additonal Function
troppuSegaugnaL-itluM
tnemriuqerecivedlanoitpoSPGlanretxEroftroplaireS1SPG
troppusretemoleccasixa3*rosneS-G
elbaclanoitpotroP1deriuqeRrellortnoCetomeRrofrevieceRRIlanretxE
System
aideM/232SRgniggubeD&lortnoC
)xx.6.2.reV(xuniLdeddebmEmetsySnoitarepO
Dimension (WxHxD mm) 150x150mm for main board
(172x174x40mm with set, 200x205x130mm with package box)
)egakcaphtiwGK2(GK1thgieWteN
)lennahc4(aremacotCDV5.01tuOrewoP
A1V92~9ecruoSrewoP
* Optional functions
** Customizing project
Page 7 of 24
DVR400SD User’s manual
1.4. Martrial in a Package
Main item in the package.
*CF-card (Storage) and Power supply are not included
MOBILE DVR Remote Controller
AAA BATTERY
MANUAL & UTILITY CD4P Cable X 4
POWER Cable X 1
Page 8 of 24
DVR400SD User’s manual
Optional item in the package.
CAMERA POWER, VIDEO, AUDIO CABLE
CAMERA POWER, VIDEO CABLE
IR RECEIVER
GPS
Page 9 of 24
DVR400SD User’s manual
1.5. Installation
How to connection with Basic Standard Cable
Power input from some place. This package is not included adapter or power supply because it is
installed some unfixed place also vehicles have 12V or 24V. It has covered 9 Volt to 29 Volt.
Provide standard 3 of Video/Power cable for camera and 1 of Audio/Video/Power cable for camera
to device. Connect to special connector each channel.
Optional IR extension unit connect to IR EXT stereo jack.
Audio/Video stereo jack connect convert RCA cable.
Optional GPS receiver device connect RJ11 4 pin connector which are Power, RX, TX and Ground.
4channel Sensor input and 1 channel relay out to device.
Must do cable connect before power off the device.
After connection all cables, check devices work fine with power.
Customized cables will be compatible every ports. You can connect matched it.
<Input Video/Audio Channel
& Power Out to Cameras>
<Optional IR Receiver
Extension Connector>
<Power Input 9V to 29V>
<Audio/Video Out>
<GPS Receiver
Connector>
<Sensor In 4 channel>
Page 10 of 24
DVR400SD User’s manual
Chapter II. Getting Started
2.1 IR Remote Controller
2.2 Live Screen
Anytime use 1 to 4 number button at remote controller, it will be shown that channel full screen.
Also, use enter button at remote controller then quod screen as normal.
1 Record
2 Quad Mode
3 Zoom
4 Enter
5 ESC
6 Menu
7 OSD ON/OFF
8 Cursor (Up, Down, Right, Left)
9 Channel & functions
gnidroceRdeyalpsiDrebmuNlennahCdeyalpsiD
Current Time & Date
Remained Storage
Displayed GPS data (Position & Speed)
Page 11 of 24
DVR400SD User’s manual
2.3 Menu Screen
a. Record: Set Frame Rate, Quality, Resolution each channels.
Use arrow button by remote controller then chose with enter button what you need.
Set Frame rate Each Channels
(NTSC : 0, 1, 3, 7, 15, 30)
(PAL :0, 1, 3, 6, 12, 25)
Video Quality for Each Channel
(High, Middle, Low)
Set Resolution for Each Channel
(Full D1, Half D1, CIF)
Page 12 of 24
DVR400SD User’s manual
b. Configuration: Set Date & Time, Language and Format
Set Year, Month, Time
Set GMT time zone
Display mode for Date & Time
Set Time mode
Set Language
Time Synchronize from GPS
<Set GMT time zone> <Display mode for Date & Time>
>egaugnaLteS<>edomemiTteS<
Page 13 of 24
DVR400SD User’s manual
c. Search: Search by Time & Date from recorded data.
Close : Escape from Playback mode
PREV : Revert frame by frame
FR x2, x4, x8 : Fast Revert play mode. Speed will be changed each time pressed button.
REV 1/2, 1/4, 1/8 : Slow Revert play mode. Speed will be changed each time pressed button.
REV – Revert Play mode.
PAUSE – Pause the playback
PLAY – Playback
PLAY 1/2, 1/4, 1/8 : Slow play to forward. Speed will be changed each time pressed button.
FF x2, x4, x8 : Slow play to forward. Speed will be changed each time pressed button.
NEXT – Play to forward frame by frame
Pick recorded Date
Pick Recorded Hour
Pick Recorded Minute
Page 14 of 24
DVR400SD User’s manual
d. System: Set system environment.
This part is important for system environment. All sets are in here which are System, Password,
Camera setting, Motion, Alarm and Audio. Each one has different set value but user can
change to fittheir needs.
①System Setting
Page 15 of 24
DVR400SD User’s manual
②Password Setting
Display OSD On/Off option
Automatically recording with booting system option
Format storage option (must reboot system)
Revert to factory setting option
Input Vehicle’s Identification (up to 12 Character)
Generate Password by remote controller 2 times.
Page 16 of 24
DVR400SD User’s manual
③Channel properties
Adjust environment for each channels.
Input each Camera’s Identification (up to 12 Character)
Chose Channel what you need.
Page 17 of 24
DVR400SD User’s manual
④Motion Detection Setting
Set motion detection function and action after received signal.
⑤Alarm/Sensor Detection Setting
Set Alarm/Sensor function and action after received signal.
Page 18 of 24
DVR400SD User’s manual
⑥Audio Setting
Set Audio and action how to output method.
<Chose channel out to quad screen>
<Chose audio channel arrange camera>
Page 19 of 24
DVR400SD User’s manual
Chapter III. Viewer Software
3.1 Installation Viewer on PC
1. Click next
2. Find expected Folder for install of PC VIEWER.
3. Choose install File on selected Folder.
Page 20 of 24
DVR400SD User’s manual
4. Choose Create icon on Desktop on PC.
5. After ready for installing software, Click Install button.
6. All done install for Viewer software on PC.
Table of contents
