Accentrics Home DS-D322-700-1 User manual

A
B
H
I
x2 Seat Cushion
x2 Coussin de siege
x2 Cojín del asiento
x2 Back Cushion
x2 coussin de dos
x8(Extra 1) M6*25mm Bolt *
x8(Extra 1) Boulon M6*25mm
x8(Extra 1) Perno M6*25mm
x2 Amortiguador trasero
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D322-700-1
C
x2 Chair Seat Panel
x2 Panneau de siège de chaise
x2 Panel del asiento de la silla
D
x2 Chair Back Panel
x2 Panneau arrière de la chaise
x2 Panel trasero de la silla
E
F
G
x8(Extra 1) M6*35mm Bolt *
x8(Extra 1) Boulon M6*35mm
x8(Extra 1) Perno M6*35mm
x16(Extra 1) M6 Washer *
x16(Extra 1) Rondelle M6
x16(Extra 1) Lavadora M6
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
Page 1 of 3
x2 Left Arm Panel
x2 Panneau du bras gauche
x2 Panel del brazo izquierdo
x2 Right Arm Panel
x2 Panneau de bras droit
x2 Panel del brazo derecho
x1 M6 Allen Key *
x1 Clé allen m6
x1 Llave allen M6
J
Made in China / Fabriqué au Chine / Hecho en China
Residential Use Only
* Replaceable Part
DESCRIPTION / DESCRIPCIÓN : (1 of 2) (1 sur 2) / (1 de 2) Slat Back Outdoor Set / Jeu d'extérieur Slat Back Conjunto al aire libre de la espalda del listón

C
A
G
I
J
Steps 1-2.
Lay Left Arm Panel (A) on it's side on
a soft dry surface. Add chair Seat
Panel (C) aligning the bolt holes with
those on the left arm panel. Add
Washer (I) to 25mm length Bolt (G).
Use provided Allen Wrench (J) to
tighten, but do not tighten completely.
Now add Right Arm Panel (B)
aligning the bolt holes and repeat the
bolt tightening process. Make sure
the arm and seat panels are aligned
and tighten bolts completely.
Step 3.
Add the Back Panel (D) to the
assembled parts (A,B&C) aligning the
bolt holes. Add Washer (I) to 35mm
length Bolt (H). Insert into the bolt
holes as shown in the diagram and
use the provided Allen Wrench (J) to
tighten, but do not tighten completely.
Once all four bolts have been added,
make sure the back is aligned with the
arm panels and tighten bolts
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D322-700-1
Step1 Step2
Step3
Made in China / Fabriqué au Chine / Hecho en China
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE
Page 2 of 3
G
I
J
C
B
A
C
A
B
D
H
I
J
Residential Use Only
* Replaceable Part
Step4
Add Seat Cushion (E) and Back Cushion (F).
E
F
completely.
Step 4. Make sure all bolts are ightened completely.
DESCRIPTION / DESCRIPCIÓN : (1 of 2) (1 sur 2) / (1 de 2) Slat Back Outdoor Set / Jeu d'extérieur Slat Back Conjunto al aire libre de la espalda del listón

x1 RDS-D322-700-HWKIT - Hardware Kit *
Liste des pièces de quincaillerie
Lista del kit de materiales
Made in China / Fabriqué au Chine / Hecho en China
Page 3 of 3
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D322-700-1
* Replaceable Part
REPLACEABLE PARTS / PARTIE REMPLAÇABLE / PARTE REEMPLAZABLE
Residential Use Only
DESCRIPTION / DESCRIPCIÓN : (1 of 2) (1 sur 2) / (1 de 2) Slat Back Outdoor Set / Jeu d'extérieur Slat Back Conjunto al aire libre de la espalda del listón
