Accentrics Home DS-D474-701-1 User manual

PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
Made in China / Fabriqué au Chine / Hecho en China
Residential Use Only
* Replaceable Part
C
x1 Chair Seat Panel
x1 Panneau de siège de chaise
x1 Panel del asiento de la silla
D
x1 Chair Back Panel
x1 Panneau arrière de la chaise
x1 Panel trasero de la silla
B
G
J
Page 1 of 3
x1 Left Arm Panel
x1 Panneau du bras gauche
x1 Panel del brazo izquierdo
x1 Right Arm Panel
x1 Panneau de bras droit
x1 Panel del brazo derecho
E
H
A
x14(Extra 2) M6 Washer *
x14(Extra 2) Rondelle M6
x14(Extra 2) Lavadora M6
F
I
x1 M6 Allen Key *
x1 Clé allen m6
x1 Llave allen M6
x1 Seat Cushion
x1 Coussin de siege
x1 Cojín del asiento
x1 Back Cushion
x1 coussin de dos
x1 Amortiguador trasero
x4(Extra 1) M6*30mm Bolt *
x4(Extra 1) Boulon M6*30mm
x4(Extra 1) Perno M6*30mm
x10(Extra 1) M6*40mm Bolt *
x10(Extra 1) Boulon M6*40mm
x10(Extra 1) Perno M6*40mm
DESCRIPTION / DESCRIPCIÓN : Arm Chair / Fauteuil / Sillón m.
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D474-701-1

Residential Use Only
* Replaceable Part
Step 3.
After making sure that all parts are aligned properly, and all bolts
are tightened completely, turn the sofa upright on it's legs. Add
Seat Cushions (E) and Back Cushions (F).
Your assembly is now complete. Enjoy!
Step 1.
Align the bolt holes in Back Panel
(D) with those of Right Arm (B).
Add Washer (I) to 40mm Bolt (H).
From the inside of Back Panel (D)
insert the bolts into the holes and
tighten with Allen Key (J) provided,
but do not tighten completely.
Repeat this step to attach Left Arm
Panel (A).
Step 2.
Note that the four shorter 30mm
bolts (G) will be used on to attach
the front edge of Seat Panel (C).
Add Seat Panel (C) to assembled
parts (A,B,D). Add Washer (I) to
30mm Bolts (G). Insert into the
holes on the front edge of Seat
Panel (C) and tighten with Allen
Key (J). Add Washer (I) to 40mm
Bolts (H). Insert into remaining 6
holes in the sides and back of
Seat Panel (C). Use Allen Key (J)
to tighten all bolts completely.
DESCRIPTION / DESCRIPCIÓN : Arm Chair / Fauteuil / Sillón m.
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D474-701-1
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE
Step1
Step3
Made in China / Fabriqué au Chine / Hecho en China
Page 2 of 3
J
A
B
D
HI
F
E
Step2
A
C
BD
J
J
II
H
G

Page 3 of 3
REPLACEABLE PARTS / PARTIE REMPLAÇABLE / PARTE REEMPLAZABLE
* Replaceable Part
Made in China / Fabriqué au Chine / Hecho en China
x1 RDS-D474-701-HWKIT - Hardware Kit *
Liste des pièces de quincaillerie
Lista del kit de materiales
Residential Use Only
DESCRIPTION / DESCRIPCIÓN : Arm Chair / Fauteuil / Sillón m.
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D474-701-1
