Accentrics Home DS-D476-700-1 User manual

Residential Use Only
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
* Replaceable Part
Made in China / Fabriqué au Chine / Hecho en China
C
x1 Loveseat Seat Panel
x1 Panneau de siège de loveseat
x1 Panel del asiento del loverset
D
x1 Loveseat Back Panel
x1 Panneau arrière de la loveseat
x1 Panel trasero de la loverset
B
I
x1 Left Arm Panel
x1 Panneau du bras gauche
x1 Panel del brazo izquierdo
x1 Right Arm Panel
x1 Panneau de bras droit
x1 Panel del brazo derecho
G
J
A
H
x1 M6 Allen Key *
x1 Clé allen m6
x1 Llave allen M6
x2 Seat Cushion
x2 Coussin de siege
x2 Cojín del asiento
x2 Back Cushion
x2 coussin de dos
x2 Amortiguador trasero
x18(Extra 1) M6*25mm Bolt *
x18(Extra 1) Boulon M6*25mm
x18(Extra 1) Perno M6*25mm
DESCRIPTION / DESCRIPCIÓN : Loveseat & Coffee Table / Amant & Table à café / Constelación de amantes & Mesa de café
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D476-700-1
Page 1 of 4
L
x8(Extra 1) M6 Spring Washer *
x8(Extra 1) Rondelle à ressort M6
x8(Extra 1) Cojinetes de resorte M6
E
x1 Table Panel
x1 Panneau de table
x1 Panel de mesa
F
x4 Table Leg *
x4 Pied de table
x4 Pata de la mesa
K
x18(Extra 1) M6 Washer *
x18(Extra 1) Rondelle M6
x18(Extra 1) Lavadora M6

Residential Use Only
* Replaceable Part
Step4
Step1 Step2
Step3
Made in China / Fabriqué au Chine / Hecho en China
Page 2 of 4
I
J
L
L
I
J
L
I
J
L
I
J
AA
A A
B
C
C
C
C
D
D
D
Step 1. Add Flat Washer (J) to
25mm Bolt (I). Attach Arm Panel
(A) to Seat Panel (C) by inserting
bolts and washers as shown
using Allen Wrench (L).
Step 2. Add Flat Washer (J) to
25mm Bolt (I). Attach Back Panel
(D) to Arm Panel (A) by inserting
bolts and washers as shown
using Allen Wrench (L).
Step 3. Add Flat Washer (J) to
25mm Bolt (I). Secure Seat Panel
(C) to Back Panel (D) by inserting
bolts and washers as shown
using Allen Wrench (L).
Step 4. Add Flat Washer (J) to
25mm Bolt (I). Attach Arm Panel
(B) to Seat Panel (C) by inserting
bolts and washers as shown
using Allen Wrench (L).
DESCRIPTION / DESCRIPCIÓN : Loveseat & Coffee Table / Amant & Table à café / Constelación de amantes & Mesa de café
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D476-700-1
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE

Residential Use Only
* Replaceable Part
Made in China / Fabriqué au Chine / Hecho en China
Page 3 of 4
Step8
Step5 Step6
Step7
JIL
GG
HH
A
B
D
E
F
F
F
F
L
J
K
I
Step 5. Add Flat Washer (J) to
25mm Bolt (I). Secure Back
Panel (D) to Arm Panel (B) by
inserting bolts and washers as
shown using Allen Wrench (L).
Step 6. Make sure that all bolt
sare completely tightened, then
add Seat Cushions (G) and
Back Cushions (H).
Step 7. Add Spring Washer (K)
to 25mm Bolt (I), then add Flat
Washer (J). Attach Legs (F) to
Table Panel (E) using Allen
Wrench (L). Two bolts will be
used for each leg. Tighten all
bolts completely.
Step 8. Turn assembled table
over on it's legs.
DESCRIPTION / DESCRIPCIÓN : Loveseat & Coffee Table / Amant & Table à café / Constelación de amantes & Mesa de café
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D476-700-1
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE

Residential Use Only
DESCRIPTION / DESCRIPCIÓN : Loveseat & Coffee Table / Amant & Table à café / Constelación de amantes & Mesa de café
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D476-700-1
Page 4 of 4
REPLACEABLE PARTS / PARTIE REMPLAÇABLE / PARTE REEMPLAZABLE
* Replaceable Part
Made in China / Fabriqué au Chine / Hecho en China
x1 RDS-D476-700-HWKIT - Hardware Kit *
Liste des pièces de quincaillerie
Lista del kit de materiales
x4 RDS-D476-700-TABLE LEG - Table Leg *
Pied de table
Pata de la mesa
