Accentrics Home DS-D419-006A User manual

X1 Top panel
X1 Techo
X1 Le toit
X1 Back panel
X1 Placa posterior
X1 Fond de panier
X1 Left side panel
X1 Panel izquierdo
X1 Panneau gauche
X1 Adjustanle shelf
X1 Plateau regltable
X1 Estantc ajustable
X1 Right side panel
X1 Panel lateral derecho
X1 Panneau lateral droit
X1 Right door
X1 Porte droite
X1 Derecho puerta
X1 Bottom panel
X1 Panncau inferieur
X1 Panel inferior
X2 Knob
X2 Bouton
X2 Perilla
X4 Wood dowel ( 8x30mm)
X4 Goujons de bois ( 8x30mm)
X4 Tarugo de madera ( 8x30mm)
X4 Shelf support Ø6.5mm
X4 Soporte laminado Ø6.5mm
X4 Support en stratifies Ø6.5mm
X2 Handle screw Ø5/32"*15mm
X2 Tornillo de la manija Ø5/32"*15mm
X2 Vis de poignee Ø5/32"*15mm
X1 Left door
X1 Porte droite
X1 Derecho puerta
AE1
BF2
3
G
C
DH4
PARTS LIST/ LISTE DES PIÈCES/ LISTA DE PIEZAS
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-006A
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: BLUE KD TWO DOOR CHEST / KD DEUX PORTES COFFRE/PECHO DE DOS PUERTAS KD
Page 1 of 5 Residential Use only Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
***
*
*
*
***
*
*
*

Step 1.
Lay down Bottom Panel (Part D) as shown,
attach the L/R Side Panels (Parts B&C) into Bottom
panel and press down to secure into place making sure
that the holes in the side panels are facing inward.
Step 2.
Insert Wood dowels (Part 2) on the Bottom
Panel (Part D) and attach the Back Panel (Part E)
into L/R Side Panels (Parts B&C) and press down
to secure into place. Make sure that the tops of the
back and side panels are flushed.
* Replaceable Part
Page 2 of 5 Residential Use only Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-006A
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: BLUE KD TWO DOOR CHEST / KD DEUX PORTES COFFRE/PECHO DE DOS PUERTAS KD

Step 3.
Insert Shelf Supports (Part 3) into the holes as shown.
Then, insert the Adjustable Shelf (Part F) into the
cabinet to the position where there are shelf supports.
Step 4.
Align the hinges on the Left & Right Doors (Parts
H&G) with the hinges on the side panels (Parts B&C).
Press down to secure them into place.
* Replaceable Part
Page 3 of 5 Residential Use only Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-006A
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: BLUE KD TWO DOOR CHEST / KD DEUX PORTES COFFRE/PECHO DE DOS PUERTAS KD

Step 5.
Insert the Handle Screws for the Knob (Part 4) into the
holes from the back side of the doors. Add the
Knob (Part 1) and turn the handle screws clockwise to
tighten. You will need a phillips head screw driver to tighten completely.
Step 6.
Insert Wood Dowels (Part 2) on the top of
frame. Make sure that all of the switch locking
hardware in the panels are in the open position as indicąted by the straight arrow in the diagram. Align
the hardwares in the Top Panel (Part A) with the
hardwares on the top of frame and press down so make sure the top panel is flushed with the panels. Lock|the top panel into place by turning the switches indicated the by the curved arrow in the diagram below.
* Replaceable Part
Page 4 of 5 Residential Use only Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-006A
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: BLUE KD TWO DOOR CHEST / KD DEUX PORTES COFFRE/PECHO DE DOS PUERTAS KD

A
B
E1
F2
3
G
C
DH4
* Replaceable Part
Page 5 of 5 Residential Use only
Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
REPLACEABLE PART / PARTIE REMPLACABLE / PARTE REEMPLAZABLE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-006A
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: BLUE KD TWO DOOR CHEST / KD DEUX PORTES COFFRE/PECHO DE DOS PUERTAS KD
x1 RD419-006A-TOP
Top panel
Techo
Le toit
x1 RD419-006A-BPAN
Back panel
Placa posterior
Fond de panier
x2 RD419-006A-KNOB
Knob
Bouton
Perilla
x1 RD419-006A-LSPAN
Left side panel
Panel izquierdo
Panneau gauche
x1 RD419-006A-SHELF
Adjustanle shelf
Plateau regltable
Estantc ajustable
X4 RD419-006A-DOWEL
Wood dowel ( 8x30mm)
Goujons de bois ( 8x30mm)
Tarugo de madera ( 8x30mm)
x1 RD419-006A-RSPAN
Right side panel
Panel lateral derecho
Panneau lateral droit
x1 RD419-006A-RDOOR
Right door
Porte droite
Derecho puerta
x4 RD419-006A-SUPP
Shelf support Ø6.5mm
Soporte laminado Ø6.5mm
Support en stratifies Ø6.5mm
x1 RD419-006A-OPANE
Bottom panel
Panncau inferieur
Panel inferior
x1 RD419-006A-LDOOR
Left door
Porte droite
Derecho puerta
x2 RD419-006A-SCREW
Handle screw Ø5/32"*15mm
Tornillo de la manija Ø5/32"*15mm
Vis de poignee Ø5/32"*15mm
