Accentrics Home DS-D477-701-1 User manual

Residential Use Only
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
x16(Extra 1) M6 Washer *
x16(Extra 1) Rondelle M6
x16(Extra 1) Lavadora M6
C
x2 Chair Seat Panel
x2 Panneau de siège de chaise
x2 Panel del asiento de la silla
D
x2 Chair Back Panel
x2 Panneau arrière de la chaise
x2 Panel trasero de la silla
B
G
x2 Left Arm Panel
x2 Panneau du bras gauche
x2 Panel del brazo izquierdo
x2 Right Arm Panel
x2 Panneau de bras droit
x2 Panel del brazo derecho
E
H
A
F
x1 M6 Allen Key *
x1 Clé allen m6
x1 Llave allen M6
x2 Seat Cushion
x2 Coussin de siege
x2 Cojín del asiento
x2 Back Cushion
x2 coussin de dos
x2 Amortiguador trasero
x16(Extra 1) M6*35mm Bolt *
x16(Extra 1) Boulon M6*35mm
x16(Extra 1) Perno M6*35mm
DESCRIPTION / DESCRIPCIÓN : Arm Chairs X 2 / Fauteuil X 2 / Sillón X 2
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D477-701-1
Page 1 of 4
I
Made in China / Fabriqué au Chine / Hecho en China
* Replaceable Part

Residential Use Only
A
A
A
A
B
B
CC
C
C
D
D
I
I
I
I
G
G
G
G
H
H
H
H
Step4
Step1 Step2
Step3
Made in China / Fabriqué au Chine / Hecho en China
Page 2 of 4
DESCRIPTION / DESCRIPCIÓN : Arm Chairs X 2 / Fauteuil X 2 / Sillón X 2
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D477-701-1
Step 1. Add Washer (H) to 35mm
bolts (G). Align the holes on Arm
Panel (A) with Seat Panel (C).
Insert the bolts with washers and
tighten with Allen Wrench (I).
Step 2. Add Washer (H) to 35mm
bolts (G). Align the holes on Back
Panel (D) with Arm Panel (A).
Insert the bolts with washers and
tighten with Allen Wrench (I).
Step 3. Add Washer (H) to 35mm
bolts (G). Align the holes on Arm
Panel (B) with Back Panel (D).
Insert the bolts with washers and
tighten with Allen Wrench (I).
Step 4. Add Washer (H) to 35mm
bolts (G). Align the holes on Seat
Panel (C) with Arm Panel (B).
Insert the bolts with washers and
tighten with Allen Wrench (I).
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE
* Replaceable Part

Residential Use Only
E
F
Step5
Made in China / Fabriqué au Chine / Hecho en China
Page 3 of 4
DESCRIPTION / DESCRIPCIÓN : Arm Chairs X 2 / Fauteuil X 2 / Sillón X 2
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D477-701-1
Step 5. Make sure all bolts are
tightened completely. Add Seat
Cushion (E) and Back Cushion (F).
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE
* Replaceable Part

Residential Use Only
x1 RDS-D477-701-HWKIT - Hardware Kit *
Liste des pièces de quincaillerie
Lista del kit de materiales
Made in China / Fabriqué au Chine / Hecho en China
Page 4 of 4
DESCRIPTION / DESCRIPCIÓN : Arm Chairs X 2 / Fauteuil X 2 / Sillón X 2
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D477-701-1
* Replaceable Part
REPLACEABLE PARTS / PARTIE REMPLAÇABLE / PARTE REEMPLAZABLE
