Accton Technology CheetahSwitch Workgroup-3514F Programming manual

CheetahSwitch Workgroup-3514F
CheetahSwitch Workgroup-3526F
CheetahSwitch Workgroup-3526G
Management Guide

Management Guide
CheetahSwitch Workgroup-3514F
Intelligent/Stackable Fast Ethernet Switch
with 12 10BASE-T / 100BASE-TX (RJ-45) Ports,
and Optional Media Expansion and Stack Modules
CheetahSwitch Workgroup-3526F
Intelligent/Stackable Fast Ethernet Switch
with 24 10BASE-T / 100BASE-TX (RJ-45) Ports,
and Optional Media Expansion and Stack Modules
CheetahSwitch Workgroup-3526G
Intelligent Fast Ethernet Switch
with 24 10BASE-T / 100BASE-TX (RJ-45) Ports,
and Optional Media Expansion Modules

Accton is a trademark of Accton Technology Corporation. Other trademarks or brand names mentioned
herein are trademarks or registered trademarks of their respective companies.
International Headquarters
No. 1 Creation Road III,
Science-based Industrial Park
Hsinchu 300, Taiwan, R.O.C.
Phone: [phone]
FAX: [phone]
Internet: [e-mail]
USA Headquarters
6 Hughes
Irvine, CA 92618
Phone Numbers -
Sales: 800-926-9288
Support: 888-398-4101 or 949-707-4847
RMA: 800-762-4968
FAX: [phone]
Copyright © 2000 by Accton Technology Corporation. All rights reserved.
No part of this document may be copied or reproduced in any form or by any means without the prior written
consent of Accton Technology Corporation.
Accton makes no warranties with respect to this documentation and disclaims any implied warranties of mer-
chantability, quality, or fitness for any particular purpose. The information in this document is subject to
change without notice. Accton reserves the right to make revisions to this publication without obligation to
notify any person or entity of any such changes.
ES3514F
ES3526F
ES3526G
E072000-R04
F2.2 150074-102

i
Contents
Chapter 1: Switch Management 1-1
Configuration Options 1-1
Required Connections 1-1
Console Port (Out-of-Band) Connections 1-1
Remote Management via the Console Port 1-2
Configure the Switch Site 1-2
Configure the Remote Site 1-2
In-Band Connections 1-2
Chapter 2: Using the System Configuration Program 2-1
Login Screen 2-1
Main Menu 2-3
System Information Menu 2-5
Displaying System Information 2-6
Displaying Switch Version Information 2-7
Management Setup Menu 2-8
Changing the Network Configuration 2-9
IP Configuration 2-10
IP Connectivity Test (Ping) 2-11
HTTP Configuration 2-12
Configuring the Serial Port 2-13
Assigning SNMP Parameters 2-14
Configuring Community Names 2-15
Configuring IP Trap Managers 2-16
Console Login Configuration 2-17
Downloading System Software 2-18
Using TFTP to Download Over the Network 2-18
Configuring the Switch 2-19
Configuring Port Parameters 2-20
Viewing the Current Port Configuration 2-21
Using the Spanning Tree Algorithm 2-22
Configuring Bridge STA 2-22
Configuring STA for Ports 2-24
Viewing the Current Spanning Tree Information 2-25
Displaying the Current Bridge STA 2-26
Displaying the Current STA for Ports 2-27
Using a Mirror Port for Analysis 2-28
Configuring Port Trunks 2-29
IGMP Multicast Filtering 2-31
Configuring IGMP 2-31
Configuring Bridge MIB Extensions 2-32

Contents
ii
Configuring Traffic Classes 2-33
Port Priority Configuration 2-34
802.1p Port Traffic Class Information 2-35
Configuring Virtual LANs 2-36
802.1Q VLAN Base Information 2-36
802.1Q VLAN Current Table Information 2-37
802.1Q VLAN Static Table Configuration 2-38
802.1Q VLAN Port Configuration 2-40
Monitoring the Switch 2-41
Displaying Port Statistics 2-42
Displaying RMON Statistics 2-43
Displaying the Unicast Address Table 2-45
Displaying the IP Multicast Registration Table 2-46
Configuring Static Unicast Addresses 2-47
Resetting the System 2-48
Logging Off the System 2-48
Chapter 3: Web-Based Management 3-1
Web-Based Configuration and Monitoring 3-1
Navigating the Web Browser Interface 3-2
Home Page 3-2
Configuration Options 3-3
Panel Display 3-3
Port State Display 3-4
Console Configuration 3-5
Main Menu 3-6
System Information 3-7
Switch Information 3-8
Main Board 3-8
Agent Module 3-8
Expansion Slot 3-8
IP Configuration 3-9
SNMP Configuration 3-10
SNMP Community 3-10
Trap Managers 3-11
Security Configuration 3-11
Change Password 3-11
Firmware Upgrade Options 3-12
Web Upload Management 3-12
TFTP Download Management 3-12
Address Table Configuration 3-13
Spanning Tree Algorithm (STA) 3-14
Spanning Tree Information 3-14
Spanning Tree 3-14
Ports 3-15

Contents
iii
Spanning Tree Configuration 3-16
Switch 3-16
When the Switch Becomes Root 3-16
STA Port Configuration 3-17
Configuring Bridge MIB Extensions 3-18
Bridge Capability 3-18
Bridge Settings 3-19
Priority 3-20
Port Priority Configuration 3-20
Port Traffic Class Information 3-21
Configuring Virtual LANs 3-22
VLAN Basic Information 3-22
VLAN Current Table 3-23
VLAN Static List 3-24
VLAN Static Table 3-25
VLAN Static Membership by Port 3-27
VLAN Port Configuration 3-28
IGMP Multicast Filtering 3-29
Configuring IGMP 3-29
IP Multicast Registration Table 3-30
Port Menus 3-31
Port Information 3-31
Port Configuration 3-32
Using a Port Mirror for Analysis 3-33
Port Trunk Configuration 3-34
Port Statistics 3-36
Etherlike Statistics 3-36
RMON Statistics 3-37
Chapter 4: Advanced Topics 4-1
Layer-2 Switching 4-1
Spanning Tree Algorithm 4-1
Virtual LANs 4-2
Assigning Ports to VLANs 4-3
Port Overlapping 4-3
Automatic VLAN Registration (GVRP) 4-3
Forwarding Traffic with Unknown VLAN Tags 4-4
Forwarding Tagged/Untagged Frames 4-4
Connecting VLAN Groups 4-4
Multicast Filtering 4-5
IGMP Snooping 4-5
IGMP Protocol 4-5
Class-of-Service (CoS) Support 4-6
Port Trunks 4-6
SNMP Management Software 4-6
Remote Monitoring 4-7

Contents
iv
Appendix A: Troubleshooting A-1
Troubleshooting Chart A-1
Upgrading Firmware via the Serial Port A-2
Appendix B: Pin Assignments B-1
Console Port Pin Assignments B-1
DB-9 Port Pin Assignments B-1
Console Port to 9-Pin COM Port on PC B-2
Console Port to 25-Pin DCE Port on Modem B-2
Console Port to 25-Pin DTE Port on PC B-2

1-1
Chapter 1: Switch Management
Configuration Options
For advanced management capability, the SNMP/RMON Module provides a
menu-driven system configuration program. This program can be accessed by a
direct or modem connection to the serial port on the rear panel (out-of-band), or by a
Telnet connection over the network (in-band).
The management agent is based on SNMP (Simple Network Management
Protocol). This SNMP agent permits the switch to be managed from any PC in the
network using in-band management software (such as Accton’s AccView).
The management agent also includes an embedded HTTP Web agent. This Web
agent can be accessed using a standard Web browser from any computer attached
to the network.
The system configuration program and the SNMP agent support management
functions such as:
• Enable/disable any port
• Set the communication mode for any port
• Configure SNMP parameters
• Configure VLANs or multicast filtering
• Display system information or statistics
• Configure the switch to join a Spanning Tree
• Download system firmware
• Restart the system
Required Connections
Console Port (Out-of-Band) Connections
Attach a VT100 compatible terminal or a PC running a terminal emulation program
to the serial port on the switch’s rear panel. Use the null-modem cable provided with
this package, or use a null modem connection that complies with the wiring
assignments shown in Appendix B of this guide.
When attaching to a PC, set terminal emulation type to VT100, specify the port used
by your PC (i.e., COM 1~4), and then set communications to 8 data bits, 1 stop bit,
no parity, and 19200 bps (for initial configuration). Also be sure to set flow control to
“none.” (Refer to “Configuring the Serial Port” on page 2-13 for a complete
description of configuration options.)
Note: If the default settings for the management agent’s serial port have been
modified and you are having difficulty making a console connection, you can
display or modify the current settings using a Web browser as described under
“Console Configuration” on page 3-5.

Switch Management
1-2
Remote Management via the Console Port
Configure the Switch Site
Connect the switch’s DB9 serial port to the modem’s serial port using standard
cabling. For most modems which use a 25-pin port, you will have to provide an
RS-232 cable with a 9-pin connector on one end and a 25-pin connector on the
other end. Set the modem at the switch’s site to force auto-answer mode. The
following is a sample initialization string: “ATQ1S0=1&D0&K0&W” as defined below:
Q1 : Inhibit result codes to DTE
S0=1 : Auto answer on first ring
D0 : Don’t care DTR
K0 : Disables DTE/DCE flow control
W : Write command to modem memory
Configure the Remote Site
At the remote site, connect the PC’s COM port (COM 1~4) to the modem’s serial
port. Set terminal emulation type to VT100, specify the port used by your PC (i.e.,
COM 1~4), and then set communications to 8 data bits, 1 stop bit, no parity, 19200
bps and no flow control.
In-Band Connections
Prior to accessing the Network Management Module via a network connection, you
must first configure it with a valid IP address, subnet mask, and default gateway
using an out-of-band connection or the BOOTP protocol.
After configuring the switch’s IP parameters, you can access the on-board
configuration program from anywhere within the attached network. The on-board
configuration program can be accessed using Telnet from any computer attached to
the network. The switch and stack can also be managed by any computer using a
Web browser (Internet Explorer 4.0, or Netscape Navigator 4.0 or above), or from a
network computer using network management software such as AccView.
Notes: 1. By default BOOTP is disabled. To enable BOOTP, see “IP Configuration” on
page 2-10.
2. Use the Network Configuration menu to specify the maximum number of
simultaneous Telnet sessions that are supported by the system (up to four).
3. The on-board program only provides access to basic configuration functions.
To access the full range of SNMP management functions, you must use
SNMP- based network management software, such as Accton’s free
AccView/Open software.

2-1
Chapter 2: Using the System Configuration Program
Login Screen
Once a direct connection to the serial port or a Telnet connection is established, the
login screen for the on-board configuration program appears as shown below.
If this is your first time to log into the configuration program, then the default user
names are “admin” and “guest,” with no password. The administrator has Read/
Write access to all configuration parameters and statistics. While the guest has
Read Only access to the management program.
You should define a new administrator password, record it and put it in a safe place.
Select Console Login Configuration from the Management Setup Menu and enter a
new password for the administrator. Note that passwords can consist of up to 11
alphanumeric characters and are not case sensitive.
Notes: 1. Based on the default configuration, a user is allowed three attempts to enter
the correct password; on the third failed attempt the current connection is
terminated.
2. The ES3526G does not support stacking.
Please disregard any references to the stack when using the ES3526G.
AAAAAAA
AAAAAAAAAA
AAAAA AAAA
AAAAA AAAA
AAAAA AAAA CCCCCCC CCCCCC TTTTTTTTTT OOOOOO NN NN
AAAAAAAAACCCCCCCCTTOOOONNNNN
AAAAA AAAA CC CC TT OO OO NN NN NN
AAAAA AAAA CC CC TT OO OO NN NN NN
AAAAA AAAAAAAA CC CC CC CC TT OO OO NN NNN
AAAAA AAAAAAAAA CCCCCCC CCCCCCC TT OOOOOO NN NN
CheetahSwitch Workgroup-3514/26
V2.12 04-17-2000 (c)Copyright 2000, Accton Technology Corp.
User name :
Password :

Using the System Configuration Program
2-2
After you enter the user name and password, you will have access to the system
configuration program as illustrated by the following menu hierarchy:
*Not implemented in this firmware release.

Main Menu
2-3
Main Menu
With the system configuration program you can define system parameters, manage
and control the switch, the connected stack and all its ports, or monitor network
conditions. The figure below of the Main Menu and the following table briefly
describe the selections available from this program.
Note: Options for the currently selected item are displayed in the highlighted area at the
bottom of the interface screen.
Main Menu
=========
System Information Menu...
Management Setup Menu...
Device Control Menu...
Network Monitor Menu...
Restart System Menu...
Exit
Use <TAB> or arrow keys to move. <Enter> to select.
Menu Description
System Information Menu
System Information Provides basic system description, including contact information.
Switch Information Shows hardware/firmware version numbers, power status, and
expansion modules used in the stack.
Management Setup Menu
Network Configuration Includes IP setup, Ping facility, HTTP (Web agent) setup, Telnet
configuration, and MAC address.
Serial Port Configuration Sets communication parameters for the serial port, including
management mode, baud rate, console time-out, and screen data
refresh interval.
SNMP Configuration Activates traps; and configures communities and trap managers.
Console Login Configuration Sets user names and passwords for system access, as well as the
invalid password threshold and lockout time.
TFTP Download Downloads new version of firmware to update your system (in-band).

Using the System Configuration Program
2-4
Device Control Menu
Port Configuration Enables any port, enables/disables flow control, and sets
communication mode to auto-negotiation, full duplex or half duplex.
Port Information Displays operational status, including link state, flow control method,
and duplex mode.
Spanning Tree Configuration Enables Spanning Tree Algorithm; also sets parameters for hello time,
maximum message age, switch priority, and forward delay; as well as
port priority, path cost, and fast forwarding.
Spanning Tree Information Displays full listing of parameters for the Spanning Tree Algorithm.
Port Mirror Configuration Sets the source and target ports for mirroring.
Port Trunking Configuration Specifies ports to group into aggregate trunks.
IGMP Configuration Configures IGMP multicast filtering.
Extended Bridge Configuration Displays/configures extended bridge capabilities provided by this
switch.
802.1P Configuration Configures default port priorities and queue assignments.
802.1Q VLAN
Base Information
Displays basic VLAN information, such as VLAN version number and
maximum VLANs supported.
802.1Q VLAN Current Table
Information
Displays VLAN groups and port members.
802.1Q VLAN Static Table
Configuration
Configures VLAN groups via static assignments, including setting port
members, or restricting ports from being dynamically added to a port by
the GVRP protocol.
802.1Q VLAN
Port Configuration
Displays/configures port-specific VLAN settings, including PVID,
ingress filtering, and GVRP.
Port GARP Configuration* Configures settings used in multicast filtering.
Port GMRP Configuration* Configures GMRP multicast filtering.
Network Monitor Menu
Port Statistics Displays statistics on network traffic passing through the selected port.
RMON Statistics Displays detailed statistical information for the selected port such as
packet type and frame size counters.
Unicast Address Table Provides full listing for unicast addresses, as well as search and clear
functions.
Multicast Address Registration
Table*
Provides full listing for multicast addresses, as well as search and clear
functions.
IP Multicast Registration Table Displays all the multicast groups active on this switch, including
multicast IP addresses and corresponding VLAN IDs.
Static Unicast Address Table
Configuration
Used to manually configure host MAC addresses in the unicast table.
Static Multicast Address Table
Configuration*
Used to manually configure host MAC addresses in the multicast table.
Restart System Restarts system with options to use POST, or to retain factory defaults,
IP settings, or user authentication settings.
Exit Exits the configuration program.
*Not implemented in this firmware release.
Menu Description

System Information Menu
2-5
System Information Menu
Use the System Information Menu to display a basic description of the switch,
including contact information, and hardware/firmware versions.
System Information Menu
=======================
System Information ...
Switch Information ...
<OK>
Use <TAB> or arrow keys to move. <Enter> to select
Menu Description
System Information Provides basic system description, including contact information.
Switch Information Shows hardware/firmware version numbers, power status, and
expansion modules used in the stack.

Using the System Configuration Program
2-6
Displaying System Information
Use the System Information screen to display descriptive information about the
switch, or for quick system identification as shown in the following figure and table.
System Information
==================
System Description : CheetahSwitch Workgroup-3514/3526
System Object ID : 1.3.6.1.4.1.259.6.10.9
System Up Time : 48067 (0 day, 1 hr, 2min, 34 sec)
System Name : DEFAULT SYSTEM NAME
System Contact : DEFAULT SYSTEM CONTACT
System Location : DEFAULT SYSTEM LOCATION
<APPLY> <OK> <CANCEL>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter Description
System Description System hardware description.
System Object ID MIB II object identifier for switch’s network management subsystem.
System Up Time Length of time the current management agent has been running.
(Note that the first value is 1/100 seconds.)
System Name* Name assigned to the switch system.
System Contact* Contact person for the system.
System Location* Specifies the area or location where the system resides.
*Maximum string length is 99, but the screen only displays 45 characters. You can use the arrow keys to
browse the whole string.

System Information Menu
2-7
Displaying Switch Version Information
Use the Switch Information screen to display hardware/firmware version numbers
for the main board, as well as the power status.
Switch Information : Unit 1
==================
Main Board
Hardware Version : V3.0
Firmware Version : V1.11
Serial Number : 00-CB-00-00-00-00
Port Number : 24
Internal Power Status : Active
Redundant Power Status : Inactive
Expansion Slot 1 : ---------------------
Expansion Slot 2 : ---------------------
Agent Module
Hardware Version : V3.0 (801 CPU)
POST ROM Version : V1.10
Firmware Version : V2.12
SNMP Agent : Master
<OK> <PREV UNIT> <NEXT UNIT>
Use <TAB> or arrow keys to move. <Enter> to select
Parameter Description
Main Board
Hardware Version Hardware version of the main board.
Firmware Version System firmware version in ROM.
Serial Number The serial number of the main board.
Port Number Number of built-in ports.
Internal Power Status Indicates if the primary power is active or inactive.
Redundant Power Status Indicates if the redundant power is active or inactive.
Expansion Slot 1 Shows module type if inserted
(100BASE-FX or 1000BASE-SX).
Expansion Slot 2* Shows module type if inserted
(100BASE-FX or 1000BASE-SX or 4GB Stack).
Agent Module
Hardware Version Hardware version of the agent module.
POST ROM Version Power-On Self-Test version number.
Firmware Version Firmware version of the agent module.
SNMP Agent Shows if this module is Master or Backup Master.
* Stacking is not supported on the ES3526G.

Using the System Configuration Program
2-8
Management Setup Menu
After initially logging onto the system, adjust the communication parameters for your
console to ensure a reliable connection (Serial Port Configuration). Specify the IP
addresses for the switch (Network Configuration / IP Configuration), and then set the
Administrator and User passwords (Console Login Configuration). Remember to
record them in a safe place. Also set the community string which controls access to
the on-board SNMP agent via in-band management software (SNMP Configuration).
The items provided by the Management Setup Menu are described in the following
sections.
Management Setup Menu
=====================
Network Configuration ...
Serial Port Configuration ...
SNMP Configuration ...
Console Login Configuration ...
TFTP Download ...
<OK>
Use <TAB> or arrow keys to move. <Enter> to select.
Menu Description
Network Configuration Includes IP setup, Ping facility, HTTP (Web agent) setup, Telnet
configuration, and MAC address.
Serial Port Configuration Sets communication parameters for the serial port, including
management mode, baud rate, console time-out, and screen data
refresh interval.
SNMP Configuration Activates traps; and configures communities and trap managers.
Console Login Configuration Sets user names and passwords for system access, as well as the
invalid password threshold and lockout time.
TFTP Download Downloads new version of firmware to update your system (in-band).

Management Setup Menu
2-9
Changing the Network Configuration
Use the Network Configuration menu to set the bootup option, configure the switch’s
Internet Protocol (IP) parameters, enable the on-board Web agent, or to set the
number of concurrent Telnet sessions allowed. The screen shown below is
described in the following table.
Network Configuration
=====================
IP Configuration ...
IP Connectivity Test (Ping) ...
HTTP Configuration ...
MAX Number of allowed Telnet sessions (1 -4) : 4
MAC Address : 00-E0-29-52-28-00
<APPLY> <OK> <CANCEL>
Use <TAB> or arrow keys to move. <Enter> to select.
Parameter Description
IP Configuration Screen used to set the bootup option, or configure the switch’s IP
parameters.
IP Connectivity Test (Ping) Screen used to test IP connectivity to a specified device.
HTTP Configuration Screen used to enable the Web agent.
MAX Number of Allowed Telnet
Sessions
The maximum number of Telnet sessions allowed to simultaneously
access the agent module.
MAC Address Physical address of the agent module.

Using the System Configuration Program
2-10
IP Configuration
Use the IP Configuration screen to set the bootup option, or configure the switch’s IP
parameters. The screen shown below is described in the following table.
Network Configuration : IP Configuration
========================================
Interface Type : Ethernet
IP Address : 10.1.113.29
Subnet Mask : 255.255.0.0
Gateway IP :
IP State : USER-CONFIG
<APPLY> <OK> <CANCEL>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter Description
Interface Type Indicates IP over Ethernet.
IP Address IP address of the stack you are managing. The system supports SNMP over UDP/
IP transport protocol. In this environment, all systems on the Internet, such as
network interconnection devices and any PC accessing the agent module (or
running AccView) must have an IP address.
Valid IP addresses consist of four numbers, of 0 to 255, and separated by periods.
Anything outside of this format will not be accepted by the configuration program.
Subnet Mask Subnet mask of the switch you have selected. This mask identifies the host
address bits used for routing to specific subnets.
Default Gateway Gateway used to pass trap messages from the system’s agent to the management
station. Note that the gateway must be defined if the management station is
located in a different IP segment. The default value is null.
IP State Specifies whether IP functionality is enabled via manual configuration, or set by
Boot Protocol (BOOTP). Options include:
USER-CONFIG - IP functionality is enabled based on the default or user specified
IP Configuration. (This is the default setting.)
BOOTP Get IP - IP is enabled but will not function until a BOOTP reply has been
received. BOOTP requests will be periodically broadcast by the switch in an effort
to learn its IP address. (BOOTP values can include the IP address, default
gateway, subnet mask, and TFTP server IP.)
