Accuphase E-212 Operating and installation instructions

Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
Authorized Technical Service Only
These servicing instructions are for use by qualified personnel only.
To reduce the risk of electric shock do not perform any servicing
other than that contained in the operating instructions unless you are
qualified to do so. Refer all servicing to qualified service personnel.
ここに記載したサービスに関する指示事項は、サービスに関する資格を
有する者のみが使用するものです。感電防止の観点から、サービス資格
を有していない方は、取扱指示事項以外のサービスは絶対に行わないよ
うにして下さい。
CAUTION /
回路図

EXPLANATION OF SURFACE PARTS
Meter
ﾒｰﾀｰ
(178-2034-00)
Knob for INPUT
ﾂﾏﾐ
(381-4405-04)
Knob for VOLUME
ﾂﾏﾐ
(381-4406-04)
Push-button for POWER
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5044-03)
Push-button for TONE,ATT
ﾌﾟｯｼｭﾎﾞﾀﾝ/ MONO
(389-5077-03)
Knob /SP,TONE,COMP,TAPE,BAL
ﾂﾏﾐ /6pcs.
(384-1601-04)
Front Panel Assembly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0162-01)
Front Ａrcylic
ﾌﾛﾝﾄｱｸﾘﾙ
(172-0117-13)
Decoration Screw
飾りﾈｼﾞ/2pcs.
(630-0304-14)
Washer
ﾜｯｼｬ/2pcs.
(637-9045-04)
Case
ｹｰｽ
(100-0058-02)
Bottom Plate
ﾎﾞﾄﾑﾌﾟﾚｰﾄ
(155-0079-12)
Foot
脚
(238-0023-00)
Sub Panel
ｻﾌﾞﾊﾟﾈﾙ
(134-0131-03)
Panel End-cap
ﾊﾟﾈﾙｷｬｯﾌﾟ
(132-0109-04)
Head Phone Jack
ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ
(302-1204-00)
Head Phone Ass'y
ﾍｯﾄﾞﾎﾝAss'y
(716-0601-00)
－１－
Case
ｹｰｽ
(100-0058-02)
Rubber Cushion
ﾗﾊﾞｰｸｯｼｮﾝ
(250-2021-04)/2pcs.
(250-2082-04)/1pce.
Rubber Cushion
ﾗﾊﾞｰｸｯｼｮﾝ
(250-2021-04)/2pcs.
(250-2082-04)/1pce.
Spacer
ｽﾍﾟｰｻ
(250-1042-04)

FRONT VIEW
REAR VIEW
Speaker Terminal
SP端子
(313-1019-00)
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ /5pcs.
(302-0411-00)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞｰ/10pcs.
(254-2015-04)
Foot
脚
(238-0023-00)
Decoration Plate
ｽﾛｯﾄﾊﾟﾈﾙ
(159-0059-04)
Fixing Screw
飾りﾈｼﾞ/2pcs.
(630-0302-04)
XLR (Cannon) Receptacle
ｵｰﾃﾞｨｵｺﾈｸﾀｼﾞｬｯｸ/2pcs.
(302-8011-00)
Connector Cover / Female
ｺﾈｸﾀｶﾊﾞｰ/ 2pcs.
(254-2012-00)
AC Outlet
ACｿｹｯﾄ /J type only
(305-1205-00)
AC Inlet
AC ｺﾈｸﾀﾌﾟﾗｸﾞ
(301-3304-00)
＊Power Supply Cord
電源ｺｰﾄﾞ
J type:680-1204-00
U tyep:680-2401-00
E type:680-3402-00
Rear Panel
ﾊﾞｯｸﾊﾟﾈﾙ
(135-0151-02)
Front Panel Assembly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0162-01)
1 Front Panel=131-0162-01
ﾌﾛﾝﾄﾊﾟﾈﾙ
2 Sub-panel =134-0131-03
ｻﾌﾞﾊﾟﾈﾙ
3 Panel End Cap=132-0109-04
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
4 Front Arcylic=172-0117-13
ﾌﾛﾝﾄｱｸﾘﾙ
5 Decoration Screw=630-0304-14
飾りﾈｼﾞ
Washer =637-9045-04
ﾜｯｼｬ
6 Push-button=388-5044-03
ﾌﾟｯｼｭﾎﾞﾀﾝ /POWER
Coil Spring=285-1016-04
Frame=113-0100-04
1pce.
1pce.
2pcs.
1pce.
2pcs.
2pcs.
1pce.
1pce.
1pce.
7 Push-button=389-5077-03
ﾌﾟｯｼｭﾎﾞﾀﾝ /TONE,MONO,ATT
Coil Spring=285-1023-04
Frame=113-0111-04
8 Receiver Assembly=721-0064-00
受光器Ass'y
Frame=170-0058-12
ｴｽｶｯｼｮﾝ
9 Knob Base=170-0025-04/VOLUME
10 Knob Base=170-0039-03/INPUT
台座
3pcs.
3pcs.
3pcs.
1pce.
1pce.
1pce.
1pce.
1
2
10 4 5 9
376
3
8
Knob for VOLUME
ﾂﾏﾐ
(381-4406-04)
Head Phone Jack
ﾍｯﾄﾞﾌｫｰﾝｼﾞｬｯｸ
(302-1204-00)
Knob for INPUT
ﾂﾏﾐ
(381-4405-04)
Knob for SP,TONE,BAL,
ﾂﾏﾐ / TAPE
(384-1601-04)
－２－
7
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ /1pce.
(302-0209-00)

IO Relay Assembly
IOﾘﾚｰ Ass'y
(716-0593-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-3020-00)
Logic Assembly
ﾛｼﾞｯｸ Ass'y
(721-0063-00)
Input Selector Assembly
ｲﾝﾌﾟｯﾄｾﾚｸﾀ Ass'y
(716-0596-00)
Connector Board Assembly
ｺﾈｸﾀﾎﾞｰﾄﾞ Ass'y
(716-0594-00)
Volume Assembly
ﾎﾞﾘｭｰﾑ Ass'y
(716-0595-00)
Variable Resistor
可変抵抗器
(575-2020-00)
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0071-00)
Protection Assembly
ﾌﾟﾛﾃｸｼｮﾝ Ass'y
(720-0062-00)
Electrolytic Capacitor
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
C001,002:22,000μF/63V
(CE621WG1J223AAQ)
Terminal
端子
(313-4081-04)
Ceramic Capacitor
磁器ｺﾝﾃﾞﾝｻ
C005:0.01μF/400V
(CS17F2GA103MYAS)
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(716-0603-00)
*Power Push Switch
ﾌﾟｯｼｭｽｲｯﾁ
(354-1024-00)
*Fuse
T5A L AC250V /100-120V
(310-1502-00)
T2.5A L AC250V /220-240V
(310-1204-00)
Diode /D001
ﾀﾞｲｵｰﾄﾞ
(S10VB20)
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
Attenuator Assembly
ｱｯﾃﾈｰﾀ Ass'y
(716-0600-00)
－３－
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0071-00)
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0071-00)
Connector Board Assembly
ｺﾈｸﾀﾎﾞｰﾄﾞ Ass'y
(716-0594-00)
Tape Switch Assembly
ﾃｰﾌﾟｽｲｯﾁ Ass'y
(716-0598-00)
Tone Volume Assembly
ﾄｰﾝﾎﾞﾘｭｰﾑ Ass'y
(716-0597-00)
Switch Assembly
ｽｲｯﾁ Ass'y
(716-0599-00)
IO Relay Assembly
IOﾘﾚｰ Ass'y
(716-0593-00)
Protection Assembly
ﾌﾟﾛﾃｸｼｮﾝ Ass'y
(720-0062-00)
Thermal Switch Assembly
ｻｰﾏﾙｽｲｯﾁ Ass'y
(716-0614-00)

Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(716-0603-00)
Power Push Switch
ﾊﾟﾜｰｽｲｯﾁ
(354-1024-00)
Switch Assembly
ｽｲｯﾁAss'y
(716-0599-00)
* Push Switch
ﾌﾟｯｼｭｽｲｯﾁ /S2:MODE
(354-1218-00)
* Push Switch
ﾌﾟｯｼｭｽｲｯﾁ /S1:TONE
(354-1412-00)
Variable Resistor
可変抵抗器/VR1:50kΩ-A
(575-2020-00)
Volume Assembly
ﾎﾞﾘｭｰﾑ Ass'y
(716-0595-00)
Attenuator Assembly
ｱｯﾃﾈｰﾀ Ass'y
(716-0600-00)
Push Switch
ﾌﾟｯｼｭｽｲｯﾁ
(354-1218-00)
Tone Volume Assembly
ﾄｰﾝﾎﾞﾘｭｰﾑ Ass'y
(716-0597-00)
*Variable Resistor/TONE
可変抵抗器/VR1,2
(575-2405-00)
*Rotary Switch /SP
ﾛｰﾀﾘｽｲｯﾁ
(336-4010-10)
Tape Switch Assembly
ﾃｰﾌﾟｽｲｯﾁ Ass'y
(716-0598-00)
*Rotary Sw./COMP
(336-2007-00)/S2
*Rotary Sw./TAPE
(336-3010-10)/S1
*Variable Resistor
可変抵抗器/VR1:BAL
(575-2312-10)
Rotary Switch
ﾛｰﾀﾘｽｲｯﾁ / S1
(339-0002-00)
Input Selector Assembly
ｲﾝﾌﾟｯﾄｾﾚｸﾀ Ass'y
(716-0596-00)
Power Meter
ﾊﾟﾜｰﾒｰﾀ
(178-2034-00)
Meter Connector A'y
ﾒｰﾀｺﾈｸﾀAss'y
(716-0602-00)
Pilot Lamp 1
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ/PL1,2,3
(176-7501-00)
Receiver Assembly
受光器Ass'y
(721-0064-00)
Head Phone Assembly
ﾍｯﾄﾞﾎﾝ Ass'y
(716-0601-00)
Head Phone Jack
ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ
(302-1204-00)
Selector LED Assembly
ｾﾚｸﾀLED Ass'y
(716-0614-08)
Foot
脚
(238-0023-00)
－４－
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
S2 S1
S2
S1

MISCELLANEOUS(本体その他使用部品 ）
NO.
Screws for
ﾈｼﾞ類
Accessories
付属品
Description(部品名)
Front Panel / ﾌﾛﾝﾄﾊﾟﾈﾙ用
Binding Screw/ ﾊﾞｲﾝﾄﾞﾂﾒﾂｷ
Case / ｹｰｽ用
Binding Screw /ﾊﾞｲﾝﾄﾞﾈｼﾞ
Washer /平ﾜｯｼｬ
Bottom Plate /ﾎﾞﾄﾑﾌﾟﾚｰﾄ用
Binding Neil Screw
ﾊﾞｲﾝﾄﾞﾂﾒﾂｷﾈｼﾞ
Foot /脚用
Binding Screw /ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄ
Power Transformer/電源ﾄﾗﾝｽ
Binding Neil Screw
ﾊﾞｲﾝﾄﾞﾂﾒ付ﾀｯﾌﾟﾀｲﾄﾈｼﾞ
Option Panel /ｵﾌﾟｼｮﾝﾊﾟﾈﾙ
Decoration Bolt /飾りﾈｼﾞ
Nylon Washer /ﾅｲﾛﾝﾜｯｼｬ
Owner's Manual (多ヶ国語)
取扱説明書 (日本語)
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞ /RC-23
Battery / 電池
Power Supply Cord (J type)
電源ｺｰﾄﾞ (U type)
(E type)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞｰ
Connector Cover for female
ｺﾈｸﾀｶﾊﾞｰ(雌ﾀｲﾌﾟ用)
Parts No.(部品No.)
631-0047-00
604-0408-00
637-1041-02
631-0054-00
611-0414-02
631-0030-00
630-0302-00
637-9045-04
820-3203-00
820-0203-00
729-0023-00
569-0004-00
680-1204-00
680-2401-00
680-3402-00
254-2015-00
254-2012-00
Remarks(備考)
3×8mm 4pcs.
4×8mm 4pcs.
4mm dia. 4pcs.
3×10mm 2pcs.
4×14mm 4pcs.
4×8mm 4pcs.
4pcs.
4pcs.
Multi-lingual
Japanese
RC-23
R6/ UM-3 単3型
2-conductor
2-conductor
3-conductor
10pcs.
2pcs.
NO.
PL1～3
F1
VR1
C001,2
C005
Packing
Material
梱包材
Description(部品名)
PC Board for
IO Relay Assembly
Connector Board Ass'y
Volume Assembly
Tone Volume Assembly
Tape Switch Assembly
Switch Assembly
Power Amp Assembly
Protection Assembly
Logic Assembly
Pilot Lamp /3pcs.
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ
Fuse T5A L AC250V
ﾌｭｰｽﾞ T2.5A L AC250V
Variable Resistor
可変抵抗器
Electrolytic Capacitor
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Ceramic Capacitor
磁器ｺﾝﾃﾞﾝｻ
Outer Carton Box
ﾀﾞﾝﾎﾞｰﾙｹｰｽ
Side Pad (L)
Side Pad (R)
ｻｲﾄﾞﾊﾟｯﾄﾞ
Top Board
天地当板
Sub Pad
ｻﾌﾞﾊﾟｯﾄﾞ
Cover
保護ｶﾊﾞｰ
Case for Remote
ﾘﾓｺﾝｹｰｽ
Case for E type AC Cord
Eﾀｲﾌﾟ電源ｺｰﾄﾞｹｰｽ
Poly Bag
ﾋﾞﾆｰﾙ袋
Cord Cramper
ｺｰﾄﾞｸﾗﾝﾊﾟ
Parts No.(部品No.)
115-1319-00
115-1320-00
115-1321-00
115-1323-00
115-1324-00
115-1325-00
115-0133-00
115-1330-00
115-1331-00
176-7501-00
310-1502-00
310-1204-00
575-2020-00
CE621WG1J223AAQ
CS17F2GA103MYAS
801-0223-04
803-0264-00
803-0265-00
803-0033-14
803-0303-00
810-4843-04
801-0236-00
801-0059-13
812-2030-04
812-2435-04
812-0812-04
280-0003-10
Remarks(備考)
Receiver Ass'y
for 100-120V
for 220-240V
Volume Ass'y
22,000uF/63V
0.01uF/400V
E-type only
for AC Cord
for Manual
for Battery
for AC Cord
－5－
CD
TUNER
OPTION
LINE
LINE-BAL VOLUME Control
INPUT SELECTOR

IO Relay Assembly (716-0593-00)
Ass'y
Pin Jack 302-0411-00 JK1,2
ﾋﾟﾝｼﾞｬｯｸ 302-0209-00 JK5
XLR(Canon) Receptacle 302-8011-00 JK3,4
ｵｰﾃﾞｨｵｺﾈｸﾀｼﾞｬｯｸ
Connector Jack 308-0508-00 K1
ｺﾈｸﾀｼﾞｬｯｸ 308-0407-00 K2
308-0905-00 K3
Connector Terminal 314-3011-00 JK9
ｺﾈｸﾀﾌﾟﾗｸﾞﾀｰﾐﾅﾙ
IC UPC4570HA IC1
Relay 362-1212-00 RELAY1～7
ﾘﾚｰ
Ceramic Capacitor C12,13 CC92CH1H220J 22pF/50V
磁器ｺﾝﾃﾞﾝｻ C14,15 CC92CH1H100F 10pF/50V
Electrolytic Capacitor C1 ～7 CE04W1HR22VR 0.22uF /50V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C8～11 CE04W1E220VR 22uF /25V
C16～19 CE04W1E220AVF 22uF /25V
R1～8 RD142CA104J 100kΩ 1/6W
R9～16 RD142EA101J 100Ω 1/4W
Carbon Film Resistor R17 ～20,31,32 RD142EA104J 100kΩ 1/4W
炭素皮膜抵抗器 R21,22 RD142EA123G 12kΩ 1/4W
R29,30 RD142EA221J 220Ω 1/4W
R23,24 RD142EA243G 24kΩ 1/4W
Metal Film Resistor R25,26 RN142EK1212F 12.1kΩ 1/4W
金属被膜抵抗器 R27,28 RN142EK2432F 24.3kΩ 1/4W
K1IC1
RELAY2
Connector Jack 307-3204-00 K1
ｺﾈｸﾀｼﾞｬｯｸ 307-0317-00 K5
Connector Plug 308-0324-00 K2
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0207-00 K3
308-0530-00 K4
Diode 1SR139-400 D1,2:ﾀﾞｲｵｰﾄﾞ
Zener Diode RD3.0EB1 D3,4:ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
Transistor 2SC2785-EL,FL Q1,3
ﾄﾗﾝｼﾞｽﾀ 2SA1175-EL,FL Q2,4
IC Protector 310-8251-00 F1:2.5A
ICﾌﾟﾛﾃｸﾀ
C1,2 CE04W1E222VR 2,200uF /25V
Electrolytic Capacitor C3,4 CE04W1E102CA 1,000uF /25V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C5,6,9,10 CE04W1E470VR 47uF /25V
C7,8 CE04W1E101VR 100uF /25V
C11 CE04W1E220VR 22uF /25V
R1,2 RD142EA390J 39Ω 1/4W
Carbon Film Resistor R3,4 RD142EA332J 3.3kΩ 1/4W
炭素皮膜抵抗器 R5,6,11,12 RD142EA101JFS 100Ω 1/4W
R7,8 RD142EA101J 100Ω 1/4W
R9,10 RD142EA102JFS 1kΩ 1/4W
VR1
K3
C1
K2
K1
Q3
K5
－6－
Connector Board Assembly (716-0594-00)
Ass'y
JK3 JK4 JK2 JK5 JK1
RELAY3
RELAY4
K2 K3
RELAY6
RELAY7
RELAY1
RELAY5
K4
Q4
Q2
Q1
F1
C2C5
Volume Assembly (716-0595-00)
Ass'y
Connector Plug 308-0417-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0407-00 K2
308-0306-00 K3
Variable Resistor 575-2020-00 VR1:50kΩ
可変抵抗器
K1K2
K3
Input Selector Assembly (716-0596-00)
Ass'y
Connector Jack Assembly 309-2486-04 K1
ｺﾈｸﾀｼﾞｬｯｸAss'y
Rotary Switch 39-10002-00 S1
ﾛｰﾀﾘｽｲｯﾁ
S1
K1

Tone Volume Assembly (716-0597-00)
Ass'y
Connector Plug K1 308-0809-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K3 308-0412-00
K4 308-0311-00
Connector Jack K2 309-2235-00
ｺﾈｸﾀｼﾞｬｯｸAss'y
Rotary Switch 336-3010-10 S1
ﾛｰﾀﾘｽｲｯﾁ 336-2007-00 S2
Variable Resistor 575-2312-10 VR1
可変抵抗器
Polyester Film Capacitor C1,2 CF922N1H104JMTFF 0.1uF /50V
ﾎﾟﾘｴｽﾃﾙﾌｨﾙﾑｺﾝﾃﾞﾝｻ
Carbon Film Resistor R1､2 RD142EA332J 3.3kΩ 1/4W
炭素皮膜抵抗器
Connector Plug 308-1014-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0209-00 K2
308-0311-00 K3
Rotary Switch 336-4010-10 S1
ﾛｰﾀﾘｽｲｯﾁ
Variable Resistor 575-2405-10 VR1,2:
可変抵抗器
－７－
VR1
K1K2K3
S1
Tape Switch Assembly (716-0598-00)
Ass'y
K1
C1
VR2
C2
VR1S1S2
K3
K4
K2
Switch Assembly (716-0599-00)
Ass'y
Connector Plug K1 308-0206-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0514-00
K3 308-0412-00
Push Switch S1 354-1412-00
ﾌﾟｯｼｭｽｲｯﾁ S2 354-1218-00
K1
K2K3
S2
S1
Attenuator Assembly (716-0600-00)
Ass'y
Connector Plug 308-0417-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0407-00 K2
Push Switch 354-1218-00 S1
ﾌﾟｯｼｭｽｲｯﾁ
Carbon Film Resistor RD142CA513J R1,2 ;51kΩ 1/6W
炭素被膜抵抗器 RD142CA752J R3,4 ;7.5kΩ 1/6W
S1
K2
K1
Head Phone Assembly (716-0601-00)
Ass'y
Head Phone Jack 302-1204-00 JK1
ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ
Connector Plug 308-0311-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
K1
JK1

Thermal Switch Assembly (716-0612-00)
Ass'y
Receiver Assembly (721-0064-00)
Ass'y
Connector Plug 308-0209-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
Thermal Switch 369-0019-00 TS1
ｻｰﾏﾙｽｲｯﾁ
－８－
Mete
r
Connecto
r
A
ssembly (716-0602-00)
Ass'y
Fuse Holder 306-2001-00 FH1,2
ｺﾈｸﾀﾌﾟﾗｸﾞ
Power Push Switch 354-1024-00 S1
ﾊﾟﾜｰﾌﾟｯｼｭｽｲｯﾁ
Power Switch Assembly (716-0603-00)
Ass'y
S1
TS1
K1
K1
FH2
Connector Plug 308-0412-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
FH1
R1
IC1
PL2
PL1
PL3
K1
Infrared Ray Senser NJL62H380A IC1
赤外線ﾚｼｰﾊﾞ
Electorlytic Capacitor CE04W0J470MA 47uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Carbon Film Resistor R2 RD142EA470J 47Ω1/4W
炭素皮膜抵抗器
Oxide Metal Film R1 RS143FA680JS-P 130Ω3W
Resistor
金属酸化物被膜抵抗器
Pilot Lamp 176-7501-00 PL1,PL2,PL3
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ
Connector Plug 308-0530-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
Input Selector Assembly (716-0614-00)
Ass'y
Connector Plug 308-0708-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ
LED TLS-262-C D2,3,4,5,6
D6
K1
D5
D4
D3
D2

Logic Assembly (721-0063-00)
Ass'y
CE04W0J101VR C3,4:100uF /6.3V
CE04W1H2R2VR C5,6:2.2uF /50V
Electorlytic Capacitor CE04W1V4R7VR C11,12: 4.7uF /35V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ CE04W1H100AVF C13,14: 10uF /50V
CE04W1H100CA C17,18: 10uF /50V
CE04W1H220VR C19,20,33,35:22uF/50V
CE04W1E222RS C31:2,200uF /25V
CE04W1E471VR C32:470uF /25V
CE04W1E470VR C34:47uF /25V
CE04W1C101VR C36:100uF /16V
Polyester Film Capacitor CF922N1H104J C37:0.1uF/50V
積層ｺﾝﾃﾞﾝｻ
Polyester Film Capacitor CQ922M1H101K-B C1,2,9,10,15,16
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ :100pF/50v
Polypropylen Capacitor CQ922M2A271JAPFF C21,22:270pF/100V
ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝｺﾝﾃﾞﾝｻ
Carbon Film Resistor /炭素皮膜抵抗器
R5,6,19,20 RD142EA911J R37,38 RD142HA471GFS
R9,10 RD142EA102J R41 RD142CA100J
R21,22 RD142EA331J R42,51～56 RD142CA473J
R23,24 RD142EA103J R43 RD142EA332J
R25,26 RD142EA240J R44 RD142CA152J
R27,28 RD142EA105J R45 RD142CA101J
R29,30 RD142EA101J R46,47 RD142CA102J
R31,32 RD142HA121GFS R48,50 RD142CA105J
R33,34 RD142EA101J R49 RD142CA561J
R35,36 RD142EA393J R59 RD142CA473J
Resistor Array / 抵抗ｱﾚｨ
RA1 RD92AK07C473J18 RA2 RD92AK16C473J18
Metal Film Resistor / 金属被膜抵抗器
R1～4,17,18 RN142CK5491F R13,14 RN142CK1431F
R7,8 RN142CK5231F R15,16 RN142EK2551F
R11,12 RN142EK1541F
Oxide Metal Film Resistor / 金属酸化物被膜抵抗器
R57 RS143FA120JS-P R58 RS143FA330JS-P
－９－
K2 K1K3
308-0609-00 K1
308-1511-00 K2
Connector Plug 308-0213-00 K3
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0708-00 K4
308-0906-00 K5
308-0407-00 K6,10,11
308-0606-00 K7
308-0508-00 K8
308-0214-00 K9
IC Protector 310-8251-00 F1:2.5A
IC 426-0038-20 IC9
Crystal 527-0012-00 XTAL1
UPC4570HA IC1,2
NJM2114D IC3
IC TC74VHC14F IC4
M93C46-BN6 IC5
TD62003AP IC6
NJM78M05FA IC7
TC74HC595AF IC8
LB1642B IC10
Diode MA165 D1,3
ﾀﾞｲｵｰﾄﾞ 1SR139-400 D2
Transistor 2SC3902-S,T Q1
ﾄﾗﾝｼﾞｽﾀ
IC Protector 310-8251-00 F1:2.5A
ICﾌﾟﾛﾃｸﾀｰ
Crystal 527-0012-00 XTAL1
Ceramic Capacitor CK92Y5V1H104Z C38～41:0.1uF/50
V
磁器ｺﾝﾃﾞﾝｻ
Polyester Film Capacitor CF922N1H223JMTFF C7,8:0.022uF/50v
K4K5 IC10 F1 IC1
IC2
IC2
K11
IC6IC4
IC9
Q1
IC8
IC5
K9 K10
IC7
K8K7K6
Protection Assembly (720-0062-00)
Ass'y
Speaker Terminal 313-1019-00 K1
SP端子
308-0410-00 K2
Connector Plug 308-0707-00 K3
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0306-00 K4
308-0324-00 K5
Relay 362-3204-00 FRELAY1,2
ﾘﾚｨ 362-2232-00 RELAY3
Potentiometer 583-0524-00 VR1,2
半固定抵抗器
Diodes MA167 D1～4
ICs TA7318P-2 IC1
UPC1237HA IC2
Electorlytic Capacitor CE04W0J221VR C3: 220uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ CE04W1V4R7VR C4: 4.7uF /35V
CE04W0J101VR C5: 100uF /6.3V
Polyester Film Capacitor CF922N1H334J C1,2:0.3uF/50V
積層ｺﾝﾃﾞﾝｻ
Polypropylen Capacitor CQ922N2A223KAPH C6,7:0.022uF/100V
ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝｺﾝﾃﾞﾝｻ
Carbon Film Resistor /炭素皮膜抵抗器
R1,2 RD142EA101J R12,13,16 RD142EA473J
R3,4 RD142EA475J R14 RD142HA183JFS
R5,6 RD142EA273J R15 RD142EA243J
R11 RD142EA333J R21,25 RD142EA102J
Oxide Metal Film Resistor / 金属酸化物被膜抵抗器
R7,8 RS143DA362JS-P R19,20 RS143DA100JS-P
R9,10 RS143FA221JS-P R23 RS143AA392JS-P
K2K3
K4
K5 IC1
IC2
VR2RELAY2
VR1
C6 K2RELAY1 RELAY1

Power Amp Assembly (71 7-0068-00)
Ass'y
－１０－
Q6 VR1 K1
Test PointC8
PC Board 115-0133-00
PCﾎﾞｰﾄﾞ
Heat Sink 240-0077-03
ﾋｰﾄｼﾝｸ
Transistor Insulator 250-1156-04 for Q14～17
絶縁ｽﾍﾟｰｻ
308-0306-00 K1
Connector Plug 308-0411-00 K2
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0212-00 K3
308-0221-00 Test Point
Potentiometer 583-0134-00 VR1:1kΩ
半固定抵抗器
IC IC1 NJM4559D-M
D1,2(Zener) HZ153L
Diode D4,5 MA165
D8,9 1SS81
D10,11 S5277G
Q1,4 2SC3478-K,U
Q2,3 2SA1376-K,U
Q5 2SC2705-Y
Q6 2SA1145-Y
Q7 2SC3902-S,T
Transistors Q8 2SA1507-S,T
ﾄﾗﾝｼﾞｽﾀ Q9 2SC4685
Q10 2SC2710-O,Y
Q11 2SA1150-O,Y
Q12 2SC4793
Q13 2SA1837
Q14,16 2SC2837-O,P,Y
Q15,17 2SA1186-O,P,Y
Polyester Film Capacitor C3 CQ922M1H152J-B 1,500pF /50V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ C21,22 CF922MF2E104KD-A 0.1uF /250V
C1 CE04W2A4R7RBNC2 4.7uF /100V
C2 CE04W1HR47VR 0.47uF /50V
Electorlytic Capacitor C4,5 CE04W1H100VP 10uF /50V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C6,7 CE04W1C101CA 100uF /16V
C8～11 CE04W2A471VR 470uF /100V
C17,18 CE04W2C100RE3 10uF /160V
Polypropylene Capacitor C12,13 CQ922N2A682JAPS 6,800pF /100V
ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝｺﾝﾃﾞﾝｻ C14 CQ922N2A223JAPSF 0.022uF /100V
C19,20 CQ922N2A102JAPS 1,000pF /100V
R1 RD142EA105JF 1MΩ 1/4W
R2,16,17 RD142EA753JF 75kΩ 1/4W
R3,44,45 RD142EA471JF 470Ω 1/4W
R4,5 RD142EA303JF 30kΩ 1/4W
R6,7 RD142EA472JF 4.7kΩ 1/4W
Carbon Film Resistor R8,9 RD142EA220JF 22Ω 1/4W
炭素皮膜抵抗器 R14,15 RD142EA392JF 3.9kΩ 1/4W
R18,19 RD142EA102JF 1kΩ 1/4W
R22 RD142EA302JF 3kΩ 1/4W
R23 RD142EA511JF 510Ω 1/4W
R25,26 RD142EA221JF 220Ω 1/4W
R27,28 RD142EA222JF 2.2kΩ 1/4W
R32,33 RD142EA2R2JF 2.2Ω 1/4W
R34～37 RD142EA822JF 8.2kΩ 1/4W
Fuse Resistor R20,21 RF142EA101G-P 100Ω 1/2W
ﾌｭｰｽﾞ抵抗器 R42 RF142EAR47J 0.47Ω 1/4W
R10 RN142EK7680F 768Ω 1/4W
Metal Film Resistor R11 RN142EK86R6F 86.6Ω 1/4W
金属被膜抵抗器 R12,13 RS143DA562JS-P 5.6kΩ 2W
R29 RS143DA470JS-P 47Ω 2W
Metal Plate Resistor R38～41 RW993DJR22K-H 0.22Ω 2W
金属板抵抗器
IC1
Q5
R39,41
Q8
Q10
Q14
Q16
Q13
Q9
Q12
Q15
Q17
Q7
C11
Q1,3,2,4
K2 K3 Q11
C10R38,40
C8
C22 C21
D11

－１１－
Notes ※1. Internal input resistance of volt-ohm meter should be higher than 10k-ohms.
テスターは、入力抵抗10kΩ以上のものをお使い下さい。
※2. Adjustments should be made in case of the PC Board or Transistors being changed.
調整はPCボードあるいはトランジスタを交換した場合に行って下さい。
※3. After feeding 1～10 watts output for about 15 minutes, check bias adjustment again.
出力1～10ワット前後で通電動作させた後、バイアス電流を再チェックします。
STEP ADJUST ITEM PROCEDURE
ｽﾃｯﾌﾟ 調整項目
Bias Current of L ch.
Power Amp
Lch.
バイアス電流
V.O. Meter
set range to
less than
DC 0.3V
ﾃｽﾀｰ
DC0.3V 以下
のﾚﾝｼﾞ
Bias Current of R ch.
Power Amp
Rch.
バイアス電流
Power Amp Ass'y
ﾊﾟﾜｰｱﾝﾌﾟAss'y
(717-0071-00)
Test Point pin
ﾃｽﾄﾎﾟｲﾝﾄ
VR1
forL ch.
VR1
for R ch.
Adjust for 4mV
reading of
V.O. meter
ﾃｽﾀｰの指示
4mVに調整する
1
2
ADJUST REMARKS
調整箇所 調整・備考
Peak-0dB Calibration
for L ch.
Lch.0dB較正
VTVM
Input : 1kHz
Sine Wave
入力 :1kHz
正弦波
Load :None
無負荷
Peak-0dB Calibration
for R ch.
Rch.0dB較正
Speaker Terminal
出力端子
VR1
for L ch.
VR2
for R ch.
Adjust input signal so
that VTVM reads
26.8V.Then adjust VR1
and VR2 so that meter
read 0dB.
VTVMの指示が26.8Vに
なる入力信号を入れ､ﾒｰﾀ
の指示が0dBとなるよう
にVR1,2を調整する｡
3
4
Test Point
Test Point
Meter Calibration /メータ調整
Rch. 0dBLch. 0dB
TEST EQ'PT
検出器
CONNECTING POINT
接続点

－１２－
The unit can be used with differnt voltage of 100V,120V,230V.
(Use the Japanese domestic model at 100V only, and never change the voltage in Japan.)
Refer the photo and illustration for the wiring on the junction terminal as shown below,
and have to select the correct fuse and power supply cord.
電源電圧は 、 100V､120V､230V に対応で き ますが以下はその方法を示 し ます 。
（ 日本国内は100V仕様ですので 、 この電圧以外の変更は出来ません ）
電源電圧の変更を する場合は 、 フ ュ ーズ 、 電源 コ ー ド は以下の指定 さ れた コ ー ド を 使用し ます 。
100V
120V
220V
230/240V
1
WHT,GRY
WHT,GYY
WHT
WHT
2
VIO
VIO
VIO
VIO
3
YEL
BRN
YEL,GRY
YEL,GRY
4
BRN,RED
YEL,ORG
RED
ORG
5
ORG
RED
ORG
RED
6
BRN
BRN
Fuse /
310-1502-00 T5A L AC250V
310-1502-00 T5A L AC250V
310-1204-00 T2.5A L AC250V
310-1204-00 T2.5A L AC250V
680-1204-00
680-2401-00
680-3402-00
680-3402-00
7
8
3
4
5
6
RED
GRY
YEL
BRN
WHT
VIO
BLK
BLK
ORG
RED
BLK
RED
GRN
BLU
Power Transformer
(510-3020-00) C005;0.01uF/400V
AC Outlet/ACｿｹｯﾄ
(305-1209-00)
*J type only
Terminal /端子板
(313-4081-00)
N
(W)
AC100/120/230V
50/60Hz
Fuse
T5A L250V for at 100-120V
(310-1502-00)
T2.5A L250V for at 220-240V
(310-1204-00)
C005
103/2G
Powef Switch Ass'y
(716-0603-00)
Power Transformer
(510-3020)
YEL
BLU
WHT
BLU
BRN
BLK
N
(W)
VOLTAGE SELECTOR
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
1
2
1
2
3
4
5
6
7
8

－1３－
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞ RC-23
(729-0023-00)
Case for RC-23
ﾘﾓｺﾝｹｰｽ
(801-0236-00)
Poly Bag for AC cord
ﾋﾞﾆｰﾙ袋/電源ｺｰﾄﾞ
(812-2030-04)
Battery :R6/UM3
電池 / 単3型
(569-0004-00)
Poly Bag for Battery
ﾋﾞﾆｰﾙ袋 / 電池用
(812-0812-00)
Poly Bag for Owner's Manual
ﾋﾞﾆｰﾙ袋 /取扱説明書
(812-2435-04)
Side Pad (L)
ｻｲﾄﾞﾊﾟｯﾄﾞL
(803-0264-00)
Side Pad (R)
ｻｲﾄﾞﾊﾟｯﾄﾞR
(803-0265-00)
Top Board
天地当板
(803-0033-14)
Outer Carton Box
ダンボールケース
(801-0233-04)
Cover
保護カバー
(801-4843-04)
Sub Pad
ｻﾌﾞﾊﾟｯﾄﾞ
(803-0303-00)

K3
K2
K1+
-
VolumeAss'y K1
HeadPhone Ass'y
K1
K3
K2
I/ORelay Ass'y
K5
K3
K2
K4
ProtectionAss'y
C001
223
/1J
R001
363
2H
D001
S10VB20
C002
223
/1J
R002
363
2H
K3
K2
K1
Poweramp Ass'yRch
K3
K2
K1
Poweramp Ass'yLch
K1
K3K2
SwitchAss'y
K1
K2
K4 K3
K5
Connectorboard Ass'y
K3
K4
K8
K11
K5
K6
K7
K10
K9
K1
K2
LogicAss'y
K1
K4
K2
K3
TapeSwitch Ass'y
K1
Inputselector Ass'y
K1
SelectorLED Ass'y
K1
ReceiverAss'y
RED
VIO
RED
VIO
RED
VIO
OptionBoard
VIO
BLK
716-0593
716-0595
716-0598 716-0599
721-0063
716-0594
716-0596
716-0614
721-0064
717-0071
717-0071
720-0062
716-0601
C003
103K /2D
C004 103K /2D
K1
K2
K3
ToneVolume Ass'y
716-0597
K1 716-0602
MeterConnector Ass'yLch
K1 716-0602
MeterConnector Ass'yRch
GRY
VOLTAGESELECTOR
N
(W)
ORG
RED
GRY
YEL
BRN
VIO
WHT
RED
BLK
RED
BLK
BLK
BLK
BLU
GRN
YEL
8
7
6
5
4
3
510-3020-00
C005
103
/2G
(W)
N
2
1
K1K2
716-0600
Att.Ass'y
!!
!Attentionmark indicatingcritical componentsfor safety.
Replacementmust bemade withidentical partsof specifiedpart number.
CAUTION
WHT
!
WHT
716-0603
PowerSw. Ass'y
K1 716-0612
TharmalSw. Ass'y
I
G
O
IC1001
NJM78M05FA
BLK
BRN
BLU
VOLTAGESELECTION TABLE
100V
120V
220V
230/240V
WHT.GRY
WHT.GRY YEL BRN
YEL.GRY
YEL.GRY
BRN.RED
YEL.ORG
RED
ORGWHT
WHT
ORG
RED
ORG
RED
1 2 3 54
VIO
VIO
VIO
VIO BRN BRN
6
BRN BLKBLK
!T2.5AL 250Vat 220-240V
T5AL 250Vat 100-120V
AC100Vonly
Fuse:
E-212 MASTER CIRCUIT DIAGRAM
- 1 -
to Logic Ass'y K
RCH
AGND
LCH
VOL+ VOL-
LOGIC Ass'y K9from
LTP
RTP
fromAGND
AGND
to TAPE SW. Ass'y K4
RCH
AGND
LCH
AGND
4A
3A
2A
1A
4B
1B
2B
3B
1C 2C
VR1 1
2
3
K3
308-0306-00
from ATT Ass'y K1
1
2
3
4
K1 308-0417-00
1
2
3
4
K2
308-0407-00
Volume Ass'y (716-0595-00)
LOUT
ROUT
GND
1
2
3
K1
308-0311-00
R
L
G
JK1 302-1204-00
from PROTECTION Ass'y K4
Head Phone Ass'y
(716-0601-00)
3A1A
2A 4A
VR1A
575-2405-10
3A1A
2A 4A
VR2A
575-2405-10
3B1B
2B 4B
VR1B
575-2405-10
3B1B
2B 4B
VR2B
575-2405-10
to Logic Ass'y K2 (pin1-10)
GND GND L1 LT2 LB2 RT2 R1 RB2 R3 L3
1A
2A
3A 4A
5A
S1A
5B
1B
2B 3B
4B
S1B
A-SP B-SP
SPEAKER
A+B
B
A
Off
Common
from Protection Ass'y K5
to Th. Sw. Ass'y KI
1 2 3 4 5 6 7 8 9
10
K1
308-1014-00
1 2 3
K3
308-0311-00
1 2
K2
308-0209-00
Tone Volume Ass'y (716-0597-00)
AC12V AC0V DGND RCON +5V
R2
470
C1
470
/0J
PL1
176-7501-00
PL2
176-7501-00 PL3 176-7501-00
1 2 3 4 5
K1 308-0530-00
G
4
G
2O 1
G5
V
3
IC1
NJL62H380A R1
680 3F
Receiver Ass'y (721-0064-00)
2 1
S1
FH2
306-2001-00
FH1
306-2001-00
!
!
!
!Attentionmark indicatingcritical componentsfor safety.
Replacementmust bemade withidentical partsof specifiedpart number.
CAUTION
Power Switch Ass'y (716-0603-00)

RCH
LCH
RCH
LCH
RCH
LCH
TUNER CD LINE
RCH
LCH
RCH
LCH
PLAY REC
RCH
LCH
LINEBAL
+12 OPT1
+12 TUN
+12 CD +12 LINE +12 S/T +12 REC +12 BAL
OPT1 BAL TUN CD LINE S/T REC +12
+15 OptionL OptionR -15 LCH RCH GND GND
R2
104 2C
R1
104 2C
R4
104 2C
R3
104 2C
R6
104 2C
R5
104 2C
R7
104 2C
R8
104 2C
R9 101 R10 101 R11 101 R12 101 R13 101 R14 101 R16 101 R15 101
R17
104
R18
104 R19
104
R20
104
R25
1212F
R26
1212F
R27 2432F R28 2432F
R29 221 R30 221
R31
104
R32
104
C1
R22 /1H
1
4
6
8
16
13
11
9
RELAY1
1
4
6
8
16
13
11
9
RELAY2
1
4
6
8
16
13
11
9
RELAY3
1
4
6
8
16
13
11
9
RELAY4
1
4
6
8
16
13
11
9
RELAY5
1
4
6
8
16
13
11
9
RELAY6
1
4
6
8
16
13
11
9
RELAY7
C2
R22 /1H
C3
R22 /1H
C4
R22 /1H
C5
R22 /1H
C6
R22 /1H
C7
R22 /1H
C8
220/1E
C12
220
C13
220
C16 220 /1E C17 220 /1E
C18
220
/1E
C19
220
/1E
C10 220 /1E C11 220 /1E
C9
220/1E
C14 100F C15 100F
R21 123G R23 243G R24 243G
TAPE
toTAPE SWAss'y K1(pin1-4)toLOGIC Ass'yK5toCONNECTOR Ass'yK4
1 2 3 4
K2
308-0407-00
3 42
1 5
IC1A
UPC4570HA
7 68
9
IC1B
UPC4570HA
1 2 3 4 5 6 7 8 9
K3
308-0905-00
OPT1_S
1 2 3 4 5
K1
308-0508-00
OPT1_S
1A 1G 1B 2A 3G 2B 5G 2G 4G
JK1
302-0411-00
1A 1G 1B 3G 2G
JK5
302-0209-00
1A 1G 1B 2A 3G 2B 5G 2G 4G
JK2
302-0411-00
2
3
1
1G
JK4
302-8011-00
2
3
1
1G
JK3
302-8011-00
JK9
314-3011-00
Option_sel
R22 123G
- 2 -
IO Relay Ass'y (716-0593-00)
LOUT
ROUT
GND
1
2
3
K1
308-0311-00
R
L
G
JK1 302-1204-00
from PROTECTION Ass'y K4
(716-0601-00)
1
1
2
233
44
M1
1 2 3 4
K1
308-0412-00
lamp lamp meta+ meta-
(716-0602-00)
1
2
3 4
5
6
7
8
910
11
12
13 1415
16
S1
339-0002-00
SEL_A SEL_B SEL_C DGND
1 2 3 4
K1
(716-0596-00)
Input Selector
Ass'y
Meter Connector Ass'yHead Phone Ass'y
TS1
369-0019-00 1
2
K1
308-0209-00
!Attentionmark indicatingcritical componentsfor safety.
Replacementmust bemade withidentical partsof specifiedpart number.
CAUTION
!
Thermal Switch Ass'y
(716-0612-00)

1a
1b
2a
2b
3a
3b
4a
4b
5a
5b
6a
6b
7a
7b
8a
8b
9a
9b
10a
10b
11a
11b
12a
12b
13a
13b
14a
14b
15a
15b
16a
16b
K1 307-3204-00
REG
REG
REG
REG
REG
REG
REG
REG
R-IN
R-IN
AGND
AGND
L-IN
L-IN
-12V
-12V
GND
GND
+12V
+12V
R-OUT
R-OUT
AGND
AGND
L-OUT
L-OUT
DGND
DGND
ST1
ST3
ST0
ST2
for Option Board
from Power Transformer
AC12V GND
C1
222
/1E
C2
222
/1E
to RELAY Ass'y K1
SelOp-L SelOp-R
-12V
+12V
GND
toTONE AMPAss'y K1(pin1,2)
D1
1SR139-400
D2
1SR139-400
D3
RD3.0EB1
D4
RD3.0EB1
C5
470
/1E
C6
470
/1E
-12V +12V
GND
1 2
K3 308-0207-00
C9
470
/1E
C10
470
/1E
C3
102
/1E
C7
101
/1E
C4
102
/1E
C8
101
/1E
R7 101
R8 101
R1
390 R3
332
R5
101
R9
102 R11
101
R2
390 R4 332 R6 101 R10 102 R12 101
1
J8
314-3011-00
C11
220
/1E
+5V
1 2 3
K5
307-0317-00 +5V
1 2 3 4 5
K4
308-0530-00
1
2
3
K2 308-0324-00
+17.5V
-17.5V
+15.4V(+13.8V)
-14.7V(-13.0V)
Q2
2SA1175_-EL,FL
Q1
2SC2785_ -EL,FL Q3 2SC2785_ -EL,FL
Q4
2SA1175_-EL,FL
Option_sel
12
F1
310-8251-00
E-212 Connector Board Ass'y (716-0594-00)
- 3 -
ModeTone
toTAPE SWAss'y K2fromLogic Ass'yK2(pin1-4)toPOWER AMPAss'y K1
L-ch GND R-ch GND fromTONE outL-ch GND fromTONE outR-ch fromLINE outL-ch fromLINE outR-ch
1 2
K1
308-0206-00
6
5
4
12
11
10
3
2
1
9
8
7S1354-1412-00
3
2
1
6
5
4S2354-1218-00
1 2 3 4
K3
308-0412-00
1 2 3 4 5
K2
308-0514-00
Switch Ass'y (716-0599-00)
1 2 3 4
K1
308-0417-00
R3
752
Att-Lout GND GND Att-Rout Att-Rin GND GND Att-Lin
1 2 3 4
K2
308-0407-00
R1
513 R2
513
R4
752
Att.
fromTAPE SW.Ass'y K1(pin 5to,8)
Off<--> On
toVolume Ass'yK4
3
2
1
6
5
4
S1
354-1218-00
Attenuator Ass'y (716-0600-00)
1A
2A 3A 4A
5A
S1A
336-3010-10
5B
1B 2B 3B
4B
S1B
336-3010-10
TapeRecorder
TapeSourceRec Off
SW_TAPE
from LOGIC Ass'y K4(pin1-3)
SW_RECOFF DGND
BalVol-Lin
GND
BalVol-Lout 1A 3A
2A
VR1A
575-2312-10
3B1B
2B
VR1B
575-2312-10
BalVol-Rin
BalVol-Rout
GND
GND GND
from IO.RELAY Ass'y K2 to ATT Ass'y K1(pin5-8)
to SW Ass'y K1
Rch
Lch
SW_RECON
1 2 3 4 5 6 7 8
K1
308-0809-00
1 2 3 4
K3
308-0412-00
1 2 3
K4
308-0311-00
RchVolume Tap LchVolume Tap
to VOLUME Ass'y K3
AGND
C1
104
C2
104
R2
332
R1
332
5B
1B 2B
3B
4BS2B
336-2007-00
1A
2A 3A
4A
5A
S2A
336-2007-00
1
2
K2
Tape Switch Ass'y (716-0598-00)
LEDCOM LED2 LED3 LED4 LED5 LED1 /LED1
/LED2 /LED3 /LED4 /LED5
D6
TLS262_-C
D2
TLS262_-C
D3
TLS262_-C
D4
TLS262_-C D5
TLS262_-C
1 2 3 4 5 6 7
K1
308-0708-00
Selector LED Ass'y
(716-0614-00)

- 4 -
R3
475
R4
475
R6
273
R5
273
R11
333
R16
473
R15
243
R12
473 R13
473
C5
101
/0J
C7
223
/2A
C6
223
/2A
C3
221
/0J
C4
4R7
/1V
+55V -55V
AC42V
GND
A-SPL-CH GND GND A-SPR-CH
GND L-CH GND
R-CH
from POWER AMP output
COM
to Logic K4(pin4-6)
L-CH
R-CH
HPGND
L-CHHP
R-CHHP
R10
221 3F
R9
221 3F
R7 362 3D
R8
362 3D
R20
100
3D
R19
100
3D
R23
392
3A
1
4
6
8
16
13
11
9
RELAY3
C1
334
/1H
C2
334
/1H
R14 183 2H
G
1
O1
2
H1
3
I1
4
V-
5
I2
6
H2
7
O2
8
V+
9
IC1
TA7318P-2
OVLD
1
CTVT
2
LATH
3
ACSN
4
GND
5
RLDV
6
PMT
7
POWR
8
IC2 UPC1237HA
3
2
1
VR1
471
3
2
1
VR2
471
3
6
1 8
4
5
RELAY2
3
6
1 8
4
5
RELAY1
D4
MA167
D2
MA167
D3
MA167
A-SP
SPCommon
B-SP
B-SPL-CH GND
GND
B-SPR-CH
1A 2A 3A 4A
K1A
1B 2B 3B 4B
K1B
D1
MA167
1 2 3 4
K2
L-GND R-GND L-CH R-CH
to PUSH SW Ass'y K4
to PHONES Ass'y K1
1
2
3
K4
1 2 3 4 5 6 7
K3
R1
101 R2
101
R21
102 R25 102
1 2 3
K5
Protection Ass'y (720-0062-00)
SUB
IN
GND
+
-
OUT
-52.1V
GND
AC35V
AC0V(GND)
+52.1V
<+.55V
<-.57V
<+1.55V
<-1.47V
<-56.1V
<+53.7V
<-53.7V
>-54mA
<+54mA
<-42mA +42mA >
<+56.1V
D4
MA165
D5
MA165
D8 1SS81
D9 1SS81
D1
HZ153L
C10
471
/2A
C8
471
/2A C18
100
/2C
C17
100
/2C
D11
S5277G
1
2
3
K1
D10
S5277G
1
2
K3
1
2
3
4
K2
R13
562
3D
R12
562
3D
D2
HZ153L
R10
7680F
R18
102 R20 101G
3
2
1
VR1
102
C11
471
/2A
C9
471
/2A
R25 221
R27
222
R16 753
R17
753
R19
102 R21 101G
R22
302
R23
511
R26 221
R28
222 R29
470
3D
R32
2R2
R33 2R2
R34
822 R36 822
R35
822 R37 822
R38
R22K
3D
R39
R22K
3D
R40
R22K
3D
R41
R22K
3D
R42 R47
Q1
2SC3478_
-K,U
Q6
2SA1145_
-Y
Q8
-S,T
2SA1507
Q5 2SC2705_
-Y Q7
-S,T
2SC3902_
Q14
2SC2837_
-O,P,Y
Q16
2SC2837_
-O,P,Y
Q15
2SA1186_
-O,P,Y
Q17
2SA1186_
-O,P,Y
6
5
7IC1B
2
3
1
84
IC1A
NJM4559D-M
C15
151
C12
682
C13
682
C14 223
Q3
2SA1376_
-K,U
R1
105 R2 753
R3 471
R4
303
R6
472
R5
303
R7
472
R8
220
R9
220
R44
471
C20
102
R45
471
C19
102
C22
104
C21
104
C3
152
C6
101
/1C C7
101
/1C
C16
151
R11
86R6F
R14
392G
Q2
2SA1376_
-K,U
Q4
2SC3478_
-K,U
Q10
2SC2710_-O,Y
Q11
2SA1150_
-O,Y
1
2TP
C4
100 /1H
C5 100/1H
Q12
2SC4793_
Q13
2SA1837_
C2
R47
/1H
KT1
R15
392G
Q9
2SC4685_
C1
4R7 /2A
Power Amp Ass'y
(717-0071-00)

LAT_LED OPTION2 SCLK SDATA /SHUTDN DO_EEP DI_EEP SK_EEP CS_EEP
C41 104
D3
MA165
VCC
XI 1
XO 3
G
2
XTAL1
527-0012-00
VCC
SCLK2
CS 1
SK 2
DI 3
DO 4
VCC
8NC
7ORG
6GND
5IC5 M93C46-BN6
P70 1 P71 2 P72 3 P73 4 P74 5 P75 6 P76 7 P77 8 P00 9 P01 10 P02 11 P03 12 P04 13 P05 14 P06 15 P07 16 P10 17 P11 18 P12 19 P13 20 P14 21 P15 22 P16 23 P17 24 P20 25
TEST 26
P21 27 P22 28
/RST 29
XIN 30
XOUT 31
GND 32
VCC
64 P67 63 P66 62 P65 61 P64 60 P63 59 P62 58 P61 57 P60 56 P56 55 P55 54 P54 53 P53 52 P52 51 P51 50 P50 49 P47 48 P46 47 P45 46 P44 45 P43 44 P42 43 P41 42 P40 41 P37 40 P36 39 P35 38 P34 37 P33 36 P32 35 P31 34 P30 33
IC9
426-0038-20
/SHUTDN
UNB/BAL
SW-T1 EXT SW-EXT SW-REC LED_EXT LED_6CH LED_MIX LED_PAS SW-T2 SW-MIX SW-PASS
CDB/LB 6-CH
LED_MUT
1 2
IC4A
TC74VHC14F
11 10
IC4E
TC74VHC14F
13 12
IC4F
TC74VHC14F
3 4
IC4B
TC74VHC14F
5 6
IC4C
TC74VHC14F
C40
104
4-CH
VOL_DN
C37
104
OPTION1
VOL_UP
R54
473
/SEL_C /SEL_B /SEL_A
I1 1 I2 2 I3 3 I4 4 I5 5 I6 6 I7 7
GND 8
O1
16 O2 15 O3 14 O4 13 O5 12 O6 11 O7 10 COM
9
IC6 TD62003AP
STS-0 STS-1 STS-2 STS-3
V1
1
V2
2
O2
3
I1
4
G1
5
G2
6I2 7
O1
8
V3
9
V4
10
IC10LB1642B
VCC
VR- VR+
VCC
SCLK SDATA SCLK2 /SEL_C /SEL_B /SEL_A /SEL_C /SEL_B /SEL_A
SER
14 QA 15
QB 1
SRCK
11 QC 2
SCLR
10 QD 3
QE 4
RCK
12 QF 5
G
13 QG 6
QH 7 QH 9
IC8
TC74HC595AF
/RST
R49
561
LED2 LED3 LED4 LED5 LED1 LEDCOM
toSELECTOR LEDAss'y K1
toIO RELAYAss'y K3
VCC
SW-ROFF LED_EXT EXT SW-EXT LED_6CH LED_MIX LED_PAS LED_MUT SW-T1 SW-6CH SW-MIX
SW-ROFF
LED_MUT
POSITIONOF SELECTOR
SW-T2
OPTION1
UNB/BAL
SW-REC
R52 473
R53
473
VCC
R51
473
VCC
VCC
/RCON
toRecever Ass'yK1toInput Sel.Ass'y K1
forVolume Ass'y(Motor)
VCC
C39
104
C32
471
/1E
C33
220
/1H
VCC
R46 102 R47
102 C36
101
/1C
R48105
R44
152 R45
101
Q1
2SC3902_ -S,T
C34
470 /1E
C35
220
/1H
+13V
D1 MA165
12 F1
310-8251-00
I
G
O
IC7
NJM78M05FA
R43
332
C38
104
C31
222
/1E
1 2
K3
308-0213-00
AC 0V AC 11V
R50
105
VCC
9 8
IC4D
TC74VHC14F
LINE-2 TUNER CD LINE-1 S/T REC_OFF T1/T2
AC Common AC 10V
toMeter Ass'yK1 L-ch
R41
100
D2
1SR139-400
SW-6CH
+13V
Status: 0000- 1111
1101: L1-LB-CD-TU-OP1
/RCON
VCC
R55
473
R42
473
R56
473
DGND REMO +5V
HPOUT
RA1
RD92AK07C_18
SW-OFF
VCC
RA2
RD92AK16C_18
SW-PASS SW-OFF
ToTransformer
STS_2 STS_1 STS_0 VASS VAREF STS_3
LINE BAL S/T REC_OFF OPTION1 LINE-1 CD TUNER +12V
DGND SEL_C SEL_B SEL_A
VCC
OUT-EXT OUT-PAS
1 2
K9
308-0214-00
R57
120J
3F
VCC
PREOUT
AC 12V AC 0V
R58
330J
3F
AC 0V AC Common Meta+ Meta- Meta+ Meta-
toMeter Ass'yK1 R-ch
Meter R-ch Common Meter L-ch Rec Off Sw Tape Sw DGND
SW-ROFF SW-T1
OPTION1
1 2 3 4 5 6 7 8 9
K5
308-0906-00
-12V
LIN GND RIN +12V
R25
240 R26
240
fromCONNECTOR Ass'yK2(pin2,3)
R3
5491F 2C
R5
911
C13
100
/1H
C1 101
C3
101/0J
C5
2R2
/1H
R1
5491F
2C
R9
102
R11 1541F
R7 5231F
2C
C7
223 R13
1431F
2C
R15 2551F
R19
911
R17
5491F 2C
C9 101
R21
331
R23
103
C14
100
/1H
R4
5491F 2C
R6
911
C2 101
C4
101 /0J
C6
2R2
/1H
R10
102
R12 1541F
R8 5231F
2C
C8
223
R16 2551F
R20
911
R18
5491F 2C
C10101
R22
331
R24
103
R14
1431F
2C
3
42
15
IC1A
UPC4570HA
7
68
9
IC1B
UPC4570HA
3
42
15
IC2A
UPC4570HA
7
68
9
IC2B
UPC4570HA
toSW Ass'yK2
L In L Out R Out R In
R2
5491F
2C
R29
101
R27
105
R28
105
R30
101
2
3
1
84
IC3A
NJM2114D
6
5
7IC3B
NJM2114D
C16
101
C15
101
fromTONE VRAss'y K1
GND
toVOLUME Ass'yK1 GND
1 2 3 4 5 6
K1
308-0609-00
R33
101
C17
100
/1H
R35
393
R34
101
C18
100
/1H
R36
393
C12
4R7
/1V
C11
4R7
/1V
R31
121G 2H C19
220 /1H C20
220 /1H
C21
271
C22
271
+12V-12V
-12V+12V
-12V
+12V
-12V
+12V
-12V
+12V
1 2 3 4 5 6
K7
308-0606-00
+17.5V
Rec On Sw
SW-REC 1
2 3 4 5 6 7
K4
308-0708-00
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
K2
308-1511-00
R59 473
VCC
toPROTECTION Ass'yK4
toTAPE SWAss'yK3
1 2 3 4
K6
308-0407-00
1 2 3 4 5
K8
308-0508-00
1 2 3 4
K10
308-0407-00
1 2 3 4
K11
308-0407-00
!
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
CAUTION
R32
121G 2H
R37
471G 2H
R38
471G 2H
R39
472
- 5 -
Logic Ass'y (721-0063-00)

2-14-10 SHIN-ISHIKAWA, AOBA-KU, YOKOHAMA, JAPAN
2001-8 861-3122-00
Printed in Japan
SPECIFICATIONS [Guaranteed specifications are measured according to EIA standard RS-490.]
(both channel driven, 20 - 20,000Hz)
115 watts per channel into 4 ohms
105 watts per channel into 6 ohms
90 watts per channel into 8 ohms
(both channel driven, 20 - 20,000Hz)
0.04% with 4 to 16 ohms load
0.01%
HIGHLEVEL INPUT
20-20,000Hz +0, -0.2dB (at rated continuous average output)
100 (with 8-ohm load ,50Hz)
Sensitivity
Input for rated output for 1watt output (EIA) Input Impedance
HIGH LEVEL 213mV 22.5mV 20k Ω
BALANCED 213mV 22.5mV 40kΩ
HIGH LEVEL INPUT →OUTPUT : 42dB
(UNBALANCED/BALANCED)
Turnover frequency and adjustment range
BASS : 300Hz ±10dB (50Hz)
TREBLE 3kHz ±10dB (20kHz)
+6dB (200Hz) (Volume control setting -30dB)
-20dB
Input shorted,IHF-A weighting
Input S/N ratio at rated input S/N ratio (EIA)
HIGH LEVEL 110dB 81dB
BALANCED 98dB 81dB
Logarithmic compression,peak reading meters with a dB
scale calibrated for an 8-ohm load
4-16 ohms
Suitable impedance : 8-100 ohms
120V /230V (Voltage as indicated on rear panel)
AC,50/60Hz
30 watts idle
220 watts in accordance with IEC-65
Width 475 mm (18-11/16")
Height 150mm (5-7/8")
Depth 422mm (16-5/8")
18.9 kg (41.6lbs) net
23.0 kg (50.7lbs) in shipping carton
Remote control principle :Infrared pulse
Power supply :3V DC(IEC R6 batteriesx2)
Dimensions : 45(W)x136(H)x18(D)mm
Weight : 85g(including batteries)
(両チャンネル同時動作 20～20,000Hz間)
115 W/ch 4Ω負荷
105 W/ch 6Ω負荷
90 W/ch 8 Ω負荷
(両チャンネル同時動作 20～20,000Hz間)
0.04% 4～16Ω
0.01%
HIGH LEVEL INPUT
定格連続平均出力時 :20 ～20,000Hz 0 -0.2dB
100 (8Ω負荷 50Hz)
入力感度
入力端子 定格出力時 EIA(1W出力)入力ｲﾝﾋﾟｰﾀﾞﾝｽ
HIGH LEVEL 213mV 22.5mV 20kΩ
BALANCED 213mV 22.5mV 40k Ω
HIGH LEVEL INPUT →OUTPUT : 42dB
: 300Hz ±10dB (50Hz)
:3kHz ±10dB (20kHz)
+6dB (200Hz) : VOLUME -30dB にて
-20 dB
入力ショート(A- 補正)
入力端子 定格出力時S/N 入力換算雑音 EIA S/N
HIGH LEVEL 110dB -129dBV 81dB
BALANCED 92dB -111dBV 81dB
対数圧縮型ピークレベル表示
dB目盛及び8Ω負荷の出力直読
4～16Ω
適合インピーダンス 8～100 Ω
AC100V 50 /60Hz
30W 無入力時
220W 電気用品取締法
336W 8Ω負荷定格出力時
法
幅475mm×高さ150mm ×奥行422mm
18.9kg
ﾘﾓｺﾝ方式 :赤外線ﾊﾟﾙｽ方式
電源 :DC3V ・乾電池 単3型2個使用
最大外形寸法 :45 ㎜ｘ136 ㎜ｘ18 ㎜
質量 : 85g(電池含む)
