Accuphase E-308 Operating and installation instructions

Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
Authorized Technical Service Only
These servicing instructions are for use by qualified personnel only.
To reduce the risk of electric shock do not perform any servicing
other than that contained in the operating instructions unless you are
qualified to do so. Refer all servicing to qualified service personnel.
ここに記載したサービスに関する指示事項は、サービスに関する資格を
有する者のみが使用するものです。感電防止の観点から、サービス資格
を有していない方は、取扱指示事項以外のサービスは絶対に行わないよ
うにして下さい。
CAUTION /
回路図

EXPLANATION OF SURFACE PARTS
Meter
ﾒｰﾀ
(178-2038-10)
Knob for INPUT
ﾂﾏﾐ
(381-4503-04)
Knob for VOLUME
ﾂﾏﾐ
(381-4501-14)
Push-button for POWER
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5044-03)
Push-button for ATT
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5077-13)
Front Panel Assembly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0177-11)
Front Glass
ﾌﾛﾝﾄｶﾞﾗｽ
(172-0129-03)
Decoration Screw
飾りﾈｼﾞ/2pcs.
(630-0304-14)
Washer
ﾜｯｼｬ/2pcs.
(637-9045-04)
Bottom Plate
ﾎﾞﾄﾑﾌﾟﾚｰﾄ
(155-0062-52)
Foot
脚
(238-0023-00)
Sub Panel
ｻﾌﾞﾊﾟﾈﾙ
(134-0145-02)
Panel End-cap
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
(132-0106-04)
-１-
Side Panel
ｻｲﾄﾞﾊﾟﾈﾙ
(139-0034-22）
Side Panel
ｻｲﾄﾞﾊﾟﾈﾙ
(139-0034-22)
Top Plate
ﾄｯﾌﾟﾌﾟﾚ-ﾄ
(150-0068-12)
Head Phone Jack
ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ
(302-1204-00)
Head Phone Ass'y
(716-0676-00)
★★
★
★
Push-button for TONE
ﾌﾟｯｼｭﾎﾞﾀﾝ/1pce.
(389-5080-03)
Push-button for Opener
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-0305-04)
Power Push Switch
(354-1023-00)
Knob for SP,COPY,RECORDER
ﾂﾏﾐ/6pcs.
(384-1405-04)
mark parts not supplied
Binding Screw
ﾊﾞｲﾝﾄﾞねじ/4pcs.
(604-0408-00)
Washer
平ﾜｯｼｬ/4pcs.
(637-0042-07)
★

FRONT VIEW
REAR VIEW
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ /5pcs.
(302-0411-00)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ/20pcs.
(254-2015-04)
Foot
脚
(238-0023-00)
Decoration Plate
ｽﾛｯﾄﾊﾟﾈﾙ
(159-0059-04)
Fixing Screw
飾りﾈｼﾞ/4pcs.
(630-0302-04)
ﾜｯｼｬ/4pcs.
(637-9045-04)
XLR (Cannon) Receptacle
ｵｰﾃﾞｨｵｺﾈｸﾀｼﾞｬｯｸ/4pcs.
(302-8011-00)
Connector Cover/Female
ｺﾈｸﾀｶﾊﾞ/ 4pcs.
(254-2012-00)
AC Outlet
ACｿｹｯﾄ/J type only
(305-1209-00)
AC Inlet
AC ｺﾈｸﾀﾌﾟﾗｸﾞ
(301-3304-00)
Power Supply Cord
電源ｺｰﾄﾞ
J type:680-1204-00
U type:680-2401-00
E type:680-3402-00
Rear Panel
ﾊﾞｯｸﾊﾟﾈﾙ
(135-0166-02)
Front Panel Assembly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0177-11)
1 Front Panel=131-0177-11
ﾌﾛﾝﾄﾊﾟﾈﾙ
2 Sub-panel =134-0145-02
ｻﾌﾞﾊﾟﾈﾙ
3 Panel End Cap=132-0106-04
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
4 Front Glass=172-0129-03
ﾌﾛﾝﾄｶﾞﾗｽ
5 Decoration Screw=630-0304-14
飾りﾈｼﾞ
Washer =637-9045-04
ﾜｯｼｬ
6 Push-button=388-5044-03
ﾌﾟｯｼｭﾎﾞﾀﾝ /POWER
Coil Spring=285-1016-04
Frame=113-0100-14
7 Panel Name Plate=180-1095-13
ﾊﾟﾈﾙﾈｰﾑﾌﾟﾚｰﾄ
1pce.
1pce.
2pcs.
1pce.
2pcs.
2pcs.
1pce.
1pce.
1pce.
1pce.
8 Push-button=389-5080-03
ﾌﾟｯｼｭﾎﾞﾀﾝ /TONE,COMP,MODE,METER
EXTPRE
9 Push-button=389-5077-13
ﾌﾟｯｼｭﾎﾞﾀﾝ /ATT.
Coil Spring=285-1023-04
Frame=113-0111-14
10 Push-button=388-0305-04
ﾌﾟｯｼｭﾎﾞﾀﾝ /OPEN.
11 Indicator=173-9077-03
ｲﾝﾃﾞｨｹｰﾀ
Light Holder=234-1095-03
ﾗｲﾄﾎﾙﾀﾞ
Rubber Cushion=250-2119-04
ﾗﾊﾞｰｸｯｼｮﾝ
12 Knob Base=170-0032-04/VOLUME
13 Knob Base=170-0033-13/INPUT
台座
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
145
Knob for VOLUME
ﾂﾏﾐ
(381-4501-14)
Head Phone Jack
ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ
(302-1204-00)
Knob for INPUT
ﾂﾏﾐ
(381-4503-04)
Knob for TONE,BAL
ﾂﾏﾐ
(384-1405-04)
-２-
Speaker Terminal
出力端子
(313-0041-00)
11 12
13
10 9
Binding Screw
ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄ/4pcs.
(611-0414-02)

IO Relay Assembly
IOﾘﾚｨ Ass'y
(716-0674-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-3026-00)
Logic Assembly
ﾛｼﾞｯｸ Ass'y
(721-0075-00)
Input Selector Assembly
ｲﾝﾌﾟｯﾄｾﾚｸﾀ Ass'y
(716-0677-00)
Connector Board Assembly
ｺﾈｸﾀﾎﾞｰﾄﾞ Ass'y
(716-0673-00)
Volume Assembly
ﾎﾞﾘｭｰﾑ Ass'y
(716-0679-00)
Variable Resistor
可変抵抗器
(575-2021-00)
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0079-00)
Protection Assembly
ﾌﾟﾛﾃｸｼｮﾝ Ass'y
(720-0068-00)
Electrolytic Capacitor
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
C004,005:22,000μF/63V
(CE621WG1J223EAQ)
Polypropylene
Capacitor
ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝ
ｺﾝﾃﾞﾝｻ
C002,003;0.01uF/200V
(CQ922N2D103JAPH
Power Push Switch
ﾊﾟﾜｰ ﾌﾟｯｼｭｽｲｯﾁ
(354-1023-00)
Head Phone Assembly
ﾍｯﾄﾞﾎﾝ Ass'y
(716-0676-00)
-３-
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0079-00)
Line Amp Assembly
ﾗｲﾝ ｱﾝﾌﾟ Ass'y
(712-0093-00)
Connector Board Assembly
ｺﾈｸﾀﾎﾞｰﾄﾞ Ass'y
(716-0673-00)
Tone Amp Assembly
ﾄｰﾝｱﾝﾌﾟ Ass'y
(712-0094-00)
Protection Assembly
ﾌﾟﾛﾃｸｼｮﾝ Ass'y
(720-0068-00)
Tone Amp Assembly
ﾄｰﾝｱﾝﾌﾟAss'y
(712-0094-00)
Fuse
T6.3A L AC250V/100-120V
(310-1602-00)
T3.15A L AC250V/220-240V
(310-1302-00)
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
Boltage Selector Assembly
ﾎﾞﾙﾃｰｼﾞｾﾚｸﾀ Ass'y
Dtype (716-0680-11）
U,Ttype (716-0680-12)
Etype (716-0680-13)
Balance Input Amp Assembly
ﾊﾞﾗﾝｽ入力ｱﾝﾌﾟ Ass'y
(712-0092-00)
Diode /D001
ﾀﾞｲｵｰﾄﾞ
(S15VB20)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-3026-00)
Line Amp Assembly
ﾗｲﾝ ｱﾝﾌﾟ Ass'y
(712-0093-00)
Thermal Switch Assembly
ｻｰﾏﾙｽｲｯﾁAss'y(716-0675-00）

Power Push Switch
ﾊﾟﾜｰｽｲｯﾁ
(354-1023-00)
Variable Resistor
可変抵抗器/VR1:50kΩ-A
(575-2021-00)
Volume Assembly
ﾎﾞﾘｭｰﾑ Ass'y
(716-0679-00)
Push Switch/ATT
ﾌﾟｯｼｭｽｲｯﾁ
(354-1218-00)
Rotary Switch
ﾛｰﾀﾘｽｲｯﾁ / S1
(339-0002-00)
Input Selector Assembly
ｲﾝﾌﾟｯﾄｾﾚｸﾀ Ass'y
(716-0677-00)
Power Meter
ﾊﾟﾜｰﾒｰﾀ
(178-2038-10)
Pilot Lamp 1
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ/PL1,2,3
(176-3501-00)
Receiver Assembly
受光器Ass'y
(721-0076-00)
Head Phone Assembly
ﾍｯﾄﾞﾎﾝ Ass'y
(716-0676-00)
Head Phone Jack
ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ
(302-1204-00)
Selector LED Assembly
ｾﾚｸﾀLED Ass'y
(723-0094-00)
Foot
脚
(238-0023-00)
-４-
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
Indicator
ｲﾝﾃﾞｨｹｰﾀ
(173-9077-03)
Display Assembly
ﾃﾞｨｽﾌﾟﾚｲAss'y
(723-0092-00)
Front Glass
ﾌﾛﾝﾄｶﾞﾗｽ
(172-0129-03)
Knob Base
台座 /INPUT
(170-0033-13)
Knob Base
台座 /VOLUME
(170-0032-04)
Push Button/POWER
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5044-03)
Push-button Frame
ﾌﾟｯｼｭﾎﾞﾀﾝﾌﾚｰﾑ
(113-0100-14)
Coil Spring
ｽﾌﾟﾘﾝｸﾞ
(285-1016-04)
Push Button/ATT
ﾌﾟｯｼｭﾎﾞﾀﾝ
(389-5077-13)
Push-button Frame
ﾌﾟｯｼｭﾎﾞﾀﾝﾌﾚｰﾑ
(113-0111-14)
Coil Spring
ｽﾌﾟﾘﾝｸﾞ
(285-1023-04)
Tone Amp Assembly
ﾄｰﾝｱﾝﾌﾟAss'y
(712-0094-00)
Switch Assembly
ｽｲｯﾁ Ass'y
(716-0678-00)
Rubber Cussion
ｺﾞﾑｸｯｼｮﾝ
(250-2079-04)
Connector Ass'y
ｺﾈｸﾀ Ass'y
(309-4138-04)
mark parts not supplied
Position Indicator
ﾎﾟｼﾞｼｮﾝｲﾝﾃﾞｨｹｰﾀ/8pcs.
(173-1902-04)
Binding Screw
ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄ/4pcs.
(611-0414-02)
Panel End Cap
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
(132-0106-04)

MISCELLANEOUS 本体その他使用部品
NO.
Screws for
ﾈｼﾞ類
Accessories
付属品
Description(部品名)
Front Panel / ﾌﾛﾝﾄﾊﾟﾈﾙ用
Binding Screw/ ﾊﾞｲﾝﾄﾞﾂﾒﾂｷ
Panel End Cap /ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
Pan Head ISO Metric Screw
Side Panel/ｻｲﾄﾞﾊﾟﾈﾙ用
Oval Head Screw/丸ｻﾗﾈｼﾞ
Binding Screw/ﾊﾞｲﾝﾄﾞﾈｼﾞ
Washer/平ﾜｯｼｬ
Top Plate/ﾄｯﾌﾟﾌﾟﾚｰﾄ用
Round Head Screw
ﾌﾞﾚｻﾞｰﾂﾒﾂｷﾈｼﾞ
Binding Neil Serew
ﾊﾞｲﾝﾄﾞﾂﾒﾂｷﾈｼﾞ
Bottom Plate/ﾎﾞﾄﾑﾌﾟﾚｰﾄ用
Binding Noil Screw
ﾊﾞｲﾝﾄﾞﾂﾒﾂｷﾈｼﾞ
Foot /脚用
Binding Screw /ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄ
Power Transformer/電源ﾄﾗﾝｽ
Binding Screw
ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄﾈｼﾞ
Option Panel /ｵﾌﾟｼｮﾝﾊﾟﾈﾙ
Decoration Bolt /飾りﾈｼﾞ
Nylon Washer /ﾅｲﾛﾝﾜｯｼｬ
Owner's Manual (多ヶ国語)
取扱説明書 (日本語)
Caution Notes (多ヶ国語)
注意書 (日本語)
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞ /RC-20
Battery / 電池
Power Supply Cord (J type)
電源ｺｰﾄﾞ (U,T type)
(E type)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
Connector Cover for female
ｺﾈｸﾀｶﾊﾞ(雌ﾀｲﾌﾟ用)
Parts No.(部品No.)
631-0047-00
600-0306-02
612-0308-00
604-0408-00
637-0042-07
616-0306-02
631-0054-00
631-0032-02
611-0414-02
611-0408-02
630-0302-04
637-9045-04
820-3221-00
820-0221-00
820-3221-00
820-0221-00
729-0020-00
569-0004-00
680-1204-00
680-2401-00
680-3402-00
254-2015-04
254-2012-00
Remarks(備考)
3×8mm 6pcs.
3×6mm 4pcs.
3×8mm 4pcs.
4×8mm 4pcs.
4pcs.
3×6mm 6pcs.
3×10mm 2pcs.
3×8mm 12pcs.
4×14mm 4pcs.
8pcs.
4pcs.
4pcs.
Multi-lingual
Japanese
English
Japanese
RC-20
R6/ UM-3 単3型
2-conductor
3-conductor
3-conductor
20pcs.
4pcs.
NO.
PL1～3
F1
VR1
C004,5
C001
Packing
Material
梱包材
Description(部品名)
PC Board for
Balance Inpnt Assembly
Tone Amp Assembly
Switch Assembly
Power Amp Assembly
Voltage Selector Assembly
Connector Board Assembly
Volume Assembly
IO Relay Assembly
Protection Assembly
Logic Assembly
Pilot Lamp/ 3pcs.
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ
Fuse T6.3A L AC250V
ﾌｭｰｽﾞ T3.15A L AC250V
Variable Resistor
可変抵抗器
Electrolytic Capacitor
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Metalized polyester
Capacitor
MPｺﾝﾃﾞﾝｻ
Outer Carton Box
ﾀﾞﾝﾎﾞｰﾙｹｰｽ
Top Pad
ﾄｯﾌﾟﾊﾟｯﾄ
Bottom Pad
ﾎﾞﾄﾑﾊﾟｯﾄ
Top Board
天地当板
Cover
保護ｶﾊﾞ
Accessories Case
付属品ｹｰｽ
Cover
保護ｶﾊﾞ
Poly Bag
ﾋﾞﾆｰﾙ袋
Cord Cramper
ｺｰﾄﾞｸﾗﾝﾊﾟ
Parts No.(部品No.)
115-1514-10
115-1523-10
115-1522-30
115-1511-10
115-1525-20
115-1508-10
115-1524-00
115-1509-00
115-1512-00
115-1510-00
176-3501-00
310-1602-00
310-1302-00
575-2021-00
CE621WG1J223EAQ
CF99MF2E224MR46
801-0259-04
803-0344-00
803-0345-00
803-0358-00
803-0347-00
803-0033-14
810-4843-04
801-0250-10
810-4545-04
810-2030-04
810-2030-04
812-2435-04
812-0727-00
280-0003-10
Remarks(備考)
PL1～3 :3pcs.
for 100-120V
for 220-240V
Volume Ass'y
22,000uF/63V
0.22uF/250V
Front
Rear
Front
Rear
for Cover
for AC Cord
for Remote
for Manual
for RC-20
for AC Cord
-5-
CD BAL
LINE-2
OPTION-2
CD
TUNER
OPTION-1
LINE-1
LINE-BAL
INPUT SELECTOR
VOLUME Control
＋
－

Balance Input
A
mp
A
ssembly (712-0092-00)
Ass'y
Relay RELAY1,2 362-1212-00
ﾘﾚｨ
IC IC1,2 UPC4570C
Ceramic Capacitor C1,2,7,8 CC14CH1H200JS 20pF /50V
磁器ｺﾝﾃﾞﾝｻ C3,4,9,10 CC14CH1H100JS 10pF /50V
Electrolytic Capacitor C5,6,11,12 CE04W1E101VK 100uF/25V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C13,14,15,16 CE04W1H220VK 22uF/50V
Polyester Capacitor C17～20 CQ922M1H223J-B 0.022uF/50V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ
Diode MA165 D1,2
ﾀﾞｲｵｰﾄﾞ
Carbon Film Resistor R1,2,5,6,13,14,17,18 RD142CA103J 10kΩ 1/6W
炭素被膜抵抗器 R3,4,11,12,15,16,23,24 RD142CA203J 20kΩ 1/6W
R9,10,21,22 RD142CA471J 470Ω 1/6W
R25,26,27,28 RD142EA101JF 100Ω 1/4W
Metal Film Resistor R7,8,19,20 RN142CK2052F 20.5kΩ 1/6W
金属被膜抵抗器
-６-
XLR(Cannon)Receptacle JK1～４ 302-8011-00
ｵｰﾃﾞｨｵｺﾈｸﾀｼﾞｬｯｸ
Connector Plug K1 308-0407-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0206-00
K3 308-0306-00
Electrolytic C1,2 CE04W1H100VK 10uF/ 25V
Capacitor C7,8 CE04W0J121LXVE 120uF/ 6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C9,10,13 CE04W1E101VK 100uF/ 6.3V
C11,12 CE04W1E332VK 3300uF/ 25V
C14,15,16,17 CE04W1E470VRE 47uF/ 25V
Ceramic Capacitor C3,4 CC14CH1H101JS 100pF / 50V
磁器ｺﾝﾃﾞﾝｻ
Polyester Capacitor C5,6 CQ921MG1H222KDEPF 2200pF/ 50V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ
R1,2 RD142CA334J 330kΩ 1/6W
R3,4 RD142CA473J 47kΩ 1/6W
R5～20 RD142CA101J 100Ω 1/6W
R21～28 RD142CA273J 27kΩ 1/6W
Carbon Film Resistor R29～36,45～52 RD142CA100J 10Ω 1/6W
炭素被膜抵抗器 R37,38,39,40 RD142CA512J 5.2kΩ 1/6W
R41,42,43,44 RD142CA301J 300Ω 1/6W
R53,54 RD142EA241GFS 240Ω 1/6W
R55,56 RD142EA240GFS 24Ω 1/6W
R57,58 RD142CA104J 100kΩ 1/6W
R59,60 RD142CA820J 82Ω 1/6W
Connector Plug K1 308-0407-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0508-00
K3 308-0715-00
K4 308-0214-00
K5 308-0207-00
IC Protector F1 310-8251-00
ICﾌﾟﾛﾃｸﾀ
IC IC1 UPC79M12HF
IC2 UPC78M12AHF
IC3 NJM78M05FA
Diode D1,2,3,4 MA165
ﾀﾞｲｵｰﾄﾞ D5,6 1SR139-400
Q1,2,5,6,9,10 2SC2785-EL
13,14,19,20,23～26
Tarnsistor Q3,4,7,8,11,12 2SA1175-EL
ﾄﾗﾝｼﾞｽﾀ 15～18,21,22,27,28
Q29,30,33,34 2SA1015-GR/Y
Q31,32,35,36 2SC1815-GR/Y
Line Amp Assembly (712-0093-00)
Ass'y
RELAY2
JK4
JK3 JK2
JK1
K1 K2 K3
IC1
RELAY1
IC2
IC1 IC3
K4
K2
K5
K3
K1
IC2
Q32
Q36
Q34
Q30
C11 C12
F1
Q33 Q29
Q35
Q31
C2
C1

Tone Amp Assembly (712-0094-00)
Ass'y
-７-
Connector Jack K1,2 307-3204-00
ｺﾈｸﾀｼﾞｬｯｸ
Connector Plug K3 308-0508-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K4 308-0606-00
Relay RELAY1,2 362-1202-00
ﾘﾚｨ
Zener Diode D1,2 RD5.1EB1
ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
Diode D3,4 MA165
ﾀﾞｲｵｰﾄﾞ
Carbon Film Resistor R1,2 RD142CA134J 130kΩ 1/6W
炭素被膜抵抗器 R3,4 RD142EA331J 330Ω 1/4W
Connector Board Assembly (716-0673-00)
Ass'y
Connector Plug K1,6 308-0306-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0206-00
K3 308-0214-00
K4 308-1206-00
K7 308-0508-00
K8 308-0805-00
Connector Jack K5 307-0515-00
ｺﾈｸﾀｼﾞｬｯｸ
Rotary Switch S1,3 336-4817-00
ﾛｰﾀﾘｽｲｯﾁ S2 336-3903-00
Relay RELAY1 362-1202-00
ﾘﾚｨ
Variable Resistor VR1,2 575-2406-10
可変抵抗器 VR3 575-2309-00
Diode D1 MA165
ﾀﾞｲｵｰﾄﾞ
Electorlytic Capacitor C1,3,5,7,21,22 CE04W1H100VK 10uF /50V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C2,6 CE04W0J561KZEE 560uF/6.3V
C4,8 CE04W1H220VK 22uF /50V
Polyester Capacitor C9,11 CQ922M1H222J-B 2,200pF/50V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ C10,13 CQ922M1H473J-B 0.047uF/50V
C19,20 CQ922M1H152J-B 1,500pF/50V
R2,4,10,14 RD142CA132G 1.3kΩ 1/6W
R3,9 RD142CA301J 300Ω 1/6W
R5,13 RD142CA152J 1.5kΩ 1/6W
Carbon Film Resistor R15,17,20,22 RD142CA681J 680Ω 1/6W
炭素被膜抵抗器 R16,21 RD142CA271J 270Ω 1/6W
R18,23 RD142CA331J 300Ω 1/6W
R19,24 RD142CA103J 10kΩ 1/6W
R35,36 RD142CA2R2J 2.2Ω 1/6W
Metallized Film Caacitor R1,7,8,12 RN142CK1331F 1.33kΩ 1/6W
金属被膜抵抗器 R6,11 RN142CK6040F 604Ω 1/6W
RE1LA1
RE1LA1
RE1LA2
K1
IC2
IC1 K4 K3 K2
K6 K5
K8
K7
S1
S2
S3
VR1
VR2
VR3
K1
K2
K3
K4
R3
R4

Input Selector Assembly (716-0677-00)
Ass'y
-８-
IO Relay
A
ssembly (716-0674-00)
Ass'y
Pin Jack JK1,2,3,4,5 302-0411-00
ﾋﾟﾝｼﾞｬｯｸ
K1 308-1301-00
K2 308-0606-00
Connector Plug K3 308-0407-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K4 308-0417-00
K5,6 308-0206-00
K7 308-0513-00
K8 308-0214-00
Relay RELAY1～12 362-1212-00
ﾘﾚｨ
Diode D1～12 MA165
ﾀﾞｲｵｰﾄﾞ
Carbon Film Resistor R1 ～10 RD142EA101J 100Ω 1/4W
炭素被膜抵抗器 R11,12 RD142EA102J 1kΩ 1/4W
K1
RELAY12
RELAY3
RELAY5
K8
K3
RELAY8
RELAY9
RELAY1
RELAY4
RELAY6
RELAY10 RELAY2
RELAY7
K4
JK1
JK2
JK3JK4
PC Board 115-1517-00
PC ﾎﾞｰﾄﾞ
Connector Assembly K1 309-3428-04
ｺﾈｸﾀ Ass'y
Rotary Switch S1 339-0002-00
ﾛｰﾀﾘｰｽｲｯﾁ
Head Phone Assembly (716-0676-00)
Ass'y
RELAY11
K7
JK5
K6
K5
K2
PC Board 115-1516-00
PC ﾎﾞｰﾄﾞ
Head Phone Jack JK1 302-1204-00
ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ
Connector Plug K1 308-0306-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0407-00
K3 308-0417-00
Push Switch S1 354-1218-00
ﾌﾟｯｼｭｽｲｯﾁ
Carbon Film Resistor R1,2 RD142CA682J 6.8kΩ 1/6W
炭素被膜抵抗器 R3,4 RD142CA433J 43kΩ 1/6W
Thermal Switch Assembly (716-0675-00)
Ass'y PC Board 115-1513-00
PC ﾎﾞｰﾄﾞ
Connector Plug K1 308-0234-00
ｺﾈｸﾀﾌﾟﾗｸﾞ
Themal Switch TS1 369-0032-00
ｻｰﾏﾙｽｲｯﾁ
TS1
K1
K2
K1
K3
S1
JK1
K1
S1

Flat Cable K1 673-0505-10
ﾌﾗｯﾄｹｰﾌﾞﾙ
Push Switch S1,2,3,4,5 354-1111-00
ﾌﾟｯｼｭｽｲｯﾁ
-９-
Switch Assembly (716-0678-00)
ｽｲｯﾁ Ass'y
Voltage Selector Assembly
ﾎﾞﾙﾃｰｼﾞｾﾚｸﾀ Ass'y
S1
S2
K1 S3
S4
S5
Volume Assembly (716-0679-00)
ﾎﾞﾘｭｰﾑ Ass'y
Connector Plug K1,3 308-0407-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0417-00
Relay RELAY1 362-1202-00
ﾘﾚｨ
Variable Resistor VR1:50kΩ 575-2021-00
可変抵抗器
Polyester Capacitor C1,2 CF922N1H104JMTFF 0.1uF/ 50V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ
Ceramic Capacitor C3 CK92Y5V1H104Z 0.1uF/ 50V
磁器ｺﾝﾃﾞﾝｻ
Diode D1 MA165
ﾀﾞｲｵｰﾄﾞ
Carbon Film Resistor R1,2 RD142CA105J 1MΩ 1/6W
炭素被膜抵抗器 R3,4 RD142CA332J 3.3kΩ 1/6W
K1 K2
K3
RELAY1
VR1
Fuse Holder FH1,2 306-2001-00
ﾋｭｰｽﾞﾎﾙﾀﾞ
Connector Plug K1 308-0236-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K6 308-0433-00
K7 308-0432-00
Metalized Polyester C1 CF99MF2E103MR46 0.01uF/250V
Capacitor
MPｺﾝﾃﾞﾝｻ
D type (716-0680-11)
U type (716-0680-12)
E type (716-0680-13)
K1
K6 K7
C1
FH1 FH2
K4
K2 K3
K5
BUL WHT
(D)100V K6 K7
(U)120V K4 K5
(E)230V K2 K3

VR1
Test Point
Q4,8
Q21
Q16
Q13
Q20
Q1,5
K2 K3
Q11
Q18 Q19
K1 I C 1 I
C9
-10-
PC Board 115-1511-10
PCﾎﾞｰﾄﾞ
Heat Sink 240-0082-03
ﾋｰﾄｼﾝｸ
Transistor Insulator 250-1156-04
絶縁ｽﾍﾟｰｻ
Connector Plug K1 308-0207-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0212-00
K3 308-0411-00
T.P.1 308-0221-00
Terminal 314-0514-04
端子
Potentiometer VR1 ;220Ω 583-0224-00
半固定抵抗器
IC IC1 UPC4570C
Zener Diode D1,2,11,12 HZ153L
ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ D7,10 HZ9A2L
Diode D3,4 MA167
ﾀﾞｲｵｰﾄﾞ D5,6 1SS81
D8,9 S5277B
D13,14 1SR139-400
Q1,3,6,8 2SA1376-K/U
Q2,4,5,7 2SC3478-K/U
Q9 2SA1145-Y
Q10 2SC2705-Y
Transistor Q11 2SA1507-S/T
ﾄﾗﾝｼﾞｽﾀ Q12 2SC3902-S/T
Q13 2SC4685
Q14 2SC2547-D/E
Q15 2SA1085-D/E
Q16 2SC4793
Q17 2SA1837
Q18,20 2SC2837-O/P/Y
Q19,21 2SA1186-O/P/Y
Electorlytic C1 CE04W1H100PWE 10uF /50V
Capacitor C5,6 CE04W1E470VRE 47uF /50V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C8,9 CE04W2A331R20E 330uF /100V
C16,17 CE04W2A100VRE 10uF /100V
C18,19,20,21 CE04W2A471VRE 470uF /100V
C22,23 CE04W1C100VPE 10uF / 16V
Ceramic Capacitor C10,11 CC92CH2H151J 150pF/500V
磁器ｺﾝﾃﾞﾝｻ
Polyester Film C2 CF922MF2E152KDAZ 1,500pF/250V
Capacitor C7,14,15 CF922MF2E104KDAZ 0.1uF/250V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ C12,13 CF922MF2E682KDAZ 6,800pF/250V
Polypropylene C3,4 CQ922N2A681JAPHF 680pF/100V
Capacitor
ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝｺﾝﾃﾞﾝｻ
R1 RD142EA273J 27kΩ 1/4W
R2,14,15 RD142EA471J 470Ω 1/4W
R3,43,44 RD142EA753J 75kΩ 1/4W
R4,5,6,7 RD142EA243J 24kΩ 1/4W
R8,9,10,11 RD142EA220J 22Ω 1/4W
Carbon Film Resistor R12,13 RD142EA302J 3kΩ 1/4W
炭素被膜抵抗器 R18,19,22 RD142EA102J 1kΩ 1/4W
R23 RD142EA271J 270Ω 1/4W
R27,28 RD142EA2R2JF 2.2Ω 1/4W
R29,30 RD142EA391J 390Ω 1/4W
R31～34 RD142EA911J 910Ω 1/4W
R53,54 RD142EA100J 10Ω 1/4W
Metal Film Resistor R45 RN142EK7680F 768Ω 1/4W
金属被膜抵抗器 R46,47 RN142HK3831FF 3.83kΩ 2W
R48 RN142EK86R6F 86Ω 1/4W
Oxide Metal Film R16,17 RS143DA432JS-P 4.3kΩ 2W
Resistor R24,25 RS143DA101JS-P 100Ω 2W
金属酸化物被膜抵抗器 R26 RS143DA470JS-P 470Ω 2W
Fuse Resistor R20,21 RF142EA101G-P 100Ω 1/4W
ﾌｭｰｽﾞ抵抗器 R35 RF142EAR47J 0.47Ω 1/4W
R51,52 RF142EAR10J 1Ω 1/4W
Metal Plate Resistor R37～40 RW993DJR22K-H 0.22Ω 2W
金属板抵抗器
Q12
C8
C18 C20
Q2,6
Q3,7
Q17
C19 C21
Q14 Q15
R37
R39
R38
R40
Power Amp Assembly (717-0079-00)
Ass'y
(T.P.1)

Connector Plug K1 308-0707-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0306-00
K3 308-0508-00
Relay RELAY1,2 362-3204-10
ﾘﾚｨ RELAY3 362-2232-00
Choke Coil L1,2 506-0008-00
ﾁｮ-ｸｺｲﾙ
Potentiometer VR1,2 583-0524-00
半固定抵抗器
Zener Diode D1 HZ9A2L
ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
Diode D2,3,5～7 MA167
ﾀﾞｲｵｰﾄﾞ
IC IC1 TA7318P-2
IC2 UPC1237HA
Transistor Q1,2 2SC2458-GR
ﾄﾗﾝｼﾞｽﾀ
Electorlytic Capacitor C3 CE04W0J221VRE 220uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C4 CE04W1V4R7VRE 4.7uF / 35V
C5 CE04W0J101VRE 100uF /6.3V
Polyester Film Capacitor C1,2 CF922N1H334J 0.3uF /50V
積層ｺﾝﾃﾞﾝｻ
Polypropylen Capacitor C6,7 CQ922N2A223JAPHF 0.022uF/100V
ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝｺﾝﾃﾞﾝｻ
R1,2 RD142EA331JF 330Ω 1/4W
R3,4 RD142EA475J 4.7MΩ 1/4W
R7,13,17,18 RD142EA473J 47kΩ 1/4W
Carbon Film Resistor R8 RD142EA154J 150kΩ 1/4W
炭素被膜抵抗器 R11,12 RD142EA393J 39kΩ 1/4W
R14 RD142HA183JFS 18kΩ 1/4W
R15,26 RD142EA333J 33kΩ 1/4W
R16 RD142EA243J 24kΩ 1/4W
R24,25 RD142EA102JF 1kΩ 1/4W
Oxide Metal Film R5,6 RS143DA362JS-P 3.6kΩ 2W
Resistor R9,10 RS143FA221JS-P 220Ω 2W
金属酸化物被膜抵抗器 R19～22 RS143DA100JS-P 10Ω 2W
R23 RS143AA392JS-P 3.9kΩ 2W
Protection
A
ssembly (720-0068-00)
ﾌﾟﾛﾃｸｼｮﾝ Ass'y
-11-
PC Board 115-1520-00
PC ﾎﾞｰﾄﾞ
Pilot Lamp PL1,2,3 176-3501-00
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ
Connector Plug K1 308-0530-00
ｺﾈｸﾀﾌﾟﾗｸﾞ
Infrared Ray Senser IC1 NJL62H380A
赤外線ﾚｼｰﾊﾞ
Electorlytic Capacitor C1 CE04W0J470MA 47uF/6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Oxide Metal Film R1 RS143FA131JS-P 130Ω 3W
Resistor
金属酸化物被膜抵抗器
Carbon Film Resistor R2 RD142CA470J 47Ω 1/6W
炭素被膜抵抗器
Receiver Assembly (721-0076-00)
受光器 Ass'y
VR1 VR2
K3
K2 K1
IC1
IC2 RELAY1 RELAY2
PL3
PL1
PL2
IC1
Q1
C1
RELAY3
Q2
K1
R1
C6 C7

-12-
K2
K1 K3 K4
IC1
IC2
Q1
K8 IC5
K9
K10
IC7
K11
K7
IC3
RELAY1 XTAL1
Digital Transistor X1,2,3 RN1206
ﾃﾞｼﾞﾀﾙﾄﾗﾝｼﾞｽﾀ
Transistor Q1 2SC3902-S/T
ﾄﾗﾝｼﾞｽﾀ
C1,3 CE04W1E102VK 1,000uF/ 25V
C4 CE04W1H2R2VK 2.2uF/ 50V
Electorlytic Capacitor C6 CE04W1E471VK 470uF/ 50V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C7 CE04W1E101VK 100uF/ 50V
C9 CE04W0J220VRE 22uF/6.3V
C10 CE04W1C220VRE 22uF/ 16V
Ceramic Capacitor C2,5,8,11,12 CK92Y5V1H104Z 0.1uF/50V
磁器ｺﾝﾃﾞﾝｻ
R1 RD142EA120J 12Ω 1/4W
R2 RD142EA4R7J 4.7Ω 1/4W
R3 RD142CA103J 10kΩ 1/6W
R4 RD142CA220J 22Ω 1/6W
R5 RD142CA105J 1MΩ 1/6W
Carbon Film Resistor R6 RD142CA223J 22kΩ 1/6W
炭素被膜抵抗器 R7 RD142CA152J 1.5kΩ 1/6W
R8 RD142CA101J 100Ω 1/6W
R9 RD142CA471J 470Ω 1/6W
R10 RD142CA332J 3.3kΩ 1/6W
R11～16 RD142CA102J 1kΩ 1/6W
R17 RD142CA473J 47kΩ 1/6W
Resistor Array RA1 RD92AK15C104J18
抵抗ｱﾚｨ
X3
X1
X2
K5 K6
F1
Logic Assembly (721-0075-00)
Ass'y
Connector Plug K1 308-0206-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K2 308-0213-00
K5,10 308-0407-00
K6 308-0508-00
K7 308-1207-00
K8 308-0707-00
K9 308-1303-00
K11 308-0311-00
Connector Jack K4 307-0911-00
ｺﾈｸﾀｼﾞｬｯｸ
Connector Assembly K3 309-2260-04
ｺﾈｸﾀAss'y
IC Protector F1 310-8251-00
ICﾌﾟﾛﾃｸﾀ
Relay RELAY1 362-1212-00
ﾘﾚｨ
Crystal XTAL1 527-0012-00
ｾﾗﾛｯｸ
Diode D1,2,3 MA165
ﾀﾞｲｵｰﾄﾞ D4 1SR139-400
IC1 TC74HC14AP
IC2 NJM78M05FA
IC IC3 TMP87PH00N
IC4,6 TD62003AF
/TD62003F/EL
IC5 LB1642
IC7 M93C46-BN6
IC4
IC6
C6C3
C1

-13-
Lamp Assembly (723-0093-00)
ﾗﾝﾌﾟ Ass'y
Selector LED Assembly (723-0094-00)
ｾﾚｸﾀ LED Ass'y
PC Board 115-01518-00
PC ﾎﾞｰﾄﾞ
Pilot Lamp PL1,2 176-4501-10
ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ
Connector Plug K1 308-0209-00
ｺﾈｸﾀﾌﾟﾗｸﾞ
PC Board 115-1521-00
PC ﾎﾞｰﾄﾞ
LED Spacer 250-1118-00
LED ｽﾍﾟｰｻ
Flat Cable Holder K1 280-9009-00
ﾌﾗｯﾄｹｰﾌﾞﾙﾎﾙﾀﾞ
Flat Cable 673-0910-10
ﾌﾗｯﾄｹｰﾌﾞﾙ
LED D1～8 EMVR3371X
PL1 PL2
K1
D1
D2
D3
D4
D5
D6
D7
D8
Flat Cable 673-0910-10
ﾌﾗｯﾄｹｰﾌﾞﾙ
K1
Display Assembly (723-0092-00)
ﾃﾞｨｽﾌﾟﾚｲ Ass'y
PC Board 115-1515-00
PCﾎﾞｰﾄﾞ
Connector Plug K1 308-0721-00
ｺﾈｸﾀﾌﾟﾗｸﾞ
LED D1～6 BR1111R-B/C/D/E
K1
D1 D2 D3 D4 D5 D6

-14-
Notes. ※1. Internal input resistance of volt-ohm meter should be higher than 10k-ohms.
テスターは、入力抵抗 10kΩ以上のものをお使い下さい。
※2. Adjustments should be made in case of the PC Board or Transistors being changed.
調整は PCボードあるいはトランジスタを交換した場合に行って下さい。
※3. Afer feeding 1～10watts output for about 15 minutes,check bias adjustments again.
出力1～10ﾜｯﾄ前後で通電動作させた後、ﾊﾞｲｱｽ電流を再ﾁｪｯｸする。
STEP
ｽﾃｯﾌﾟ
ADJUST ITEM
調整項目 TEST EQ'PT
検出器
ADJUST
調整箇所
REMARKS
調整・備考
CONNECTING POINT
接続点
PROCEDURE
電圧検出
Bias Current of
L ch.Power Amp
Lch. ﾊﾞｲｱｽ電流ｽ
V.O. Meter set range
to less than DC 0.3V
テスター
DC 0.3V以下のﾚﾝｼﾞ
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0079-00)
Test Point Pin and
ﾃｽﾄﾎﾟｲﾝﾄ ,
VR1
for Lch. Adjust for "5mV"
reading of V.O. meter
ﾃｽﾀｰの指示"5mV"に
調整する
Bias Current of
R ch.Power Amp
Rch. ﾊﾞｲｱｽ電流
VR1
for Rch.
１
２
Lch.
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0079-00)
Bias Current
ﾊﾞｲｱｽ電流
Test Point
ﾃｽﾄﾎﾟｲﾝﾄ
Rch.
Power Amp Assembly
ﾊﾟﾜｰｱﾝﾌﾟ Ass'y
(717-0079-00)
Bias Current
ﾊﾞｲｱｽ電流
Test Point
ﾃｽﾄﾎﾟｲﾝﾄ
Protection Assembly
ﾌﾟﾛﾃｸｼｮﾝ Ass'y
(720-0068-00)
１
２
Peak-0dB Calibration
for Lch.
Lch.0dB 較正
Peak-0dB Calibration
for Rch.
Rch.0dB 較正
VTVM
Input:1kHz Sine Wave
入力 :1kHz正弦波
Load :None
無負荷
Speaker Terminal
出力端子
VR1
VR2
Adjust input signal so that
VTVM reads 28.3V.Then adjust
VR1 and VR2 so that Meter
reads 0dB.
VTVMの指示が28.3Vになる入力
信号を入れ、ﾒｰﾀの指示が0dBと
なるようにVR1,2を調整
/0dB for Rch. /0dB for Lch.

The unit can be used with differnt voltage of 100V,120V,230V.
(Use the Japanese domestic model at 100V only, and never change the voltage in Japan.)
Refer the photo and illustration for the wiring on the junction terminal as shown below,
and have to select the correct fuse and power supply cord.
電源電圧は 、 100V､120V､230V に対応で き ますが以下はその方法を示 し ます 。
（ 日本国内は100V仕様ですので 、 この電圧以外の変更は出来ません ）
電源電圧の変更をする場合は 、 フ ュ ーズ 、 電源コ ー ド は以下の指定さ れた コー ド を使用し ます 。
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
Photo is shown
Japanese model
wiring.
写真は日本国内
ﾓﾃﾞﾙの配線を示す
N
(W )
AC100/120/230V
50/60Hz (W )
N
2 1
S001
!
!
!
!Attention mark indicating critical components for safety.
Re
p
l acement mu st b e mad e with i d en tical
p
arts of s
p
ecified
p
art number.
CAUTION
K1
K3
K2
K5
K7
K4
K6
JK1
gy
K1
K3
K2
K5
K7
K4
K6
JK1
716-0680
ORG
RED
GRY
YEL
BRN
WHT
RED
BLK
BLU
510-3026
RED
0V
100V
117V
0V
100V
117V
ORG
!
BLU
GRY
BRK
VIO
ORG
BRK
GRY
1
2
3
4
BLUE
1
2
3
4
WHITE
230V
117V
100V
T6.3A L250V at 100-120V
T3.15A L250V at 220-240V
WHITE
BLUE
WHITE
BLUE
WHITE
BLUE
AC100V only
T001
① Remove the Bottom Plate.
本体のﾎﾞﾄﾑﾌﾟﾚｰﾄを外 し ます｡
② Set the connector position of voltage selector
Ass'y for required voltage.
ﾎﾞﾙﾃｰｼﾞｾﾚｸﾀAss'yのｺﾈｸﾀ位置を適正電圧位置
に合わせます｡
③ The fuse of a proper value is used.
同適正な値のﾌｭｰｽﾞを使用 し ま す｡
④ The AC Cable which suits voltage is used.
仕向に合 っ た 電源ｺｰﾄﾞを使用 し ます｡
Blue White
100V K6 K7
120V K4 K5
230V K2 K3
-15-
Voltage Selector Ass'y
ﾎﾞﾙﾃｰｼﾞｾﾚｸﾀ Ass'y
D:100V (716-0680-11)
U:120V (716-0680-12)
E:230V (716-0680-13)
Power Transformer
電源ﾄﾗﾝｽ
(510-3026-00)
K3
K5
K7
K4
K6 K2
STEP
Type Voltage Description Part No.
D ,U 100-120V T6.3A L250V 310-1602-00
E 230-240V T3.15A L250V 310-1302-00
Type Ass'y No.Fuse Connector Power Supply Cord
ﾀｲﾌﾟ Ass'y番号 ﾌｭ-ｽﾞ ｺﾈｸﾀ 電源ｺｰﾄﾞ
100V (D) 716-0680-11 T6.3A L 250V 310-1602-00 K6/BLU K7/WHT 680-1204-00
120V (U,T) 716-0680-12 T6.3A L 250V 310-1602-00 K4/BLU K5/WHT 680-2401-00
220-240V (E) 716-0680-13 T3.15A L 250V 310-1302-00 K2/BLU K3/WHT 680-3402-00

Accessories Case
付属品ｹｰｽ
(801-0250-10)
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞ RC-20
(729-0020-00)
Cover for AC Cord and RC-20
保護ｶﾊﾞ/電源ｺｰﾄﾞ
(810-2030-04)
Battery :R6/UM-3
電池 / 単3型
(569-0004-00)
Cover
保護ｶﾊﾞ
(810-4545-04)
Poly Bag for Owner's Manual
ﾋﾞﾆｰﾙ袋 /取扱説明書
(812-2435-04)
Bottom Pad(R)
ﾎﾞﾄﾑﾊﾟｯﾄﾞ(R)
(803-0347-00)
Top Board
天地当板
(803-0033-14)
Outer Carton Box
ﾀﾞﾝﾎﾞｰﾙｹｰｽ
(801-0259-04)
Cover
保護カバ
(810-4843-04)
Top Pad(R)
ﾄｯﾌﾟﾊﾟｯﾄﾞ(R)
(803-0345-00)
Top Pad(F)
ﾄｯﾌﾟﾊﾟｯﾄﾞ(F)
(803-0344-00)
Bottom Pad(F)
ﾎﾞﾄﾑﾊﾟｯﾄﾞ(F)
(803-0358-00)
Cover
保護ｶﾊﾞ/ﾘﾓｺﾝ
(810-2030-04)
Poly Bag
保護ｶﾊﾞ
(812-0727-00)
Accessories/付属品
Manual
取扱説明書
Caution Notes
注意書
お客様ｶｰﾄﾞ(国内のみ)
Power Supply Cord
電源ｺｰﾄﾞ
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞ
-16-

K3
K2 K1
Volume Ass'y
K8 K7
K4
K3
K1
K6
K5 K2
Tone Amp. Ass'y
K2 K1
K3
Head Phone Ass'y
K1 K4 K2 K3 K5 K6 K7 K8
I/O Relay Ass'y
K4 K5 K7 K1 K3
K2 K8
K11
K9
K10
K6
K13 K12
Protection Ass'y
+
Left
+
Right A Speaker A Speaker
- -
C004 223 /1J
C003 103J
/2D
D001
S15VB20
N
(W)
AC100/120/230V 50/60Hz
C002 103J /2D
C005 223 /1J
(W)
N
K3 K2K1
Rch Power Amp. Ass'y
K3 K2K1
Lch Power Amp. Ass'y
K2 K3 K1
Balanced Input Amp. Ass'y
K2
K3
K1
K4
Connector board Ass'y
K7
K2 K5
K10 K8 K11 K9 K4
K6 K1 K3
Logic Ass'y
K1
Input Selector Ass'y
K1
Selector Led Ass'y
K1
Receiver Ass'y
RED VIO
RED VIO
RED VIO
Option2 Board
28.3V/8ohm
Option1 Board
K1
Display Ass'y
+
Left
+
Right B Speaker B Speaker
- - 28.3V/8ohm
2 1
S001
!
!
!
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
CAUTION
K1
K3 K2 K5 K7 K4 K6
JK1
Voltage Selector Ass'y
C001 224M
/2E
Lch METER
+-
Rch METER
+-
BLK BLK BLK
WHT
716-0673
716-0674
716-0679
716-0676
712-0092
716-0680
712-0094
721-0075
716-0677
723-0094 721-0076 723-0092
717-0079 717-0079
720-0068
ORG
RED
GRY
YEL BRN
WHT
RED
BLK BLU
510-3026
RED
0V
100V 117V
0V
100V 117V
ORG
!
BLU
GRY
BRK
VIO
ORG
K1
716-0675
Thermal Sw. Ass'y
BRK
K1
Lamp Ass'y
723-0093
K1
K3
K2 K5
K4
Line Amp Ass'y
712-0093
GRY
1 2 3 4
BLUE
1 2 3 4
WHITE
230V 117V 100V
T6.3A L250V at 100-120V T3.15A L250V at 220-240V
Ass'y No.
716-0680-11
Connector No.
K6 , K7
716-0680-12 K4 , K5 716-0680-13 K2 , K3
AC 100V AC 120V AC 230V
CONNECTOR SETTING TABLE
WHITE BLUE WHITE BLUE WHITE BLUE
K1
716-0678
Sw. Ass'y
AC100V only
T001
- 1 7 -
E
-
3
0
8
M
A
S
T
E
R
C
I
R
C
U
I
T
D
I
A
G
R
A
M
I/O Relay Ass'y

R8
2052F
R7
2052F
C2 200
C1 200
C3 100
C4
100
+12Va
-12Va
C6 101 /1E C5 101 /1E
2 3
1
84
IC1A UPC4570C
6 5
7
IC1B UPC4570C
R20
2052F
R19
2052F
C8 200
C7 200
C9 100 C10
100
+12Vb
-12Vb
C12 101 /1E C11 101 /1E
R24 203
R23 203
2 3
1
84
IC2A UPC4570C
6 5
7
IC2B UPC4570C
CD BAL LINE BAL
2
3
1
1G
JK2
302-8011-00
2
3
1
1G
JK1
302-8011-00
2
3
1
1G
JK4
302-8011-00
2
3
1
1G
JK3
302-8011-00
R L R L
1
4
6
8
16
13
11
9
RELAY2
362-1212-00
1
4
6
8
16
13
11
9
RELAY1 362-1212-00
R25 101 R26 101
C16 220 /1H
C15 220 /1H
+12Va
-12Va
D1
MA165
D2
MA165
1 2 3K3
308-0306-00
BALR AGND BALL
to IO RELAY K3
+12V -12V +12VD /CDBAL /LINEBAL
to LINE K3
to LOGIC K11
1 2 3 4
K1 308-0407-00
AGND
1 2K2
308-0206-00
R4
203
R10
471
R12 203
R2 103
R6 103
R3 203
R9 471
R11 203
R1
103 R5
103
R16
203
R22
471
R14
103
R18 103
R15
203
R21
471
R13
103
R17 103
C14 220 /1H
C13 220 /1H
R27 101 R28 101
+12Vb
-12Vb
C18 223 C17 223 C20 223 C19 223
- 1 8 -
E
-
3
0
8
B
A
L
A
N
C
E
I
N
P
U
T
A
M
P
A
S
S
'
Y
(
7
1
2
-
0
0
9
2
-
0
0
)
1a
1b
2a
2b
3a
3b
4a
4b
5a
5b
6a
6b
7a
7b
8a
8b
9a
9b
10a 10b 11a 11b 12a 12b 13a 13b 14a 14b 15a 15b 16a 16b
K1 307-3204-00
REG REG REG REG SEL REG +5V +5V R-IN R-IN AGND AGND L-IN L-IN -15V -15V GND GND +15V +15V R-OUT R-OUT AGND AGND L-OUT L-OUT DGND DGND ST1 ST3 ST0 ST2 for Option Board 1
1a
1b
2a
2b
3a
3b
4a
4b
5a
5b
6a
6b
7a
7b
8a
8b
9a
9b
10a 10b 11a 11b 12a 12b 13a 13b 14a 14b 15a 15b 16a 16b
K2 307-3204-00
REG REG REG REG SEL REG +5V +5V R-IN R-IN AGND AGND L-IN L-IN -15V -15V GND GND +15V +15V R-OUT R-OUT AGND AGND L-OUT L-OUT DGND DGND ST1 ST3 ST0 ST2 for Option Board 2
1 2 3 4 5
10
9 8 7 6
RELAY1 362-1202-00
D3 MA165
1 2 3 4 5
10
9 8 7 6
RELAY2 362-1202-00
D4 MA165
from IO Relay K2
/OPTION2
/OPTION1
OP-R
OP-L
-12V
+12V
-12V
+12V
+12rV +12rV
+12VD
+12rV
+5V +5V
+5V
+12V
-12V
+5V -12V+12V
D1 RD5.1EB1
D2 RD5.1EB1
from LINE K3
AGND
R2 134
2C
1
2
3
4
5
6
K4
308-0606-00
R1 134
2C
1
2
3
4
5
K3
308-0508-00
AGND
AGND
R3 331
R4 331
(
7
1
6
-
0
6
7
3
-
0
0
)
TS1 369-0032-00
!
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
CAUTION
1 2
K1
308-0234-00
to TONE K2
T
H
E
R
M
A
L
S
W
I
T
C
H
A
S
S
'
Y
(
7
1
6
-
0
6
7
5
-
0
0
)
C
O
N
N
E
C
T
O
R
B
O
A
R
D
A
S
S
'
Y
AC13V
/RCON
DGND
VCC
C1 470 /0J
PL2
176-3501-00
PL1
176-3501-00
PL3
176-3501-00
from LOGIC K6
G
4
G
2O
1
G5
V
3
IC1 NJL62H380A
DGND
R2 470 R1
131 3F
1
2
3
4
5
K1
308-0530-00
R
E
C
E
I
V
E
R
A
S
S
'
Y
(
7
2
1
-
0
0
7
6
-
0
0
)
0V AC 12.5V
PL1
176-4501-10
PL2
176-4501-10
from Logic Ass'y K3
1 2
K1
308-0209-00
L
A
M
P
A
S
S
'
Y
(
7
2
3
-
0
0
9
3
-
0
0
)

R24 273
R28
273
R8
101
R12
101
R16
101
R20
101
Q4
2SA1175_-EL Q12
2SA1175_
-EL
Q8
2SA1175_-EL
Q16
2SA1175_
-EL
Q2
2SC2785_-EL
Q10
2SC2785_-EL
Q6
2SC2785_-EL
Q14
2SC2785_
-EL
R6
101
R10
101
R14
101
R18 101
R22
273
R26 273
R32
100
R36 100
R30
100
R34
100
Q20
2SC2785_ -EL
Q24
2SC2785_
-EL
R40
512
Q18
2SA1175_ -EL
Q22
2SA1175_
-EL
R38 512
R44
301
R42 301
D4 MA165
D2 MA165
Q32
2SC1815_
-GR/Y
Q36
2SC1815_
-GR/Y
Q30
2SA1015_
-GR/Y
Q34
2SA1015_
-GR/Y
R48
100
R52 100
R46 100
R50 100
C4
101
R56
240G
R4 473
R2 334
C8
121 /0J R58
104
R60
820
R54
241G
R23 273
R27
273
R7
101
R11
101
R15
101
R19
101
Q3
2SA1175_-EL Q11
2SA1175_
-EL
Q7
2SA1175_-EL
Q15
2SA1175_
-EL
Q1
2SC2785_-EL
Q9
2SC2785_-EL
Q5
2SC2785_-EL
Q13
2SC2785_
-EL
R5
101
R9
101
R13
101
R17 101
R21
273
R25 273
R31
100
R35 100
R29
100
R33
100
Q19
2SC2785_ -EL
Q23
2SC2785_
-EL
R39
512
Q17
2SA1175_ -EL
Q21
2SA1175_
-EL
R37 512
R43
301
R41 301
D3 MA165
D1 MA165
Q31
2SC1815_
-GR/Y
Q35
2SC1815_
-GR/Y
Q29
2SA1015_
-GR/Y
Q33
2SA1015_
-GR/Y
R47
100
R51 100
R45 100
R49 100
C3
101
R55
240G
R3 473
R1 334
C7
121 /0J R57
104
R59
820
R53
241G
+12V +12V
-12V -12V
C10 101 /1E C9 101 /1E
C11 332 /1E C12 332 /1E
+12V
-12V
D6
1SR139-400
D5
1SR139-400
12 F1
310-8251-00
1 2K5
308-0207-00
LOUT GND ROUT PGND AC
C13 101 /1E
+5V
+5V
+12V-12V
CONNECT K3
BAL K2 toTONE K7
LCH LGND RCH
VOL K1
+5V PGND +12V +12V -12V -12V
+17.3V(+16.6V)
-17.4V(-17.6V)
(*) DAC-10+AD-10
(*) DAC-10+AD-9
PGND
IO K8TRANS
1 2 3 4
K1
308-0407-00
RGND
1 2 3 4 5K2
308-0508-00
+12V -12V
+12V-12V
C5 222 /1H C6 222 /1H
1 2 3 4 5 6 7
K3 308-0715-00
AGND AGND
1 2
K4 308-0214-00
Q27
2SA1175_
-EL
Q25
2SC2785_
-EL
Q26
2SC2785_
-EL
Q28
2SA1175_
-EL
I
G
O
IC3 NJM78M05FA
C14 470 /1E C16 470 /1E C15 470 /1E C17 470 /1E
C1
100 /1H
C2
100 /1H
I
G
O
IC1 UPC79M12HF
I
G
O
IC2 UPC78M12AHF
- 1 9 -
E
-
3
0
8
L
I
N
E
A
M
P
A
S
S
'
Y
(
7
1
2
-
0
0
9
3
-
0
0
)
R
L
G
JK1 302-1204-00
ATT
LINE/R
LINE/L
from TONE K8
RGND
3 2 1
6 5 4
S1
354-1218-00
RCH
LCH
to VOLUME K2
RGND
R3
433
from PROT K1
R4
433
R1
682
R2
682
1
2
3
K1
308-0306-00
1
2
3
4
K2
308-0407-00
LGND
1
2
3
4
K3
308-0417-00
LGND
LCH
HPGND
RCH
(
7
1
6
-
0
6
7
6
-
0
0
)
H
E
A
D
P
H
O
N
E
A
S
S
'
Y
SEL_A
SEL_B
SEL_C
DGND
1 2 34
5 6 7 8 910
11 12
13
14 15
16
S1 339-0002-00
to LOGIC K5
1
2
3
4
K1
309-3428-04
I
N
P
U
T
S
E
L
E
C
T
O
R
(
7
1
6
-
0
6
7
7
-
0
0
)
TONE MONO METER
EXT COMP
to TONE K5
1 2 3 4
G
S3
354-1111-00
1 2 3 4
G
S5
354-1111-00
1 2 3 4
G
S2
354-1111-00
1 2 3 4
G
S1
354-1111-00
1 2 3 4
G
S4
354-1111-00
RET3 RET2 RET1 SCAN2 SCAN1
TM1 314-0539-04
TM2 314-0539-04
TM3 314-0539-04
TM4 314-0539-04
TM5 314-0539-04
TM6 314-0539-04
1 2 3 4 5
K1
280-9005-00
673-0505-10
S
W
I
T
C
H
A
S
S
'
Y
(
7
1
6
-
0
6
7
8
-
0
0
)
A
S
S
'
Y
1 3
K1
308-0236-00
1 2 3 4
K5
308-0432-00
1 2 3 4
K3
308-0432-00
1 2 3 4
K7
308-0432-00
230V 117V 100V
100V 100V 100V
100V100V100V
117V 117V 117V 117V 117V 117V NC NC NC 0V 0V 0V
NC 0V
NC 0V
NC 0V
C1
103 /2E
FH2 FH1
JK1
!!
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
CAUTION
!
1 2 3 4
K2
308-0433-00
1 2 3 4
K4
308-0433-00
1 2 3 4
K6
308-0433-00
Ass'y No.
716-0680-11
Connector No.
K6 , K7
716-0680-12 K4 , K5 716-0680-13 K2 , K3
! ! !
!!!
AC 100V AC 120V AC 230V
to OUTLET
FUSE
T6.3A L250V at 100-120V T3.15A L250V at 220-240V
!
CONNECTOR SETTING TABLE
V
O
L
T
A
G
E
S
E
L
E
C
T
O
R
A
S
S
'
Y
U
(
7
1
6
-
0
6
8
0
-
1
2
)
E
(
7
1
6
-
0
6
8
0
-
1
3
)
D
(
7
1
6
-
0
6
8
0
-
1
1
)
