Ace CommandHMI Series User manual

ACE AUTOMATION Europe - support.aceautomation.eu
CommandHMI series
Installation Instructions
Amazing PLCs & HMIs
MQTT Modbus Gateway
Thank you for purchasing a commandHMI!
Before installing or operating the unit, please read this installation
guide carefully to ensure correct use.
For detailed specifications and operation, please refer
to the [Help] menu of the HMI-Tool software found at
support.aceautomation.eu
Compliances FCC, Class A
Tested to conform to European CE requirements EN50022/24
Dielectric strength test 1000V AC,1 minute
IP 65 Front Panel
Unpacking the Unit
•This installation Instruction
•CommandHMI
•Power connector on the HMI
•4 brackets with screws
Cutout and Power supply
HMI Screen size
Cutout
Power supply
4.3” 16/9
142 x 85 mm
12 - 24 VDC +/-15%
5.0” 16/9
157 x 95 mm
12 - 24 VDC +/-15%
7.0” 16/9
192 x 138 mm
12 - 24 VDC +/-15%
10.2” 16/9
259 x 201 mm
24 VDC +/-15%
→ Do not press the screen (but the frame) to
insert the HMI into the cut-out of its slot!

ACE AUTOMATION Europe - support.aceautomation.eu
Wiring of the SUB-D9 serial port(s) of the HMI
RS232
2:RX↔Tx*
3:TX↔Rx*
5:GND↔▽*
RS422
6:RX-
7:RX+
8:TX-
9:TX+
RS485
8:B-
9:A+
*Wiring of the CBL-SC1 HMI cable to the ACE PLC
Connecting power supply and ground
→HMI and other equipment must have the same electrical grounding
(reference voltage level), otherwise communication errors may occur.
Connecting the PC with HMI-Tool software
Connect the cable on the USB-A side to the PC and on the
USB-B side to the HMI
→We suggest you use our USB isolator if you want to connect your PC to the
HMI or ACE PLC in an industrial environment to avoid problems with potential
differences between the 2 devices
DIP-Switch on the back of the HMI
1
2
3
4
5
Normal operation
OFF
OFF
OFF
OFF
OFF
Touch screen calibration
ON
OFF
OFF
OFF
OFF
Parameter display (Versions)
OFF
ON
OFF
OFF
OFF
Parameter Setting (Clock, IP,…)
ON
OFF
ON
OFF
OFF
See our Amazing PLCs, HMIs & Modbus MQTT Gateway
at aceautomation.eu
USB A
(PC)
USB B
(HMI)
➢Ground/GND
➢- DC 0V
➢+ DC 24V
Rx
Tx
▽
