TouchKit Setup
Reminder:
Be extremely careful when putting back on
the LCD housing; make sure the screws are
NOT tightened all the way down. Discontinue action
immediately as soon as force is felt on the housing.
Further tightening of the screws will cause touch
screen to crack resulting in inaccurate cursor.
Package Content
Controller Board Preparation
Apply rubber adhesive on the bottom side of the Touch-Hub Controller
board as insulation.

Acer Aspire One Installation Guide
Step 1.
1. Remove all 6 screws for LCD housing.
Step 2.
1. Remove both rubber feet.
2. Remove back door for controller fitting.
zRemove all 8 screws for bottom
housing.
Step 3.
zRemove keyboard by pushing in the 3
springs.

Step 4.
zRemove both FPC for keyboard and
touchpad in the direction indicated.
Step 5.
zRemove all 6 screws for keyboard
housing.
Setp 6.
1. Use thin double-sided tape to secure
the touch screen panel on the metal frame
of the LCD module.
zRemove all 4 screws to detach the LCD
module from the housing.

Step 7.
1. Remove microphone connector.
2. Remove camera module connector.
Step 8.
zUse Camera Harness provided in the
TouchKit to connect the camera module to
the USB output port of the controller board.
Step 9.
zMove the camera connector from the top to the left
location of the LCD module indicated by the pictures. This
connector will be used as USB input for the controller board.

Step 10.
1. Hub Harness connecting the camera
connector to the USB input port of the
controller board.
2. Hide all loose wires behind the hinge
for proper fitting.
Step 11.
1. Remove speaker connector
zRemove all 5 screws to release
motherboard from the bottom housing.

Step 12. Touch-Hub Controller Board
1. To touch screen panel
2. USB input (Hub Harness)
3. USB output
4. USB output (to camera module)
5. USB output
Step 13.
zConnect camera harness to the USB
output port of the controller board and slide
it underneath the chassis from right to left
direction. The back door needs to be
removed to perform this procedure.
Step 14.
1. Touch screen panel connector location.
2. Hide all wires behind the hinge for
proper fitting.

Step 15.
zPlace Shock Absorber Rubber on the
metal frame of the LCD module surrounding
the touch screen panel.
Be extremely careful when putting back on the LCD housing; make sure the screws are NOT
tightened all the way down. Discontinue action immediately as soon as force is felt on the
housing. Further tightening of the screws will cause touch screen to crack resulting in inaccurate
cursor.
