Self-Repair 1-1
Self-Repair
This chapter highlights the limited self-repair capabilities of the product.
Prior performing self-repair, familiarize yourself with the Safety Guidelines and
Recommended Equipment sections first as described in the chapter "Disassembly
Procedures".
Depending on model, the following key components are eligible for self-repair (if
applicable);
Battery pack
HDD / SSD module
DIMM module(s)
WLAN module
LTE module
If a particular key component is listed and thus would be eligible for self-repair, but is
not described in the "Disassembly Procedures" section, then this component is either not
present on the respective model, or it is present but embedded on the motherboard and
therefore not eligible for self-repair.
NOTE:
NOTE:
Do not attempt to replace other components than those listed above.
NOTE:
NOTE:
For replacement parts, always use only Acer certified components in order to
safeguard quality, optimum system performance, stability and reliability of the
product.
NOTE:
NOTE:
Any damage to the product that occur during self-repair, or which has occurred as
a result of a careless or unsuccessful self-repair attempt, is not covered by the
standard product warranty.
Software Recovery 0
This product has embedded software recovery tools which can be used to either perform
a partial or full software recovery, but also to create a Factory Default recovery media.
For more information about the software recovery options, how to perform a software
recovery or creating a Factory Default recovery media, please refer to the chapter
"Recovery" which is available in the User Manual of the product.
NOTE:
NOTE:
In the event of not being able to create a Factory Default recovery media, it is
possible to obtain a copy of the recovery media through Acer Customer Service
(http://www.acer.com/support)
This is not a free of charge service.

1-2 Disassembly Procedures
Disassembly Procedures
Safety Guidelines 0
This chapter contains step by step procedures on how to remove and de-install
components from the computer. Use the following safety guidelines to ensure your
personal safety. Each procedure included in this chapter assumes that you are preparing
your computer for recycling and disposal. By performing any of these procedures you
acknowledge that any remaining warranty applicable to your computer will be voided.
Before you start any of the procedures in this chapter, make sure to read the following
safety guidelines and the respective instructions within the chapter.
CAUTION!
Turn off your computer and disconnect all power sources before opening the
computer cover or panels.
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap
or by periodically touching an unpainted metal surface at the same time as
touching a connector on the back of the computer.
Take off any metal objects on your arms or fingers such as bracelets, rings or
watches and make sure your hands are completely dry. Even if your unit is
unplugged, there may still be some remaining electric charge.
If a component does not come out easily, do not forcefully remove it. Instead,
check that you are removing it correctly and that no wires or other parts are in the
way.
When you disconnect a cable, pull on its connector or on its pull-tab, not on the
cable itself. Some cables have connectors with locking tabs; if you are
disconnecting this type of cable, press in on the locking tabs before you disconnect
the cable.
Recommended Equipment 0
The following equipment are recommended to do the following maintenance
procedures:
Wrist grounding strap and conductive mat
Philips screwdriver
Plastic tweezers
Flat plastic pry

Disassembly Procedures 1-3
WEEE Annex VII Component 0
These components are classified as requiring selective treatment:
Battery pack
WLAN module
Touchpad module
Mainboard
USB board
LCD panel

1-4 Disassembly Procedures
Pre-disassembly Instructions 0
Do the following prior to starting any maintenance procedures:
1. Place the system on a stable work surface.
2. Remove AC adapter (A) from the system and peripherals (Figure 1-1).
3. Remove the SD card from the SD card slot (B) (Figure 1-1).
4. Remove all cables from system.
Figure 1-1. AC Adapter Outlet & SD Card Removal
NOTE:
NOTE:
Make sure the system is completely powered off.
B
A

Disassembly Procedures 1-5
Base Cover Removal 0
1. Remove twelve (12) screws from the base cover (Figure 1-2).
Figure 1-2. Base Cover Removal
2. Using a flat headed tool, carefully pry open the base cover starting from the gap
between the left LCD hinge compartment and the base cover (Figure 1-3).
Figure 1-3. Base Cover Removal

1-6 Disassembly Procedures
3. Continue prying open the base cover from the gap between the right LCD hinge
compartment and the base cover(Figure 1-4).
Figure 1-4. Base Cover Removal
4. Remove the base cover from the system (Figure 1-5).
Figure 1-5. Base Cover Removal

Disassembly Procedures 1-7
Battery Pack Removal 0
Prerequisite:
Base Cover Removal
1. Find the battery (A) on the top assembly (Figure 1-6).
2. Disconnect the battery cable (B) from the mainboard connector (C) (Figure 1-6).
Figure 1-6. Battery Pack Removal
3. Remove the battery pack from the system (Figure 1-7).
Figure 1-7. Battery Pack Removal
IMPORTANT:
+
Follow local regulations for battery disposal.
C
B
A
WEEE Annex VII Component: Battery

1-8 Disassembly Procedures
WLAN (Wireless Local Area Network) Module Removal 0
Prerequisite:
Battery Pack Removal
1. Find the WLAN module (B) on the top assembly (Figure 1-8).
Figure 1-8. Component Location
2. Disconnect WLAN antenna cables (A) from the WLAN module (Figure 1-9).
3. Remove one (1) screw (C) securing the WLAN module in place (Figure 1-9).
Figure 1-9. WLAN Module Removal
F
C
B
A
D
E
C
A

Disassembly Procedures 1-9
4. Remove the WLAN module (B) from the mainboard connector (D) (Figure 1-10).
Figure 1-10. WLAN Module Removal
BD
WEEE Annex VII Component:
WLAN module

1-10 Disassembly Procedures
Touchpad Module Removal 0
Prerequisite:
Battery Pack Removal
1. Find the touchpad module (E) on the top assembly. Refer to Figure 1-8.
2. Remove the adhesive tape (F) from the touchpad connector (Figure 1-11).
Figure 1-11. Touchpad Tape Removal
3. Disconnect the touchpad FPC (B) from the touchpad connector (A) and the
mainboard connector (C) then remove the touchpad FPC from the top assembly
(Figure 1-12).
4. Remove four (4) screws (D) securing the touchpad module in place (Figure 1-12).
Figure 1-12. Touchpad FPC Removal
E
F
C
B
AD

Disassembly Procedures 1-11
5. Remove the touchpad module from the top assembly (Figure 1-13).
Figure 1-13. Touchpad Module Removal
CAUTION:
!
Touchpad FPC (Flexible Printed Circuit) can be damaged if removed while the
mainboard connector and the touchpad connector are locked.
WEEE Annex VII Component:
Touchpad

1-12 Disassembly Procedures
LCD Module Removal 0
Prerequisite:
Battery Pack Removal
1. Disconnect the WLAN antennas from the WLAN module (A) (Figure 1-14).
2. Disconnect the G-sensor cable from the mainboard connector (B) (Figure 1-14).
3. Disconnect the digitizer cable from the mainboard connector (C) (Figure 1-14).
4. Disconnect the eDP cable from the mainboard connector (D) (Figure 1-14).
5. Unthread all cables from the cable guides (Figure 1-14).
Figure 1-14. LCD Module Removal
B
A
B
D
B
C
A

Disassembly Procedures 1-13
6. Place the system on a flat surface and open the LCD module (E) as shown in
Figure 1-15.
7. Remove four (4) screws securing the LCD module in place (Figure 1-15).
Figure 1-15. LCD Module Removal
8. Lift and remove the LCD module away from the top assembly (Figure 1-16).
Figure 1-16. LCD Module Removal
E

1-14 Disassembly Procedures
CAUTION:
!
Make sure all cables and antennas are unthread from the cable guides to
avoid damage removal.

Disassembly Procedures 1-15
Mainboard Removal 0
Prerequisite:
LCD Module Removal and
WLAN (Wireless Local Area Network) Module Removal
1. Find the mainboard (D) on the top assembly. Refer to Figure 1-8.
2. Remove the adhesive tape (I) from the keyboard connector (Figure 1-17).
Figure 1-17. Keyboard Connector Tape Removal
3. Disconnect the 30-pin USB board FPC from the mainboard connector (B). Refer to
Figure 1-18.
4. Disconnect the 40-pin USB board FPC from the mainboard connector (C). Refer to
Figure 1-18.
5. Disconnect the second camera module cable from the mainboard connector (E). Refer
to Figure 1-18.
6. Disconnect the keyboard FPC from the mainboard connector (A). Refer to
Figure 1-18.
7. Disconnect the touchpad FPC from the mainboard connector (F). Refer to Figure 1-18.
8. Disconnect the speaker cable from the mainboard connector (G). Refer to
Figure 1-18.
CAUTION:
!
Make sure all cables and FPCs are disconnected from the connectors on the
mainboard to avoid damage during removal.
D
II

1-16 Disassembly Procedures
9. Remove four (4) screws (H) securing the mainboard in place (Figure 1-18).
Figure 1-18. Mainboard Removal
10. Remove the mainboard from the top assembly (Figure 1-19).
Figure 1-19. Mainboard Removal
F
E
B
C
AG
H
H
WEEE Annex VII Component:
Mainboard

Disassembly Procedures 1-17
Figure 1-20. Mainboard
IMPORTANT:
+
Circuit boards >10 cm² have been highlighted with a yellow rectangle as
shown in Figure 1-20. Remove the circuit board and follow local
regulations for disposal.

1-18 Disassembly Procedures
USB Board Removal 0
Prerequisite:
LCD Module Removal
1. Find the USB board (C) on the top assembly. Refer to Figure 1-8.
2. Disconnect the 30-pin USB board FPC (B) from the mainboard connector (D) and the
USB board connector (A) and remove the 30-pin USB board FPC (Figure 1-21).
3. Disconnect the 40-pin USB board FPC (F) from the mainboard connector (G) and the
USB board connector (E) and remove the 40-pin USB board FPC (Figure 1-21).
4. Remove one (1) screw (H) securing the USB board in place (Figure 1-21).
Figure 1-21. USB Board Removal
5. Remove the USB board from the top assembly (Figure 1-22).
Figure 1-22. USB Board Removal
H
C
D
G
B
A
EF
WEEE Annex VII Component:
USB board
