Acer ExtensaTM 670 User manual

Extensa™ 670 Series
Notebook Computers
User’s Guide
49.47001.021
Printed in Taiwan

Copyright © 1997 Acer Incorporated
All Rights Reserved — Printed in Taiwan
Part No. 49.47001.021
Original Issue: May 1997
Changes may be made periodically to the information
in this publication. Such changes will be incorporated
in new editions of this manual.
Record the serial number, purchase date, and model
number in the space provided below. The serial
number and model number are recorded on the label
affixed to the case. All correspondence concerning
your unit should include the serial number, model
number, and date of purchase.
No part of this publication may be reproduced, stored
in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, photocopy,
recording, or otherwise, without the prior written
permissionof Acer Incorporated.
Extensa Notebook Computer
Model_______Serial No.____________Purchase Date________

Contents
3
This is a product of Acer Incorporated, developed to TI
specifications. The icons in the Windows Notebook and Startup
groups are copyrighted by Texas Instruments. Texas Instruments,
TI and the TI logo are registered trademarks of Texas Instruments
Inc.
IBM, AT, PS/2, and Token Ring are registered trademarks and
OS/2 is a trademark of International Business Machines
Corporation.
Microsoft, MS-DOS, Windows and Xenix are registered trademarks
of Microsoft Corporation.
Ethernet is a registered trademark of Xerox Corporation.
Kensington is a registered trademark of Kensington Microware,
Inc.
Synaptics is registered trademark of Synaptics, Inc.
SimulSCAN is a trademark of Cirrus Logic, Inc.
IrDA is a trademark of Infra Red Data Association.
XJACK is a registered trademark of Megahertz Corporation.

This device has been tested and found to comply with the limits
for a Class B digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
device generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this device does cause harmful
interference to radio or television reception, which can be
determined by turning the device off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
nReorient or relocate the receiving antenna
nIncrease the separation between the device and receiver
nConnect the device into an outlet on a circuit different from
that to which the receiver is connected
nConsult the dealer or an experienced radio/television
technician for help
Notice: Shield Cables
All connections to other computing devices must be made using
shielded cables to maintain compliance with FCC regulations.
Notice: Peripheral Devices
Only peripherals (input/output devices, terminals, printers, etc.)
certified to comply with the Class B limits may be attached to this
equipment. Operation with non-certified peripherals is likely to
result in interference to radio and TV reception.
Caution
Changes or modifications not expressly approved by the
manufacturer could void the user’s authority, whiãh is granted
by the Federal Communications Commission, to operate this
computer.

FCC Notice
Use Conditions
This part complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Notice: Canadian Users
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Remarque à l’intention des utilisateurs canadiens
Cet appareil numérique de la classe B respected toutes les
exigences du Règlement sur le matériel brouilleur du Canada.

Duracell Notice
The Texas Instruments Extensa 670CD and 670CDT use a
Duracell DR35 or DR201 Rechargeable Battery. Texas
Instruments participates in the Duracell pro.link program. If you
would like to purchase additional batteries, please call the
Authorized Duracell Purchase Hotline at 1-800-603-8225. If you
have questions about battery performance, recycling a used
battery, or any other battery-related question, please call
Duracell Consumer Relations at 1-800-551-2355 (9:00 AM - 5:00
PM EST).

Contents
viii
Preface
Chapter 1 Before You Begin
Creating Backup Disks.................................1-2
Features of the Computer .............................1-3
Environmental Specifications........................1-5
Using the Computer .....................................1-7
Power Saving Modes .....................................1-9
Securing the Computer...............................1-14
Using the AC Adapter .................................1-15
Chapter 2 Using Your Computer
Starting the Computer..................................2-3
Using the Brightness and Contrast Controls..2-4
Turning the Speakers On and Off..................2-5
Using the Microphone...................................2-6
Using PC Cards............................................2-7
Using Indicator Lights.................................2-10
Using the Touchpad....................................2-13
Using Disk Drives.......................................2-15
Adding Memory ..........................................2-25
Using the Keyboard ....................................2-28
Using the Internal Numeric Keypad.............2-32
Using Connectors and Ports........................2-34
Chapter 3 Using Battery Power
Guidelines for Battery Use............................3-2
Switching to Battery Power ...........................3-4
Responding to Low Battery Conditions ..........3-5
Recharging the Battery .................................3-7
Calibrating the Battery .................................3-8
Removing and Installing the Battery Pack....3-10
Re-Installing the Battery Compartment Door..3-12
Conserving Battery Power...........................3-13

Contents
ix
Chapter 4 Options
AC Adapter...................................................4-2
PC Cards......................................................4-3
PS/2 Devices................................................4-4
External Monitor ..........................................4-5
External Mouse ............................................4-6
Memory........................................................4-7
Audio Options ..............................................4-8
Docking Option ............................................4-9
Miscellaneous Options................................4-10
Chapter 5 Using Software
Using Supplied Software...............................5-2
Getting Online Help......................................5-3
Guidelines for Installing Applications............5-4
Using System Passwords ..............................5-6
Chapter 6 Mobility
Disconnecting from the Desktop ...................6-2
Moving Around.............................................6-3
Taking the Computer Home ..........................6-4
Traveling with the Computer.........................6-7
Traveling Internationally with the Computer ....6-9
Chapter 7 Care and Troubleshooting
Cleaning the Computer.................................7-2
Troubleshooting Tips ....................................7-3
Startup Error Messages................................7-4

Preface
x
This manual describes features of the Texas
Instruments Extensa™ 670 Series notebook
computers. The Extensa series computers are
similar in appearance and incorporate such
features as CardBus, 16-bit stereo audio,
module bay, Fast Infrared and internal pointing
device.
This manual should answer most of the
questions you have about the day-to-day
operation of your Extensa notebook computer.
Use the Just for Starters… instructions that
came with your computer to get your computer
running for the first time.
You should also take advantage of the online
help files that are available with almost all of the
programs shipped with your computer.
We hope you enjoy your Extensa computer.
With proper care, your computer will provide
you with years of productive service.

1
Before You Begin
1-1
After completing the instructions in Just for
Starters…, read this chapter to learn about the
important functions of your computer. Some
functions, such as Creating Backup Disks,
should be performed as soon as possible after
the purchase of your computer.
Contents
Creating Backup Disks................................ 1-2
Features of the Computer ............................ 1-3
Standard Features................................ 1-3
Customizing Features........................... 1-4
Environmental Specifications....................... 1-5
Using the Computer..................................... 1-7
Power Saving Modes .................................... 1-9
0V Suspend Mode............................... 1-11
5V Suspend Mode............................... 1-12
Standby Mode .................................... 1-13
Securing the Computer.............................. 1-14
Using the AC Adapter ................................ 1-15

Creating Backup Disks
1-2
You should create your backup system disks as
soon as possible after purchasing your
computer. The process you follow depends on
the operating system you selected when you
installed the computer for the first time.
Windows® 95
Backing up Windows 95 requires approximately
43 formatted 3½-inch, 1.44 MB floppy disks.
Labels for the floppy disks are included with the
manual.
To create backup system disks, use the Create
System Disk tool from Windows 95.
Windows for Workgroups
Backing up MS-DOS®and Windows for
Workgroups requires approximately twenty 3½-
inch, 1.44 MB floppy disks.
To create backup system disks, use the Make
Disk utility, which is located in the Main
program group.

Features of the Computer
1-3
Standard Features
The following list displays the standard features
of your Extensa computer:
qPCI Bus architecture
q16 MB EDO (Extended Data Out) memory
q2 MB EDO video memory
qFast video graphics accelerator
q0-Volt Suspend, 5-Volt Suspend and
Standby power saving modes
qNo-reboot setup function
qSTN or TFT color display
q16-bit stereo audio
qFast infrared communication
qDuracell NiMH (Nickel-Metal-Hydride) or
optional Li-Ion (Lithium-Ion) battery pack
q1.43 GB (or higher) capacity hard disk drive
with Local Bus
qInternal touchpad pointing device
qSmall, lightweight AC adapter

Features of the Computer
1-4
Customizing Features
The following features allow you to customize
your computer to fit your requirements.
qModular bay that accepts a 3½ inch floppy
disk drive module or CD-ROM drive module
qPS/2 port for connecting an external
keyboard, numeric keypad, or mouse
q9-pin serial port for connecting external
devices such as a modem or mouse
qSimultaneous display with external CRT
qOne Type III or two Type II/I Cardbus PC
Card slots; lower slot accepts Zoomed Video
port enabled PC cards
qParallel port with EPP and ECP for
connecting to a printer or the floppy disk
drive module
q8 MB, 16 MB and 32 MB EDO 64-bit type
small outline dual inline memory module
(soDIMM) upgrades
qAdvanced PCI Card slot for installing a
feature upgrade option

Environmental Specifications
1-5
This section provides information on the
optimum operating environment for your
Extensa notebook computer.
Temperature
Operating: 50° to 95°F
(10° to 35°C)
Storage: -4° to 140°F
(-20° to +60°C)
Relative Humidity (Noncondensing)
Operating: 20% to 85%
Storage: 20% to 85%
Shock
Operating: Maximum 5g pulse in X,
Y, and Z orientations
Storage: Maximum 50g pulse in X,
Y, and Z orientations
Vibration
Operating: Sinusoidal 5 to 25.6 Hz
limited to 0.015 inch
peak-to-peak maximum
displacement
0.5g, 25.6 to 250 Hz
Storage: Sinusoidal 5 to 27.1 Hz
limited to 0.016 inch
peak-to-peak maximum
displacement
2.0g, 27.1 to 500 Hz

Environment
1-6
Note: Your computer is equipped with a fan to
keep the computer cool under extreme high
temperature conditions. The fan will not normally
operate, but may turn on when the computer’s
internal components become warm. You will hear
the fan when it turns on, this is nothing to be
concerned about.

Using the Computer
1-7
qNever pick up or carry the computer by the
display.
qNever use the computer in harsh
environments where it could be subjected to
rapid temperature changes or excessive
dust.
qNever expose the computer to excessive
vibration.
qNever expose the hard disk drive or floppy
disk(s) to strong magnetic fields, such as
those generated by audio system speakers,
telephone handsets, or hand-held metal
detectors.
qTo avoid overheating the computer, never
place anything on top of the computer when
it is operating or recharging the battery.
qBefore moving an active computer, press the
0V Suspend hot key (Fn+F2) to put the
computer into 0V Suspend mode and close
the display (refer to 0V Suspend Mode in the
next section).
qDo not try to force the display beyond its
fully opened position — about 180 degrees.

Using the Computer
1-8
!
Caution: In the rare event that you see or
smell anything that indicates overheating
(smoke or a strange smell):
1. Turn off the power.
2. Disconnect the AC adapter from the power
source and the computer.
3. Remove the battery pack.
4. Contact your Extensa dealer or service
center.

Power Saving Modes
1-9
Power Savings Options
Your Extensa system offers several options for
you to extend your battery life while you are not
actively using your computer. These options
power off different sections of the computer that
are not currently being used.
These options are listed in the POWER
MANAGEMENT page of the System Setup screen
(accessed via Fn+F1 anytime or F2 during boot
up). They are described below:
Power
Management This option determines when power management is enabled. .
ALWAYS: Enables the time out
settings regardless of whether the
computer is on AC or battery power.
BATTERY ONLY: Only enables the
time outs when the computer is
running off of the battery power
DISABLE: Disable all power time out
settings.
Standby
Timeout The amount of time the computer needs to be idle before the computer
enters Standby mode.
5V Suspend
Timeout The amount of time the computer needs to be idle before the computer
enters 5V Suspend.

Power Saving Modes
1-10
0V Suspend
Timeout The amount of time the computer needs to be idle before the computer
enters 0V Suspend.
Hard Disk
Timeout The amount of time the computer needs to be idle before the hard disk
will spin down the motor.
Display
Timeout The amount of time the computer needs to be idle before the display
back light turns off
The computer will not enter any of the power
management time out modes if the hard disk
drive, CD ROM, or floppy disk drive is active.
Note: If the “Auto Insert Notification” option is
enabled in the CD ROM setting, the computer will
not time out on any of the power management
time outs because Windows 95 will constantly be
actively looking for a new CD to be inserted. This
option is set to a default of DISABLED.

Power Saving Modes
1-11
0V Suspend Mode
0V Suspend mode saves the exact spot you are
at on your computer, then removes all power
without losing any data.
In 0V Suspend mode, the computer saves the
current computer state onto your hard disk
drive then shuts off. When you turn the
computer on again, it restores the computer to
the saved state within about a minute.
Press the 0V Suspend hot key (Fn+F2) to enter
0V Suspend mode. To resume normal operation,
press the power switch. 0V Suspend mode
occurs automatically if the 0 VOLT SUSPEND
TIMEOUT parameter in Setup is enabled and
times out or if the BATTERY LOW SUSPEND option is
enabled and your battery runs down to a
critically low level.
Note: Your computer will not enter 0V Suspend
mode if the 0V Suspend file is missing or is the
incorrect size. Refer to Chapter 2, Adding Memory
section for further information.
5V Suspend Mode
5V Suspend mode consumes very little power
when you are not using your computer, yet still
resumes quickly. With a fully charged battery,
your computer can remain in 5V Suspend mode
for days.
