AL532
Service Manual

TABLE OF CONTENTS
SERVICE WARNING∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙1
A. IMPORTANT SAFETY INSTRUCTION∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙1
B. SPECIFICATIONS∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙2
C. TIMING CHART∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙3
D. CONTROL LOCATION∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙5
E. CONDUCTION VIEW∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙6
F. ADJUSTMENT PROCEDURE∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙10
G. TROUBLE SHOOTING HINTS∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙11
H. REPLACEMENT PARTS LIST∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙15
I. BLOCK DIAGRAM∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙21
J. SCHEMATIC DIAGRAM∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙22

WARNING
To prevent from fire or shock hazard,do not expose monitor to any rain or any form of water.High voltage is
inside the monitor so please do not remove the back cover of the cabinet if you are not a qualified monitor
engineer.Contact the local dealer or the nearest Acer branch office if you need help.
A. IMPORTANT SAFETY INSTRUCTION
Prior to using this service manual,please ensure that you have carefully followed all the procedures outlined in
the user's manual for this product.
1. Read all of these instructions.
2. Save these instructions.
3. Follow all warnings and instructions a marked on the product.
4. Unplug this product from the wall outlet before cleaning.Do not use liquid cleaners or aerosol
cleaners, use a damp cloth for cleaning.
5. Do not use this product near water.
6. Do not place this product on an unstable cart,stand or tablle.The product may fall,causing serious
damage to the product.
7. Slots and openings in the cabinet and the back or bottom are provided for ventilation,to ensure
reliable operation of the product and to protect it from overheating,those openings must not be
blocked or covered.The openings should never be blocked by placing the product on a bed,sofa, rug,
or other similar surface.This product should not be placed in a built-in installation less proper
ventilation is provided.
8. This products should be operated from the type of power source indicated on the marketin label.
If you are not sure of the type of power available, consult your dealer or local power company
9. This product is equipped with a 3-wire grounding type plug,a plug having a third (grounding)
pin.This plug will only fit into a grounding-type power outlet.This is a safety feature,if you are
unable to insert the plug into the outlet,contact your electrician to replace your obsolete outlet.Do
not defeat the purpose of the grounding-type plug.
10. Do not allow anything to rest on the power cord.Do not locate this product where persons will walk
on the cord.
11. If an extension cord is used with this product,make sure that the total of the ampere ratings on the
product plugged into the extension cord to the waplugged into outlet does not exceed 15 ampere.
12. Never push objects of any kind into this product through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a risk of fire or electric shock.Never spill liquid
of any kind on the product.
13. Do not attempt to service this product yourself,as opening or removing covers may expose you to
dangerous voltage points or other risks.Refer all servicing to service personnel.
14. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the
following conditions.
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally,when the operating instructions are followed.Adjust
only those controls that are covered by the operating instructions since improper adjustment of
other controls may result in damage and will often require extension work by a qualified
technician to restore the product to normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance,indicating a need for service.

B. SPECIFICATIONS
1. Maximum Resolution 1024 x 768 @ 75Hz
2. Recommend Resolution 1024 x 768 @ 60Hz
3. Synchronization Range
Horizontal
Vertical
31 – 60 KHz
56– 75 Hz
4. Active Display Area 304.1mm (H) x 228.1mm (V)
5. Dot Pitch 0.297(H) x 0.297(V) mm
6. Support display colors 16.7M color
7. Contrast Ratio (Typical) 500
8.Luminance of White 300cd/m²
9. Bandwidth 80MHz
10. User Control 4 Key Switch
11. OSD Function Brightness, Conrast, H-Position, V-Position, H-Size, Phase,
Color Select, Auto, Reset, Language, OSD Adjust, Exit
12. View Angle
Horizontal
Vertical
140 Degrees
120 Degrees
13. Power Source 100 – 240 Vac 60 / 50 Hz
14. Power Consumption 36W (max.)
15. Connection Type 15 Pin D Type
16. Input Signal
Video
Sync.
Analog R.G.B. , 0.7Vp-p / 75 Ohms
TTL level,positive or negative polarity
17. Color Temperature Cool / Warm
18. Dimension (WxHxD) 418mm x 421mm x 188mm
19. Monitor Weight 3.3 Kg
20. Base Operation
Tilt
0 / + 15 degree
21. Power Saving
ON
STAND BY
OFF
＜36W
＜5W
＜5W
22. Signal Connector Pin Assignment
Pin No.
1. Red 9. 5VDC
2. Green 10. Sync. Ground
3. Blue 11. Ground
4. Ground 12. SDA (For DDC)
5. Self Test 13. Horizontal Sync.
6. Red Ground 14. Vertical Sync.
7. Green Ground 15. SCL (For DDC)
8. Blue Ground
23. Audio signal 3.5Φstereo phone jack
Input Sensitivity : 200mV
2+2W 8ΩSpeaker

C.TIMING CHART
Video
Back porch Active display Front porch
Sync.
Sync-width
Total
Preset
Modes
VGA
720X400
VGA
640X480
VESA
640X480
VESA
640X480
VESA
800X600
VESA
800X600
Pixel clock
(MHz)
28.325 25.175 31.500 31.500 36.000 40.000
H-Frequency
(KHz) 31.472 31.469 37.861 37.500 35.156 37.879
H-Total (µs) 31.774 31.778 26.413 26.667 28.444 26.400
H-Active Display (µs) 25.419 25.422 20.317 20.317 22.222 20.000
H-Blanking (µs) 6.355 6.356 6.095 6.349 6.222 6.400
Front Porch (µs) 0.635 0.636 0.762 0.508 0.667 1.000
H-Sync-width (µs) 3.813 3.813 1.270 2.032 2.000 3.200
H-Back Porch (µs) 1.906 1.907 4.063 3.810 3.556 2.200
V-Frequency
(Hz)
70.1 59.94 72.81 75.0 56.25 60.3
V-Total
(ms) 14.267 16.683 13.735 13.333 17.778 16.579
V-Active Display (ms) 12.710 15.253 12.678 12.800 17.067 15.840
V-Blanking (ms) 1.557 1.430 1.057 0.533 0.711 0.739
V-Front Porch (ms) 0.413 0.318 0.238 0.027 0.028 0.026
V-Sync-width (ms) 0.064 0.064 0.079 0.080 0.057 0.106
V-Back Porch (ms) 1.080 1.049 0.740 0.427 0.626 0.607
H/V Sync. Polarity －＋－－－－－－＋＋＋＋
Interlace NONE NONE NONE NONE NONE NONE

Preset
Modes
VESA
800X600
VESA
800X600
VESA
1024X768
VESA
1024X768
VESA
1024X768
Pixel clock (MHz) 50.000 49.500 65.000 75.000 78.750
H-Frequency (KHz) 48.077 46.875 48.363 56.476 60.023
H-Total (µs) 20.800 21.333 20.677 17.707 16.660
H-Active Display (µs) 16.000 16.162 15.754 13.563 13.003
H-Blanking (µs) 4.800 5.172 4.923 4.053 3.657
Front Porch (µs) 1.120 0.323 0.369 0.320 0.203
H-Sync-width (µs) 2.400 1.616 2.092 1.813 1.219
H-Back Porch (µs) 1.280 3.232 2.462 1.920 2.235
V-Frequency (Hz) 72.2 75.0 60.0 70.1 75.0
V-Total (ms) 13.853 13.333 16.666 14.272 13.328
V-Active Display (ms) 12.480 12.800 15.880 13.599 12.795
V-Blanking (ms) 1.373 0.533 0.786 0.673 0.533
V-Front Porch (ms) 0.770 0.021 0.062 0.053 0.017
V-Sync-width (ms) 0.125 0.064 0.124 0.106 0.050
V-Back Porch (ms) 0.478 0.448 0.600 0.513 0.466
H/V Sync. Polarity ＋＋＋＋－－－－＋＋
Interlace NONE NONE NONE NONE NONE

D. CONTROL LOCATION
Font control panel
1. Menu Button
2. Select Button
3. Auto Button
4. Power Button
5. LED (Power Display)
Rear panel
1. VGA Signal Cable
2. Power jack
3. Line in jack

E. CONDUCTION VIEW
MAIN BOARD (Component Side)

MAIN BOARD (Solid Side)

CONTROL BOARD (Component Side)
CONTROL BOARD (Solid Side)

F. ADJUSTMENT PROCEDURE
ITEM
P
rogram Menu.
﹟Test Meter
﹡Test Point
﹫Pattern
Operation
Check
Value
A
B+
Check
﹟Digital Voltmeter
﹡CN7
﹫Crosshatch Pattern
(31.5KHz,640x480)
1. Plug power cable into the adapter, check adapter
power indicator light up green.
2. Make sure the voltage of the power plug (CN7)
on the main PCB to the value shown at right.
12.0V
±0.2V
B
Power Savin
g
Check
﹟Wattmeter
﹟PC or Pattern
generator
﹫Crosshatch Pattern
(31.5KHz,640x480)
1. Unplug the signal cable into the monitor.
2. Turn the power switch of the monitor ON.
3. Check monitor power indicator light up orange.
4. Make sure the wattmeter value shown at right.
5. OSD will be display “NO SIGNAL” Picture.
‹ 5W
C
Into Factory
mode
﹟PC or Pattern
generator
﹫Crosshatch Pattern
(31.5KHz,640x480)
1. Hold ‹key,then turn the power switch of the
monitor OFF.
2. Hold ›key,then turn the power switch of the
monitor ON.
3. You can into factory adjustment mode.
D
Auto mode
Check
﹟PC or Pattern
generator
﹫Crosshatch Pattern
(1024x768/60Hz)
1. Press and relese the MENU knob to activate the
OSD menu.
2. Move the OSD to the AUTO function,press MENU
key auto adjuat display mode to its utmost
performance according to VGA setting.
3. In the event of the display image needs further
adjustment
E
White
Balance
Adjust
﹟PC or Pattern
generator
﹫White Pattern
(1024x768/60Hz)
1. Move the OSD to the COLOR mode (AUTO COLOR).
2. set color is 9300°Kusing the OSD,Check the value
shown at below.
Y = 220 x = 0.283 y = 0.297
3. set color is 6500°Kusing the OSD,Check the value
shown at right.
Y = 220 x = 0.311 y = 0.329
Y = 220
±0.1FL
x = 0.283
±0.01
y = 0.297
±0.01
F
OSD
Language
Setting
﹟PC or Pattern
generator
1. Move the OSD to the LANGUAGE mode.
2. You can choose one of the eight language you need.

G. TROUBLE SHOOTING HINTS
NO NO
LED ON ?
YES YES
YES YES
NO NO
High Voltage !
NO
YES
YES
NO NO
YES
Power
adapter ?
Change
adapter
LED Color
change ?
Check main
board U2/Pin2
Make sure the
connection of
Inverter is fine
Check
F1(Fuse) of inverter
B
Display ?
OK !
Check the CN1/Pin1
of Inverter
+12V ?
To Step 2
Back light
ON?
Hi / Lo under
push power
sw?
Push the power
ON/OFF switch
No Displa
y
( Black )
To Step 2
A

NO
YES
YES
NO
YES
NO
B
Hi / Lo under
push power
sw?
Change the
Inverter
Display ? OK !
Check the
connection o
f
CN8 cable Change the
main board
OK !
Display ?
A
Change the
main board
To Step 2

NO
YES
NO
YES
YES
YES
YES
NO
NO
YES
Check the main
board 12V ?
Check
F1,D5
+5.0 V ? Check
U9,U11,R43
Check
U5
Check the main
board U5 / Pin 3 ?
H/V input
Signal ?
Change
U8
Check
H/V Signal
Change
Signal Cable
Display ?
OK !
Step 2

NO
YES
NO
YES
NO
YES
YES
NO
NO
Check the main
board 5V ?
Check
U9,U11,R43
+3.3V ? Check
U7,U12
Change
Signal Cable
Display ?
Check
H/V Signal
H/V Input
Signal ?
Check the main
board U8/Pin1 ?
Check
3.3V Circuit
Change
U8
No display
(White)
YES
OK !

H. REPLACEMENT PARTS LIST
AL532
NO Parts No. Description Part Location Q’ty
988-1A0-1001C AS-576 Pcking material+TCO99 SANYO 1
002-001-TCO9 TCO99 Dcclaration 1
002-L01-5EACER AS576 User’s Manul Acer logo 1
003-101-TCO9 All Series TCO99 Label for Crton 1
005-002-5EACER AS576 Carton Acer Logo 1
170-000-0848C PE BAG 0.07mm 14*30.5cm. 1
170-005-LCD5 LCD 15" PE Bag For DC Line 1
170-005-VM541 LT-541 PE Zipper Bag 300*200mm. For LCD 1
826-000-AS576 AS-576 Series pcking material For Manual 1
160-00L-AS576 AS576 Polyfom (L). 1
160-00R-AS576 AS576 Polyfom (R). 1
846-120-C0AL-AT Adapter 12V 3A 36W 1
003-H01-AS576 Acer AL532 TCO99 Label 1
003-401-AS576 Acer AL532 Carton Label 1
002-G00-ACER
N
F-787NS warranty card for Europe"Acer” 1
902-AS0-1001C AS-576 TUV/GS/CE TCO99 Panel 1
151-002-AS576 AS576 Rear cover Acer 1
154-002-ABS6E Plastic material ABS HB EM-006E 1
110-4R0-20646 Screw M4*H8*Φ6.6mm 2
154-001-AS576 AS576 Key TOP PC 1
123-B02-AS576 AS576"Acer+AL532" logo 1
820-001-5EST AS576 stand ass’y 1
123-701-AS576 AS576 Base neck AL or ZN. 1
123-700-AS576 AS576 Base AL or ZN. 1
155-001-AS576 Rubber 10*20 Black 4
100-010-4033 Screw P4*10 ISO BASE+NECK*3 3
600-151-0404 Power cord for Germany 150cm White 1
610-151-15RM-1 SH570/770Signal Cable UL20276 1.5m 1
827-001-AS576 AS-576 LCD Panel Assy material for SANYO 1
100-008-3013 Screw R3*8mm TP1 For Key Top*2 2
100-010-4033 Screw P4*10 ISO
N
eck+Hinge*2 2
101-005-2032 Screw M2*5 ISO Speaker*4 4
101-005-3032 Screw M3.0*5 ISO. Main PCB*4, Inverter*2 6
103-006-4033 Screw F4*6mm ISO ZI3C For Rear Cover+Hinge 1
103-010-3012 Screw TAP-BASE. Panel+Rear Plate*4 4
105-006-3012 Screw T3*6mm TP1. Control PCB*2 2
105-006-4033-1 Screw T4*6mm ISO Hinge+Rear Plate*2 2
105-010-3012 SCREW T3*10mm TP1. Rear Plate+Rear Cabinet*4 4
110-4R0-20646 Screw M4*H8*Φ6.6mm For Rear Cabinet*2 2
154-002-AS576 AS576 Mylar Sheet T=0.5mm For Panel C02RD0534 1

506-178-E62BP-40 SMD CPU IC(WINBOND:W78E62BP-40 P1 for U2 ,Socket 1
631-003-A014-C Audio Cable 3.5ØSTERE0 to 2*RCA connector 1
631-006-7020-T SH570/770 1061#28 6P2.0mm EMI 1
631-008-G020-W 8Pin 1.5Pitch <-> 8Pin 1.5Pitch CTR/B->M/B 1
631-030-F576 30 PIN FFC Cable L182mm 1
631-040-F576 40 PIN FFC Cable L193mm 1
824-00Q-AY565L AY565 Speaker Ass'y L 1
154-000-SPCS AY/CY Series Speaker Case 006 ABS HB 1
710-20A-Y565 AY/CY-565 Speaker (8Ω/1.5W) 40*20mm 1
631-002-904L CY/AY-565 Speaker Wire 2.0mm pith 1
824-00Q-AY565R AY565 Speaker Ass'y R 1
154-000-SPCS AY/CY Series Speaker Case 006 ABS HB 1
710-20A-Y565 AY/CY-565 Speaker (8Ω/1.5W) 40*20mm 1
631-002-902R HG562A R Speaker Wire 2.0-TIN. 1
154-003-AS576 AS576 Mylar Sheet 168*126mm 1
831-300-0100 Key 粘膠 (5000NS) 1
831-750-0500 Tape 50mm Black For Key Top*1 0.032
121-000-AS576 Rear Plate SECC 1.0T. 1
126-000-AS576 AS576 Hinge Steelness. 1
600-151-5004-M Power Cord for UK 150cm White 1
600-151-5504 Power Crd for Swiss 150cm 白色. 1
899-00M-AS576 AS576 Main PCB for SANYO Panel 1
852-00M-AS576 AS576 Main PCB for SANYO Panel SMD 1
200-100-AS576 AS576 Main Board PCB 1
281-031-20014 SMD RES 2K ohm 0603. 1% R55 1
281-031-62014 SMD RES 6.2K ohm 0603 R46 1
281-035-0R04 SMD RES 0 ohm 0603 5% L12,R21,S1,S2,R13,R14,R63,R64,R65 9
281-035-1014 SMD RES 100 ohm 0603 5% R42,R44,R45,R82 4
281-035-1024 SMD RES 1K ohm 0603 5% R6,R7,R24,R29,R30,R31,R33,R37,R73 9
281-035-1034 SMD RES 10k ohm 0603 5% R2,R8,R9,R15,R34,R35,R36,R48,R61,R70 10
281-035-1054 SMD RES 1M ohm 0603 R53,R17 2
281-035-1514 SMD RES 1M ohm 0603 R12 1
281-035-2034 SMD RES 20K ohm 0603 R56,R59,R78,R80,R84,R87,R88,R90 8
281-035-2224 SMD RES 2.2K ohm 0603 R22,R25,R40,R41,R52,R81,R83 7
281-035-3304 SMD RES 33 ohm 0603 R3,R5,R47,R50,R51,L11 6
281-035-3334 SMD RES 33K ohm 0603 R85,R57 2
281-035-4704 SMD RES 47 ohm 0603 R72 1
281-035-4724 SMD RES 4.7K ohm 0603 R4,R11,R16,R19,R20,R28,R32,R39 8
281-035-4734 SMD RES 47K ohm 0603 R66,R77 2
281-035-5104 SMD RES 51 ohm 0603 R68,R71 2
281-035-5114 SMD RES 510 ohm 0603 R10 1
281-035-7504 SMD RES 75 ohm 0603 R1,R74,R75,R76 4
282-330-2454 SMD RES 33 ohm 1206 ARRAY RP1,RP4,RP5,RP6,RP7,RP8,RP9,RP10,RP11,RP12,
RP13,RP14,RP15,RP16 14
282-472-2454 SND RES 4.7K ohm 1206 8P4R RP3 1

381-151-032554 SMD CC 150pF/25V NPO 0603 C77 1
381-220-032554 SMD CC 22pF/25V NPO 0603 C17,C18,C56,C62,C70,C97,C98,C127 8
381-301-032554 SMD CC 300pF/25V NPO 0603 C68 1
381-330-032554 SMD CC 33pF/25V NPO 0603 C100,C131 2
382-103-032564 SMD CC 0.01uF/25V X7R 0603 C47,C50,C60,C72,C74,C82,C86,C88,C90,C93,C107,
C110,C112 13
382-393-032564 SMD CC 0.039uF/25V X7R 0603 C84 1
382-472-035064 SMD CC 4700pF/50V X7R C87,C91,C94 3
382-682-035064 SMD CC 6800P/50V X7R 0603 C135,C99 2
385-104-032584 SMD CC 0.1uF/25V Y5V 0603
C1,C2,C3,C4,C5,C7,C8,C9,C10,C14,C15,C16,C20,
C21,C23,C24,C25,C26,C28,C29,C33,C36,C41,C43,
C44,C45,C46,C49,C51,C52,C53,C54,C55,C57,C58,
C61,C63,C65,C66,C69,C78,C83,C85,C89,C92,C95,
C96,C111,C115,C116,C117,C118,C125,C126
54
385-105-041684 CHIP-C 1uF/16V Y5V 0805 C130,C132,C133 3
481-LCC-0440 PLCC SOC 44PIN 1.27 U2 1
485-415-S070 D-SUB 3R15 FEMALE 180D 7.0 CN9 1
506-0AI-C1084 SMD IC AIC1084CM REG. 3.3V 5A U7 1
506-0AI-CX33 SMD IC AIC1720-33 100mA SOT89 U12 1
506-0AP-4835 SMD IC APA4835RI AUDIO/ANPEC U14 1
506-2AI-C1578 SMD IC AIC1578 U11 1
506-524-LC21 SMD IC 24LC21 MEMORY U13 1
506-5NM-24C16 SMD IC NM24C16M-8 U1 1
506-774-LVT14 SMD IC 74LVT14 ADCW HI SPEED U10 1
506-800-358D SMD IC LM358D S08 OP U5 1
506-SMA-SCOT-V SMD IC SCALER CHIP MASCOT V MRT U8 1
518-02N-3904 TR. 2N3904 SMD Q1,Q2,Q3,Q4,Q5 5
518-1CE-9435 SMD IC CE9435A C08 MOSFET U4,U9 2
528-2BA-T54C SMD DIODE BAT54C SOT23 Q6 1
558-352-5000 SMD FUSE 1206 24V 5A F1 1
780-103-3000 SMD BEAD SBK160808-300Y (0603) L13,L14 2
780-104-6010 SMD BEAD SBK-201209T-601Y-S (0805) L9,L10,L16,L20,L21 5
780-107-1210 SMD BEAD MLB-321611-0120P-N1 (1206) L1,L6,L8,L18 4
630-030-9003A FFC CNC 30P 0.5 CN6 1
630-040-9003A FFC CNC 40P 0.5 CN3 1
780-103-8000A SMD Bead FCM1608K-800T07 L22,L23,L24 3
780-103-3000A Bead FCM1608K-300T07 L25,L26,L27 3
003-H02-ALL9 ALL AI PCB code 15*8MM Label (white) 1
851-00M-AS576 AS576 Main PCB for SANYO Panel DIP 1
232-R02-505T WR-C-5W 0.020ohm 5% R43 1
330-100-16255 EC H5mm 10uF/16V 105C M TP C104 1
330-101-16255 EC H5mm 100uF/16V 105C M TP C6,C37,C39,C42,C64,C75,C101,C124 8
330-220-16255 EC H5mm 22uF/16V 105C 4*5 C22 1
330-221-16255 EC H5mm 220uF/16V 105C M C38,C40,C48,C59,C79,C119 6
330-2R2-50275 EC H5mm 2.2uF/50V 105C C123 1
409-003-0110 DC Jack 3.5D SCD510 CN12 1

409-003-0111 RCA Jack SCP606 CN11 1
409-003-0112 RCA Jack SCP606 CN10 1
504-000-6300L Reset IC. V6300L TO92 (DIP) TU2 1
504-007-A431 KIA431/KEC TU3 1
520-030-B340-T Schttky SB340 TP D4 1
531-110-49US Crystal 11.0592MHz X1 1
531-120-49US Crystal 12MHz X2 1
630-002-1008 Base Pitch 2.0 2Pin JWT A2001 CN7,CN8 2
630-006-4002R Base Pitch 2.0 6Pin CN5 1
630-008-C001 JST 1.5mm Header ZR S8B-ZR CN2 1
745-050-3072 Line Coil 5uH JBT0385 100805-4 L19 1
745-470-20621 Choke 47UH@3A L7 1
152-000-SH570 TOSHIBA DC Jack Support Nylon. 1
849-40X-AS576 Inverter 2 to 4 8ma E-MAX 1
899-400-AS576 AS-576 Control PCB Ass'y. 1
200-701-0576 AS576 Control Key PCB 1
401-170-0220 Tact Switch H5mm S1,S2,S3,S4,S5 5
520-005-L937 LED 2Pin Blue/Yellow L937MBYW D1 1
630-008-C001 JST 1.5mm Header ZR S8B-ZR J1 1
705-350-2916 SANYO Panel TM150XG-26L06A. 1
