Acer X193HQ Series User manual

- 1 -
Product Service Manual – X193HQ
Service Manual for acer: X193HQ
P/N: 9J.0NA11.xxx
9J.0NA12.xxx
Applicable for All Regions
Version: 001
Date:2008/07/15
Notice:
- For RO to input specific “Legal Requirement” in specific NS regarding to r
esponsibility and liability
statements.
First Edition (July, 2008)
© Copyright Acer Corporation 2008. All Right Reserved.

- 2 -
Content Index
Abbreviations & Acronyms ............................................................................... 3
1. About This Manual ......................................................................................... 3
1.1. Trademark ........................................................................................................ 3
2. Introduction .................................................................................................... 4
2.1. RoHS (2002/95/EC) Requirements ................................................................. 4
2.2. Safety Notice ................................................................................................... 4
2.3 .Compliance Statement.................................................................................... 4
2.4. General Descriptions ...................................................................................... 4
3. Product Overview........................................................................................... 5
3.1. Introduction ..................................................................................................... 5
3.2. Operational Specification............................................................................... 6
3.3. Operational & Functional Specification ...................................................... 10
3.4. LCD Characteristics...................................................................................... 13
3.5. User Controls ................................................................................................ 14
3.6. Mechanical Characteristics.......................................................................... 15
3.7. Pallet & Shipment.......................................................................................... 16
3.8. Certification ................................................................................................... 16
3.9 Packing ........................................................................................................... 18
4. Disassembly /Assembly .............................................................................. 19
4.1. Exploded View.............................................................................................. 19
4.2. Disassembly /Assembly ............................................................................... 20
5. Level 1 Cosmetic / Appearance / Alignment Service ............................... 28
5.1 Alignment procedure (for function adjustment) .......................................... 28
5.2 Software / Firmware Upgrade Process......................................................... 31
5.3 EDID Upgrade Procedure .............................................................................. 36
5.4 OSD Operation Guide .................................................................................... 39
6. Level 2 Circuit Board and Standard Parts Replacement ......................... 43
6.1. Trouble Shooting Guide................................................................................ 43
6.2 Circuit Operation Theory ............................................................................... 46
6.3 Spare Parts List .............................................................................................. 49
Appendix 1 – Screw List / Torque................................................................... 50
Appendix 2 – Physical Dimension Front View and Side view..................... 51
Appendix 3 – Control Board ........................................................................... 53
Appendix 4 –Power Board .............................................................................. 54
Appendix 5 –Interface Board .......................................................................... 56

- 3 -
Abbreviations & Acronyms
1. About This Manual
This manual contains information about maintenance and service of acer products.
Use this manual to perform diagnostics tests, troubleshoot problems, and align the
acer product.
1.1. Trademark
The following terms are trademarks of Acer Inc. :
Acer
Importance
Only trained service personnel who are familiar with this Acer Product
shall perform service or maintenance to it. Before performing any
maintenance or service, the engineer MUST read the “Safety Note”.

- 4 -
2. Introduction
This section contains general service information, please read through carefully. It should be
stored for easy access place for quick reference.
2.1. RoHS (2002/95/EC) Requirements
– Applied to all countries require RoHS.
The RoHS (Restriction of Hazardous Substance in Electrical and Electronic Equipment Directive)
is a legal requirement by EU (European Union) for the global electronics industry which sold in EU
and some counties also require this requirement. Any electrical and electronics products
launched in the market after June 2006 should meet this RoHS requirements. Products launched
in the market before June 2006 are not required to compliant with RoHS parts. If the original
parts are not RoHS complaints, the replacement parts can be non ROHS complaints, but if the
original parts are RoHS compliant, the replacement parts MUST be RoHS complaints.
If the product service or maintenance require replacing any parts, please confirming the RoHS
requirement before replace them.
2.2. Safety Notice
1. Make sure your working environment is dry and clean, and meets all government safety
requirements.
2. Ensure that other persons are safe while you are servicing the product.
DO NOT perform any action that may cause a hazard to the customer or make the product
unsafe.
3. Use proper safety devices to ensure your personal safety.
4. Always use approved tools and test equipment for servicing.
5. Never assume the product’s power is disconnected from the mains power supply. Check that
it is disconnected before opening the product’s cabinet.
6. Modules containing electrical components are sensitive to electrostatic discharge (ESD).
Follow ESD safety procedures while handling these parts.
7. Some products contain more than one battery. Do not disassemble any battery, or expose it to
high temperatures such as throwing into fire, or it may explode.
8. Refer to government requirements for battery recycling or disposal.
2.3 .Compliance Statement
Caution: This Optical Storage Product contains a Laser device. Refer to the product specifications
and your local Laser Safety Compliance Requirements.
2.4. General Descriptions
This Service Manual contains general information. There are 3 levels of service:
Level 1: Cosmetic / Appearance / Alignment Service
Level 2: Circuit Board or Standard Parts Replacement
Level 3: Component Repair to Circuit Boards

- 5 -
3. Product Overview
3.1. Introduction
X193HQ is defined as 18.5”W LCD Monitor supports 1366x768@60Hz resolution with DPMS
(Display Power Management System) and acer eColor function. There are dual input types, D-sub,
DVI. X193HQ adopts AUO panel, M185XW01 V0 and scalar, RTD2525LH.
The features summary is shown as below,
* All panel spec. in Q201 definition depends on the variance of panel source.
* All spec. of monitor need to warm up at least 1hr.
* To test the “Contrast Ratio” and “Luminance” functions, the color status must be “User
preset” mode.
* 1. “Contrast Ratio”: Set “brightness” at 100, and “contrast” at 50.
* 2. “Luminance”: Set “brightness” at 100, and “contrast” at 100.
Feature items Specifications Remark
Panel supplier & module name AUO M185XW01 V0 TN, Normally white
Screen diagonal 470.1 mm(18.51”)
409.8 mm(H) x230.4
mm(V)
Display Format 1366(H) x 768 (V) Panel Display information
Pixel Pitch 0.3(H) x 0.3(V) (TYP.) per one triad
Viewing Angle (@ Contrast Ratio >= 10)
R/L:85/85 degrees (typ)
and U/D: 80/80 degrees
(typ)
Analog interface with Scaling supported Yes
With 15-pin D-sub
connector
DVI interface with Scaling supported Yes For 1A1D model
Max resolution mode supported 1366 (H) x 768 (V)@60Hz
Number of Display Colors supported 16.7 Millions RGB 6-bit +HiFRC
Contrast Ratio 1000:1 (typ.), 600 (min)
Test Condition: Set
Contrast at 50, Brightness
at 100, Color at User
preset
Luminance 300 cd/m2(typ.), 240 cd/m2
(min)
Test Condition: Set
contrast at 100, brightness
at 100 , color at User
preset.
AC power input Yes 90-264 Volts, 47-63 Hz.
DC power input (with AC power adapter) No
DPMS supported Yes <1W
LED indicator for power status showed Yes Blue/Amber/None
OSD for control & information supported Yes
Multi-language supported for OSD Yes EMEA
Non-EMEA
Buttons control supported Yes
6 buttons including 1
monitor power on/off
control button.
Flywheel control supported No
Scaling function supported Yes

- 6 -
Auto adjustment function supported Yes “Auto-Key” function
DDC function supported (EDID ver. 1.3) Yes DDC2B
DDC-CI support version 1.1 or later Yes DDC-CI
Audio speakers supported No
Audio Jack (input connector) supported No
Earphone Jack (input connector)
supported No
Microphone function supported No
Mechanical Tilt base design Yes From -5 to +23 degree
VESA wall mounting design Yes
Mechanical Rotate design No
Mechanical Lift base design No
Kensington compatible lock design Yes
3.2. Operational Specification
3.2.1 Power supply
Item Condition Spec OK N.A Remark
Input Voltage range Universal input full
range 90~264VAC /47~63Hz
√
Input Current range 90 ~ 264VAC ≤2.0 Arms √
Power Consumption Normal “On” operation ≤30 W √ LED: Blue
DPMS DPMS “Sleep” state ≤2 W √ LED: Amber
DPMS DPMS “Off” state ≤1 W √ LED: OFF
Inrush Current 110 VAC
220 VAC
< 30 A (peak)
< 60 A (peak) √
Cold-start
Earth Leakage Current 264 VAC/50Hz < 3.5 mA √
Hi-Pot
1. 1500VAC, 1 sec
2. Ground test: 30A,
1sec
Without damage
< 0.1 ohm √
(on-line test)
(in-lab test)
Power Line Transient IEC1000-4-4 1KV √
IEC1000-4-5 (Surge) Common: 2KV,
Differential: 1KV √
CCFL operation range 90 ~ 264VAC 3~8mA √ Depends on panel
source
CCFL Frequency 90 ~ 264VAC 40KHz ~ 80KHz √ Depends on panel
source
Power cord
Color: Black
Length: 1800 +/- 50
mm
√

- 7 -
3.2.2 Signal interface
Item Condition Spec OK N.A Remark
15-pin D-Sub
Color: Black
Length: 1800 +/- 30
mm
√
Signal Cable
24-pin DVI-D
Color: Black
Length: 1800 +/- 50
mm
√
15-pin D-sub
connector
See Note-1 √ For 15-pin D-sub
24-pin DVI-D
connector
See Note-2 √ For 24-pin DVI-D
Pin assignment
19-pin HDMI
connector
See Note-3 √For 19-pin HDMI
Signal type
Separate analog R/G/B
√
For 15-pin D-sub
Level 700 mV (peak to peak)
√
Analog input
Impedance 75 Ohms +/- 1.5 Ohms
√
Signal type Separate H/V-sync
(Positive/Negative) √
For 15-pin D-sub
Level
Logic High: 2.4V ~
5.5V
Logic Low: 0V ~ 0.5V
(TTL level)
√
Refer to VESA
VSIS Standard
V1R1
Impedance Minimum 2.2KΩ(pull
down) √
10KΩfor
application
Sync input
Sync Pulse Width
(SPW)
0.7µs < H-SPW
1H < V-SPW
√
Level 600mV for each
differential line
√
Digital input Impedance 50 Ohm TDR Scan
needed for DVI cable
and interface board
√
Note-1: The pin assignment of 15-pin D-sub connector is as below,
Pin Signal Assignment Pin Signal Assignment
1 Red video 9 PC5V (+5 volt power)
2 Green video 10 Sync Ground
3 Blue video 11 Ground
4 Ground 12 SDA
5 Cable Detected 13 H-Sync (or H+V)
6 Red Ground 14 V-sync
7 Green Ground 15 SCL
8 Blue Ground

- 8 -
Note-2: The pin assignment of 24-pin DVI-D connector is as below,
Pin Signal Assignment Pin Signal Assignment
1 TMDS RX2- 13 Floating
2 TMDS RX2+ 14 +5V Power
3 TMDS Ground 15 Ground
4 Floating 16 Hot Plug Detect
5 Floating 17 TMDS RX0-
6 DDC Clock 18 TMDS RX0+
7 DDC Data 19 TMDS Ground
8 Floating 20 Floating
9 TMDS RX1- 21 Floating
10 TMDS RX1+ 22 TMDS Ground
11 TMDS Ground 23 TMDS Clock+
12 Floating 24 TMDS Clock-
3.2.3 Video performance
Item Condition Spec OK N.A Remark
Max. support Pixel rate 135 MHz √
Both for analog and
digital inputs
Max. Resolution 1366 x 768 √
Both for analog and
digital inputs
Rise time + Fall time
< 5 ms
(50% of minimum pixel
clock period)
√
1366 x 768 @ 60Hz
(max. support
timing)
Settling Time after
overshoot /undershoot
< 5% final full-scale
value √
Refer to VESA
VSIS Standard
V1R1
Overshoot/Undershoot
< 12% of step function
voltage level over the
full voltage range
√
Refer to VESA
VSIS Standard
V1R1
3.2.4 Scan range
Item Condition Spec OK N.A Remark
Horizontal 31-80KHz √
Vertical 55-76 Hz √

- 9 -
3.2.5 Plug & Play DDC2B DDC-CI Support
Item Condition Spec OK N.A Remark
DDC channel type DDC2B √
EDID Version 1.3 √
Refer to S/W spec.
document to see
the detailed EDID
data definition.
DDC-CI Version 1.1 or Later √
Refer to S/W spec
3.2.6 Support Timings
Mode
Resolution
(active dot)
Resolution
(total dot)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Nominal Pixel
Clock (MHz)
640x480@60Hz 800 x 525 31.469 59.941 25.175
640x480@72Hz 832 x 520 37.861 72.809 31.500
640x480@75Hz 840 x 500 37.500 75.000 31.500
MAC
640x480@66.66Hz
864x525 35 66.66 30.24
VESA 720x400@70Hz 900x449 31.469 70.087 28.322
800x600@56Hz 1024 x 625 35.156 56.250 36.000
800x600@60Hz 1056 x 628 37.879 60.317 40.000
SVGA
800x600@75Hz 1056x625 46.875 75.000 49.500
MAC 832x624@74.55Hz 1152x667 49.722 74.55 57.28
1024x768@60Hz 1344x806 48.363 60.004 65.000
1024x768@70Hz 1328x806 56.476 70.069 75.000
XGA
1024x768@75Hz 1312x800 60.023 75.029 78.750
MAC 1152x870@75Hz 1568x909 68.700 75.000 84.520
1152x864@75Hz 1600x900 67.5 75 108
VESA
1280x960@60Hz 1800x1000 60 60 108
1280x1024@60Hz 1688x1066 63.981 60.020 108.000
SXGA
1280x1024@75Hz 1688x1066 79.976 75.025 135.000
1280x720@60Hz 1650x750 44.955 59.940 74.176
1280x768@60Hz 1664x798 47.776 59.870 79.500
VESA
1280x768@75Hz 1696x805 60.289 74.893 102.250
WXGA
1280x800@60Hz 1680x831 49.702 59.81 83.5
1366x768@60Hz 1792x798 47.712 59.79 85.5
Note:
1. Show “Input Not Supported” warning message. When Vertical Frequency is over 76Hz or
under 55Hz, but Pixel Clock is between 25.175MHz and 135MHz, the monitor can show
image, and the same time has “Input Not Supported” warning message. If Pixel Clock is over
the range of 25.175MHz ~ 135MHz, the display is Black and show warning message.
2. If Hf /Vf is set in the range of 31KHz~80KHz and 55Hz ~76Hz, and Pixel Clock is set in the
range of 25.175MHz~135MHz, but is not the above Resolution, then it will display the nearest
mode.

- 10 -
3.3. Operational & Functional Specification
3.3.1 Video performance
*All spec. of monitor need to warm up at least 1hr.
Item Condition Spec OK N.
A
Remark
Resolution
Any input resolution
modes which are under
1366x768
1366x768 √
Contrast ratio 600(min),1000(typ) √
Test Condition:
Set Contrast at
50, Brightness
at 100, Color at
User preset.
Brightness At R/G/B saturated
condition 300 cd/m2(typ.),240(min)
√
Test
Condition : Set
contrast at
100 ,
brightness at
100 , color at
User preset.
Response time Rising + Falling time On/off:5 ms
(typ.),8ms(max) √
Test
Equipment:
Westar TRD
100 or equal
level
equipment ;
At Contrast ratio = 10 R/L: 85/85 degrees (typ.)
75/75 degrees (min) √
Viewing angle
At Contrast ratio = 10 U/D: 80/80 degrees (typ.)
70/70 degress(min) √
CIE coordinate of White (0.313, 0.329) +/- (0.03,
0.03) √
Display colors 16.7 Millions colors √ 6 bit+HiFRC
3.3.2 Brightness Adjustable Range
Item Condition Spec OK N.
A
Remark
Brightness adjustable
range
At default contrast level
(saturate point) & Full-
white color pattern
(Max. brightness value –
Min. brightness value)
≧100 cd/㎡
√
3.3.3 Acoustical Noise
Item Condition Spec OK N.
A
Remark
At 30cm distance ≦22dB/A √
Acoustical Noise At 5cm distance ≦35dB √
Need to test if
system acoustic test
is failed. Monitor
internal key
components (power,
inverter, panel...)

- 11 -
3.3.4 Environment
Item Condition Spec OK N.
A
Remark
Operating 0 ~ +40 ℃√
Temperature Non-operating -20 ~ +60 ℃√
Operating 10 ~ 90% √Non-
condensing
Humidity
Non-operating 10 ~ 90% √Non-
condensing
Operating 12,000(ft) √at 25°C (hold
3.5 hrs)
Altitude
Non-operating 40,000(ft) √at -30 °C (hold
1 hr)
3.3.5 Transportation
Item Condition Spec OK N.
A
Remark
(1) Vibration Package, Non-Operating
Test Specification:
1. Frequency Hertz 5 ~
250 HZ , PSD Level
0.0054 (G2/Hz)
2. Grms = 1.146
3. Sweep Time : 30
minutes per Axis
4. Axes : X,Y,Z
√
(2) Unpackaged Vibration
Unpackaged, Non-
Operating
Test Spectrum:
20 Hz 0.0185(g2/Hz)
200Hz 0.0185(g2/Hz)
Duration
: 5 Minutes
Axis : 3 axis
( Horizontal and Vertical
axis ,Z axis)
(3) Drop Package, Non-Operating
76 cm Height (MP stage)
(1 corner, 3 edges, 6
faces)
√
(4) Shock Wooden package, Non-
Operating
1. Amplitude : Half sine-
wave 50G
2. Duration : 10 ms
3. Test Times : 1
4.Test Sides : All 6 Sides
√
3.3.6 Electrostatic Discharge Requirements
Item Condition Spec OK N.
A
Remark
Electrostatic Discharge IEC801-2 standard Contact: 8KV
Air: 15KV √

- 12 -
3.3.7 EMC
Item Condition Spec OK N.
A
Remark
Electric Band 1 < 10 V/m
Band 2 < 1 V/m √
TCO03
Magnetic Band 1 < 200nT
Band 2 < 25nT √
FCC part 15J class B
EMI
EN55022 class B
After Mass production
under 1dBuv for constant
measure. Besides DNSF
and VCCI class-2 are
optional.
√
3.3.8 Reliability
Item Condition Spec OK N.
A
Remark
MTBF Prediction Follow Qisda Generic
Spec > 25,000 Hours √Excluding CCFL
CCFL Life time At 25℃, under 6.5mA 40,000 Hours (min) √See Note-4
Note-4: CCFL lifetime is determined as the time at which brightness of lamp is 50%. The typical
lifetime of CCFL is on the condition of 7.5mA CCFL current and 25±2℃.
3.3.9 Audio performance
Item Condition Spec OK N.
A
Remark
Preamp + Power amp
(1)Output power 1 W rms/CH @ 1KHz √
(2)THD (@ 1W) <1% √
(3)S/N ratio >40dB √
Speaker Driver
(1)Nominal impedance 8 ohm √
(2)Rated input power 1 W/CH √
(3)Frequency response 500~20KHz SPL-10dB √
(4)Output sound pressure
level
80 ± 3 dB (1W 0.5M) √
(5)Dimension of box 63x25x13mm2√
Audio Control
(1)Volume range 0 ~100 levels √
(2)Mute On/Off √

- 13 -
3.4. LCD Characteristics
3.4.1 The Physical definition & Technology summary of LCD panel
AUO M185XW01 V0
Item Condition Spec OK N.
A
Remark
LCD Panel Supplier AUO √
Panel type of Supplier M185XW01 V0 √
Screen Diagonal 470.1 mm(18.5”W) √
Display area Unit=mm 409.8(H) x230.4(V) √
Physical Size Unit=mm 430.37(H) x254.6(V) x 16.5(D) √
Weight Unit=gram 2000(Max) √
Technology TN type √
Pixel pitch Unit=mm 0.3(H) x 0.3(W) √Per one triad
Pixel arrangement R/G/B vertical stripe √
Display mode Normally White √
Support color 16.7Millions colors √6 bit + HiFRC
3.4.2 Optical characteristics of LCD panel
AUO M185XW01 V.0
Item Unit Conditions Min. Typ. Max. Remark
[degree]
[degree]
Horizontal (Right)
CR = 10 (Left)
75
75
85
85
-
-
Viewing Angle [degree]
[degree]
Vertical (Up)
CR = 10 (Down)
70
70
80
80
-
-
Contrast ratio Normal Direction 600 1000
[msec] Rising Time - 3.6 5.7
[msec] Falling Time - 1.4 2.3
Response Time
[msec] Rising + Falling - 5 8
Red x 0.618 0.648 0.678
Red y 0.309 0.339 0.369
Green x 0.262 0.292 0.322
Green y 0.573 0.603 0.633
Blue x 0.113 0.143 0.173
Color / Chromaticity
Coordinates (CIE)
Blue y 0.040 0.070 0.100
White x 0.283 0.313 0.343Color Coordinates (CIE)
White
White y 0.299 0.329 0.359
Luminance Uniformity [%] 9 points
measurement 75 80
White Luminance @ CCFL
7.50mA (center)
[cd/m2] 240 300 -
Crosstalk (in 75Hz) [%] 1.5
* The test methods for the above items’ definition, please refer to the relative panel specification.

- 14 -
3.5. User Controls
3.5.1 User’s hardware control definition
Item Condition Spec OK N.A Remark
Power button √
Auto button(Exit button) √
Right/Inc. button √
Left/Dec. button √
Menu button √
Mode button √
Input Select button √
E-Key button √
Mute button √
3.5.2 OSD control function definition
Item Condition Spec OK N.A Remark
Auto Adjust Auto-Geometry √
Brightness √
Contrast √
Horizontal Position √
Vertical Position √
Pixel Clock √
Phase √
Color
Cool:色溫 9300
Warm:色溫 6500
User: Separate R/G/B
adjustment
Reset Color
√
OSD Position OSD Horizontal position
OSD Vertical position √
OSD Time From 10 sec to 120 sec √
OSD Lock √
Language
EMEA/Non-EMEA
languages for Asia/Europe
Version
√
Recall Recall All √
Mode Acer Empower Mode √
Input Select D-sub
DVI √
Sharpness √
Display Information For input timing √
Volume √
Mute √
Hot key for Auto √
Hot key for Contrast √
Hot key for Volume √
Hot key for Input Select √
Hot key for Mode √
The detailed firmware functions’ specification, please refer to C212 S/W spec. document.

- 15 -
3.6. Mechanical Characteristics
3.6.1 Dimension
Item Condition Spec OK N.A Remark
Bezel opening 411.7*232.3 mm √
Monitor without Stand W x H x D mm 456.41*280.56*68.46m
m √
Monitor with Stand W x H x D mm 456.41*334.54*163.72m
m √
Carton Box (outside) L x W x H mm 504*126*394mm √
Tilt and Swivel range Tilt: -5 ~ +15 degree
Swivel: 0 degree √
3.6.2 Weight
Item Condition Spec OK N.A Remark
Monitor (Net) 3.56Kg √
Monitor with packing
(Gross)
4.22Kg √
3.6.3 Plastic
Item Condition Spec OK N.A Remark
Flammability >ABS<,94-HB √
Heat deflection To ABS 65 ℃√
UV stability ABS Delta E < 8.0 √
Resin
BEZEL: PMMA+ABS
UC,BASE:ABS
(Bezel:Cheil/BF
-0677F,
LG/XG586,BASF/
BX13036)
Other:
HF380/SD0150)
√
Texture UC:AT-IM-D02;
Bezel: AT-IM-D01 √
Color BEZEL : DB19A;
UC: DB19A √
3.6.4 Carton
Item Condition Spec OK N.A Remark
Color Kraft √
Material B Flute √
Compression strength 200KGF √
Burst Strength 16 KGF/cm2√
Stacked quantity 4 Layers Vertical +2
layers H √

- 16 -
3.7. Pallet & Shipment
3.7.1 Container Specification
Stowing Type
ontainer
Quantity of products
(sets)
(Every container)
Quantity of Products
(sets)
(Every Pallet)
Quantity of pallet
(sets)
(Every Container)
20' 940 Pallet A: 94 Pallet A: 10
Pallet B: Pallet B:
40' 2068 Pallet A: 94 Pallet A: 22
With pallet
Pallet B: Pallet B:
20' X X
X X
40' X X
Without pallet
X X
3.7.2 Carton Specification
3.7.2.1 Product:
Net Weight (Kg) Gross Weight (Kg) Dimension w/o Base
W*H*D (mm)
Dimension w/ Base
W*H*D (mm)
3.56Kg 4.22Kg 456.41*280.56*68.46mm 456.41*334.54*163.72mm
3.7.2.2Package:
Carton Interior Dimension (mm)
L*W*H
Carton External Dimension (mm)
L*W*H
496*117*379mm 504*126*394mm
3.8. Certification
Item Condition Spec OK N.A Remark
Green design API Doc. 715-C49 √
ISO14000
Requirement
Blue Angel German Standard √
E-2000 Switzerland √
EPA USA Standard √
TCO’99 √
TCO’03 √
MPR2 √
Environment
Green Mark √
Microsoft Windows PC98/99 √
DPMS VESA √
DDC 2B Version 1.3 √
PC-Monitor
USB External √
UL (USA) UL60950 3rd edition √
CSA (Canada) CAN/CSA-C22.2 No.
60950 √
Safety
Nordic / D.N.S.F EN60950 √

- 17 -
FIMKO EN60950 √
CE Mark 73/23/EEC √
CB IEC60950 √
CB EN60950 √
TUV/GS EN60950 /
EK1-ITB 2000:2003 √
CCC (China) CB4943 √
GOST EN60950 √
TUV type-approved √
SASO IEC60950 √
CE Mark 89/336/EEC √
FCC (USA) FCC Part 15 B √
EN55022 Class B √
CISPR 22 Class B √
VCCI (Japan) VCCI Class B √
BSMI (Taiwan) CNS 13438 √
EMC
C-Tick (Australia) AS/ NZS CISPR22 √
DHHS (21 CFR) USA X- Ray Standard √
DNHW √
X- Ray Requirement
PTB German X- Ray
standard √
TUV / Ergo √
ISO 13406-2 √
Ergonomics
prEN50279 √

- 18 -
3.9 Packing

- 19 -
4. Disassembly /Assembly
4.1. Exploded View
1
1
2
1
3
1
5
1
4
1
10
1
7
1
9
1
6
1
11
8
1
18
19
14
13
12
20
15
17 16

- 20 -
4.2. Disassembly /Assembly
Assembly SOP
Preparation before assemble
1. Clean the room for work
2. Identify the area for material
3. Prepare the implement, equipments, material as bellow:
1) Press-fixture
2) Working table
3) Screw-driver
4) Knife*1
5) Glove
6) Cleaning cloth
7) ESD protection
ite
m
picture Operation Tool Notes
1
Put panel on the
cushion carefully,
2 Stick a big Al tape to
panel which can protect
the WIRE.
3 Check and put CLM-F
on the cushion
carefully,
