ACHOICE P1 User manual
User Manual
True Wireless Earbuds
01
09
18
26
34
Appearance
1
1
65
3
2
4
7
Earbuds cap
01
2Charging port 3Touch control 4Indicator
5
Microphone 6Charging contactor 7Charging case
01
Charging the Earbuds
Place earbuds into the charging case to charge. The red light mean they're
being charged from charging case. It will be turn off when fully charged.
Red light off
Red light on（Charging）
（fully charged）
Blue light flash
Blue light on
（Charging）
（fully charged）
Charging the Case
Charge the case with USB-C cable to 5V/1A adaptor , the blue indicator keep
flashing when charging. It will stop flashing when fully charged.
Note:Min 10 minutes at the 1st time Check the earbuds' power in the phone
status bar after connect to the device.
Charging
01
Specifications
Bluetooth Profile
Bluetooth Codec
Waterproof
Transmission distance
Horn
Standby time
Music playback time
Earbuds battery
Charging case battery
Charging time
Charging input
Product Weight
Product Size
Bluetooth version
HFP HSP A2DP AVRVP
AAC SBC
IPX5
>10m
Φ13.0 * H2.8mm * 2
60 hours
4 hours (45% volume)
35mAh
500mAh
2h±0.1h
Type-C 5V / 800mA (Max 1A)
Charging case 40.3g, Earbuds 3.5g*2
53.27*29.12*59.16mm
V5.0
01
Power On
Take out earbuds from the case,
it will power on automatically.
Power Off
Put earbuds back into the case,
it will shut down automatically.
Notes:
When you want to turn off one of the individual earbuds during use, touch
the left/right earbud for 7 seconds and the voice prompts "power off".
When you want to turn on one of the individual earbuds during use, touch
the left/right earbud for 4 seconds and the voice prompts "power on".
Power ON/OFF
L R
L R
01
The size of caps would affect the comfort of use, please select the proper
earbud cap according to the ear canal to place when wear earphones.
Earbuds Led Indicator
Wear Tips
Power off
Pairing state
Pair succeed
Charging process
Fully charged
DUT mode
Power on
Blue light on for 1 second
The main earbud flashes red and blue alternately
The light off
Red light on
Red light o
purple light on
Red light on for 1 second
S
M
L
01
1. Take out earphones from the case, it will automatically power on and pair
with each other(L&R), with red light.
2. Once paired successfully, the red light will become to the red & blue alternately.
3. Open Bluetooth of your device, choose P1 to pair. The light will turn off when
finish to pair with your device (10-15m without obstacle).
Way to Pair
When the device turn off Bluetooth, or it's over the range to connect, the
earbuds will be waiting to connect. If there is no connection with 5 minutes,
the earbuds will power off.
Disconnection
Red light
（pairing）
L R
P1
F1
The earbuds will automatically connect with the device they were last paired
with when the case is opened.
Each earbud could be used independently.
Notes:
01
Operation & Response
Answer calling Tap L/R when incoming calls
Cut calling Touch L/R for 2 seconds
Pause/Play Tap L/R when listen music
Previous Double tap L
Next Double tap R
Game mode
Touch and hold L/R for 2 seconds to
turn on/off game mode
Sound alert one beep game mode off,
two beeps game mode disconnect
Factory reset
Under the shut-down and disconnection,
touch L/R for 6 seconds, remove historical
record of connection
Voice assistant Triple tap L/R to wake up
Sir/Google voice assistant
01
After Service
Warning
We provide 1 year warranty service. If you have other issues during your use,
This product has built-in lithium battery.Do not expose the
product to strong sunlight, fire or throw it to the fire to
avoid explosion.
1. Keep away from extreme ambient temperatures below -20 degrees or
above 50 degrees .
2. Keep away from children and pets.
3. Keep away from corrosive liquids to avoid damages to the product.
4. Don't use the product in thunderstorm weather to avoid malfunction or
electric shock.
5. If it has not been used for more than a month, please charge and maintain
it in time to ensure that it is safe.
Model: P1 Made in China
FCC ID: WC2-00T82
