iMoshion TWS In-Ear Headset User manual

User Manual
TWS In-Ear Headset

In the Box
• TWS earphones with charging case
• Charging cable
• User’s instructions
Specifications
• Bluetooth 5.1: 10 m range
• Play time: 4-5 h
• Charging-case battery: 250 mAh
• Earphone battery: 25 mAh
• Charging time: 40-60 minutes
• Charging-case input: 5 V
• Frequency: 20-20000 Hz
• Sensitivity: 103 dB
EN

Charging
During charging, the LED flashes orange.
When fully charged, the LED is solid orange.
Note
To maintain the life cycle of their batteries, the
earphones and the charging case should be charged
at least once a month. Use a 5 V charger to charge
the case. Using fast chargers with an output over 5 V
may damage the charging case.
Touch Controls
• Play/pause, answer/end call: tap once
• Reject an incoming call: press for 2 seconds
• Previous track: tap twice on the L earphone
• Next track: tap twice on the R earphone
• Activate voice assistant: press for 2 seconds
then release
Product Overview
1. Charging case
2. LED indicator
3. USB-C charging port
4. Mic
5. Touch controls
6. Charging contacts
1 2 3 4 5 6
ENEN

Power On/Off
Automatic
• Turn on: take the earphones out of the
charging case.
• Turn off: place the earphones back in
the case.
Manual
• Turn on: press for 2 seconds.
• Turn off: press for 5 seconds.
Note
When the earphones are not connected to any
Bluetooth-compatible device for 3 minutes, they
will automatically turn off.
ENEN
Bluetooth Pairing
First use
1. Turn on the earphones. The two earphones will
automatically connect to each other and go into
pairing mode. In pairing mode, the LED indicator on
one of the earphones will flash red and blue, while
the LED indicator on the other earphone will stop
flashing.
2. Make sure the Bluetooth function on your smart-
phone (or another compatible device) is activated.
3. Select “iMoshion TWS-i2” from the phone’s list of
available Bluetooth devices.
Automatic pairing
After they have been manually paired to a device, the
earphones will automatically connect to it every time
they are turned on provided the device is within their
Bluetooth range and its Bluetooth function is on.

Troubleshooting
A. The earphones cannot be turned on.
Check if the earphones still have battery power.
Place the earphones in the charging case and
connect the case to power to charge for at
least 1 h.
B. Only one earphone has sound, and the 2
earphones cannot pair to each other.
1. Make sure both earphones are charged and
can be turned on.
2. With the earphones turned off, tap 7 times to
reset and return them to the factory settings.
Manually pair the earphones with the device
anew.
C. The Bluetooth device cannot find the earphones.
1. The battery of the earphones is low.
2. The earphones are out of the device’s 10 m
Bluetooth range.
3. Check if there are too many Bluetooth devices in
the area. Turn some of them off and try again.
D. The earphones are stuck or disconnect
while in use.
1. Check if their battery is low.
2. The earphones are out of the device’s 10 m
Bluetooth range.
3. An obstacle is blocking the Bluetooth signal.
4. The earphones are not paired and synchronized.
Restart them.
ENEN

Safety Instructions
• Do not use the earphones in situations where your
hearing is required to avoid injury or damage.
• To avoid hearing damage, keep the volume at a
moderate level when using the earphones. If you feel
uncomfortable, remove the earphones, or turn down
the volume immediately.
• To avoid distraction, do not use the earphones to listen
to music or to take calls while driving and follow the
legislation in your area.
• To avoid improper use, keep the earphones out of
children’s reach.
• Do not store or use the earphones at extreme tempe-
ratures, otherwise the lifespan of the battery may be
affected.
• Do not use the earphones in hot and humid environ-
ments such as in bathrooms.
• Do not immerse or expose the earphones to water or
other liquids. Do not expose them to direct sunlight for
an extended period.
• Do not open, dismantle, or attempt to repair the ear-
phones yourself as that may cause damage, fire etc.
Imported by:
M&M E-Commerce BV, Buitenplaatsweg 1,
3833 AG Leusden, The Netherlands
For Europe:
Frequency band of operation: 2,400 to 2,483,5 MHz.
Bluetooth: maximum transmit power less than 20 dBm/
MHz EIRP.
Bluetooth Low Energy: maximum power spectral density
less than 10 dBm/MHz EIRP.
The crossed-out wheelie-bin symbol means that,
in the European Union, this product must not be
disposed of with unsorted household waste. It
must be delivered to an appropriate recycling
facility in your area.
Area for declaration of conformitiy.
ENEN
