Ack!Industries dAck! User manual

1
dAck!
Instruction Manual
Rev. 1.3
Overview
Thank you very much for choosing the Ack!Industries dAck!. The dAck! is a self-
contained digital-to-analog converter intended for use with high-fidelity audio systems. It takes
as input a digital signal compliant with the S/PDIF standard and generates high quality two-
channel analog signals for use into a preamplifier or integrated amplifier. This D-to-A converter
utilizes the filterless concept devised by Ryohei Kusunoki (MJ Magazine, 1996-7) to provide
focused and cohesive, yet dynamic, sound that embodies many of the features inherent in analog
music reproduction. dAck! is designed to be compatible with a very wide variety of systems,
and its primary design goal is to provide long-term satisfaction to the end user.
Please study this manual carefully before using your dAck!. We ask that you pay special
attention to the important battery usage information on page 3. Understanding this information
will ensure that your dAck! delivers its full potential for the duration of your ownership.
Preparation for use
dAck! should be carefully removed from the packaging. Make sure that both of the
following parts are accounted for: 1) dAck! chassis, and 2) Battery charger. The charger
requires minor assembly before it can be used. Please refer to Appendix A for instructions on
how to prepare the charger for use.
Place the unit on a stable support surface in a location where it will not be knocked over.
As with any high-fidelity equipment, a good support surface may improve its performance by
isolating it from external vibrations. Do not place any equipment or small items on top of the

2
dAck!’s vent holes. If you would like to prevent dust from entering the chassis, it is OK to cover
the unit with a light cloth when not in use.
Familiarize yourself with the dAck!’s inputs, outputs, and controls. The following
figures show the important features and their purposes.
Connect the input of the dAck! to your digital source’s digital output. Best performance
will be obtained if you use a 75Ωcable with 75Ωterminations (if using BNC, keep in mind that
BNC termination alone is not an indicator of matched impedance; many BNC terminations have
a non-75Ωimpedance spec, usually 50Ω). Next, connect the dAck!’s outputs (Red=right
channel, Black=left channel) to your pre-amplifier or integrated amplifier inputs using a high-
quality pair of interconnects.
Plug the charger unit into an available power outlet (120VAC) and connect the charger’s
output to the charger in socket on dAck!’s rear panel. The quality of power supplying the
charger has no effect on sound, so the charger needs not be placed on a specially conditioned AC
circuit. It is advantageous to place the charger in a location where its indicator lights will be
easily seen.
Operation
When the switch is in the up position, your dAck! is energized and ready for use. A blue
indicator will illuminate, showing that the circuit is receiving power. When there is a compatible
signal at the digital input, a green indicator will also illuminate, showing that there is a data latch.
Some digital transports maintain a datastream even when not playing while others latch only
when playing music, so the behavior of the latch indicator will depend on your particular
transport. The dAck! is designed to latch quickly to incoming digital signals. If for some reason
Front
Back

3
the unit fails to latch when first turned on, quickly cycling power on the unit may yield the latch
condition.
The dAck! will sound great as soon as it is turned on. However, allowing a few minutes
for the circuit to stabilize will result in best performance. Since the circuit does not run hot, the
only major break-in will be in forming and conditioning capacitor dielectrics. This will occur
over the course of a couple weeks, after which the unit will give a slightly warmer, fuller sound.
Since it has been designed for utmost simplicity, the dAck! will only properly decode
44KHz, 16-bit stereo signals. If the input contains the wrong type of signal (for example, DTS
5.1 from a DVD), dAck! will still try to interpret the incorrect data, producing noise from its
audio outputs. In the case of multi-channel movies, dAck! will only work properly if the digital
source is configured for two-channel stereo.
Care and Maintenance
When the switch is in the down position, the batteries are being charged. An orange LED
indicator on the battery charger means that the dAck! is in bulk charge mode. Avoid interrupting
the bulk charge cycle if possible. When the light on the battery charger is green, the dAck!’s
battery cells are full or nearly full and are being float charged. Your dAck! will be happiest if it
is allowed to float charge most of the time. The charger light stays green when no load is
attached to it, showing that it is working properly. Keep the charger attached to the dAck! at all
times.
Important!
 For best battery life, we recommend that you not use your
dAck! for more than 8 hours between recharge cycles, or
about 10 CDs. (For rapid charger version , <3 hours between
recharge cycles, or 3-4 CDs).
 When dAck! is not being used, it should always be switched to
charge mode (switch in down position).
 Do not forget to turn off your dAck! when not in use or you may
severely diminish its battery performance.†
More details on battery use can be found in Appendix B at the end of this manual.
Store the batteries in a fully charged state. If the charger is not connected to AC – for
example if you are going to store your dAck! for a long period of time – disconnect the charger
from the rear panel. The batteries will deteriorate if connected to a non-energized charger during
storage.
†Note: If you discover you have forgotten to turn your dAck! off for several hours, immediately switch it into
charge mode and allow it to float charge for at least 2 hours before use.

4
dAck! ships for use in the horizontal position. By default, the power switch actuates in
an up-and-down direction relative to a horizontally-oriented chassis. The unit is also
configurable as a space-saving vertical tower with a small footprint. If this is the preferred
configuration, the power switch can be rotated counter-clockwise by 90° for vertical actuation
using a pair of needle-nose pliers.
The enclosure can be cleaned with a slightly moist cloth. Avoid allowing water to enter
inside the chassis. A weak solvent such as rubbing alcohol can be used to remove smudges and
fingerprints. No other routine service is necessary.
With proper care, your dAck! will provide the same level of performance for years.

5
Technical specifications
The Ack!Industries dAck! is a high-performance digital to analog converter. It utilizes a
Cirrus Logic receiver chip to interpret S/PDIF signals for D-to-A conversion using the Philips
TDA1545 continuous calibration DAC chip. The DAC chip output is converted to analog
voltage signals using high-precision FET-input operational amplifiers from Analog Devices
biased into class-A operation for high linearity and low output impedance. Three precision-
regulated supplies power the main circuit, with bulk power provided by batteries for perfect
isolation and stable supply.
Special care has been taken to guarantee low noise and electrical isolation. The metal
chassis acts to block RFI and stray magnetic fields. The input is configured to latch very quickly
to incoming signals. Furthermore, the DAC is decoupled from the digital circuit, rejecting much
of the noise commonly found in DVD players connected to TV’s. This also makes dAck! an
outstanding interface between hi-fi systems and PC’s, which are notoriously noisy due to high-
speed internal signals and switching power supplies.
Each analog channel passes through a single ultra-precision bulk foil resistor and a high-
quality film capacitor. Ground is referenced to the preamplifer ground through the left RCA
jack.
Input: Gold-plated 75ΩRCA input for receiving S/PDIF compliant signal
(44KHz 16-bit stereo only)
Output: Gold-plated stereo single-ended outputs
 Output impedance: <100Ω
 Downstream component should have >5KΩinput impedance
Signal amplitude: 2V peak-to-peak for 1KHz 0dB signal
Quiescent current: 4-6mA per channel
Power supply: 12V sealed lead acid cells
Power consumption: ~100mA during playback
Charger supply: 12V 1000mA automatic charger
Play time per charge: 4hr maximum (recommended)
Charge time: <45min typical after 4 hours use; <2hr from deep discharge.
Dimensions: 15.25cm x 19cm x 6.5cm (6” x 7.5” x 2.5”)
Weight: 2.25kg (5lbs)

6
Warranty
•30 day limited warranty on batteries
•1 year parts and labor limited warranty
Batteries are covered for one month from date of purchase. Batteries will be replaced
within the 30-day warranty period in the event of failure to supply 4 hours of continuous power
after having had 24 hours of continuous float charge. The warranty coverage does not apply in
the event of battery misuse (i.e., deliberate deep discharge), incorrect connection, or use of
batteries for devices other than the Ack!Industries dAck!.
The parts and labor warranty covers defects in materials and workmanship in your dAck!,
excluding batteries, for up to one year from date of purchase. Warranty service or replacement
will be provided free of charge in the event of component failure. This does not cover neglectful
use, utilization in a way not specified in this manual, or normal wear and tear (surface finish,
humidity, etc.). In the event of service need, the customer is responsible for transport costs to
and from factory, and assuring safeguards such as adequate packaging and insurance provisions.
All questions and concerns should be directed to Ack!Industries
WWW: http://ack.dhs.org
E-mail: [email protected]

7
Appendix A: Charger assembly
Minor assembly is required. The distribution cable is packed separately from the charger
and must be connected to the terminals of the charger before use. You will need a Philips head
screwdriver for assembly. Follow these steps:
1. Identify the polarity of the terminals on the
cable as well as on the charger (see photos
on right).†
2. Unscrew the terminal screws slightly and
insert the terminal forks underneath the
square washers.
3. Tighten the terminal screws with moderate
force. Do not overtighten.
4. Put the plastic cap over the screw terminals to
prevent an accidental short. If the polarity is
reversed, the cap will not fit properly.
†Do not connect charger with incorrect polarity to the dAck!, as this
will degrade and ultimately destroy the power cells.
Appendix B: Charger use
The indicator on the charger denotes the health status of the charger and battery. The
colors depict the state of the charger, and the condition of the batteries can be inferred by reading
this indicator.
POWER/FLOAT – When the charger is plugged into the
AC mains with no cells connected, the indicator should be
green. When the power cells are connected to the charger,
this indicator also shows when the cells are float charging.
This is the healthiest condition and the dAck! should be
kept in this mode as often as possible.†
FAST CHARGE – When the charger is connected to depleted cells, they undergo
a rapid charge cycle. At this point, the indicator should turn yellow. The yellow
indicator will turn green when the charger enters float mode.
FAULT – A red indicator denotes fault status. It indicates a grounding error,
batteries connected with incorrect polarity, or internal fault. If a red indicator
illuminates and you cannot determine the cause of the problem, please contact
Ack!Industries for help.
†Technical note: When the indicator switches from yellow to green, the cells are not 100% charged. In actuality,
the charger switches to float status at about 90% capacity and gradually ramps the cells to 100% over a long period
of time.

8
Maintaining the life of your power cells
The following table shows the recommended schedule for charge/discharge for both
charger models compatible with the dAck!:
Type rating
cycle time
(recommended)
max cycle
time
recharge
time
Standard 0.3A 0-8hr 10hr overnight
Rapid 0.8A 0-3hr 5hr 30min
For best battery life, cycle the batteries in a shallow fashion, and try to allow the cells to reach
float status before using them again. We do not advise exceeding the recommended cycle time.
If you discover that you have forgotten to turn your dAck! off for several hours beyond the
recommended cycle time, immediately switch to charge mode and allow it to float charge for
several hours before use.
As the power cells age, their maximum cycle time will get shorter. Appropriately de-
rating (shortening) the cycle time will allow more recharge cycles out of the cells. When the
maximum cycle time becomes too short for your listening habits, it is time to replace the cells.
Replacement power cells are available from Ack!Industries.
Standard – this model is designed for lengthier listening habits. It provides gentler charging
conditions appropriate for deep discharge cycles, perfect if you use your dAck! for 0-8
hours at a time. The charge time from a deep discharge is several hours, so it is perfect
for day-long listening followed by recharging overnight.
Rapid – this charger’s usage is similar to the original chargers that previously shipped with the
dAck!. It offers fast recovery time from discharge, but requires shallow cycling. We
recommend using this charger if you tend to listen to music for 0-3 hours at a time and
often switch between sources. Its recharge times are similar to those of the original
dAck! charger.
The usage schedule presented above is designed for battery longevity – if you do not
mind shortening battery lifespan, you can push the cells further. There is considerable overlap
between usage schedule of the two charger types, so if you have standard, you can still cycle
quickly as you would with the rapid charger without damage. Likewise, if you have rapid, you
can extend the play time every so often. The key to battery longevity is to keep the indicator
green most of the time, which means remembering to turn the dAck! off when not in use.
Happy listening!
All questions and concerns should be directed to Ack!Industries
WWW: http://ack.dhs.org
E-mail: [email protected]
