Caton Vpro 5100 User manual

VprO 5100/5100D User's Guide
Professional
Professional
Professional
Professional H.264/MPEG-2
H.264/MPEG-2
H.264/MPEG-2
H.264/MPEG-2 HD
HD
HD
HD
Integrated
Integrated
Integrated
Integrated Receiver
Receiver
Receiver
Receiver Decoder
Decoder
Decoder
Decoder
Vpro
Vpro
Vpro
Vpro 5100/5100D
5100/5100D
5100/5100D
5100/5100D User's
User's
User's
User's Guide
Guide
Guide
Guide
Copyright © 2009-2010 Caton Technology Inc all rights reserved
Revision 1.2

VprO 5100/5100D User's Guide
- 2 -
CONTENTS
CONTENTS
CONTENTS
CONTENTS
CONTENTS ............................................................................................................................................... - 2 -
ABOUT THIS MANUAL ........................................................................................................................... - 3 -
END USER LICENSE AGREEMENT .................................................................................................... - 4 -
1.Introduction ............................................................................................................................................. - 6 -
1-1 Overview ..................................................................................................................................... - 6 -
1-2 Features ...................................................................................................................................... - 6 -
1-3 Feature Highlights ...................................................................................................................... - 7 -
1-4 Component Names .................................................................................................................... - 7 -
2. Front panel Control .............................................................................................................................. - 8 -
2-1Basic Operations ......................................................................................................................... - 8 -
2-1-1 Turn on the VprO ............................................................................................................ - 8 -
2-1-2 Operating status display ................................................................................................ - 8 -
2-1-3 LEDs status introduction ............................................................................................... - 8 -
2-1-4 Basic set operations ....................................................................................................... - 9 -
2-2 VprO Menu Hierarchy ................................................................................................................ - 10 -
2-3 Receiver Menu ......................................................................................................................... - 13 -
2-3-1 Tuner1 and Tuner2 menu parameters setting and display .................................... - 13 -
2-3-2 ASI menu parameter display ...................................................................................... - 14 -
2-3-3 IP menu parameter setting and display .................................................................... - 14 -
2-4 Decoder Menu .......................................................................................................................... - 15 -
2-5 CA Menu .................................................................................................................................... - 18 -
2-6 TSOUT Menu ........................................................................................................................... - 19 -
2-7 Testsig Menu ............................................................................................................................ - 19 -
2-8 System Menu ............................................................................................................................ - 20 -
3 . Web Control ......................................................................................................................................... - 21 -
3-1 Some operate pages in common use ................................................................................... - 22 -
3-1-1 Receiver column ........................................................................................................... - 22 -
3-1-2 Decoder column ........................................................................................................... - 22 -
3-1-3 System column ............................................................................................................. - 23 -
4 . SNMP Control ...................................................................................................................................... - 25 -
5. Addendum ............................................................................................................................................ - 27 -
5-1 Upgrade and technical support .............................................................................................. - 27 -
5-2 Other products of Caton Technology .......................................................................................... - 27 -

VprO 5100/5100D User's Guide
- 3 -
ABOUT
ABOUT
ABOUT
ABOUT THIS
THIS
THIS
THIS MANUAL
MANUAL
MANUAL
MANUAL
The information in this manual is considered to be changed without notice, and the Caton
technology Inc will not take any responsibility for the likely impact of the changes. The use of the
product should be based on the terms of the agreement. No reproduction and dissemination of the
contents in this manual are permitted without the express written consent from Caton Technology
Inc, including photocopying, recording, information storage and recovery systems, etc.
Copyright © 2009-201 2 Caton Technology Inc all rights reserved.
Caton Technology Inc reserves the right to modify the manual without notice. Generally the
information provided in this document is correct and reliable. This manual shall be only used as a
usage guide, and no other products mentioned shall be considered as implied or express warranty
of any kind.
“ Caton ” and “ VprO ” are the trade marks of the Caton Technology Inc. The trade marks,
products labels, and product names of other companies described in this manual are owned by
their respective copyright holders.

VprO 5100/5100D User's Guide
- 4 -
END
END
END
END USER
USER
USER
USER LICENSE
LICENSE
LICENSE
LICENSE AGREEMENT
AGREEMENT
AGREEMENT
AGREEMENT
Important, please read carefully: this end user license agreement is the legal agreement
reached between you (personal) and Caton Technology Inc on “ Caton VprO H.264/MPEG2 HD
Professional Decoder ” . An amendment or additional terms of the agreement may be provided with
the “ Caton VprO H.264/MPEG2 HD Professional Decoder ” . Once you use the “ Caton VprO
H.264/MPEG2 HD Professional Decoder ” , it means that you accept the restrictions in the
agreement. If you do not agree to be bound by the terms and conditions of this agreement, please
do not use the product. Caton Technology Inc reserves the right to change and interpret the End
User License agreement.
PLEASE READ THE FOLLOWING TERMS AND CONDITIONS. USING OF THE DEVICE
INDICATES YOUR ACCEPTANCE OF THE FOLLOWING TERMS AND CONDITIONS.
(a) You have acquired a license granted by Caton Technology Inc with product warranty.
(b) You have acquired an amendment or additional terms of the “ Caton VprO H.264/MPEG2
HD Professional Decoder ” license.
1) PERENNIAL LICENSE. Under the Perennial License, Licensor grants you the rights as
followings:
Documentation License. The accompany documentation with “ Caton VprO H.264/MPEG2 HD
Professional Decoder ” could be only for internal and noncommercial use and reference.
2) License termination. Your license may be terminated if you install other version of “ Caton
VprO 3002 H.264/MPEG2 Professional Decoder ” restricted by the agreement; you relinquish all
rights granted under this agreement. Any such unauthorized use shall result in immediate and
automatic termination of this license. And you must stop using the device in any case
3) Rights reserved and all rights. All rights not expressly granted here are reserved to Caton
Technology Inc.
“ Caton VprO H.264/MPEG2 HD rofessional Decoder ” is protected by Copyright and other
Intellectual Property Laws and treaties. Caton Technology Inc has the entire property rights,
copyright and intellectual property of “ Caton VprO H.264/MPEG2 HD Professional Decoder ” . Your
license confers no title or owner ship in the copyright and the property right and should not be
construed as a sale of any right of the copyright and property right. And this agreement doesn ’ t
grant you the right to use the trade marks or product labels of Caton Technology Inc.
4) No rent/business hosting. You could never rent out “ Caton VprO H.264/MPEG2 HD
Professional Decoder ” , or provide commercial hosting services.
5) Using data
。
You allow Caton Technology Inc and its subsidiaries to collect and use the
relevant technical information of “ Caton VprO H.264/MPEG2 HD Professional Decoder ” as parts
of the provision of product support services, we could warrant the disclosure without revealing
your personal identity.
6) Additional software/services. Caton Technology Inc would provide the upgrade and
additional components, if there are additional provisions about it.
7) Export restrictions. You acknowledge that “ Caton VprO H.264/MPEG2 HD Professional
Decoder ” subject to U.S. export law. You agree to comply with all international and domestic law
applicable in “ Caton VprO H.264/MPEG2 HD Professional Decoder ” includes the U.S. Export
Administration Regulations, as well as end-users, end-use and destination restrictions issued by
the United States and other governments.
8) License Restrictions. You may not distribute, sublicense, transfer, or lend the license to any
third party.
9) Termination. If you do not comply with the terms and conditions in this agreement, Caton
Technology Inc may terminate this agreement without prejudice to any other rights.
Limited
Limited
Limited
Limited Warranty
Warranty
Warranty
Warranty and
and
and
and Disclaimer
Disclaimer
Disclaimer
Disclaimer of
of
of
of Warranty:
Warranty:
Warranty:
Warranty:
Statutory rights are not affected – the following warranties are not limited to any areas.
Warranty:
– Licensor warrants that it has the right and authority to grant the rights described in this

VprO 5100/5100D User's Guide
- 5 -
agreement. Licensor further warrants that the device as provided will substantially perform the
functions described in the document when operated in the intended environment. Caton
Technology Inc does not warrant that the device is error free. And Caton Technology Inc
warrants: for 90days since the license is working the device will work well as described in the
manual. And any supports and services should be substantially in accordance with the
agreement, and the support engineers will make reasonable efforts to solve the problems.
If you have any questions on this End User License Agreement, or want to contact Caton
Technology Inc for any reasons, please contact Caton Technology Inc.
http://www.caton.com.cn/en
Contact Information
：
Caton Technology Shanghai Branch
Room 1001,NO.77,Eshan Road,Pudong,Shanghai 200127,P.R.China
Phone ：[phone]
Fax ：[phone]
postal code ：200127
URL ：www.caton.com.cn

VprO 5100/5100D User's Guide
- 6 -
1.Introduction
1.Introduction
1.Introduction
1.Introduction
1-1
1-1
1-1
1-1 Overview
Overview
Overview
Overview
The VprO 5100/5100D is a broadcast-quality decoder, decryptor , TS Processor and
i nterface converter that provides MPEG-2 and H.264 SD/HD decoding, advanced
transport stream processing, cutting-edge IP processing technologies and variety of
front-ends, including DVB-S/S2, MPEG over IP and more.
The Vpro 5100/5100D enables the applications in receiving and decoding of HD/SD
streams transported through IP, satellite and ASI network. The system supports UDP
or RTP/UDP DVB over IP outputs, and multi-channel DVB-ASI outputs. The error
alarm and system log functions provide users with an easy approach to monitor and
control the broadcasting status and trouble clearing.
1-2
1-2
1-2
1-2 Features
Features
Features
Features
�Support IPTV
�Support point to point video capture
�Support real-time video conference
�Support real-time RVC
�Support SNG receiving

VprO 5100/5100D User's Guide
- 7 -
1-3
1-3
1-3
1-3 Feature
Feature
Feature
Feature Highlights
Highlights
Highlights
Highlights
● H.264(MPEG-4 AVC)High Profile@level 4.1HD decoding
● Multi-input and output selection;DVB-S/S2,DVB-ASI and IP input/output
● SDI output contained embedded audio and auxiliary data, enable AC3 pass through
● Supports SD/HD video format and converting the format up and down, selectable
output format includes: 576i, 480i, 720p/50Hz, 720p/60Hz, 1080i/25Hz, 1080i/30Hz,
1080i/29.97Hz
● Selectable control&monitor modes （Front panel, CGI, SNMP, CLI)
● Lower time delay, minimum 160ms for end to end latency
● Easy upgrade through WEB or FTP
● Dual CI descrambler interface use for decode or loop through, enable multi-channel
descrambling through CAM card, maximum 8 channels.
● Redundant power for base unit
● Aspect ratio: 4:3/16:9
1-4
1-4
1-4
1-4 Component
Component
Component
Component Names
Names
Names
Names
(1)(2)AES/EBU (3)(4)HD/SD-SDI (6)(8)RF IN (5)(7)RF Loop out
(9)Control Port (10)Stream Port (11)(12)ASI IN (13)(14)ASI OUT
(15)(16)CVBS OUT (17)RS232 (18)Analog Audio (19)(20)Power

VprO 5100/5100D User's Guide
- 8 -
2.
2.
2.
2. Front
Front
Front
Front panel
panel
panel
panel Control
Control
Control
Control
2-1Basic
2-1Basic
2-1Basic
2-1Basic Operations
Operations
Operations
Operations
2-1-1 Turn on the VprO
To turn on the VprO, follow these steps :
①Press the power switch on the rear panel.
②When the VprO is turned on, the message shown below appears on the
screen
Figure 2-1 Messages appearing after the VprO is turned on
The initializing sequence of VprO is within 30s. Turning it off and back on
in a short interval of time could cause it to malfunction .
2-1-2 Operating status display
After the initializing sequence is completed, the operating status window
displays on the screen as shown in Figure 2-2.
Figure 2-2 Operating Status Window
2-1-3 LEDs status introduction
①If no source detected by VprO. the LEDs appear as shown in Figure 2- 3
Figure 2- 3 No source detected by VprO
i nitializing
Receiver TSOut Decoder
System CAS Testsig

VprO 5100/5100D User's Guide
- 9 -
②If VprO has detected a valid source but decoding is not started, LEDs appear as
shown in Figure 2- 4
Figure 2- 4 Decoding is not started with valid source detected
③Under normal decoding condition, the LEDs appear as shown in Figure 2- 5
Figure 2- 5 Under normal decoding condition
④When press the UID key , the LEDs appear as shown in Figure 2-6
Figure 2- 6 When press the UID key
Apart from the above three cases, there may some hardware defects with
the device. In such cases, please contact your sales support for technical
review.
2-1-4 Basic set operations
Esc and UID key
LEDs
Direction and
Enter key
LCD

VprO 5100/5100D User's Guide
- 10 -
1. Navigating the menus:
Use ”▲“ , “▼” ," E nter"," Esc " to navigate the menus in VprO
2. Conducting settings in menus:
1) Use " ► " to enter “ editable mode ” ;
2) Then use ”▲““▼” " ◄ "" ► " to select the numbers or options;
3) Press the “ E nter ” key to save the settings ;
4) P ress “ E sc ” key to cancel the modification and quit “ editable mode ” .
3. Warm reboot by front panel:
1) Press " ◄ " and “ UID ” at th e same time.
2) When the screen shows message “ REBOOTING ” , release the button and wait
for finish.
3) After finishing rebooting the VprO, the screen displays as shown in Figure 2-2.
4. Keypad lock and unlock:
Press ”▲“ and “▼” at same time and hold for 3s will lock or unlock the keypad.
2-2
2-2
2-2
2-2 VprO
VprO
VprO
VprO Menu
Menu
Menu
Menu Hierarchy
Hierarchy
Hierarchy
Hierarchy
VprO menus are organized in a hierarchical structure, use up/down button to
navigate within a single menu level and enter/exit button to navigate to an upper or
lower menu.

VprO 5100/5100D User's Guide
- 11 -

VprO 5100/5100D User's Guide
- 12 -
Figure 2-6 shows the flow of navigating at the top(main) menu level
RECEIVER
SYSTEM
TSOUT
CA
DECODER
TESTSIG
To the Receiver setting menu
To the System setting menu
To the TSout setting menu
To the CA setting menu
To the Decoder setting menu
To the Testsig setting menu

VprO 5100/5100D User's Guide
- 13 -
2-3
2-3
2-3
2-3 Receiver
Receiver
Receiver
Receiver Menu
Menu
Menu
Menu
The Receiver menu has Tuner 1
、
Tuner2
、
ASI1
、
ASI2
、
IP f ive submenus
2-3-1 Tuner 1 and Tuner2 menu parameters setting and display
More information http://www.cnsat.net/
Name Setting range Explanation
Mode DVB-S /S2(readonly) Support DVB-S /S2 signal
Freq L Band 950-2150 950-2150MHz
KU Band 10750-12750 10750-12750MHz
C Band 3000-4200 3000-4200MHz
LNBH N/A
LNBL C Band 5150 5150MHz
KU Band 10000 10000MHz
11000 11000MHz
11300 11300MHz
11700 11700MHz
Current
LNB
10600 10600MHz
97500 97500MHz
LNBTone Default
Tone-OFF
22KHz
Sym Rate 2000-45000 2MBand-45MBand
Polarity Horizontal Demodulate in horizontal polarity
Vertical Demodulate in vertical polarity
Band C Band Demodulate in C band
KU Band Demodulate in KU band
Quality XXX% Display signal quality
Strength XXX% Display signal strength
When all the settings are correct, the status of tuner will shows SYNC
ON. If you want to use tuner as the source of decoding, don ’ t forget to select it
in workmode menu.

VprO 5100/5100D User's Guide
- 14 -
2-3-2 ASI menu parameter display
ASI menu requires no parameter setting and it works automatically. if valid signal
is detected, it will show SYNC ON.
2-3-3 IP menu parameter setting and display
Name Setting range Explanation
Port Num 0-65535 Set ip in port num
IP Type Multicast Set multicast receive mode
Unicast Set unicast receive mode
PKT Type RTP Receive RTP packet
UDP Receive Raw UDP packet
Multicast Addr XXX.XXX.XXX.XXX Set multicast address
SSM Enable Open SSM
Disable Close SSM
Source Addr XXX.XXX.XXX.XXX Set Source Address
When the RF signal is from a QPSK/8PSK modulator, you need to
check two things
One: if LnbLow=0 then Freq=DownFreq
Two: if LnbLo=!0 then
Under C band :Freq=LNBLow-DownFreq, LNBLow can be set 5150
Under KU band:Freq=LNBLow+DownFreq,LNBLow can be set 10000
Multicast setting will be active only if IP Type is set to Multicast. If IP
Type is set to Unicast, it uses the IP address which can be configured in
network menu.
When all of the parameter settings are correct the IP menu shows
SYNC ON. If you want to use IP as the source of decoding, don ’ t forget to
select it in workmode menu.

VprO 5100/5100D User's Guide
- 15 -
2
2
2
2 -4
-4
-4
-4 Decoder
Decoder
Decoder
Decoder Menu
Menu
Menu
Menu
Name Setting range E x planation
Source ASI 1 Select ASI 1 for source
ASI2 Select ASI 2 for source
Tuner 1 Select Tuner 1 for source
Tuner2 Select Tuner 2 for source
IP Select IP for source
Descramble1 Select Descramble1 for source
Descramble2 Select Descramble2 for source
Prose l M od e
(selected services ID)
Auto Auto work mode
(Decoder first service)
Manual Manual work mode
ServiceList* Select a program decoding
A/V Sync Auto Auto select SYNC
PCR Set PCR SYNC
VID Set VID SYNC
AUD Set AUD SYNC
OFF Set SYNC OFF
Video info Horizontal XXX( readonly ) Horizontal
Vertial XXX( readonly ) Vertical
AspectRatio X:X( readonly ) AspectRatio
Profile XX( readonly ) Profile
Level XX( readonly ) Level
Frame Rate XX( readonly ) Fram Rate
Encoding Type XXX( readonly ) Encoding Type
Pri-Aud Mute ON Open mute function
OFF close mute function
Volume
-50 ～0db
Set Audio volume
Delay 0-90msec Set Audio delay
SampleRate XXX( readonly ) SampleRate
BitRate XXX( readonly ) BitRate
Coding mode XXX( readonly ) Coding mode
Content XXX( readonly ) Content
DigitalOut AES/EBU Set AES/EBU Audio
PASS Audio pass througth
Mode Mono Mono
Stereo Strtro
Dual right Dual right
Dual left Dual left

VprO 5100/5100D User's Guide
- 16 -
AUD Buff 0-1200msec AUD Buff
Sec-Aud Mute ON Open mute function
OFF close mute function
Volume
-50 ～0db
Set Audio volume
Delay 0-90msec Set Audio delay
SampleRate XXX( readonly ) SampleRate
BitRate XXX( readonly ) BitRate
Coding mode XXX( readonly ) Coding mode
Content XXX( readonly ) Content
Mode Mono Mono
Stereo Strtro
Dual right Dual right
Dual left Dual left
AUD Buff 0-1200msec AUD Buff
Display Default Picture Black Set black default picture
Sync OFF Set sync off default picture
Freeze Set freeze default picture
Col.Bar Set col.bar default picture
Output Format 480i 480iHz
576i 576iHz
720p60 720p60Hz
1080i50 1080i50Hz
1080i59.94 1080i 59.94 Hz
1080i60 1080i60Hz
AspectRatio Auto Auto
16:9 Set 16:9 AspectRatio
4:3 Set 4:3 AspectRatio
AR convert PAN_SCR Set PAN_SCR AR convert
IGNORE Set IGNORE convert
COMBINE Set COMBINE convert
LET_BOX Set LET_BOX convert
Auto Mode: VprO will decode the first program automatically in the
selected source. Attention, decoding may failed if the first program is
scrambled, you may need an authorized access card form your service
provider.

VprO 5100/5100D User's Guide
- 17 -
2-5
2-5
2-5
2-5 CA
CA
CA
CA Menu
Menu
Menu
Menu
Name Setting range Explanation
CI CAM1 XXX (readonly) Information about CAM1
CAM1 Source Tuner1 Set Tuner 1 as Descramble1 source
Tuner2 Set Tuner 2 as Descramble1 source
ASI1 Set ASI1 as Descramble1 source
ASI2 Set ASI2 as Descramble1 source
The name preceeding with "$" indicates the program is a scrambled
one.
Only CVBS interface can support all 4 types of default picture. SDI
interface don't support Sync OFF and Col.Bar
Auto mode in Output Format can only output SD stream,when you
need to change SD to HD or HD to SD you need restart the device
AR Convert is available when AspectRatio is set as non-original aspect
ratio.
A/V Sync is used for adjusting the synchronization of video and audio in
accordance with actual situation. Recommend enabling PCR with tuner input
and ASI input, enabling Audio with IP input or selecting the default Auto.
You must enable the function of DigitalOut within Pri-Aud and set it as
"PASS" if select 1channel audio loopingout.

VprO 5100/5100D User's Guide
- 18 -
IP Set IP as Descramble1 source
CAM1 Bit* 72/77/83/90/98/108/120 Set CI module bitrate
CAM1 Service Map Channel 1-8 Select the program for descramble
CAM 2 XXX (readonly) Information about CAM 2
CAM2 Source Tuner1 Set Tuner 1 as Descramble2 source
Tuner2 Set Tuner 2 as Descramble2 source
ASI1 Set ASI1 as Descramble2 source
ASI2 Set ASI2 as Descramble2 source
IP Set IP as Descramble2 source
CAM2 Bit* 72/77/83/90/98/108/120 Set CI module bitrate
CAM2 Service Map Channel 1-8 Select the program for descramble
BISS Mode Mode-0 BISS-0
Mode-1 BISS-1
Mode-E BISS-E
2-6
2-6
2-6
2-6 TSOUT
TSOUT
TSOUT
TSOUT Menu
Menu
Menu
Menu
Name Setting range Explanation
IP OUT Enable Open IP OUT
Disable Close IP OUT
* W ork mode
* S oure Set source for IP out
* C ast mod Unicast or Multicast
*Dest IP Set a destination IP address
*Dest Port Set a destination port
*Protlcol Transmit RTP or UDP packet
*TTL Time to livet
* S ervice S elect Program list
ASI OUT ASI 1 Set ASI1 for ASI OUT
ASI 2 Set ASI2 for ASI OUT
Tuner1 Set Tuner1 for ASI OUT
Tuner2 Set Tuner2 for ASI OUT
IP Set IP for ASI OUT
CAM1 and CAM2 have three status:
1) Removed ; 2)L oading ; 3) I nformation about CI card

VprO 5100/5100D User's Guide
- 19 -
Descramble1 Set Descramble1 for ASI OUT
Descramble2 Set Descramble2 for ASI OUT
2-7
2-7
2-7
2-7 Testsig
Testsig
Testsig
Testsig Menu
Menu
Menu
Menu
Name Setting range Explanation
Testsig Audio 1 OFF
Close Audio1 test signal
ON Open Audio1 test signal
Audio 2 OFF
Close Audio2 test signal
ON Open Audio2 test signal
video OFF Close Video testsignal
4:3 Output 4:3 testsignal
16:9 Output 16 : 9 test signal
2-8
2-8
2-8
2-8 System
System
System
System Menu
Menu
Menu
Menu
Name Setting range Explanation
Control DHCP ON Open DHCP
OFF Close DHCP
IP Address XXX.XXX.XXX.XXX Set an IP address
Subnet Mask XXX.XXX.XXX.XXX Set a subnet mask
Gateway XXX.XXX.XXX.XXX Set a gateway
Stream DHCP ON Open DHCP
OFF Close DHCP
IP Address XXX.XXX.XXX.XXX Set an IP address
Subnet Mask XXX.XXX.XXX.XXX Set a subnet mask
Gateway XXX.XXX.XXX.XXX Set a gateway
Profile Factory default Factory default
Device Info Serial Num XXXXX Device Serial Num
Model XXXX (readonly) Device Model
Flash Size XX (readonly) Flash Size
HW Version X.X (readonly) Hardware Version
SW Version X.X.X (readonly) Software Version
ASI Version X.X.X(readonly) ASI Version
Status Ser name fmt XXXXX Program information
It will display color bar after open up the testing signal and appear beep sound.

VprO 5100/5100D User's Guide
- 20 -
UID XXXX UID
Pri AUD XXXX Pri AUD information
Sec AUD XXXX Sec AUD information
Quality 1 XXXX Tuner1 ’ s sign quality
Strength 1 XXXX Tuner1 ’ s sign strength
Quality 2 XXXX Tuner2 ’ s sign quality
Strength 2 XXXX Tuner2 ’ s sign strength
NTP ServerAddress XXXX NTP's Server Address
Time zone XXXXX Time zone
Sync hronous XXXXX hourons
Password Web password XXXXX Set web password
Snmp password XXXX Set snmp password
3
3
3
3 .
.
.
. Web
Web
Web
Web Control
Control
Control
Control
Users can configure VprO via network browser. The configuration menu layouts
of web pages are similar to those in front panel configurations.
1) Connecting a PC to the control port of VprO.
2) Entering the control port IP address of VprO in browser.
Then c an be seen in VprO Web control interface
