Cypress CSC-5500 User manual

CSC-5500
Multi Input Scaler
Operation Manual
Operation Manual

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of fi re,
electrical shock and injury to persons.
• To prevent fi re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person to walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
suffi cient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 27/06/13 Preliminary Release
VS1 24/07/13 Updated format/diagrams
VR2 08/04/15 RS-232 Command

CONTENTS
1. Introduction............................................1
2. Applications...........................................1
3. Package Contents ................................1
4. System Requirements............................1
5. Features..................................................2
6. Operation Controls and Functions.......3
6.1 Front Panel.........................................3
6.2 Rear Panel .........................................4
6.3 Remote Control.................................5
6.4 RS-232 Protocols................................6
6.5 RS-232 and Telnet Commands........7
6.6 OSD Menu........................................11
6.7 Telnet Control..................................15
6.8 Web GUI Control.............................17
6.9 Input Resolution Support................18
6.10 Output Resolution Support...........19
7. Connection Diagram ..........................20
8. Specifi cations ......................................21
9. Acronyms.............................................22

1
1
1. INTRODUCTION
This Multi Input Scaler has Composite Video, Component Video, PC
(VGA), and HDMI inputs and can switch and scale the signal to HDMI
or VGA with audio outputs. It supports HDMI output resolutions up
to 1080p/WUXGA and Analog Digital Conversion (ADC) and Digital
Analog Conversion (DAC) allowing a wide range of AV signals to be
displayed on a HDMI or VGA display. Further, the On-screen Display
(OSD), IR remote, RS-232, IP and on-panel controls make this product
very versatile.
2. APPLICATIONS
• Analog and digital source integration
• Upscaling standard defi nition video for high-defi nition displays
• Conference centres
• Lecture halls
• Schools and universities
3. PACKAGE CONTENTS
• Multi Input Scaler
• Remote Control (CR-122)
• IR Extender Cable
• D-Sub to RCA Adaptor Cable
• Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Source equipment such as Blu-ray/DVD players or PC/Laptop and
output to displays, AV Receivers or active speakers.

2
2
5. FEATURES
• Supports switching and scaling of multiple AV inputs to HDMI or PC/
HD outputs
• Supports EDID and HDCP
• Supports 3D de-interlace, noise reduction and 3D comb fi lter
• Supports frame rate conversion
• Supports RS-232, IP(Telnet/Web GUI) and IR controls
• Supports output timing hot keys switching
• HDMI compatible with DVI
• Supports Digital to Analog (DAC) and Analog to Digital (ADC) Audio
conversion
• Supports Non-HDCP signal of Apple computers

3
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
•
UNEM3IMDH2IMDH1IMDH3CP2CP1CPPMOCVCREWOP
XGA
ENTER
- +
720P
3 4 5 621
1POWER Button and LED: Press this button to switch the device on
or to set it to standby mode. Once the device is connected to
an active power supply and the Power Switch on the back panel
is turned on, the LED will illuminate and the device will switch on
automatically.
2IR Receiver Window: Receives only the IR signal from the remote
control included in the package.
3INPUT Buttons and LEDs: Press these buttons to switch directly to
the required source. An LED will illuminate to indicate the selected
input source.
4MENU: Press this button to enter the On-screen Display (OSD)
menu.
5Plus/Minus (−/+) Buttons: Press these buttons to navigate down
and up in the OSD menu.
6ENTER: Press this button to confi rm the selection in the OSD menu.
Note: Press this button simultaneously with the '+' (plus) button to
instantly switch the output to XGA resolution or with the '−' (minus)
button to instantly switch the output to 720p resolution.

4
4
6.2 Rear Panel
POWER
DC 5V
CONTROL
HDMI 2HDMI 1 PC/HD
RS232 COAX AUDIO
SERVICE
OUTPUT
3CP2CP1CP3IMDH2IMDH1IMDH Cr/Pr Cb/Pb
RL
YRLCV
AUDIO
INPUT
IR IN
5 84
1 2 3 6 7
1IR IN: Connect the supplied IR extender to receive the IR signal
from the included IR remote. Ensure that the remote is within the
direct line-of-sight of the IR extender.
2SERVICE: Reserved for manufacturer use only.
3RS-232: Connect to a PC/Laptop or RS-232 control system to use
RS-232 commands to control the device (See Section 6.5 for details
on RS-232 commands).
4OUTPUT
1) HDMI 1/2: Connect to an HDMI display or AV Receiver for video
and/or audio output.
2) PC/HD: Connect to a monitor/display for video output. For
HD (Component) output, use the supplied D-Sub 9pin to 3 RCA
adaptor cable for HD resolutions from 480p~1080p.
Note: When the selected HDMI input source signal has HDCP
content the VGA/Component output will not display any image.
3) COAX: Connect to an amplifi er or active speakers for audio
output in digital format.
Note: When the input audio source signal is in bitstream format
and the AUDIO SOURCE setting is set to AUTO in the OSD menu,
the coaxial output will bypass the input audio signal including
compatible surround sound formats.
4) AUDIO: Connect to an amplifi er or active speakers for audio
output in stereo format.
5INPUT
1) HDMI 1/2/3: Connect to HDMI sources such as Blu-ray/DVD
player for both video and audio signal conversion.
2) PC 1/2/3: Connect to a PC/Laptop source for video signal input
with a D-Sub 15pin cable.

5
4
6.2 Rear Panel
POWER
DC 5V
CONTROL
HDMI 2HDMI 1 PC/HD
RS232 COAX AUDIO
SERVICE
OUTPUT
3CP2CP1CP3IMDH2IMDH1IMDH Cr/Pr Cb/Pb
RL
YRLCV
AUDIO
INPUT
IR IN
5 84
1 2 3 6 7
1IR IN: Connect the supplied IR extender to receive the IR signal
from the included IR remote. Ensure that the remote is within the
direct line-of-sight of the IR extender.
2SERVICE: Reserved for manufacturer use only.
3RS-232: Connect to a PC/Laptop or RS-232 control system to use
RS-232 commands to control the device (See Section 6.5 for details
on RS-232 commands).
4OUTPUT
1) HDMI 1/2: Connect to an HDMI display or AV Receiver for video
and/or audio output.
2) PC/HD: Connect to a monitor/display for video output. For
HD (Component) output, use the supplied D-Sub 9pin to 3 RCA
adaptor cable for HD resolutions from 480p~1080p.
Note: When the selected HDMI input source signal has HDCP
content the VGA/Component output will not display any image.
3) COAX: Connect to an amplifi er or active speakers for audio
output in digital format.
Note: When the input audio source signal is in bitstream format
and the AUDIO SOURCE setting is set to AUTO in the OSD menu,
the coaxial output will bypass the input audio signal including
compatible surround sound formats.
4) AUDIO: Connect to an amplifi er or active speakers for audio
output in stereo format.
5INPUT
1) HDMI 1/2/3: Connect to HDMI sources such as Blu-ray/DVD
player for both video and audio signal conversion.
2) PC 1/2/3: Connect to a PC/Laptop source for video signal input
with a D-Sub 15pin cable.
5
3) 3.5mm Mini-jacks: Connect to source's L/R output with 3.5mm
mini-jack for audio signal conversion.
Note: For HDMI signals you can select in the OSD Menu whether
you require audio from the HDMI (AUTO) or from the analog audio
inputs (EXT)
4) YCbCr/YPbPr + L/R: Connect to source equipment such as a
DVD player for both video and audio signal conversion.
5) CV + L/R: Connect to a composite video source such as a
video/DVD player for both video and audio signal conversion.
6CONTROL: This port is the link for Telnet or Web GUI controls,
connect to an active Ethernet link with an RJ45 terminated cable
7POWER: Switch this power toggle to turn on and activate the
device or turn off to shut it down.
8DC 5V: Connect the power adaptor included in the package to
the device and plug it into an AC wall outlet for power supply.
6.3 Remote Control
1POWER: Press this button to switch the
device on or to set it to standby mode.
2HDMI1/2/3, PC1/2/3, CV and COMP:
Direct source selection keys. Press one
of these keys to switch to the required
source.
3MENU: Press this button to enter the OSD
menu.
4 EXIT: Press this button to exit the menu or
the current selection in the OSD menu.
5 OK & ▲▼◄►: Press OK to confi rm the
selection or press the arrow buttons to
navigate the OSD menu. When the OSD
menu is not active, use the LEFT/RIGHT
(◄►) to control the volume level.
6AUTO ADJUST: Press this button when the image being outputted
does not correctly fi t the display's screen. The device will auto
adjust the image to fi ll the screen.
7RESET: Press this button to reset the device back to the default
settings.
CR-122
POWER
EXIT MENU
OK
RESET AUTO
ADJUST
PC1PC2 PC3
CV COMP
HDMI2HDMI1 HDMI3
1
3
6
5
4
7
2

6
6
6.4 RS-232 Protocols
Multi-Input Scaler
►
◄
Remote Control
PIN Assignment PIN Assignment
1 NC 1 NC
2Tx 2Rx
3Rx 3Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200bps
Data bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1

7
7
6.5 RS-232 and Telnet Commands
COMMAND DESCRIPTION
S POWER 0/1 0=OFF 1=ON
R POWER Reports the numeric equivalent for POWER
setting (as above)
S SOURCE 1~8 1=HDMI 1
2=HDMI 2
3=HDMI 3
4=YPbPr
5=VIDEO
6=PC 1
7=PC 2
8=PC 3
R SOURCE Reports the numerical equivalent for
SOURCE setting (as above)
S OUTPUT 0~21*10=640×480
1=800×600
2=1024×768
3=1280×768
4=1360×768
5=1280×720
6=1280×800
7=1280×1024
8=1440×900
9=1400×1050
10=1680×1050
11=1600×1200
12=920×1080
13=1920×1200
14=480p
15=720p6@0
16=1080i@60
17=1080p@60
18=576p
19=720p@50
20=1080i@50
21=1080p@50
R OUTPUT Reports the numerical equivalent for
OUTPUT setting (as above)
S SIZE 0~6 0=OVERSCAN
1=FULL
2=FOLLOW INPUT
3=PAN SCAN
4=LETTER BOX
5=UNDER 2
6=UNDER 1
R SIZE Reports the numerical equivalent for SIZE
setting (as above)
