ACME DSR-220 Instruction Manual

DSR-220 MANUAL SEALER
Part No. 306210
GENERAL SAFETY CONSIDERATIONS
1. EYE INJURY HAZARD.
Failure to wear safety glasses with side shields
can result in severe eye injury or blindness.
Always wear safety glasses with side shields
which conform to ANSI Standard Z87.1 or EN 166.
2. FALL HAZARD.
Maintaining improper footing and/or balance
when operating the tool can cause you to fall. Do
not use the tool when you are in an awkward
position.
3. CUT HAZARD.
Handling strap or sharp parts could result in cut
hands or fingers. Wear protective gloves.
4. TRAINING.
This tool must not be used by persons not
properly trained in its use. Be certain that you
receive proper training from your employer. If
you have any questions contact your Acme
Representative.
5. TOOL CARE.
Take good care of the tool. Inspect and clean it
daily, lubricate it weekly. Replace any worn or
broken parts.
6. WORK AREA.
Keep work areas uncluttered and well lighted.
7. TENSIONING STRAP.
When tensioning strap use proper tensioner for
specific strap sizes. Read the tensioner's
operation and safety manual.
Several combinations of strap, seals and tools can be
used with this sealer. Use the correct Acme products
for your application. If you need help contact your
Acme Representative.
SAFETY PROCEDURES FOR TOOL
OPERATION
1. Before using this sealer, read all the instructions
in this Operation, Parts and Safety Manual.
2. Always lift and carry the tool by the tool handle
knob. Lifting the tool at any other point may
expose the hand to a "pinch point."
3. Make sure the sealer jaws are placed directly on
the seal.
4. While sealing, position yourself to one side of the
tensioned strap.
5. This tool is a double reverse notch
sealer. A properly notched seal will
appear as shown in the illustration.
If the notched seal does not appear
as shown, inspect the tool for worn
and/or damaged parts. Replace tool parts as
needed. Do not ship any loads secured with
improperly notched seals. Seal must be properly
notched.
CUTTING TENSIONED STRAP
FLYING STRAP HAZARD. Using claw hammers,
crowbars, chisels, axes or similar tools will cause
tensioned strap to fly apart with hazardous force.
Use only cutters designed for cutting strap. Read the
instructions in the cutters manual for proper
procedure in cutting strap. Before using any Acme
product read its operation and safety manual.
SPECIFICATIONS
For use with 1-1/4" High Tensile steel strapping .025"
to .035" thick.
OPERATING INSTRUCTIONS
1. Fully open the sealer handles and center the
open jaws on the seal.

OPERATING INSTRUCTIONS, Continued
2. Bring the sealer handles completely together to
assure a proper notch.
3. Remove the sealer.
NOTE: If the gauge of the strap being used will not
allow it to be bent, cut the strap supply as close to
the seal as possible using an approved strap cutter.
4. To avoid contact with the sharp end of the strap,
retract the strap end back into the strap
dispenser.
PARTS LIST
KEY QTY PART# DESCRIPTION
1 3 020370 SHCS, 5/16-24 x 2 1/16
2 2 020369 Side plate
3 2 020378 Handle grip
4 3 020366 Jaw pin
5 1 020368 Spacer
6 4 020365 Jaw
7 2 020361 Toggle link pin
8 1 020367 Notcher
9 1 020360 Toggle link female
10 2 020362 Short link
12 1 422007 Upper handle arm assembly
13 1 020359 Toggle link male
15 1 020363 Short link pin
KEY QTY PART# DESCRIPTION
16 1 020355 Latch trigger pin
17 1 020357 Trigger spring
18 1 020364 Link pin
19 1 020356 Latch trigger
20 1 020358 Trigger spacer
21 1 020354 Latch spring
22 1 020353 Latch spacer
23 1 020351 Latch
24 3 004964 Flexloc nut, thin, 5/16-24
25 1 003132 Caution plate
26 1 584-1127 Name plate
28 1 422009 Lower handle arm assembly
When ordering parts, please show tool model, part number and name. All recommended spare parts are underlined
and should be stocked.
MAINTENANCE
Inspect tool daily for worn or broken parts and
replace if necessary. Clean and apply light machine
oil to all moving parts - weekly.
For parts and repair contact:
Acme Sales
3624 W. Lake Street
Glenview, IL 60026 For Parts Support Call 1-800-541-5736
800-788-0830
www.acme-ds.com
© Copyright 2008, Acme 512156 Rev. 11/2008
