ACMEEAR VS-ZT01 Series User manual

VS-ZT01-XX
User Manual
ShenZhen Sheng Tong Technology Co.,Ltd

② ①
③
④
①: power key and Function keys ②：Volume"-"button
③：Volume “+”button ④：Micro USB port: battery charging port
Bone conduction earphones do not need to be inserted into or cover the ears, but the vibration unit
(commonly known as: vibrator or speaker) is attached to the temporal bone protrusion in front of the
human ear. It will be very comfortable to wear correctly and will not cause any burden on the ear and
neck
Part1.The correct way to wear bone conduction Bluetooth headset
Part 2.Component position description of bone conduction headset

① ⑤
⑤
⑤：indicator lamp
3.1 power key and Function keys ：
（1） Turn on: Press and hold the power key for 2 seconds to turn on the power.
3.2 Volume"-"button ：
（3）When the headset is connected to Bluetooth to play music, press the power key to
drive the music to pause or replay.
（4）The earphone is connected to Bluetooth. If there is an incoming call w'hen the
music is playing, you can press the power button to answer the call or hang up.
Part 3. Bone conduction headset components and instructions for using
（5） Power off: In the power on state, press and hold the power switch for 4 seconds,
the headset will turn off and the indicator light will go out.
When answering a call or playing music, press the "-" key, the sound heard by the ear
becomes smaller, and the user can choose the appropriate volume to meet his comfort
re
q
uirements.
（2）Connect the headset to the mobile phone via Bluetooth: When the headset is turned
on, press and hold the power button for 1 second, and the indicator light flashes
alternately in red and green. At this time, find the VS-ZT01-XX headset on the mobile
phone and confirm the pairing. When the headset is heard, the headset connection is
completed . Connect the headset to the mobile phone and you can use it normally.

3.3 Volume “+”button ：
3.4 Micro USB port: battery charging port
（4）Charger parameters: I/P：100-240V O/P:5VDC 2A
3.5 indicator lamp ：
3.6 Basic product parameters:
（2）Adapter : FX2U-050200U Input:100-240V AC 50/60Hz, Output:DC 5.0V 2.0A
(3）Bluetooth version：V5.0
(4) Bluetooth transmission distance：10m Min
（1）：Micro USB port，The headset has a built-in battery charging input port. When the
battery voltage is too low, the headset will emit beeps at regular intervals. At this
time, you should use the dedicated charger and dedicated charging cable equipped by our
company to charge the headset in time, and it will be fully charged in about 2:00 hours.
（1）Battery specifications: Built-in rechargeable battery capacity 3.7V 260mAh
(5）The normal working voltage of the earphone is 3-4.2VDC, and the working current is
about 20mA.
（1）When the headset is turned on, the indicator light will flash green in regular
intervals (about 5 seconds)
（2）Charging in the off state, the red light flashes when charging. The light goes
out when full.
When answering a call or playing music, press the “+” key, the sound heard by the
ear becomes smaller, and the user can choose the appropriate volume to meet his comfort
requirements.
（2）When the battery is fully charged, it can work continuously for about 10 hours at
half volume.
（3）When charging, please use our special charger, and disable non-our chargers to
char
g
e the headset to
p
revent dama
g
e to the headset.
（3）When Bluetooth is searching, the indicator light flashes red and green
alternately.

—Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is
not responsible for any changes or modifications not expressly approved by the party
responsible for compliance. such modifications could void the user's authority to operate
the equipment.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna. —Increase the separation between the
equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Part 4.Conforming to standard
FCC ID: 2AYRR-VST01
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
