Acoustas Melody-G User manual

Melody-G
Wireless Guitar Microphone
Installation and Operation Manual

3300 W. Clay St., Richmond, VA, 23230
http://www.acoustas.com/
Thank you for your purchase of an Acoustas Melody-G. Please visit our website at
http://www.acoustas.com/ for up-to-date information on the Melody-G and other products and to
contact us with uestions or comments. This manual will describe how to properly install,
connect, and operate your versatile new wireless microphone.
Transmitt r (l ft) and r c iv r (right)
The following should be included in your shipment:
•Transmitter with three suspension pegs for mounting
•Lithium-ion battery (s uare) with two-pin connector
•Piezoelectric film microphone (rectangular) with three-pin connector
•Receiver with attached 2.4GHz antenna
•Standard-A to mini-B USB cable for use with both devices
•USB right-angle adapter for use with the transmitter
•Charging brick with USB port for use with both devices
2

3300 W. Clay St., Richmond, VA, 23230
http://www.acoustas.com/
Federal Communications Commission and Industry Canada Notices for the Melody-G
Master Unit (Transmitter)
Th mast r unit can b id ntifi d by th s markings:
Model FCC ID: 2AC35-MELODYGTX
IC: 12297A-MELODYG
Th following notic s ar applicabl :
This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectri ue subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Note: Changes or modifications not expressively approved by the party responsible for
compliance could void the user's authority to operate the e uipment.
This e uipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the e uipment is operated in a commercial
environment. This e uipment generates, uses, and can radiate radio fre uency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this e uipment in a residential area is likely to cause
harmful interference in which case the user will be re uired to correct the interference at his own
expense.
This device should not be co-located with any other antenna or transmitter. It should remain
at least 3 centimeters (1-1/8 inches) from the user at all times while switched on in order to
reduce harmful radio fre uency exposure.
3

3300 W. Clay St., Richmond, VA, 23230
http://www.acoustas.com/
Federal Communications Commission and Industry Canada Notices for the Melody-G
Slave Unit (Receiver)
Th slav unit can b id ntifi d by th s markings:
Model FCC ID: 2AC35-MELODYGRX
IC: 12297A-MELODYG
Th following notic s ar applicabl :
Note that the Melody-G slave transceiver may only be used with the 3 dBi gain monopole
antenna provided, or a 50 Ohm antenna of the same type, with e ual or lesser gain.
This e uipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the e uipment is operated in a commercial
environment. This e uipment generates, uses, and can radiate radio fre uency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this e uipment in a residential area is likely to cause
harmful interference in which case the user will be re uired to correct the interference at his own
expense.
This device should not be co-located with any other antenna or transmitter. It should remain
at least 20 centimeters (7-7/8 inches) from the user at all times while switched on in order to
reduce harmful radio fre uency exposure.
4

3300 W. Clay St., Richmond, VA, 23230
http://www.acoustas.com/
Transmitter Installation
As a first step, remove all strings from the guitar. Next, make sure the battery, piezoelectric
film microphone, and optional peg connection are in place. The connectors should snap into the
transmitter very easily and cannot be reversed by accident due to their design. The battery, input,
and output connections are all labeled on the transmitter printed circuit board. Ensure the
transmitter turns on with its switch - a green light should glow very brightly.
The transmitter should be mounted right near the edge of the sound hole, on the top side when
the guitar is being held normally (closer to the player's head). Right-handed players can refer to
the images below; left-handed players should use the mirror image of this position.
The transmitter comes supplied with three hook-and-loop adhesive pads. Peel away the
protective plastic sheets from these adhesive pads. Clean and dry the receiving surface inside the
guitar, and with a single firm push, affix the transmitter. Next, place the battery and piezoelectric
film microphone in a similar manner, ensuring their wires are out of the way of the sound hole.
Finally, re-string the guitar. A good first test of Melody-G is to connect the receiver to a
computer's USB port in order to tune the guitar with the help of an online tuning application.
Turn the transmitter on and make sure the receiver's green indicator is consistently on and its
volume is turned all the way up.
5
Right-hand d Martin installation Right-hand d Epiphon installation

3300 W. Clay St., Richmond, VA, 23230
http://www.acoustas.com/
Transmitter and Receiver Pairing
At any given time, each Melody-G receiver will only accept sound from a single transmitter.
The transmitter and receiver form a pair and thus the method to link them is called “pairing.”
Any receiver can be set to accept sound from any transmitter by pressing the pairing button and
holding the two uite close together. After the receiver's button is pressed, its green indicator
will blink twice in uick succession every second for up to fifteen seconds or until a transmitter
is brought close enough. During this process, ensure that the transmitter which is to be paired is
switched on and all others that may be in the near vicinity are switched off. All sets come pre-
paired, so most players will not normally need to use this feature.
R c iv r's pairing button (c nt r)
