Ventless Submittal Information
ARX & MRX SERIES
225 49th Ave. Dr. SW, Cedar Rapids, IA 52404
800-233-2366, 319-368-8120, Fax: [phone]
www.acpsolutions.com

ARX/MRX Ventless Submittal Information
ARX/MRX Ventless Q&A..............................................................3
ETL Listing....................................................................................4
ETL Explanation ...........................................................................5-7
Test Reports.................................................................................8-9
Guidelines for Ventless Use..........................................................10
Heat Load Calculations.................................................................11-12
Specification Sheets .....................................................................13-16
Quick Start Reference Guide........................................................17-22
Application for Exemption from Mechanical Ventilation.................23
LA County Exemption from Mechanical Ventilation Letter.............24-26
225 49th Ave. Dr. SW, Cedar Rapids, IA 52404
800-233-2366, 319-368-8120, Fax: [phone]
www.acpsolutions.com
Page 2 of 26

ARX/MRX Ventless Q & A
How are the ARX and MRX High Speed Ovens certified ventless?
The ARX/MRX employs an integral precious metal catalyst to manage Volatile Organic
Compounds (VOC’s) and fine particulate matter (PM) to levels below the UL 197
threshold of 5 mg/m3
How are the ARX and MRX certified?
The ARX/MRX is certified ventless by Intertek Testing Services and received the ETL
Listed Mark.
How are the ARX and MRX tested?
The ARX/MRX is tested and certified by a third party National Certification Body (NCB).
Tests involve eight hours of cooking 160 pepperoni pizzas in succession or
approximately one pizza every three minutes.
Why is ventless important?
Vent hoods consume energy, increasing operating costs. When the ARX/MRX is used
appropriately in a ventless environment a Type I hood is not required. This can save
operators money by eliminating hood installation costs and reducing HVAC and energy
costs.
What if local inspector questions ventless installation?
ACP, Inc. will assist with approvals. In general you need to notify the appropriate local
agency having jurisdiction (AHJ) and prepare a submittal package including menu items.
ACP, Inc. can provide additional information to assist and guide you through the process.
225 49th Ave. Dr. SW, Cedar Rapids, IA 52404
800-233-2366, 319-368-8120, Fax: [phone]
www.acpsolutions.com
Page 3 of 26

225 49th Ave. Dr. SW, Cedar Rapids, IA 52404
800-233-2366, 319-368-8120, Fax: [phone]
www.acpsolutions.com
Page 4 of 26

    
    

1 Scope
           
       
      
          
  
 
  
                  
                
 
 
      
 
  
   
 
             
          3  
              
   
           
 







3

a







0






m

o·
















z

0



m



r








w




0

0
Page 5 of 26

AUTHORIZATION TO MARK
Applicant: Manufacturer:
Address: Address:
Country: Country:
Contact: Contact:
Phone: Phone:
FAX: FAX:
Email: Email:
Standard(s):
Product:
Brand Name:
Models:
ACP Inc.
ACP Inc.
225 49th Ave. Dr. SW
Cedar Rapids, IA 52404
225 49th Ave. Dr. SW
Cedar Rapids, IA 52404
USA
USA
Mr. Patrick Henry
Mr. Patrick Henry
[phone]
[phone]
[phone]
[phone]
[e-mail]
[e-mail]
Party Authorized To Apply Mark:
Same as Manufacturer
Report Issuing Office:
Oakdale, MN
Control Number:
3197057
Authorized by:
for Dean Davidson, Certification Manager
This document supersedes all previous Authorizations to Mark for the noted Report Number.
This Authorization to Mark is for the exclusive use of Intertek's Client and is provided pursuant to the Certification agreement between Intertek and its Client. Intertek's responsibility and liability are
limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned
by the use of this Authorization to Mark. Only the Client is authorized to permit copying or distribution of this Authorization to Mark and then only in its entirety. Use of Intertek’s Certification mark is
restricted to the conditions laid out in the agreement and in this Authorization to Mark. Any further use of the Intertek name for the sale or advertisement of the tested material, product or service must
first be approved in writing by Intertek. Initial Factory Assessments and Follow up Services are for the purpose of assuring appropriate usage of the Certification mark in accordance with the
agreement, they are not for the purposes of production quality control and do not relieve the Client of their obligations in this respect.
Intertek Testing Services NA Inc.
545 East Algonquin Road, Arlington Heights, IL 60005
Telephone [phone] or 847-439-5667 Fax [phone]
Microwave Cooking Appliances [UL 923:2013 Ed.7+R:19Jul2017]
Microwave Ovens [CSA C22.2#150:2016 Ed.4]
Commercial Convection/Microwave Oven Cooking Appliance
ARX followed by 1, 2, 51, 52, 513 or 523; followed by up to 4 characters
MRX followed by 1, 2, 51, 52, 513 or 523; followed by up to 4 characters
Amana and Menumaster
This authorizes the application of the Certification Mark(s) shown below to the models described in the Product(s)
Covered section when made in accordance with the conditions set forth in the Certification Agreement and Listing
Report. This authorization also applies to multiple listee model(s) identified on the correlation page of the Listing
Report.
This document is the property of Intertek Testing Services and is not transferable. The certification mark(s) may be
applied only at the location of the Party Authorized To Apply Mark.
Page 1 of 1ATM for Report 102452452MIN-001 ATM Issued: 18-Dec-2017
ED 16.3.15 (20-Apr-17) Mandatory
Page 6 of 26

AUTHORIZATION TO MARK
Applicant: Manufacturer:
Address: Address:
Country: Country:
Contact: Contact:
Phone:
Phone:
FAX: FAX:
Email:
Email:
Standard(s):
Product:
Brand Name:
Models:
ACP Inc. ACP Inc.
225 49th Ave. Dr. SW
Cedar Rapids, IA 52404 225 49th Ave. Dr. SW Cedar Rapids, IA 52404
USA USA
Patrick Henry Patrick Henry
319-368-8178 319-368-8178
319-368-8194 319-368-8194
[email protected]m [email protected]
Party Authorized To Apply Mark: Same as Manufacturer
Report Issuing Office: Columbus
Control Number:
3197057
Authorized by:
for Dean Davidson, Certification Manager
This document supersedes all previous Authorizations to Mark for the noted Report Number.
This Authorization to Mark is for the exclusive use of Intertek's Client and is provided pursuant to the Certification agreement between Intertek and its Client. Intertek's responsibility and liability are limited
to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use
of this Authorization to Mark. Only the Client is authorized to permit copying or distribution of this Authorization to Mark and then only in its entirety. Use of Intertek’s Certification mark is restricted to the
conditions laid out in the agreement and in this Authorization to Mark. Any further use of the Intertek name for the sale or advertisement of the tested material, product or service must first be approved in
writing by Intertek. Initial Factory Assessments and Follow up Services are for the purpose of assuring appropriate usage of the Certification mark in accordance with the agreement, they are not for the
purposes of production quality control and do not relieve the Client of their obligations in this respect.
Intertek Testing Services NA Inc.
545 East Algonquin Road, Arlington Heights, IL 60005
Telephone [phone] or 847-439-5667 Fax [phone]
Commercial Cooking, Rethermalization And Powered Hot Food Holding And Transport Equipment [NSF
4:2016 ]
Commercial Microwave/Convection oven
ARX1, ARX2, ARX51, ARX 52, MRX1, MRX2, MRX51, MRX 52
Amana or Menumaster
This authorizes the application of the Certification Mark(s) shown below to the models described in the Product(s)
Covered section when made in accordance with the conditions set forth in the Certification Agreement and Listing
Report. This authorization also applies to multiple listee model(s) identified on the correlation page of the Listing Report.
This document is the property of Intertek Testing Services and is not transferable. The certification mark(s) may be
applied only at the location of the Party Authorized To Apply Mark.
Page 1 of 1ATM for Report 102452452COL-002 ATM Issued: 2-Nov-2017
ED 16.3.14 (20-Apr-17) Mandatory
Page 7 of 26

NON-CONFORMANCE LETTER REPORT
1717 Arlingate Lane
Columbus, OH 43228
Telephone: [phone]
Facsimile: [phone]
www.intertek.com
This report is for the exclusive use of Intertek's Client an is provi e pursuant to the agreement between Intertek an its
Client. Intertek's responsibility an liability are limite to the terms an con itions of the agreement. Intertek assumes no
liability to any party, other than to the Client in accor ance with the agreement, for any loss, expense or amage occasione by
the use of this report. Only the Client is authorize to permit copying or istribution of this report an then only in its entirety.
Any use of the Intertek name or one of its marks for the sale or a vertisement of the teste material, pro uct or service must
first be approve in writing by Intertek. The observations an test results in this report are relevant only to the sample teste .
This report by itself oes not imply that the material, pro uct, or service is or has ever been un er an Intertek certification
program.
Version: 6-March-2017 GFT-OP-10a
20-Mar-2018 Intertek Report No. 103443931COL-001A
Intertek Project No. G103443931
Patrick Henry Ph: [phone]
ACP Inc. Fx: [phone]
225 49th Ave. Dr. SW
Ce ar Rapi s, IA 52404
Email: [e-mail]
Subject: EPA 202 Emissions Testing Performance Compliance – Commercial
Convection/Microwave Oven Cooking Appliance – ARX an MRX Mo el Series
Dear Mr. Patrick Henry,
This letter report represents the results of our evaluation of the above reference pro uct(s)
to the requirements containe in the following stan ar s:
EPA Method 202 – Particulate Matter Emissions Test
SECTION 1
SUMMAR
Intertek wish to inform you that all sai mo els were foun to be in compliance with EPA
Metho 202 – Particulate Matter Emissions Test. Results of EPA Metho 202 Emissions
Testing may be foun in performance test report, 102452452COL-001. Safety information
for sai mo els may be foun in Listing Constructional Data Report (CDR), 102452452MIN-
001.
Mo els:
ARX followe by 1, 2; followe by up to 4 characters
MRX followe by 1, 2; followe by up to 4 characters
Mo el Nomenclature:
* R X * *
1 2 3 4 5
1) A for Amana Bran or M for Menumaster Bran
2) R for Raptor Combination Oven
3) X for Xpress™
4) 1 for 60 Hz/1000 watts, 2 for 60 Hz/2000 watts
5) Alphanumeric character(s) use to istinguish, graphic, visual, customer proprietary
menus or software feature changes, or national plug styles.
Page 8 of 26

NON-CONFORMANCE LETTER REPORT
ACP Inc.
Intertek Report No.:
103443931COL-001A
Version: 6-March-2017 GFT-OP-10a
SECTION
3
PROJECT STATUS & ACTION
Issuance of this letter report completes the scope covere by Intertek Project No.
G103443931.
If there are any questions regar ing the results containe in this report, or any of the other
services offere by Intertek, please o not hesitate to contact your e icate Intertek
Project Manager, Emilie Engesether, [e-mail].
Complete by: Cameron Brackman Reviewe by: Donal Hubbar
Title: Project Engineer Title: Technical Specialist
Signature: Signature
Date 20-Mar-2018 Date: 20-Mar-18
Please note: this Letter Report oes not represent authorization for the use of any Intertek
certification marks.
Page 9 of 26

For LA County: Ventless Exemption Plan Check No.: ME-2013-004
ACP, Inc. Guidelines for Ventless Use
The ARX / MRX High Speed Oven conforms to UL 923, EPA202 and NFPA96. The UL 923
standard covers the electrical and product safety standard. The EPA202 and NFPA96
standard covers the low particulate matter emissions standard to which we conform. While
both standards cover different aspects of the oven, they both overlap as it relates to grease
and fire handling.
The EPA202 and NFPA96 listing for ventless operation covers food items with particulate
matter emissions of less than 5 mg/m3. The foods outlined below fall below the particulate
matter emissions identified by EPA202 and NFPA96 and should meet the requirements for
ventless operation:
Bakery
-Toasted Bagel
-Toasted Breads
-Toasted English muffin
-Cookies
-Baked desserts
-Pies
-Cakes
-Pastries
-Muffins
-Breads
-Garlic Bread
Precooked Proteins
-Precooked chicken, pork or beef
-Lean meats & seafood, such as
chicken breast without the skin
-Shrimp
Breakfast
-French Toast
-Pancakes
-Omelets (meat, cheese,
vegetable)
-Precooked bacon
-Precooked sausage patties
Sandwiches
-Toasted Breakfast Sandwiches
(egg, meat, & cheese)
-Toasted Sub Sandwiches (meat &
cheese)
-Egg Sandwiches (egg & cheese)
Pastas/Entrees
-Baked pastas
-Pot pies
-Mac and Cheese
Vegetables
-Hashbrowns
-Fries
-Roasted potatoes
-Roasted vegetables
-Baked potatoes
Appetizers
-Quesadillas
-Egg Rolls
-Jalapeno Poppers
-Cheese Sticks
-Chicken wings
-Chicken nuggets/bakeable
appetizers
Pizza
-Pizza
-Calzone
Items that may not fall below the particulate matter emissions as outlined by EPA202 and
NPA 96 are as follows:
-Raw frozen uncooked hamburger
-Raw fresh/frozen skin on chicken
-Uncooked bacon
-Raw fresh/frozen sausage
-Raw fresh/frozen steaks with fatback
-Raw chicken wings
Page 10 of 26
