ACP HDC Y Series User manual

©2020 ACP, Inc.
Cedar Rapids, IA 52404
Part No. 20289100
Original Instructions
Quick Start Guide
Refer to Owner’s Manual for Safety Statements. Complete Owner’s Manual available online.
This document covers HDC*-Y* and MDC*-Y* models
AIR FILTER INSTALLATION
Oven ships with two (2) Air Filters taped to the oor of the oven interior.
⚠Do NOT operate oven without the air lters installed.
1. Remove and discard tape.
2. Locate air lter in the recessed grills along the base of the left and right sides of the oven.
3. Angle the Air Filter with the lower edge placed inside the bottom of the recessed grill.
4. Rotate the top of the air lter to snap into place.
5. Repeat steps 2-4 for the other side and air lter.
(F) Secondary Function Keypads
To activate, press and hold corresponding
number keypad.
(i) Manual Time Entry Mode (keypad “1”)
(ii) Power Level (keypad “2”)
(iii) Programming Mode (keypad “3”)
(iv) User Options (number keypad “4”)
(v) X2 - Double Quantity Cooking (keypad “5”)
(vi) Menu A/B (keypad “6”)
A
B
C
D
A
D
B
C
So…how do I use it?
Manual Time Entry Mode
Time entry mode allows the user to manually enter cook time and power level, without
changing the preset program keypads.
1. Open oven door, place food in oven, and close door.
2. Press and hold number keypad “1”/ TIME ENTRY.
3. Press number keypads to enter desired cook time.
4. Press and hold number keypad “2”/ POWER LEVEL to change power level.
• Press number keypads to enter % microwave power (“1”=10%, “2”=20%,etc.)
For 100% power level, press and hold number keypad “2”/ POWER LEVEL.
5. Press START/OK keypad to begin cooking.
6. At the end of the cooking cycle, the oven beeps. Carefully remove food from oven.
Programming Mode
1. Press and hold number keypad “3”/ PROGRAM.
2. Press number keypad(s) to open the desired program location.
3. To edit name: Press number keypad “0”. Press number keypads to enter recipe name.
Press START/OK keypad.
4. To edit cook time for Stage One: Press number keypad “1”. Press number keypads to
enter cook time. Press START/OK keypad.
5. To edit power level for Stage One: Press number keypad “5”. Press number keypads to
enter % microwave power (“1”=10%, “2”=20%,etc.). For 100% power level, press and hold
number keypad “2”/ POWER LEVEL.
6. If stage cooking is desired, repeat steps 4-5 for each additional stage, substituting
corresponding number keypads for each stage.
7. To save and exit programming mode: Press START/OK keypad.
OVEN CLEARANCES
A. Allow at least 2” (5.1 cm) of clearance
around top of oven. Proper air ow around
oven cools electrical components. With
restricted air ow, oven may not operate
properly and life of electrical parts is
reduced.
B. There is not an installation clearance
requirement for the back of the oven.
C. Allow at least 1” (2.54 cm) of clearance
around sides of oven.
D. Install oven so oven bottom is at least
3 feet (91.5 cm) above oor.
(C)
(F)
(i)
(B)(D)(E)
(ii) (iii)(iv) (v)(vi)
(A)
CONTROL PANEL FEATURES
(A) USB Port
(B) Display
(C) Number Keypads
(D) Start/ OK Keypad
(E) Stop/ Reset Keypad
2
3
Air Filters
Preset Program Keypads
To cook food using preprogrammed cooking
sequences:
1. Open oven door, place food in oven, and
close oven door.
2. Press desired number keypad(s).
3. Oven operates and time counts down.
4. At the end of the cooking cycle, the oven
beeps. Carefully remove food from oven.
X2 -DOUBLE QUANTITY COOKING
1. Press and hold number keypad “5”/ X2 to
toggle double quantity feature ON.
“X2” appears at top center of screen
when enabled.
2. Press desired number keypad(s).
Display counts down cooking time for
two quantities.
MENU A/B (select models)
Press and hold number keypad “6” to toggle
between A and B menus.
4

©2020 ACP, Inc.
Cedar Rapids, IA 52404
Part No. 20289100
Original Instructions
For full product documentation visit:
www.acpsolutions.com
Access and Modify User Options
There are several options you can change to customize the operation of the oven for your business.
Options are shown below. The factory setting is shown in bold type.
1. Press and hold keypad number “4”/ USER OPTIONS.
If prompted, enter the PIN Code and press START/OK keypad
2. Press the START/OK keypad to scroll through pages of user options
3. To access an individual user option, press the corresponding number keypad
• To change the setting, press corresponding number keypad
• To return to User Options Menu, press START or STOP/RESET
4. Press STOP/RESET keypad to exit User Options Menu
Quick Start Guide
Refer to Owner’s Manual for Safety Statements. Complete Owner’s Manual available online.
Refer to Owner’s Manual for complete care and
cleaning instructions.
⚠Do NOT use abrasive cleaners or cleaners
containing ammonia, citrus, phosphates,
chlorine, sodium or potassium hydroxide (lye).
Use of unapproved cleaning agents will void
the terms of the warranty.
No metal pans
No metal pans
DO NOT power spray
DO NOT power spray
DO NOT use steam cleaning
STANDARD DEFAULT PER MODEL (FACTORY SETTINGS IN BOLD)
Factory setting may vary by model
SETTING DISPLAYED OPTIONS DESCRIPTION
End of Cycle Beep 3 Seconds
Continuous
Burst
3 second continuous beep
Continuous beep until door is opened
5 beep bursts until door is open
Speaker Volume Low
Medium
High
Sets volume to low
Sets volume to medium
Sets volume to high
Key Beep On
O󰀨
Allows beep when keypad is pressed
Prevents beep when keypad is pressed
Reset on Door Open End Cook Cycle
Pause Cook Cycle
Cancels heating time count down after door is opened during cycle.
Allows oven to resume heating time countdown after door is opened during cycle
Digit Entry Single Digit
Double Digit
Folders
Allows 10 (0-9) preprogrammed items
Allows 100 (00-99) preprogrammed items
Allows 10 folders (0-9), each with 10 preprogrammed items
Manual Programming On
O󰀨
Allows use of manual time entry and preprogrammed keypads
Allows use of preprogrammed keypads only
Time Entry On
O󰀨
Manual time entry/cooking allowed
Manual time entry/cooking not allowed
Maximum Cook Time 10 minutes
60 minutes
Allows 10 minutes of heating time
Allows 60 minutes of heating time
Keypad Enable Window 15 seconds
30 seconds
1 minute
2 minutes
15 seconds after oven door is opened, keyboard disabled
30 seconds after oven door is opened, keyboard disabled
1 minute after oven door is opened, keyboard disabled
2 minutes after oven door is opened, keyboard disabled
On-the-Fly On
O󰀨
Allows pushing additional keypads to add or change time in the middle of a cook cycle
Disables pushing any additional keypads during a cook cycle
Quantity Prompt* On
O󰀨
Prompts the user for portion quantity multiplier (1-9) upon selecting a preset program
Allows user to cook individual portions and/or use X2 quantity multiplier feature
Default to Menu A or B* Menu A
Menu B
Menu A displayed by default
Menu B displayed by default
PIN Code O󰀨
On
Set PIN Code
PIN Code not required to access User Options
PIN Code required to access User Options
PIN Code required. Create new 4 digit PIN Code
Language Bengali, Chinese (Mandarin), Danish, Dutch, English, Filipino, French, German, Greek, Hindi, Italian, Japanese, Korean, Laotian,
Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Swedish, Thai, Ukrainian, Vietnamese
Load File N/A Detects USB ash drive and imports .xml format menu le
* Available on select models only (only displayed in User Options menu if factory option is enabled)
The switching operation of this microwave oven can cause voltage uctuations on the supply line. The operation of this oven under unfavorable voltage supply
conditions can have adverse e󰀨ects. This device is intended for the connection to a power supply system with a maximum permissible system impedance Zmax of
0.31 Ohms at the interface point of the user’s supply. The user has to ensure that this device is connected only to a power supply system which fullls the requirement
above. If necessary, the user can ask the public power supply company for the system impedance at the interface point.
