Balanced Flue Gas Stoves
NEO
USER, INSTALLATION & SERVICING INSTRUCTIONS
For use in GB & IE (United Kingdom and Ireland)
This appliance has been tested and cered for other counes (see technical data). However to install appliance in other countries, modicaon
of the appliance and its method of installaon may be necessary in order to use the appliance safely and correctly. The manual for the local
language must be obtained. Contact ACR for further informaon.
To be retained by the user for future reference.

Contents
Thankyou for purchasing an ACR Gas Stove.
To ensure you gain the most from your purchase, please read through this manual before
operang for the rst me.
Please keep this manual safe as it will be required to be completed by your Gas Safe
engineer aer each annual service.
P
age 2. General Notes & User Instrucons
P
age 3. User Instrucons
P
age 4. Symax Handset User Instrucons
P
age 11. Manual User Instrucons
P
age 12. Cleaning & Maintenance
P
age 13. Installaon Instrucons
P
age 15. Clearance Requirements
P
age 16. 
P
age 17. Burner Installaon
P
age 19. Flue Connecon
P
age 27. Posioning of Logs & Embers
P
age 32. Commissioning the Appliance
P
age 34. Brieng & Handover to the Customer
P
age 35. Gas Checklist, Dealer & Installer Informaon
P
age 36. Fault Finding Checklist
P
age 40. Spare Parts List.
P
age 41. Technical Informaon
Page 42. Technical Data
Page 43. Dimensions
Page 44. Servicing
Page 45. Annual Service Records
Page 47. Warranty
Page 48. Warranty Claim Form

General Notes
IMPORTANT
Please read these instrucons carefully before installaon or use.
This appliance must be installed and serviced by a qualied person in accordance with local
and naonal regulaons.
The ue system must be installed and inspected by a qualied person in accordance with
local and naonal regulaons.
This product has been tested, and cered also for use on Biopropane Gas. Biopropane Gas
can be used as a fuel, with no adjustment necessary if the product is installed as an LPG
version.
This Manual covers the following Products:
NEO3FGAS – Neo 3F Gas Stove, 2 side windows 1 front door glass on 4 legs
NEO3PGAS – Neo 3P Gas Stove , 2 side windows 1 front door glass on a pedestal.
This ACR gas appliance is a high eciency, Balanced Flue Live Fuel Eect appliance. It
provides radiant and convected heat using the latest burner technology. As well as having a
variable heat output, these res also ulise a special control system that allows the
appliance to funcon in thermostac and mer modes. The stove can also be operated by a
smart phone or tablet in conjuncon with My Fire app & Module
Installaon and service must be performed by a qualied installer,
service agency, or the gas supplier. Installaon shall conform with
local codes, or in the absence of local codes, in accordance with
the Naonal Fuel Gas Code ANSI Z223.1 /NFPA 54 or the IFGC or
CSA B149.1. All piping and tubing must comply with local codes
andordinances.
U
se only your hand to push in or turn the gas control knobs. Never
u
se tools. If a knob will not push in or turn by hand, do not try to
r
epair it. Call a qualied service technician. Force or aempted
r
epair can result in a re or explosion.
D
o NOT use a product if you suspect it has been subjected to high
t
emperatures, damaged, tampered with, or taken apart. Do NOT use
a
product if you suspect it has been under water or that liquid has
s
eeped into the product. Any of these incidents can cause leakage
o
r other damage that may aect proper operaon and cause
p
otenally dangerous combusonproblems.
D
o NOT store or use gasoline or other ammable vapours and liquid
s
i
n the vicinity of this control or other appliances.
WHAT TO DO IF YOU SMELL GAS
▪Do NOT operate anyappliance.
▪Do NOT touch any electrical switches; DO NOT use any
phone in the building.
▪Immediately evacuate the area and contact the gas
supplier. Follow the gas supplier’s instrucons.
▪If you cannot reach the gas supplier, call the re
department.
Read these instrucons carefully and completely before
installing or operang. Failure to follow them could
result in a re or
explosion causing property damage, personal injury, or
loss of life. Service and installaon must be performed
by a trained/experienced service technician.
2

User Instrucons
B
efore installaon, check that the local distribuon condions, nature of the gas and
p
ressure, and adjustment of the appliance are compable.
T
his appliance is intended for use on a gas installaon with a governed meter.
T
his gas installaon may only be installed by a registered professional competent person
(
Gas Safe installer in the UK). The installaon must adhere to the requirements of the local
a
nd naonal Building Regulaons and naonal standards. The installaon manual must also
b
e followed.
E
mergency Gas Isolaon
I
n the event of a gas leak or if gas is smelt, the appliance must be isolated. This is done by
t
urning OFF the gas at the isolaon tap. This isolaon tap is located at the rear of the
a
ppliance.
We strongly recommend a carbon monoxide detector conforming to EN50291 is
permanently xed in the same room as the appliance.
O
perang the Appliance for the First Time
B
efore igning the appliance, ensure that all packaging, safety sckers and any protecve
w
rapping have been removed, and that the glass has been cleaned, including all ngerprints
f
rom the glass. If ngerprints are not removed, they will permanently mark the glass.
E
nsure that the room is adequately venlated the rst me that the appliance is ignited; we
w
ould recommend opening windows if possible. Run the appliance at full seng for a few
h
ours so that the paint gets an opportunity to fully cure. Take care not to touch the paint
d
uring this process as this will leave a mark.
D
uring this period, it is possible for some fumes and vapours to be given o. We would
r
ecommend keeping children and pets out of the area at this me.
Do NOT use if leakage is detected. There is a danger of re or explosion depending on condions.
3

Symax Handset User Instrucons
Technical Data
AMBIENT TEMPERATURE RANGE
CSA: 32 °F to 131 °F
CE: 0 °C to 55 °C
RADIO FREQUENCY
CSA: 918.0 MHz for U.S. (FCC), Canada
(ISED),
New Zealand (RNZ) and Australia
(ACMA) (handset, Receiver)
CE:868.1 MHz for Europe (handset,
Receiver)
POWER SUPPLY
Handset: 2 x 1.5 V “AAA” (quality alkaline recommended)
Radio Frequency Receiver & Handset
A code is selected automacally for all Merk Maxitrol electronics from among 65,000 codes
available. The Receiver must be paired with a handset.
Handset One Buon & Two Buon Ignion
To keep the Receiver free from debris, dirt, and humidity, do not
remove the Receiver from the plasc bag unl all construcon is
complete.
Wiringof valveandReceivermustbecompletedbeforestarng
ignion. Failure to do so could damage the electronics.
The handsets and Receivers are not interchangeable with previous
electronics G6R and B6R-R8(9)U(T).
NOTICE
To avoid damaging the electronics, do NOT use metal tools to remove the baeries from the handset / Receiver.
Without using a mains adapter,baery replacement is recom- mended at the beginning of each heang season.
Old or dead baeries should be removed immediately. If lein the unit the baeries can overheat, leak, and/or explode.
Do NOT expose baeries (including during storage) to direct sunlight, excessive heat, re, moisture, or severe impact. Each of these
condions can cause the baeries to overheat, leak, and/or explode.
Baeriesmustbekeptwithintheirrecommendedtemperature limits (ambient baery temperature range: 32 °F to 131 °F / 0 °C to 55°C).
New and old baeries and dierent brands of baeries should not be used together. Mixing of various baeries can cause the baeries
to overheat, leak, and/or explode.
Change from one buon (default seng) to two buon ignion or vice versa by pressing and
holding buon for 10 sec. immediately aer installing baeries The handsets and Receivers
are not interchangeable with previous electronics G6R and B6R-R8(9)U(T). ON is displayed and
1 or 2( One or Two Buon Ignion) is ashing. When change is complete changes to 2or vice
versa.
4

Symax Handset User Instrucons
Deacvate Funcons
Acvate Funcons
Install baeries. All icons are displayed and ashing.
To acvate a funcon, press the relevant buon and hold for 10 sec.
The funcon icon will connue to ash unl acvaon is complete. Acvaon is
complete when the funcon icon is displayed.
The Following Funcons can be Deacvted/Acvated
Child Proof
Program Mode
Thermostac Mode (also deacvates Program Mode)
Eco Mode
Light/Dimmer Operaon
Circulang Fan Operaon
2nd Burner Feature
Countdown Timer
Install baeries. All icons are displayed and ashing.
While the icons are ashing, press the relevant funcon buon and hold for 10 sec.
The funcon icon will ash unl deacvaon is complete. Deacvaon is complete
when the
funcon icon and two horizontal bars are displayed.
NOTE: If a deacvated buon is pressed, there is no funcon, and two horizontal bars are
displayed.
NOTE: Deacvaon remains in eect aer change of baeries.
5

Symax Handset User Instrucons
10 Buon Handset Layout
To change between °C and °F,
press and buons
simultaneously.
NOTE: Choosing °F results in a 12
hour clock. Choosing °C results in a
24 hour clock.
ON:
To acvate press and
buons simultaneously.
is
displayed and the Symax is
rendered inoperable, except
for the OFF funcon.
OFF:
To deacvate press and
buons simultaneously.
disappears.
Seng The Time
Press and buons simultaneously.
Day ashes.
Press or buon to select a number to
correspond with the day of the week
(Monday = 1, Tuesday = 2, Wednesday = 3,
Thursday = 4, Friday = 5, Saturday = 6, Sunday = 7)
Press and buttons simultaneously. Hour
ashes.
To select hour press or buon.
Press and buons simultaneously. Minutes
ash.
To select minutes press or buon.
To conrm press and buons
simultaneously or wait.
Flame Height Adjustment
Child Proof
Seng The Fahrenheit or Celsuis
To increase ame height, press and
hold buon
To decrease ame height or to set
appliance to pilot ame, press and
hold buon.
6

Symax Handset User Instrucons
NOTICE
BEFORE OPERATING
Make sure MANUAL knob on the GV60 valve is in the ON, full counter clockwise posion.
PlacetheON/OFF switch (if equipped)in the I(ON) posion.
When pilot ignion is conrmed, motor turns automacally to maximum ame height.
Ifthepilotdoesnotstaylitaer severaltries,turn themainvalve knob to OFF
To Turn ON Fire
Press buon (One Buon
Ignion) or and buon
simultaneously (Two Buon
Ignion) unl two short beeps (CE
version) or connuous beeping (CSA
version) and a blinking series of lines
conrms the start
sequence has begun; release
buon(s).
Main gas ows once pilot ignion is
conrmed.
The Symax automacally goes into
Manual Mode aer main burner
ignition.
Standby Mode ( Pilot Flame)
Handset
Pressandhold buon to set appliance
to pilot ame.
To Turn OFF Fire
Press buon to turn o.
NOTE: A new ignion is
possible aer the OFF icon
stops ashing.
Designated Low/High Fire
To go to low re, double-click
buon. LO is displayed.
NOTE: Flame goes to high re
rst be fore going to low re.
To go to high re, double-click
but- ton. HI is displayed.
Countdown Timer
ON / SETTING:
Press and hold buon unl are
displayed, and hourashes.
To select hour press or buon.
To conrm press buon. Minutes ash.
Toselect minutes press or buon.
To conrm press buon or wait.
OFF:
Press buon and Countdown Timedisappear.
NOTE: At end of Countdown Time period, the re
shuts o. The Countdown Timer only works in
Manual, Thermo- stac, and Eco Modes.
Maximum Countdown Time is 9 hours and 50
minutes.
7

Symax Handset User Instrucons
Thermostac Mode
ON: Press buon unl temperature gage
is displayed, present temperature is
displayed briey, and then room
temperature is displayed.
OFF: Press buon.
Press Up or Down buon to enterManual
Mode.
Press Program buon to enter Program
mode.
Press Eco buon to enter Eco Mode.
Eco Mode
ON:
Press buon to enter Eco Mode. is
displayed.
OFF:
Press Eco buon. Press Up or Down buon to
enterManual Mode.
Press buon to enter
Thermostac Mode. Press buon to enter
Program Mode.
Program Mode
ON:
Press Program Buon
Program, 1 or 2, ON or OFF is displayed.
OFF:
Press Program buon.
Press or UP or DOWN buon to enter Manual Mode.
Press buon to enter Thermostac Mode.
Press buon to enter Eco Mode.
NOTE: The set temperature for Thermostac Mode is the tem- perature for the ON me in Program
Mode. Changing the Thermostac Mode set temperature also changes the ON me temperature in
Program Mode.
ON TIME (Thermostac) TEMPERATURE: 70 °F / 21 °C
OFF TIME TEMPERATURE: ” - -” (pilot ame only)
Modes of Operaon
8

9
Symax Handset User Instrucons
Default Seng
ON TIME (Thermostac) TEMPERATURE: 70 °F / 21 °C
OFF TIME TEMPERATURE: “- -” (pilot ame only)
Press buon and hold unl ashes and set temperature (seng in Thermostac Mode) is
displayed.
Toconnuepress buon or wait is displayed, temperature ashes.
Select OFF temperature by pressing the or buon.
To conrm press buon.
NOTE: The ON (Thermostac) and OFF set temperatures are the same for each day.
Program Mode – Day Mode
ALL ashes. Press UP or DOWN buon to choose between ALL, SA:SU, 1, 2, 3, 4, 5,6, 7
Press the program buon to conrm
ALL selected
ON TIME SETTING (PROGRAM 1):
Program, ON, 1 is displayed. ALL is displayed shortly & HOUR ashes.
To select hour press UP or DOWN buon.
Toconrm press Program Buon. Program, 1 , ON is displayed, ALL is displayed shortly, and minutes ash.
To select minutes press or button. To conrm press buon.
OFF TIME SETTING (PROGRAM 1):
Program, OFF, 1 is displayed. ALL is displayed shortly & HOUR ashes.
To select hour press UP or DOWN buon.
Toconrm press Program Buon. Program, 1, OFF is displayed, ALL is displayed shortly, and minutes ash.
To select minutes press or button. To conrm press buon.
Program Mode - connued

Symax Handset User Instrucons
NOTE: Either connue to PROGRAM 2 and set ON and OFF mes or stop programming at this point, and PROGRAM 2
remains deacvated.
NOTE: PROGRAM 1 and 2 use the same ON (Thermostac) and OFF temperatures for ALL, SA:SU and Daily mer
(1,2,3,4,5,6,7) Once a new ON (Thermostac) and / or OFF temperature has been set, that temperature
becomes the new default seng.
NOTE: If ALL, SA:SU or Daily Timer are programmed for PROGRAM 1 and PROGRAM 2. ON and OFF mes these become
the new default mes. The baeries must be removed to clear the PROGRAM 1 and PROGRAM 2 ON and OFF
mes and temperatures.
SA:SU or Daily Timer (1,2,3,4,5,6,7) selected
Set ON me and OFF me using same procedure as ALL selected (above)
SA:SU set ON me and OFF me for both Saturday and Sunday
Daily Timer: Unique ON and OFF mes may be set for a single day of the week, for mulple day of the week, or for everyday
of the week.
Wait to nish seng.
2nd Burner Feature
The latching solenoid valve will open automacally aer ignion or aer switching the system OFF, so
that the maximum ow of gas is supplied to both burners assisng with the ignion process. Aer
pressing the buon for the 2nd Burner the motor will turn 7 seconds in the ON direcon unl the max.
posion is reached.
ON:
To switch a burner ON, press the buon displayed.
OFF:
To switch the burner OFF, press the buon disappears.
NOTE: The latching solenoid valve cannot operate manually. If the Receiver battery runs down it will
remain in the last operang posion.
Light/Dimmer Operaon
ON: Press button (is displayed). Light is ON at present level.
OFF: Press button (button disappears).
SETTING:
Press buon and hold unl ashes. Adjust light between 20-100% using UP and DOWN.
To conrm seng either press buon or wait unl buon is displayed.
NOTE: The light works independently of the pilot ame. If you want the light ON but no ames press buon
10

Manual User Instrucons
K
nob Sengs
KNOB POSITION FUNCTION
Main valve
knob
OFF Permits main gas flow through valve.
Main valve
knob
ON
Permits main gas flow through valve if pilot is lit and
thermocouple is generating sufficient power.
Manual knob MAN
Allows pilot to the manually ignited and prevents main gas
flow.
Manual knob ON Allows automatic ignition.
M
anual Turn O
I
n the event that the appliance needs to be turned OFF manually, for instance, if the remote
c
ontrol is lost or the baeries become totally at, the control valve must be accessed and
t
he switch ipped to OFF (marked “0”).
T
he picture below shows the control valve.
T
he control valve is located behind the control hatch in the Base of the appliance.
11

Cleaning & Maintenance
Never aempt any cleaning or maintenance of the
appliance unless the appliance is cold
T
his appliance should be inspected and serviced once a year by a qualied, competent and
r
egistered person.
T
he inspecon and maintenance must at least ensure that the appliance is working correctly
a
nd safely.
I
t is advisable to clean the exterior of the appliance of any dust and debris regularly during
t
he heang season and especially if the appliance has not been used for some me.
T
his can be done with a sobrush and a vacuum cleaner or a damp cloth and if required a
n
on-abrasive cleaning agent.
D
o not use corrosive or abrasive substances to clean the exterior of the appliance as this
m
ay damage the painted nish of the stove.
T
his appliance uses 4 x AA baeries for the ignion and control of the stove.
T
o access to these baeries, reach under the appliance and remove the control unit located
t
o the rear right hand side of the appliance, remove the top cover and replace the exisng
b
aeries.
N
ever use a metal tool to remove the baeries as this may damage the control unit.
O
nce the baeries have been replaced always ret the contro
12

Installaon Instrucons
Unpacking
Remove the appliance from its packaging and check for any damage or missing items before
commencing the installaon.
Packing List
•Appliance
•Log Set
•Remote control handset
•Bag of embers
•Glow bre pack
•Burner
Before commencing installaon, conrm that the details on the appliance data plate
correspond to the local distribuon condions, gas type and pressure to which the
appliance is to be installed. Check you are in receipt of the correct gas type burner.
Ensure the gas supply and supply pipe is capable of delivering the required volume and
pressure of gas and is in accordance with the rules in force.
Protecve clothing should be worn when installing the appliance.
Care should be taken when liing this appliance due to it’s weight.
We strongly recommend a carbon monoxide detector (conforming to EN50291) is permanently xed in the same room as the appliance.
Ensure that the Flue Terminal is not in any way obstructed and is clear of vegetaon, i.e. trees, shrubs etc. and that no objects are leant
against the terminal or guard.
Always clean the Window Panel before the re is inially ignited. Any nger prints must be removed, as these will be burnt into the glass
and will be un-removable.
Do not operate this appliance if the glass panel has been broken (or cracked), removed or is open.
The appliance is designed to t numerous installaon situaons as listed in these installaon instrucons. However only ue approved by
ACR for this appliance may be used. 3 standard kits are available through ACR. Addional parts can be purchased from Poujoulat but must
be approved by ACR.
This appliance is a balanced ue product and is room sealed and as such requires no addional venlaon for operaon. However an
adequate supply of fresh air to maintain temperatures and a comfortable environment is recommended.
This appliance is designed as a heang appliance, and as such will get very hot in operaon; all surfaces (except the controls and access
door) are considered to be working surfaces and as such should not be touched. The front windows and surrounds are not considered to
be fully secure guards against accidental contact. It is recommended that an approved re screen be used if children, the elderly or
persons with limited mobility are to be present in the same area.
Do not place curtains, laundry, furniture etc. within a safe distance of 300mm of this appliance.
Do not aempt to burn rubbish on this appliance.
If this appliance is exnguished, on purpose or other, no aempt to relight should be made within 3 minutes.
13

Installaon Instrucons
G
as Connecon
T
his appliance has a gas inlet connecon of Ø 8mm.
V
enlaon
T
his appliance is a Balanced Flue room sealed appliance, and as such needs no addional
v
enlaon. However, an adequate supply of fresh air to maintain temperatures and a
c
omfortable environment is recommended.
T
his appliance may be installed in a completely sealed or mechanically venlated house.
D
o not install the appliance in a bathroom or a room that contains a bath or shower.
D
o not cover the appliance and or do not wrap it in an insulaon blanket or any other
m
aterial.
D
o not make any changes to the appliance.
T
he gas connecon must be in accordance with local and naonal regulaons.
T
his appliance is intended for use on a gas installaon with a governed meter.
A
ppliance Fireplace Installaon
D
etermine the posion required for the appliance.
C
reate a gas connecon for the appliance in approximately the correct locaon for the gas
c
ontrols.
T
he gas controls are connected to the Burner of the appliance.
F
or clearance details see below.
T
he clearance distance of the Flue from combusbles must not be less than 75mm. This
d
imension can be reduced to 25mm as the distance from the underside and the sides of
h
orizontal ue runs.
H
earth
A
hearth conforming to naonal regulaons should be provided for the stove extending
t
o at least the front of the supporng legs, and to at least each side of the stove. ACR
r
ecommend a hearth footprint 50mm more on all 4 sides than the footprint of the
appliance. The hearth should have a minimum thickness of 12mm.
14

Clearance Requirements
C
orner Installaon – Distance to combusbles
Above – Distance to combusbles
Side & Rear – Distance to combusbles
15
100mm
100mm 500mm
75mm
250mm
All clearances stated provide the minimum distance to combustible material. If the appliance is
to be installed in a non-combustible opening, these clearances can be reduced but the clearance
for the rear must always be 50mm minimum. You must ensure that if reducing the clearances to
the sides or above, provision is made for servicing & maintenance purposes and adequate air
flow around the appliance can be maintained. However, we would recommend you adhere to
the clearances to combustibles wherever possible.

Installaon of the appliance
The appliance is supplied in separate boxes, please refer to the packing list above.
The installer is required to install the burner, oponal rear panel, oponal LED kit and log
set to the appliance.
Flue conguraon
The appliance is pre-set with a vercal ue conguraon, if this is the desired ue route
then no further acon needs to be taken.
The appliance is able to be installed with a rear ue opon when used in conjuncon with
the ACR snorkel kit, to prepare the appliance for this applicaon the ue collar assembly will
need to be removed from the top of the appliance and swapped to the rear of the
appliance.
1. Remove free oang top plate, remove air
intake collar and gasket, and remove
inner ue outlet collar and gasket.
2. Swap the blanking plates, ue collars and
gaskets and reghten
xing bolts. Place the cosmec blanking
plate onto the top of the free - oang
top plate.
16

3. Unpack the complete burner and insert the burner into the
combuson chamber. Secure the burner to the base of the
appliance using the 4 bolts provided ensuring that the seal is
fully compressed on all sides. Please pay careful aenon to
make sure that the aached control box and associated
wiring are not trapped between the boom of the burner and
the combuson chamber. Ensure that the exible gas supply
pipe is not damaged in any way and that it’s protruding from
the rear of the appliance, or if desired from the removeable
plate located in the pedestal.
2. Lift
out the perforated grate from the combuson chamber.
Burner installaon
Before connecng the burner please ensure that the gas supply pipework is in the correct
posion for connecon to the unit, please ensure that the gas supply pipework is purged
and free from debris.
1. To access the combuson chamber please loosen the retaining bolt located in the
handle below the roller cam locking mechanism.
17

4. Place the control box into the holder located on the underside back leof the appliance ensuring
that the wiring is not trapped in any way.
7. The appliance is now ready to be connected to the gas supply pipework and the ue connecon
can be made.
5.Replace the perforated grate.
6. Place the elevated burner ports onto the leand right gas outlets as shown. The
le- hand elevated port should sit in the 6th groove from the front. The right-hand
elevated port should sit in the 3rd groove from the front. Make sure that both ports
are securely located on the outlet ports.
18

Flue Connecon
G
eneral Notes
T
his appliance may be installed with a roof terminal or a wall terminal.
T
his appliance may only be used with Balanced Flue (otherwise known as Concentric Flue)
p
arts as specied by ACR. The ACR specied ue parts have been approved with the
a
ppliance. If the appliance is installed on non-ACR approved parts, ACR cannot guarantee or
a
ccept any responsibility for the proper and safe working of the appliance. Please check the
l
atest approved ue suppliers with ACR prior to purchasing,
T
he ue system must be constructed from the appliance upwards, with all joints being fully
l
ocked and sealed using the ACR specied parts.
I
f installing the ue renovaon kit, the exisng ue must be swept & checked for soundness
p
rior to installaon.
T
imber Frame Construcon
W
hilst it is possible to install room-sealed appliances in mber frame properes, great care
n
eeds to be taken to ensure that the ue assembly does not interfere with the weather
p
roong qualies of any outer wall which it may penetrate. Before aempng this work,
f
urther details need to be referenced, (e.g. “Gas Installaons in Timber Frame Buildings”
f
rom the GAS SAFE installer publicaons in the UK).
C
ar Port or Building Extension
W
here a ue terminal is sited within a car port or building extension, it should have at least
t
wo completely open and unobstructed sides. The distance between the lowest part of the
r
oof and the top of the terminal should be at least 600mm.
N
ote: A covered passageway should not be treated as a car port. Flues should not be sited in
a
covered passageway between properes.
B
asements, Lightwells and Retaining Walls
F
lue terminals should not be sited within the connes of a basement area, lightwell or
e
xternal space formed by a retaining wall, unless steps are taken to ensure the
p
roducts of combuson can disperse safely at all mes. It may be possible to install this
B
alanced Flue system in such a locaon provided that it is not sited lower than 1m from the
t
op level of that area to allow combuson products to disperse safely.
F
lue terminals should be sited to ensure total clearance of the combuson products in
a
ccordance with the manual.
W
hen the products of combuson are discharged, they should not cause a nuisance to
a
djoining or adjacent properes and they should be posioned so that damage cannot occur
t
o other parts of the building. If the outer wall surface is constructed of combusble
m
aterial, a non-combusble plate should be ed behind the terminal projecng 25mm
b
eyond the external edges of the terminal
19
