Acrosser Technology ACE-B7400 Installation guide

P/N：220010423-G
0
ACE-B7400
Quick Manual
P/N：220010423-G
1
ACE-B7400 Quick Manual
1. I/O Connector and Key parts illustration (Top Side)
LED1
Green LED: Power On.
Orange LED: HDD Active.
PWR_BTN1
System Power Button
DVI-D1
DVI-D Connector.
DVI-I1
DVI-I Connector.
USB1
USB 2.0 Connector
CN25
RJ45 & USB 2.0 Connector
CN26
RJ45 & USB 2.0 Connector
COM1_2
RS-232 Connector
(9-bits Protocol supported).
COM3_4
RS-232 Connector
CN7
Gaming Input Isolation
Connector.
CN6
Gaming Input Isolation Connector.
CN5
Gaming Open-Drain Output
Connector.
CN4
Gaming Open-Drain Output
Connector.
CN3
TTL, RS232, RS485, cctalk
selectable connector
(UART RX,TX signal only).
CN2
2.1 Channel Audio Amplifier Output
Connector.
CN1
System Power Input Connector.
U43
AMD FT1 APU. (T48N/T52R)
U44
AMD Hudson-E1 Fusion
Controller Hub.
CF1
CF Card Slot 1.
CF2
CF Card Slot 2.
U40
Acrosser Gaming Core (AGC).
SATA1/SATA2
SATA 3.0 Connectors.
MINI-PCIE1
Mini-PCIe Slot.
CN_DIMM1/CN_DIMM2
DDR3 SODIMM Socket.
Maximum total 8GB.
CASESW1
Micro-switch for Chassis
Open/Close Detection.
BAT_BH1
CR2032 Battery Holder
for system RTC.

P/N：220010423-G
2
1.1 Rears-Panel I/O Configurations
CN7
Gaming Input Isolation Connector.
Micro-FIT 3.0mm
2*8 PINs
Pin
Signal Pin
Signal
1 Door Switch 1 9 Button 4
2 Door Switch 2 10 Button 5
3 Door Switch 3 11 Button 6
4 Door Switch 4 12 Button 7
5 Door Switch 5 13 Button 8
6 Button 1 14 Button 9
7 Button 2 15 Button 10
8 Button 3 16 Button 11
Note:
1.All input pin logical
high-level is +5V ~ +24V,
logical low-level is 0V ~
+1.5V.
CN6
Gaming Input Isolation Connector.
Micro-FIT 3.0mm
2*8 PINs
Pin
Signal Pin
Signal
1 Button 12 9 Touch-Cal Key-Lock
2 Button 13 10 Spare Key-Lock
3 Button 14 11 Coin-In Signal A
4 Button 15 12 Coin-In Signal B
5 Button 16 13 Bill-In
6 Dissolve Key-Lock
14 Hopper Sensor
7 OM Key-Lock 15 GPI 0
8 Setup Key-Lock 16 GPI 1
Note:
1.All input pin logical
high-level is +5V ~ +24V,
logical low-level is 0V ~
+1.5V.
2.Coin-In Signal A, Coin-In
Signal B, Bill-In, and
Hopper Sensor support
input counter function.
CN5
Gaming Open-Drain Output Connector.
Micro-FIT 3.0mm
2*10 PINs
Pin
Signal Pin
Signal
1 Key-in Meter 11 Coin-Enable
2 Bill-in Meter 12 Bill-Enable
3 Coin-in Meter 13 Hopper-SSR
4 Pay-out Meter 14 GPO 0
5 Key-out Meter 15 GPO 1
6 Hand-pay Meter 1
16 GPO 2
7 Hand-pay Meter 2
17 GPO 3
8 Spare Meter 18 GPO 4
9 GND 19 GND
10 IBUT2 20 GND
Note:
1.Eight Meters support
pulse-Generator function.
2.All output pin is open-drain
circuit and operation
maximum voltage cannot
over +30V.
3.IBUT2 is short to onboard
ibuttom2 connector.
P/N：220010423-G
3
CN4
Gaming Open-Drain Output Connector.
Micro-FIT 3.0mm
2*10 PINs
Pin
Signal Pin
Signal
1 LAMP 1 11 LAMP 9
2 LAMP 2 12 LAMP 10
3 LAMP 3 13 LAMP 11
4 LAMP 4 14 LAMP 12
5 LAMP 5 15 LAMP 13
6 LAMP 6 16 Tower LAMP 1
7 LAMP 7 17 Tower LAMP 2
8 LAMP 8 18 Tower LAMP 3
9 GND 19 GND
10
GND 20 GND
Note:
1.Each LAMP output supports
open-drain 500mA
(max)
current;
each Tower LAMP output supports
open-drain 1A
(max)
current.
2.All output pin is open-drain circuit
and operation maximum voltage
cannot over +30V.
CN3
Two TTL, RS232, RS485, ccTalk selectable connector (UART RX & TX signal only)
Note: mode selected by JP6~JP13 (Please see Appendix A.)
Micro-FIT 3.0mm
2*7 PINs
Pin
Signal Pin
Signal
1
COM5 TTL/ 232 Tx/ 485 +
8 COM5 TTL/ 232 Rx/ 485 -
2
COM6 TTL/ 232 Tx/ 485 +
9 COM6 TTL/ 232 Rx/ 485 -
3
COM5 ccTalk Data 10
COM6 ccTalk Data
4
COM5 ccTalk Vcc 11
COM6 ccTalk Vcc
5
GND 12
GND
6
GND 13
GND
7
GND 14
GND
CN2
2.1 Channel Audio Amplifier Output Connector.
Micro-FIT 3.0mm
2*3 PINs
Pin
Signal Pin
Signal
1
Front Left + 4 Front Left -
2
Front Right +
5 Front Right -
3
LFE + 6 LFE -
Note:
1. Audio Amplifier is D-type amp.
2. Amplified Right and Left channel
support 10Watt
(max)
Output,
Amplified LFE channel supports
20Watt
(max)
Output.
CN1
System Power Input Connector.
Micro-FIT 3.0mm
2*4 PINs
Pin
Signal Pin
Signal
1 +12V 5 +12V
2 GND 6 GND
3 GND 7 GND
4 +12V 8 +24V
Note:
1.+12V Power Input voltage
tolerance is ±10%.
2.+24V Power Input is only use for
cctalk Vs power supply.

P/N：220010423-G
4
2. Connector & Jumper setting definition (Top Side)
FPIO1
System Power Button & Reset
connector
CN_USB1
USB 2.0 Connector
CN_USB2
USB 2.0 connector
SYSFAN2
System FAN Connector 2.
APUFAN1
APU FAN Connector.
SPAREIO1
JST 2.0mm Gaming Spare-IO
Connector. (16-bits GPIO)
SW1
8-bit DIP-Switch Input for AGC.
SATA_PWR1
SATA_PWR2
SATA Power Connectors.
CLRCMOS
Clear System CMOS Jumper.
JP6 ~ JP13
CN3 Output Signal Selection
Jumper (TTL, RS232, RS485
or ccTalk)
SYSFAN1
System FAN Connector 1.
IButtom2
External i-Button Connector.
JP2
JP3
SRAM A, B Clear Jumper.
JP4
JP5
Bill-enable, Coin-enable
Preset Jumper.
BAT_A1,
BAT_B1
Lithium Battery Connector for
SRAM, AGA and secured RTC.
JP18
RS-485 Terminal Resistor
Selection Jumper for CN3
(UART 6)
JP17
RS-485 Terminal Resistor
Selection Jumper for CN3
(UART 5)
AUDIO1
Internal 5.1 Channel Audio
Pin-Header.
JP1
cctalk Supply Power Selection
Jumper.
CASESW2
JST 2.0mm Chassis
Open/Close Detection
Connector
.
P/N：220010423-G
5
2.1 Connectors and Jumpers Setting
FPIO1
System Power Button & Reset connector
CN_USB1
CN_USB2
USB 2.0 Connector
Pin
Function
1-2
Power Button Connector
3-4
Short: Auto Power-on
Open: Power-on by
Pin1-2 Button
5-6
Reset Button Connector
Note:
Default short Pin3-4 be Auto-Power-
On
JST 2.0mm
Pin
Signal
1 VCC (+5V)
2 Data+
3 Data-
4 GND
5 N.C
SYSFAN2
System FAN Connector 2.
APUFAN1
APU FAN Connector.
Pin
Signal
1 GND
2 +12V
3 Feedback
Pin
Signal
1 GND
2 +12V
3 Feedback
SPAREIO1
JST 2.0mm Gaming Spare-IO Connector.
(16-bits GPIO)
SW1
8-bit DIP-Switch Input for AGC.
Pin
Signal Pin
Signal
1 Bit0 2 Bit8
3 Bit1 4 Bit9
5 Bit2 6 Bit10
7 Bit3 8 Bit11
9 Bit4 10
Bit12
11
Bit5 12
Bit13
13
Bit6 14
Bit14
15
Bit7 16
Bit15
17
GND 18
+3.3V
19
GND 20
+3.3V
SW 1~8 Signal
ON +3.3V
OFF GND

P/N：220010423-G
6
SATA_PWR1
SATA_PWR2
SATA Power Connectors.
CLRCMOS
Clear System CMOS Jumper.
JST 2.5mm
Pin Signal
1 +12V
2 GND
3 +3.3V
4 +5V
Jumper Function
1-2
(default) Normal
2-3 Clear CMOS
JP6 ~ JP13
CN3 Output Signal Selection Jumper
(TTL, RS232, RS485 or ccTalk) SYSFAN1
System FAN Connector 1.
Please See Appendix A.
(Default set to be RS232)
Pin
Signal
1 GND
2 +12V
3 Feedback
IButtom2
External i-Button Connector. JP2 ,JP3 SRAM A, B Clear Jumper.
JST 2.0mm
Pin1 is short to rear-panel CN5
connector Pin10
Pin
Signal
1 I-Button Signal
2 GND
Jumper Function
1-2
(default) Normal
2-3 Clear SRAM
JP4 ,JP5
Bill-enable, Coin-enable Preset Jumper. BAT_A1 ,BAT_B1
Lithium Battery Connector for SRAM, AGA and
secured RTC.
Jumper Function
1-2
(default) Preset is “High”.
2-3 Preset is “Low”.
Note:
“High” means Bill-enable, Coin-enable
open-drain output is short to ground.
“Low” means Bill-enable, Coin-enable
open-drain output is open
Pin Signal
1 POWER
2 GND
P/N：220010423-G
7
JP18
RS-485 Terminal Resistor Selection Jumper for
CN3
(COM 6). JP17
RS-485 Terminal Resistor Selection Jumper for
CN3 (COM 5).
Jumper Function
1-2 Termination
2-3
(default) Non
Note:
Terminal resistor is 120ohm.
Jumper Function
1-2 Termination
2-3
(default) Non
Note:
Terminal resistor is 120ohm.
AUDIO1
Internal 5.1 Channel Audio Pin-Header. JP1 ccTalk Supply Power Selection Jumper.
Pin
Signal Pin
Signal
1 Front-L 2 Front-R
3 GND 4 GND
5 Surround-L
6 Surround-R
7 IO4 GND 8 GND
9 Center 10
LFE
Jumper Function
1-2
(default) +12V
2-3 +24V
power is from CN1 external power
supply.
CASESW2
JST 2.0mm Chassis Open/Close Detection
Connector
.
Pin
Signal
1 Signal
2 GND

P/N：220010423-G
8
Appendix A
CN3 Output Signal TTL/RS232/RS485/cctalk Jumper Configuration
Default configuration of COM-5 and COM-6 are RS-232 mode.
 Locations:
 CN3 (COM-5) selectable functions
RS-232
(Default) TTL RS-485 ccTalk
Note: Orange block means shorted by a jumper, and others leave it N.C.
 CN3 (COM-6) selectable functions
RS-232
(Default) TTL RS-485 ccTalk
Note: Orange block means shorted by a jumper, and others leave it N.C.
P/N：220010423-G
9
Appendix B
AGC I/O Definition
I : Input I.I: Input with isolation
O.C: Open-Collector Output I/O: Spare Input/Output
Connectors Map
AGC
Channel
I/O
Type
Functions Rear panel
Gaming I/O Onboard Remark
DI0 I Door SW1 CN7 – Pin1 AGA log 0
DI1 I Door SW2 CN7 – Pin2 AGA log 1
DI2 I Door SW3 CN7 – Pin3 AGA log 2
DI3 I Door SW4 CN7 – Pin4 AGA log 3
DI4 I Door SW5 CN7 – Pin5 AGA log 4
DI5 I Door SW6 CASESW1
AGA log 8 ; Onboard chassis Switch
DI6 I Door SW7 CASESW2
AGA log 9 ; Onboard JST 2.0mm
connector for ext. switch.
DI7 I.I Button 1 CN7 – Pin6
DI8 I.I Button 2 CN7 – Pin7
DI9 I.I Button 3 CN7 – Pin8
DI10 I.I Button 4 CN7 – Pin9
DI11 I.I Button 5 CN7 – Pin10
DI12 I.I Button 6 CN7 – Pin11
DI13 I.I Button 7 CN7 – Pin12
DI14 I.I Button 8 CN7 – Pin13
DI15 I.I Button 9 CN7 – Pin14
DI16 I.I Button 10 CN7 – Pin15
DI17 I.I Button 11 CN7 – Pin16
DI18 I.I Button 12 CN6 – Pin1
DI19 I.I Button 13 CN6 – Pin2
DI20 I.I Button 14 CN6 – Pin3
DI21 I.I Button 15 CN6 – Pin4
DI22 I.I Button 16 CN6 – Pin5
DI23 I.I Dissolve Key-Lock
(Key 1) CN6 – Pin6
DI24 I.I OM Key-Lock
(Key 2) CN6 – Pin7
DI25 I.I Setup Key-Lock
(Hand Pay) (Key 3) CN6 – Pin8
DI26 I.I Touch-Cal Key-Lock
(Key 4) CN6 – Pin9
DI27 I.I Spare Key-Lock
(Key 5) CN6 – Pin10
DI28 I.I Coin-In Signal A CN6 – Pin11
AGC Counter 1
DI29 I.I Coin-In Signal B CN6 – Pin12
AGC Counter 2
DI30 I.I Bill-In CN6 – Pin13
AGC Counter 3
DI31 I.I Hopper Sensor CN6 – Pin14
AGC Counter 4
DI32 I.I General Purpose In 0 CN6 – Pin15
DI33 I.I General Purpose In 1 CN6 – Pin16

P/N：220010423-G
10
Connectors Map
AGC
Channel
I/O
Type
Functions Rear panel
Gaming I/O Onboard Remark
DI34 I DIP Switch S1 SW1 –S1
DI35 I DIP Switch S2 SW1 –S2
DI36 I DIP Switch S3 SW1 –S3
DI37 I DIP Switch S4 SW1 –S4
DI38 I DIP Switch S5 SW1 –S5
DI39 I DIP Switch S6 SW1 –S6
DI40 I DIP Switch S7 SW1 –S7
DI41 I DIP Switch S8 SW1 –S8
DO0 O.C.
Lamp1 CN4 – Pin1 500mA
(max)
current
DO1 O.C.
Lamp2 CN4 – Pin2 500mA
(max)
current
DO2 O.C.
Lamp3 CN4 – Pin3 500mA
(max)
current
DO3 O.C.
Lamp4 CN4 – Pin4 500mA
(max)
current
DO4 O.C.
Lamp5 CN4 – Pin5 500mA
(max)
current
DO5 O.C.
Lamp6 CN4 – Pin6 500mA
(max)
current
DO6 O.C.
Lamp7 CN4 – Pin7 500mA
(max)
current
DO7 O.C.
Lamp8 CN4 – Pin8 500mA
(max)
current
DO8 O.C.
Lamp9 CN4 – Pin11
500mA
(max)
current
DO9 O.C.
Lamp10 CN4 – Pin12
500mA
(max)
current
DO10 O.C.
Lamp11 CN4 – Pin13
500mA
(max)
current
DO11 O.C.
Lamp12 CN4 – Pin14
500mA
(max)
current
DO12 O.C.
Lamp13 CN4 – Pin15
500mA
(max)
current
DO13 O.C.
Lamp14 CN4 – Pin16
1A
(max)
current
DO14 O.C.
Lamp15 CN4 – Pin17
1A
(max)
current
DO15 O.C.
Lamp16 CN4 – Pin18
1A
(max)
current
DO16 O.C.
Key-In Meter
(Meter 1) CN5 – Pin1 AGC Pulse Generator 1
DO17 O.C.
Bill-In Meter
(Meter 2) CN5 – Pin2 AGC Pulse Generator 2
DO18 O.C.
Coin-In Meter
(Meter 3) CN5 – Pin3 AGC Pulse Generator 3
DO19 O.C.
Pay-Out Meter
(Meter 4) CN5 – Pin4 AGC Pulse Generator 4
DO20 O.C.
Key-Out Meter
(Meter 5) CN5 – Pin5 AGC Pulse Generator 5
DO21 O.C.
Hand-Pay Meter1
(Meter 6) CN5 – Pin6 AGC Pulse Generator 6
DO22 O.C.
Hand-Pay Meter2
(Meter 7) CN5 – Pin7 AGC Pulse Generator 7
DO23 O.C.
Spare Meter1
(Meter 8) CN5 – Pin8 AGC Pulse Generator 8
DO24 O.C.
Coin-Enable CN5 – Pin11
DO25 O.C.
Bill-Enable CN5 – Pin12
DO26 O.C.
Hopper SSR CN5 – Pin13
DO27 O.C.
General Purpose Out 0
CN5 – Pin14
DO28 O.C.
General Purpose Out 1
CN5 – Pin15
DO29 O.C.
General Purpose Out 2
CN5 – Pin16
DO30 O.C.
General Purpose Out 3
CN5 – Pin17
DO31 O.C.
General Purpose Out 4
CN5 – Pin18
P/N：220010423-G
11
Connectors Map
AGC
Channel
I/O
Type
Functions Rear panel
Gaming I/O Onboard Remark
GPIO0 I/O Spare I/O bit 0 SPAREIO1
– Pin1
GPIO1 I/O Spare I/O bit 1 SPAREIO1
– Pin2
GPIO2 I/O Spare I/O bit 2 SPAREIO1
– Pin3
GPIO3 I/O Spare I/O bit 3 SPAREIO1
– Pin4
GPIO4 I/O Spare I/O bit 4 SPAREIO1
– Pin5
GPIO5 I/O Spare I/O bit 5 SPAREIO1
– Pin6
GPIO6 I/O Spare I/O bit 6 SPAREIO1
– Pin7
GPIO7 I/O Spare I/O bit 7 SPAREIO1
– Pin8
GPIO8 I/O Spare I/O bit 8 SPAREIO1
– Pin9
GPIO9 I/O Spare I/O bit 9
SPAREIO1
– Pin10
GPIO10
I/O Spare I/O bit 10
SPAREIO1
– Pin11
GPIO11
I/O Spare I/O bit 11
SPAREIO1
– Pin12
GPIO12
I/O Spare I/O bit 12
SPAREIO1
– Pin13
GPIO13
I/O Spare I/O bit 13
SPAREIO1
– Pin14
GPIO14
I/O Spare I/O bit 14
SPAREIO1
– Pin15
GPIO15
I/O Spare I/O bit 15
SPAREIO1
– Pin16
