Acrosser Technology AR-B5205 Series Installation guide

AR-B5205 Quick Manual
AR-B5205
1
AR-B5205
Quick Manual V1.0
Content:
1. Locations of Main Component, Connectors,Jumpers and Indicators.
2. The List of All Connectors and Jumper Settings Assorted by Function.
3. Description of Jumper Settings and Connector Pin Definitions.
AR-B5205 Quick Manual
AR-B5205
2
1. Locations
zMain Chips and Standard Connectors
TOP
Bottom

AR-B5205 Quick Manual
AR-B5205
3
BAT1
Battery Connector
USB1
USB connector
CPU
Intel Celeron M /Pentium M CPU
PCI Ethernet Controller IC x 2
IIntel Ethernet controller 82541PI
FAN1 & FAN2
FAN connector
PCI EXPRESS Ethernet Contoller IC x 4
Intel Ethernet controller 82574L
North Bridge
Intel 915GME PCI1
PCI Slot
DDR2SODIMM1
Connector for DDR2 SDRAM Super I/O Controller
Winbond W3627EHG
2LAN1~2LAN3
RJ45 connector for LAN1~LAN6
South Bridge
Intel Integrated Control Hub 6（ICH6）
COM1
RS232 SATA1 & SATA2
Connector for SATA Hard Disk
MPCI1
Mini-PCI Slot
CF1
Slot for Compact Flash
DDR2SODIMM2
Connector for DDR2 SDRAM
TOP
Bottom
AR-B5205 Quick Manual
AR-B5205
4
zConnector, Jumper and Indicators
LED2~LED7 (Right to Left)
LED indicator for LAN1~LAN6.(right to Left)
CN7
CPLD Program Interface
USB2 & USB3
Each Connector for 2 ports USB
LED1
LED indicator for Power On and Hard Disk
SW1 & SW2
SW1 for FSB Frequency Setting
SW2 for CPU Frequency Setting
VGA1
VGA1 is for CRT output.
RST_BTN1
Reset Bottom for System Reset
LED0
The same function with LED1
PWR1
Power connector for Adapter POWER-IN
CN8
Connector for Power Switch
ATX_12V1
Connector for Regular ATX 4 pin 12V Input
CN5
LCM module interface
JP3
RTC Reset.
TOP

AR-B5205 Quick Manual
AR-B5205
5
KBMS1
PS/2 Keyboard and Mouse Connector
CN3
Power Supply for SATA Hard Disk
GPIO1
Connector For General Purpose I/O
AR-B5205 Quick Manual
AR-B5205
6
2. List of Connectors and Jumper Settings
Function Part Reference Description and Note
Serial Port COM1 COM1 is for RS232
VGA & LCM 1. VGA1
2. CN5
1. VGA1 is for CRT output.
2. CN5 is interface for LCM Module.
Bus Frequency SW1 & SW2 SW1 for CPU Frequency
SW2 for Front side bus Frequency
Keyboard & Mouse KBMS1 KBMS1 is connector for PS/2 keyboard and Mouse.
Indicator 1. LED0 & LED1
2. LED2~LED7
1. LED0 & LED1 are for Hard Disk and Power
2. LED2~LED7 are for LAN1~LAN6
Power 1. PWR1
2. ATX_12V1
3. CN3
4. CN8
1. PWR1 is for Adapter Power IN
2. ATX_12V1 is for regular ATX 12V input.
3. CN3 is Power Supply to SATA Hard Disk.
4. CN8 is for POWER Bottom Switch
GPIOs CPIO 8 bit GPIO.
RTC JP3 RTC Reset.
USB USB2 & USB3 USB2 & USB3 are Pin header USB host.
Bypass 1. CN7 1. CN7 is for programming Bypass CPLD
Reset RST_BTN1 Bottom For System Reset

AR-B5205 Quick Manual
AR-B5205
7
2. Jumper settings and Pin Definitions.
LED2~LED7 (Right to Left)
LED indicator for LAN1~LAN6.(right to
Left)
Light SIGNAL
GREEN LINK
Yellow ACT
CN7
CPLD Program Interface
PIN SIGNAL
1 3.3V
2 TDO
3 TDI
4 NC
5 NC
6 TMS
7 GND
8 CLK
USB2 & USB3
Each Connector for 2 ports USB
PIN SIGNAL PIN SIGNAL
1 5V 2 5V
3 -USB0 4 -USB1
5 +USB0 6 +USB1
7 GND 8 GND
9GND10 GND
LED1
LED indicator for Power On and Hard Disk
Light SIGNAL
GREEN POWER
Yellow Hard Disk
AR-B5205 Quick Manual
AR-B5205
8
SW1 & SW2
SW1 for FSB Frequency Setting
SW2 for CPU Frequency Setting
12 SETTING
ON ON
A
utomatic Setting for Dothan
CPU
OFF OFF Manual Setting or For Banias
CPU
PIN STATUS SETTING
OFF Setting For Dothan CPU
1ON Setting For Banias CPU
2ON
3ON
4OFF
Setting For 400MHz FSB
2ON
3OFF
4OFF
Setting For 533MHz FSB
2OFF
3OFF
4OFF
Automatic setting for
Dothan CPU
VGA1
VGA1 is for CRT output)
PIN SIGNAL PIN SIGNAL
1 RED 2 GND
3 GREEN 4 GND
5 BLUE 6 GND
7 V-SYNC 8 I2C Clock
9 H-SYNC 10 I2C Data
RST_BTN1
Reset Bottom for System Reset
Status Function
Push then Release System Reset
LED0
The same function with LED1
Light SIGNAL
GREEN POWER
Yellow Hard Disk
PWR1
Power connector for Adapter POWER-IN
PIN SIGNAL
Up Side 12V
Bottom side GND

AR-B5205 Quick Manual
AR-B5205
9
CN8
Connector for Power Switch
Status SIGNAL
Close Turn-On
Open Turn-Off
ATX_12V1
Connector for Regular ATX 4 pin 12V
Input
PIN SIGNAL
Right Side 12V
Left Side GND
CN5
LCM module interface
PIN SIGNAL
1 Reset
2 5V
3 DATA Out
4 DATA In
5 RTS
6 CTS
7 GND
JP2
RTC power and reset
Status function
1-2 close Normal
2-3 Close RTC Reset
KBMS1
PS/2 Keyboard and Mouse Connector
PIN SIGNAL PIN SIGNAL
1 MS data 4 5V
2 KB data 5 MS clock
3 GND 6 KB clock
CN3
Power Supply for SATA Hard Disk
PIN SIGNAL
1 12V
2 GND
33.3V
4 5V
AR-B5205 Quick Manual
AR-B5205
10
GPIO1
Connector For General Purpose I/O
PIN SIGNAL PIN SIGNAL
1 5V 2 GND
3 GPIO1 4 RP0
5 GPIO2 6 RP1
7 GPIO3 8 RP2
9 GPIO3 10 RP3
