Acrosser Technology AMB-A55EG1 Installation guide

P/N:220010435-G
2013.1.18 1
AMB-A55EG1 v1.0 Quick Manual
Contents
1. Main board illustration.........................................................................................................1
2. Connector pin define...........................................................................................................3
a. DDR3 SO-DIMM Connector.................................................................................... 3
b. SATA & mSATA connector .....................................................................................3
c. FAN Connector........................................................................................................ 3
d. CN_COM1_2 (RS-232 ,RS-232/422/485) ,CN_COM1 & ccTalk............................. 4
e. 5.1CH.Audio out & 2CH Speaker Out .....................................................................5
f. VGA, HDMI, USB & LAN connector........................................................................6
g. Other Connector......................................................................................................7
h. FPGA & PIC firmware Connector............................................................................8
3. Indicated LED.....................................................................................................................8
4. Other Jumper & Switch setting ...........................................................................................9
5. Edge Connector pin definition...........................................................................................10
1. Main board illustration
Top Side
P/N:220010435-G
2013.1.18 2

P/N:220010435-G
2013.1.18 3
2. Connector pin define
a.DDR3 SO-DIMM Connector
CN_DIMM1, CN_DIMM2
Standard
DDR3 SO-DIMM
connector
b.SATA & mSATA connector
CN_MPCIE1 (mSATA)
Standard mini-SATA module
connector
Note:
Do NOT insert the mini-PCIE
module
SATA1, SATA2
SATA_PWR1
SATA_PWR2
Power connector for
SATA storage
Standard SATA connector
PIN
Signal
1 +12V
2 GND
3 +3.3V
4 +5V
c.FAN Connector
CN_FANSYS1
CN_FANCPU1
CN_FANSYS2
PIN
Signal
1 GND
2 +12V
3 NA
3 Pin, Pitch:2.54mm
P/N:220010435-G
2013.1.18 4
d.CN_COM1_2 (RS-232 ,RS-232/422/485) & ccTalk
CN_COM1_2
RS-232, RS-422/485
connector
JP_COM2S1
COM2 connector
mode setting
Note:
Mode setting by
JP_COM2S1,
JP_RS232S1 &
JP_422_485S1
D-Sub 9pin Male connector
for Standard RS232, RS422/RS485
Up is COM1 (RS232 only)
Below is COM2 (RS232/422/485)
D-Sub9 for RS232:
PIN
Signal
PIN
Signal
6 DCR 1
DCD
7 RTS 2
RX
8 CTS 3
TX
9 RI 4
DTR
5
GND
D-Sub9 for RS422/485:
PIN
Signal
PIN
Signal
6 1
485 RX+/TX+
422 TX+
7 2
485 RX-/TX-
422 TX-
8 422 RX- 3
9 422 RX+
4
5
Mode selection:
Short
Function
1-2 RS-232
(Default)
3-4 RS-485
5-6 RS-422
Terminal resistor selection:
Short
Function
7-8 RS485 TX with 120ohm terminal
(Default)
9-10
RS422 RX with
120ohm terminal
JP_RS232S1
COM2 be RS-232 selection
JP_422_485S1
COM2 be RS-422/485
selection
Short
Function
1-2
3-4
5-6
7-8
9-10
COM2
be
RS-232
(Default)
Short
Function
1-2
3-4
5-6
7-8
9-10
COM2
be
RS-422/485

P/N:220010435-G
2013.1.18 5
CN_CCTALK1
ccTalk Type-5 connector
JP_VCCTALK1
CN_CCTALK1
Vs setting
Note:
Vs setting by
JP_VCCTALK1
Please reference to
ccTalk-Generic-Specification-v4.6
PIN
Signal
1 +Vs
2 -
3 0V
4 /DATA
Short
Function
1-2 +12V
(Default)
2-3 +24V
CN_CCTALK2
ccTalk Type-7 connector
JP_VCCTALK2
CN_CCTALK2
Vs setting
Note:
Vs setting by
JP_VCCTALK2
PIN
Signal PIN
Signal
1 /DATA 2 GND
3 NC 4 NC
5 NC 6 NC
7 +Vs 8 0V
9 NC 10
NC
Please reference to
ccTalk-Generic-Specification-v4.6
Short
Function
1-2 +12V
(Default)
2-3 +24V
e.5.1CH.Audio out & 2CH Speaker Out
CN_AUDIO1
5.1CH Audio out connector
(Without Amplifier)
2x5Pin, Pitch:2.54mm
PIN
Signal PIN
Signal
1
Front Out L
2
Front Out R
3
GND 4
GND
5
Surround L
6
Surround R
7
GND 8
GND
9
Center 10
Subwoofer
JP_AMP1
Speaker with 6W Amplifier
selection
JAMMA1 2CH Speaker output
on edge connector
Short
Function
1-3
2-4 With Amplifier (Default)
3-5
4-6 Without Amplifier
Note: Through amplifier or w/o
Amplifier depend on JP_AMP1
setting.
PIN
Signal PIN
Signal
A2
Speaker L
B2
GND
A3
Speaker R
B3
GND
P/N:220010435-G
2013.1.18 6
f. VGA, HDMI, USB & LAN connector
CN_VGA1
CN_HDMI1
Standard VGA connector
(D-Sub 15pin connector) Standard HDMI connector
CN_USB1
CN_USB2
(Optional)
Standard USB 2.0
Type-A connector
Standard USB 2.0
Type-A connector
CN_USB3
Onboard USB 2.0 connector
CN_USBLAN1
RJ45 LAN & USB 2.0
connector
PIN
Signal
PIN
Signal
1 +5V 2 +5V
3
DATA1 -
4 DATA2 -
5
DATA 1+
6 DATA2 +
7
GND 8 GND
9
NC 10 NC
Header 2X5pin, Pitch: 2.54mm
LAN LED table:
LED
ON/OFF
Status
OFF 10Mbps
Green
100Mbps
LED1
Orange
1000Mbps
Yellow
Link/Active
LED2
OFF LAN OFF

P/N:220010435-G
2013.1.18 7
g.Other Connector
JP_FPIO1 Reset Button connector
PIN
Function
1-2
(Reserved)
3,4
(Reserved)
5,6
Reset button connector
SPI_CN1
(Optional)
SPI Interface connector
PIN
Signal
PIN
Signal
1 CS#
2 +3.3V
3 MISO 4 HOLD#
5 WP# 6 CLK
7 GND 8 MOSI
9 NC 10
NC
CN_BAT1
CR2032 Battery socket
CN_LPC1
(Optional)
LPC Interface connector
CR2032 3V battery socket
for system RTC
PIN
Signal PIN
Signal
1
CLK
2 AD1
3
RST# 4 AD0
5
FRAME#
6 +3.3V
7
AD3 8 GND
9
AD2 10
GND
DOOR_SW_1 Case open Log switch
DOOR_SW_2 External Log input connector
SW Event
Push Non-case open
Release
Case opening
1-2
Signal
Open
No event
Short
Event input
CN_BAT_A1
3.7V 500mAh
Re-chargeable battery
connector
CN_IBUTTONB1 iButton signal connector
for SRAM & Security.
PIN
Signal
1 3.7~4.2V
2 GND
PIN
Signal
1 I/O Data
2 GND
P/N:220010435-G
2013.1.18 8
h.FPGA & PIC firmware Connector
CN_FPGA1
(Reserved) FPGA firmware recoded
Header
PIN
Signal
1 3.3V VCC
2 TDO
3 TDI
4 (NC)
5 (NC)
6 TMS
7 GND
8 TCK
CN_PIC1
(Reserved) PIC firmware recoded
Header
PIN
Signal
1 3V VCC
2 ISPDATA
3 ISPCLK
4 ISPVPP
5 GND
3. Indicated LED
LED_GY1 System status indicated
Green: Power ON
Yellow: HDD active
LED_5V1
5V Power IN LED
LED_24V1
24V Power IN LED
LED_12V1
12V Power IN LED
LED_CHG1
Battery charging LED
ON: Battery charging

P/N:220010435-G
2013.1.18 9
4. Other Jumper & Switch setting
JP_CCMOS1
Clear CMOS
Short
Function
1-2 Normal
(Default)
2-3 Clear CMOS
JP_SRAM1
SRAM1 data clear
Short
Function
1-2 Not clear
(Default)
2-3 SRAM Clear
JP_SRAM2
(Reserved) SRAM1 data clear
Short
Function
1-2 Not clear
(Default)
2-3 SRAM Clear
SW-FPGA1
METER OUT setting 1
SW-FPGA2
METER OUT setting 2
& HOPPER SSR setting
No
OFF/ON
Mode
OFF
KEYIN_METER MOSFET OFF
(Default)
1
ON KEYIN_METER MOSFET ON
OFF
KEYOUT_METER MOSFET OFF
(Default)
2
ON KEYOUT_METER MOSFET ON
OFF
COININ_METER MOSFET OFF
(Default)
3
ON COININ_METER MOSFET ON
OFF
BILLIN_METER MOSFET OFF
(Default)
4
ON BILLIN_METER MOSFET ON
No
OFF/ON
Mode
OFF
PAYOUT_METER MOSFET OFF
(Default)
1
ON PAYOUT_METER MOSFET ON
OFF
HOPPER_SSR MOSFET OFF
(Default)
2
ON HOPPER_SSR MOSFET ON
OFF
(Default)
3
ON (Reserved)
OFF
(Default)
4
ON (Reserved)
JP_METER1
(Reserved)
JP_CLAMP1
Edge connector GPO pins
Clamping voltage setting
Short
Function
1-2
HOPPER_SSR Pull down
(Default)
2-3 HOPPER_SSR Pull up
Short
Function
1-2 +12V
(Default)
2-3 +24V
P/N:220010435-G
2013.1.18 10
5. Edge Connector pin definition
IPH: Input (with Internal Pull High & without isolated) (only support GND & Open signal)
OD: Open Drain Output (Maximum external voltage: 24V DC)
AO: Analog Output
I/O: Spare Input/Output (5V tolerance)
P: Power
Empty: Reserved
Component Side (A)
Solder Side (B)
Function I/O Type
Pin Pin I/O Type
Function
GND P A1 B1 P GND
GND P A2 B2 P GND
Power +5V P A3 B3 P Power +5V
Power +5V P A4 B4 P Power +5V
Power +12V P A5 B5 P Power +12V
Power +12V P A6 B6 P Power +12V
Power +24V P A7 B7 P Power +24V
A8 B8
GND P A9 B9 P GND
GND P A10 B10 P GND

P/N:220010435-G
2013.1.18 11
Component Side (A) Solder Side (B)
Function I/O Type
Pin Pin I/O Type
Function
A1 B1
Left Speaker AO A2 B2 AO Audio Ground
Right Speaker AO A3 B3 AO Audio Ground
Button 1 IPH A4 B4
Button 2 IPH A5 B5
Button 3 IPH A6 B6
Button 4 IPH A7 B7
Button 5 IPH A8 B8
Button 6 IPH A9 B9
Button 7 IPH A10 B10
Button 8 IPH A11 B11
Button 9 IPH A12 B12
A13 B13
A14 B14
A15 B15
A16 B16
A17 B17
Coin-IN Signal A IPH A18 B18
Coin-IN Signal B IPH A19 B19
Button 10 IPH A20 B20 IPH Button 13
Button 11 IPH A21 B21 IPH Button 14
GND P A22 B22 IPH Hopper Sensor
Key-IN Meter (500mA max) OD A23 B23
Bill-IN Meter (500mA max) OD A24 B24
Coin-IN Meter (500mA max) OD A25 B25
Pay-OUT Meter (500mA max) OD A26 B26
Key-OUT Meter (500mA max) OD A27 B27
A28 B28
Lamp1 (500mA max) OD A29 B29 OD Lamp7 (1A max)
Lamp2 (500mA max) OD A30 B30 OD Lamp8 (500mA max)
Lamp3 (500mA max) OD A31 B31 OD Lamp9 (500mA max)
Lamp4 (500mA max) OD A32 B32 OD Lamp10 (500mA max)
Lamp5 (500mA max) OD A33 B33 OD Hopper SSR (500mA max)
Tower Lamp6 (1A max) OD A34 B34
Button 12 IPH A35 B35
GND P A36 B36 P GND
