Actia PassThru+ XS 2G User manual

PassThru+ XS 2G
communication interface
Getting started
I + M E A C T I A G m b H

PassThru+ XS 2G API (software for Windows 9x,
ME, NT, 2000, XP) is available on
www.passthruxs.com
Product includes IME 3904402 Product includes on the Web
API, Drivers &Software
Hardware
About it
PassThru+ XS 2G
I+ME ACTIA thanks you for having chosen our product
I+ME ACTIA GmbH
Dresdenstr. 17/18
38124 Braunschweig
Germany
Tel : + 49 (0) 531 38 70 1 0
Fax : + 49 (0) 531 38 70 1 88
www.passthruxs.com
www.ime-actia.com
mail: [e-mail]
Designed &manufactured by
<Processor: XC161 from Infineon Supported protocols:
<PC interfaces: RS232 up to 115kBaud <CAN 2.0B ISO 11898, CAN ISO 15765-4
USB 1.1 &2.0 full speed <SAE J1850 VPW, SAE J1850 PWM
Bluetooth V 2.0 SPP, class 1 <K-Line ISO 9141 (100mA), ISO 14230-4 (KWP
<Dimension: 165 x 68 x 25 mm 2000)
<Weight: approx. 220 g <SAE J 2610 (SCI)
<Temp. range: 0 ... +55°C
<Housing: plastic
<Power supply: 7..32 V DC (via Sub-D)
<Programming voltage: 1 -20V
Technical Data
<PassThru+ XS 2G hardware
<Bluetooth head (mounted)
<Cable head
<OBD-2 cable, 2 m
<USB cable
<RS232 cable
<USB cable type A to type B
<Allen wrench
PassThru+ XS 2G is a communication interface
providing data link between a vehicle and a PC,
enabling you to communicate with the ECU's
according to the J2534, J2534-1 and J2534-2
specifications.
PassThru+ XS 2G
I + M E A C T I A G m b H

Installation guide
1. The PassThru+ XS 2G is powered solely via Sub-D
from the vehicle. If you use an external power supply
for the vehicle or a device under test, make sure that
there is a good ground connection between the PC,
the vehicle ground and the external device.
Otherwise the PassThru+ XS 2G may be damaged.
2. Attention:
- Supply voltage 7..32 V DC
Go to our Website
Go to the Download Area (see menu ) or tip
Download the PassThru+ XS 2G API for the
workshop.
Follow the steps of the installation.
When the PassThru+ XS 2G is used the first time in
Bluetooth mode, the Bluetooth connection must be
installed on the connected PC or notebook. For this
process the PassThru+ XS 2G must be supplied with
power. The Bluetooth Device Wizzard will guide
through the installation. The passkey is ACTIA.
www.passthruxs.com
www.passthruxs.com/download.htm
You need Internet and capable browser such as
Explorer, Firefox or other.
Power supply
Important before starting Start
!
Software requirements 1.
Software installation 2.
Please read all safety instructions
4Do not use the equipment when the environment temperature is higher than +55°C or less than +/- 0°C.
4Voltage via external power supply: 7..32 V DC.
4Do not get in contact with fluid.(water, acid, solvent,etc.)
4Do not drop the equipment.
4Always unplug equipment from electrical power supply when not in use.
4To reduce the risk of fire, do not operate equipment in the vicinity of open containers of flammable liquids
(gasoline).
4Variation and deviation of external voltage outside admissible tolerances can damage the equipment.
4For cleaning the equipment from the outside a damp cloth with mild cleaning agent can be used. Do not use
solvent.
Consumer notice
The I+ME ACTIA product you
have purchased is subject to
Directive 2002/96/EC of the
European Parliament and the
Council of the European Union on
waste electrical and electronic equipment
(WEEE) and, in jurisdictions adopting that
Directive, is marked as being put on the
market after August 13, 2005, and should
not be disposed of as unsorted municipal
waste.
Please utilize our local WEEE collection
facilities in the disposition of this product
and otherwise observe all applicable
requirements.
Safety instructions
I + M E A C T I A G m b H

Connector
Technical data
I+ME ACTIA GmbH
Dresdenstr. 17/18
38124 Braunschweig
Germany
Tel : + 49 (0) 531 38 70 1 0
Fax : + 49 (0) 531 38 70 1 88
www.ime-actia.com
mail: [e-mail]
IR 12053D
Local US Support:
Tel : [phone]
Fax : [phone]
mail: [email protected]
123456789 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25
1) J1850 PWM – There is an additional possibility to connect a pair of 330 Ohm pullup to +5V to both PWM lines controlled by
software.
2) The VProg can be switched to the marked OBD pins independent of all other settings.
3) Analog Voltage Measurement is possible at OBD pin 16, 15, VProg and each K-Line
CAN High L
CAN High H
CAN 2H
CAN 2L
CAN SWC
J1850 PWM+
J1850 PWM-
J1850 VPW
K1 SCI out
K2
SCI In
V Prog
GND
1 2 3 6 78 9 10 11 12 13 14 15
