D16 Group TORAVERB2 User manual

User Manual
8 September 2017

2
www.d16.pl
OVERVIEW
Overview
Toraverb 2 is a high quality studio reverb eect unit with a modulated tail.
Toraverb graphical interface

3
www.d16.pl
OVERVIEW 
There are two secons to the user interface:
• Conguraon and preset management
Conguraon and preset selecon secon
• Signal processing control secon contains all the remaining controls

4
www.d16.pl
SIGNAL FLOWBASIC MODULES
Signal Flow
This chapter describes the signal path through Toraverb 2. It explains the basic components of the unit and its control parameters.
Basic modules
Internally Toraverb 2 consists of a few basic components. These correspond to the secons on the graphical user interface.
Pre-delay
Controls the delay between Dry and Reverberated signals
Pre-delay secon

5
www.d16.pl
SIGNAL FLOW BASIC MODULES
By default Pre-delay is expressed in milliseconds and controlled in a range of 0to 500 [ms] (when Sync mode is disabled). The value can be
adjusted by dragging the mouse pointer up or down above the digits represenng the consecuve decimal posions on the display.
Sync. toggle buon:
Sync. buon
This acvates / deacvates the synchronizaon of the Pre-delay with the host applicaon tempo. When enabled, the delay is represented
as a Rhythmic value (in tempo-dependent units) consisng of Note value and Rhythmic modier. It should be noted that when this mode is
acve the Pre-delay value is controlled in a slightly dierent manner and the look of the Pre-delay display changes.
Pre-delay secon while Sync. is acve

6
www.d16.pl
SIGNAL FLOWBASIC MODULES
Note values
The Pre-delay’s Note value can be adjusted by dragging the mouse pointer up or down while selecng it.
Pre-delay’s Note value
We can choose one of following values; 1 Bar, 1/2, 1/4, 1/8, 1/16, 1/32 and 1/64.
Rhythmic modiers
Clicking one of available Rhythmic modiers, selects it;
Pre-delay’s Rhythmic modier
There are 3 values to choose from:
• Full – Eecve delay value is equal to set Note value.
• Tri - Eecve delay value is equal to 2/3rds the duraon of set Note value.
• Dot - Eecve delay value is equal to 3/2nds the duraon of set Note value.

7
www.d16.pl
SIGNAL FLOW BASIC MODULES
Early / Late reecons secon
This secon controls the Early and Late reecons of reverb.
Early / Late secon
Switching between Early and Late tabs gives an access to parameters controlling Early and Late reecons respecvely.
Early and Late tabs

8
www.d16.pl
SIGNAL FLOWBASIC MODULES
Early reecons tab
This tab controls the early reecons of the reverb.
Secon controlling Early reecons’ tail
The following parameters can be selected:
• Size - Size of the room.
• Bass cut - Controls the properes of the reecng surface with respect to bass frequencies. Bass frequencies are cut below the value
selected. The range is from 0Hz to 22kHz.
• Crosstalk – Between the le and right channel delay lines
• Aenuaon - This parameter changes the characterisc of the reecng surface - it’s damping properes.
• Diusion – – Is the reecng surface’s ability to spread the echoes out. If this parameter is set to Sharp, the reecng surface is
perfectly at and does not distort reected waves. If this value is set to Smooth, the reecng surface distorts the waves and spreads
them out into dierent direcons.

9
www.d16.pl
SIGNAL FLOW BASIC MODULES
• Modulaon - This controls the delay lines modulaon
Parameters to the right on the tab, ones labeled with orange color, controls single-band parametric EQ, which processes Early Reecons’
output:
Parametric EQ secon

10
www.d16.pl
SIGNAL FLOWBASIC MODULES
• Type – There are three dierent types of EQ lter available:
• - Low-shelf
• - Bell
• - High-shelf
• Gain - Gain value for a band in range −24 dB to +24 dB.
• Freq. – EQ Frequency.
• Bandw. – Band width in range 0.5 to 4 octaves.

11
www.d16.pl
SIGNAL FLOW BASIC MODULES
Late reecons tab
This tab controls the Late reecons of the reverb.
Secon controlling Late reecons’ tail
The following parameters can be selected:
• Size - Size of the room.
• Bass cut - controls the properes of the reecng surface with respect to bass frequencies. Bass frequencies are cut below the value
selected. The range is from 0Hz to 22kHz.
• Feedback – Controls how much of wave energy is consumed every reecon. The less value the more energy consumes every
reecon, that means the feedback is weaker then.
• Aenuaon - This parameter changes the characterisc of the reecng surface - it’s damping properes.
• Diusion – Is the reecng surface’s ability to spread the echos out. If this parameter is set to Sharp, the reecng surface is perfect-
ly at and does not distort reected waves. If this value is set to Smooth, the reecng surface distorts the waves and spreads them
out into dierent direcons.
• Modulaon - This controls the late reecons delay lines modulaon

12
www.d16.pl
SIGNAL FLOWBASIC MODULES
Parameters to the right on the tab, labeled in orange, control the single-band parametric EQ which alter the Late Reecons.
The parameters for the EQ are the same as the parameters in the Early Reecons tab.
Early and Late decay mes
The Early me and Late me display shows the decay mes of Early and Late reecons respecvely. This is purely for informaonal purpose.
Early me and Late decay me displays

13
www.d16.pl
SIGNAL FLOW BASIC MODULES
Early / Late reecons mixer
Early / Late reecons mixer
This controls the mix of the signals coming from the Early and Late Reecons modules.
The Gain knobs set the level for each signal:
Early and Late output levels

14
www.d16.pl
SIGNAL FLOWBASIC MODULES
The balance knobs in the upper row control the Le / Right (panning) or Mid / Side balance of the signal leaving the Early and Late secons.
The MS Mode buon selects between Le / Right or Mid / Side mode:
MS Mode toggle buon
Master secon
This is where global reverb parameters are set:

15
www.d16.pl
SIGNAL FLOW BASIC MODULES
Master secon
• FX - Crossfade between Dry and reverberated Wet signal.
• Padlock
allows the Dry/Wet balance to be locked so that it does not change when loading presets.
• FX Curve – Transion characteriscs between Dry and Wet for FX knob
• Ducking – Controls the compressor which suppresses the Wet signal proporonally to the level of the Dry signal. This knob controls
the strength of the eect.
• A./Rel. – Adjusts the Ducking Aack and Release mes starng from
• 2ms of aack and 50ms of release for minimum value up to
• 16ms of aack and 400ms of release for maximum value.

16
www.d16.pl
SIGNAL FLOWREVERBERATION CHARACTERISTICS
Reverberaon characteriscs
The image below depicts the general characteriscs of the reverberaon tail within Toraverb 2:
TIME
AMPLITUDE
PRE DELAY
EARLY REFLECTIONS LATE REFLECTIONS
EARLY DIFFUSION LATE DIFFUSION
Reverberaon characteriscs

17
www.d16.pl
SIGNAL FLOW 
The path of the signal’s ow
The picture below shows the signal ow through the plug-in
EARLY REFLECTIONS LATE REFLECTIONS
IN OUT
REVERBERATOR
IN OUT
PRE-DELAY
IN OUT
EQ
IN OUT
REVERBERATOR
IN OUT
EQ
+
X
FEEDBACK
LATE IN
EARLY IN
OUT
MIXER
AUDIO IN
CONTROL IN
OUT
DUCKER
DRY/WET
OUT
IN1
IN2
INPUT OUTPUT
Signal ow through the plug-in

18
www.d16.pl
PRESET MANAGEMENTPRESET STORAGE
Preset Management
Preset Storage
Presets, both those from the Factory content, and User ones, are stored as les in proper locaons on a disc. Each me the plug-in
instance is loaded to the project, these locaons are scanned and presets found there are consolidated into one linear structure (list)
in the Preset Browser.
Browsing Presets
Presets Conguraon and Management secon enables quick navigaon and browsing the presets structure:
Presets Conguraon and Management Secon
• PRESET NAME – Displays the name of the currently loaded preset.
• PREV / NEXT – Buons that allow for linear browsing of presets list (depending on currently set lters – see secons below).
• INIT – Win ( Ctrl + PREV ), Mac ( Cmd + PREV ) – Restores inial sengs of plug-in parameters.
• RELOAD –Win ( Ctrl + NEXT ),Mac ( Cmd + NEXT ) – Reloads a current preset.

19
www.d16.pl
PRESET MANAGEMENTBROWSING PRESETS
• SAVE – Win (Ctrl + BROWSE ), Mac ( Cmd + BROWSE ) – Saves current parameters as a new preset or allows for overwring
of the exisng one (see secons below).
• BROWSE – Expands the Preset Browser panel at the boom of GUI secon.
The Preset Browser looks as follows:
Preset Browser
One can see three main secons:
• Content – Sources from which presets can be read.
• Filters – Conguraon of presets Filters (non-acve by default).
• Results – List of presets from resources that meet criteria set by Filters.

20
www.d16.pl
PRESET MANAGEMENTBROWSING PRESETS
Resources
In this secon you can choose a resource/resources in which you want to browse presets. There are two resources to choose from:
• Factory – Delivered together with the plug-in, cannot be modied (read-only).
• User – Created by the user during using the plug-in and can be freely modied, shared with other users etc.
Choosing any of them will cause narrowing the results to the presets from one resource.
Preset Filters
The plug-in enables classicaon of presets with the use of Categories and Tags system, whose aim is to facilitate the process of browsing
the content by ltering.
Preset Browser Categories Filters
